NEC Express5800/GT110e-S
Configuration Guide
Air cooling model
Introduction
This document contains product and configuration information that will enable you to configure your system. The
guide will ensure fast and proper configuration of your NEC Express5800 server.
July 17, 2013
Revision 5.0
NEC Corporation

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 2
Contents
TECHNICAL SPECIFICATION........................................................................................3
Key Features..........................................................................................................................................3
Specification..........................................................................................................................................3
EXTERNAL VIEWS .........................................................................................................7
Front View..............................................................................................................................................7
Rear Views.............................................................................................................................................7
Dimensions (mm)..................................................................................................................................8
CONFIGURATION DIAGRAM.........................................................................................9
Expansion Slots ..................................................................................................................................10
SERVER CONFIGURATION ......................................................................................... 11
1Base Models.................................................................................................................................11
2Processor .....................................................................................................................................11
3Memory .........................................................................................................................................11
Maximum Available Memory..........................................................................................................12
4Internal Hard Disk Drives............................................................................................................12
4.1 RAID Configuration..............................................................................................................12
4.2 3.5-inch Drive Configuration................................................................................................14
4.3 2.5-inch Drive Configuration................................................................................................16
5Internal Optical Drive...................................................................................................................27
6Internal RDX Drive .......................................................................................................................27
7PCI Card........................................................................................................................................28
7.1 Network Interface Controller................................................................................................28
7.2 Serial Port Adapter ..............................................................................................................28
8Other Add-in Components..........................................................................................................29
8.1 Internal Flash Memory.........................................................................................................29
8.2 Flash FDD............................................................................................................................29
8.3 Input Devices.......................................................................................................................29
9Add-on Components ...................................................................................................................30
9.1 Server Management License...............................................................................................30
9.2 Dust / Insect Proof Kit..........................................................................................................30
9.3 Medium and Cartridge.........................................................................................................30
REFERENCES...............................................................................................................31
Server Management............................................................................................................................31
OS Support Matrix for PCI Cards and Embedded Controllers .......................................................32
Supported PCI cards and Installable Slots.......................................................................................32
Copyright Notice and Liability Disclaimer........................................................................................33
REVISION HISTORY .....................................................................................................34

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 3
Technical Specification
Key Features
Ultra compact form of 93mm in width, 13 liters in volume
Up to 32 GB of high speed DDR3-1600 memory
Full manageability by integrated EXPRESSSCOPE Engine 3
Function in maximum 40° C / 104° F ambient temperature
Specification
3.5-inch Drive Model
Model
GT110e-S
Part Number
N8100-1891F
Processor
Type
Intel® Pentium® processor
G2020
Intel® Xeon® processor
E3-1220 v2
Clock speed
2.90 GHz
3.10 GHz
Number of Processors
1
Cache
3 MB
8 MB
Cores and Threads
2C / 2T
4C / 4T
Chipset
Intel® C204 Chipset
Memory
Type
DDR3-1600 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
32 GB (4 x 8 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
8 TB (2 x 4 TB)
Disk Controller
SATA : 6Gb/s (Integrated)
RAID
SATA : 1 RAID 0/1
Hot Plug
-
Optical Disk Drive
DVD-ROM
3.5-inch Media Bays
1
Disk Drive Bays
2
Expansion Slots
Total: 4 slots available
1 PCIe 3.0 2 x16 (x16 connector)
2 PCIe 2.0 x4 (x8 connector)
1 32-bit/33 MHz PCI
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 3
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
8 USB2.0 (2 front, 4 rear, 2 internal)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 100BASE-TX LAN connector for Management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
System Fan
Standard
Power Supply
1 x 250 Watt 80 PLUS® Sliver certified non-Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 4
Model
GT110e-S
Power
Consumption
(Max. Config, Idling)
61 VA / 57 Watt
73 VA / 69 Watt
(Max. Config,
Operating)
116 VA / 111 Watt
242 VA / 240 Watt
Acoustic Noise
(Sound Pressure
Level) 4
Minimum Config.
29.1 dB
36.8 dB
Maximum Config.
30.9 dB
37.2 dB
Dimensions (W x D x H )
93.0 x 386.5 x 363.0 mm / 3.6 x 15.2 x 14.3 in (4U)
Weight (Minimum / Maximum)
9 kg / 12 kg, 19.84 lbs. / 26.46 lbs.
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, CE, BSMI, CCC, UL, CB, RoHS, WEEE
Operating Systems and Virtualization
Software
Microsoft® Windows Server® 2003 R2, Standard Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise Edition SP2 or later
Microsoft® Windows Server® 2008 Standard
Microsoft® Windows Server® 2008 Standard (x64)
Microsoft® Windows Server® 2008 Enterprise
Microsoft® Windows Server® 2008 Enterprise (x64)
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard 5
Microsoft® Windows Server® 2012 Datacenter 5
Red Hat Enterprise Linux 5.8 or later 6
Red Hat Enterprise Linux 5.8 or later (EM64T) 6
Red Hat Enterprise Linux 6.2 or later 6
Red Hat Enterprise Linux 6.2 or later (EM64T) 6
VMware ESXi™5.0 update 1 7
VMware ESXi™5.1 7
1Embedded SATA RAID controller is supported only on Windows operating systems.
2The PCIe x16 slot works at PCIe 2.0 speeds on Pentium processor systems.
3Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
4Noise emission was measured in accordance with ISO 7779. The actual value may vary by the operating
environment.
5For Windows Server 2012 installation, download the driver kit from the following website and install it after OS
installation
http://www.nec.com/en/global/prod/express/download/
6For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html
7VMware ESXi is supported only on Xeon processor systems.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 5
2.5-inch Drive Model
Model
GT110e-S
Part Number
N8100-1892F
Processor
Type
Intel® Pentium® processor
G2020
Intel® Xeon® processor
E3-1220 v2
Clock speed
2.90 GHz
3.10 GHz
Number of Processors
1
Cache
3 MB
8 MB
Cores and Threads
2C / 4T
4C / 4T
Chipset
Intel® C204 Chipset
Memory
Type
DDR3-1600 ECC Unbuffered DIMM
Standard Capacity
0 GB
Maximum Capacity
32 GB (4 x 8 GB)
Internal Storage
Standard Capacity
0 GB
Maximum Capacity
SAS : 6 TB (5 x 1.2 TB) 1
SATA : 5 TB (5 x 1 TB) 1
SSD : 500 GB (5 x 100 GB) 1
Disk Controller
SATA : 6Gb/s and/or 3Gb/s (Integrated)
SAS : 6 Gb/s (Optional)
RAID
SATA : RAID 0/1 2(Standard), RAID 5/6 (Optional)
SAS : RAID 0/1/5/6/10 (Optional)
Hot Plug
Supported
Optical Disk Drive
DVD-ROM
3.5-inch Media Bays
1
Disk Drive Bays
3 to 5 1
Expansion Slots
Total: 4 slots available
1 PCIe 3.0 3 x16 (x16 connector)
2 PCIe 2.0 x4 (x8 connector)
1 32-bit/33 MHz PCI
Video
Controller (VRAM)
Integrated in Server Management Controller (32MB)
Resolution / Color
1280 x 1024 / 16.7M 4
Interfaces
1 VGA (15-pin mini D-sub,1 rear)
1 to 2 Serial (9-pin mini D-sub, RS232-C, 1 to 2 rear)
8 USB2.0 (2 front, 4 rear, 2 internal)
2 1000BASE-T LAN connector (RJ-45, 2 rear)
1 100BASE-TX LAN connector for Management (RJ-45, 1 rear)
Server Management
EXPRESSSCOPE Engine 3
System Fan
Standard
Power Supply
1 x 250 Watt 80 PLUS® Sliver certified non-Hot plug PSU
100-240 VAC ± 10% 50 / 60 Hz ± 3 Hz
Power
Consumption
(Max. Config, Idling)
68 VA / 65 Watt
79 VA / 76 Watt
(Max. Config,
Operating)
126 VA / 124 Watt
169 VA / 166 Watt
Acoustical Noise
(Sound Pressure
Level) 5
Minimum Config.
29.1 dB
37.3 dB
Maximum Config.
30.2 dB
39.8 dB
Dimensions (W x D x H )
93.0 x 386.5 x 363.0 mm / 3.6 x 15.2 x 14.3 in (4U)
Weight (Minimum / Maximum)
9 kg / 12 kg, 19.84 lbs. / 26.46 lbs.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 6
Model
GT110e-S
Temperature, Relative Humidity
(non-condensing)
Operating: 10° to 40° C / 50° to 104° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
Regulatory and Safety
FCC, CE, BSMI, CCC, UL, CB, RoHS, WEEE
Operating Systems and Virtualization
Software
Microsoft® Windows Server® 2003 R2, Standard Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise Edition SP2 or later
Microsoft® Windows Server® 2008 Standard
Microsoft® Windows Server® 2008 Standard (x64)
Microsoft® Windows Server® 2008 Enterprise
Microsoft® Windows Server® 2008 Enterprise (x64)
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2012 Standard 5
Microsoft® Windows Server® 2012 Datacenter 5
Red Hat Enterprise Linux 5.8 or later 6
Red Hat Enterprise Linux 5.8 or later (EM64T) 6
Red Hat Enterprise Linux 6.2 or later 6
Red Hat Enterprise Linux 6.2 or later (EM64T) 6
VMware ESXi™5.0 update 1 7
VMware ESXi™5.1 7
1An optional HDD Cage is required to install more than 3 hard drives. The optional HDD Cage occupies 3.5-inch
media bay.
2Embedded SATA RAID controller is supported only on Windows operating systems.
3The PCIe x16 slot works at PCIe 2.0 speeds on Pentium processor systems.
4Maximum resolution available via EXPRESSSCOPE Engine 3 remote console is 1280 x 1024 / 65K colors.
5Noise emission was measured at the operator positions in accordance with ISO 7779. The actual value may vary
by the operating environment.
6For Windows Server 2012 installation, download the driver kit from the following website and install it after OS
installation
http://www.nec.com/en/global/prod/express/download/
7For Linux support, contact your sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html
8VMware ESXi is supported only on Xeon processor systems.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 7
External Views
Front View
3.5-inch Drive Model
2.5-inch Drive Model
Legend
A.
Vent Holes Cover
F.
USB Connectors
B.
Power Button
G.
Optical Disk Drive
C.
Power LED
H.
3.5-inch Media Bay
D.
Hard Drive Activity LED
I.
2.5-inch Drive Bay
E.
System Status LED
J.
Drive Bay Cover Key
Rear Views
Leged
A.
Serial Port Connector
F.
Management LAN Connector
B.
VGA Connector
G.
Data LAN Connectors
C.
BMC Reset Switch
H.
PCI Slots (Low Profile)
D.
Dump (NMI) Switch
I.
AC Inlet
E.
USB Connectors
A
B
C
D
E
F
G
H
A
B
C
D
E
F
G
H
I
J
A
B
C
D
E
F
G
H
I

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 8
Dimensions (mm)
Tower installation
Lay-flat installation

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 9
Configuration Diagram
3.5-inch Drive model
Legend: Minimum requirement components Standard components
2.5-inch Drive model
Legend: Minimum requirement components Standard components
3.5-inch
DriveCage
PCI1
Optical
Drive
4DIMM
1DIMM
3.5-inch Drive Cage
Optical
Drive Media
Bay
PCI2
PCI3
PCI4
PCIe2.0
Power
Supply
PCI
BBU slot
PCIe3.0 or 2.0 Media
Bay
Processor
CHASSIS
INSIDE CHASSIS FRONT
CHASSIS
REAR
Power
Supply
Cooling FAN
Cooling FAN
Cooling FAN
2.5-inch
Drive Cage
PCI1
Optical
Drive
4DIMM
1DIMM
Optical
Drive Media
Bay
PCI2
PCI3
PCI4
PCIe2.0
Power
Supply
PCI
BBU slot
PCIe3.0 or 2.0 Media
Bay
2.5-inch
Drive Cage
Processor
CHASSIS
INSIDE CHASSIS FRONT
CHASSIS
REAR
Power
Supply
Cooling FAN
Cooling FAN
Cooling FAN
Cooling FAN

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 10
Expansion Slots
Legend
#1
PCIe 2.0 x4, x8 connector, Low Profile, up to 167.6mm length
#2
PCIe 2.0 x4, x8 connector, Low Profile, up to 167.6mm length
#3
PCIe 3.0 or 2.0 x16, x16 connector, Low Profile, up to 167.6mm length
#4
32-bit / 33 MHz / 5 V PCI, Low Profile, up to 167.6mm length
NOTE:
The slot #3 works at PCIe 3.0 speeds on Xeon processor systems.
#4
#3
#2
#1

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 11
Server Configuration
1 Base Models
Product Name / Description
Part Number
NEC Express5800/GT110e-S
no CPU, no RAM, no 3.5-inch HDD, no AC cable
Including:
Slim DVD-ROM drive, 3.5-inch Drive Cage, 250 Watt non-hot plug power supply,
EXPRESSBUILDER DVD
N8100-1891F
NEC Express5800/GT110e-S
no CPU, no RAM, no 2.5-inch HDD, no AC cable
Including:
Slim DVD-ROM drive, 2.5-inch Drive Cage, 250 Watt non-hot plug power supply,
EXPRESSBUILDER DVD
N8100-1892F
2 Processor
Available sockets: 1
Category
Product Name / Description
Part Number
Processors
Required
Processor Kit (2C/G2020)
Intel® Pentium ® Processor G2020 (2.90 GHz, 2C/2T, 3 MB)
N8101-637F
Processor Kit (4C/E3-1220v2)
Intel® Xeon ® Processor E3-1220v2 (3.10 GHz, 4C/4T, 8 MB)
N8101-587F
NOTE:
One processor kit from above must be installed.
3 Memory
Available slots: 4
Product Name / Description
Part Number
2GB DDR3-1600 UNB Memory Kit
2GB Unbuffered ECC DIMM, DDR3-1600(PC3-12800)
N8102-501F
4GB DDR3-1600 UNB Memory Kit
4GB Unbuffered ECC DIMM, DDR3-1600(PC3-12800)
N8102-502F
8GB DDR3-1600 UNB Memory Kit
8GB Unbuffered ECC DIMM, DDR3-1600(PC3-12800)
N8102-503F
NOTE:
Minimum one memory kit must be installed.
To install by double of memory kit is recommended in order to increase memory transfer
speed by the dual-channel symmetric configuration.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 12
Maximum Available Memory
See the table below for the maximum memory size that you can actually use on your system.
The maximum available memory is less than the maximum physical memory supported by your system
because some chipsets require PCI resource space of about 750MB. PCI resource requirements vary
depending on the type and the number of PCI cards you are using.
Maximum memory size supported by OS
Maximum available memory
Microsoft Windows Server 2003 R2, Standard Edition
Microsoft Windows Server 2008 Standard
4 GB
4 GB( HW-DEP enabled)
App. 3.5 GB (HW-DEP disabled)
Microsoft Windows Server 2003 R2, Standard x64 Edition
Microsoft Windows Server 2008 Standard (x64)
Microsoft Windows Server 2008 R2 Standard
32 GB
32 GB
Microsoft Windows Server 2003 R2, Enterprise Edition
Microsoft Windows Server 2008 Enterprise
64 GB
32 GB
Microsoft Windows Server 2003 R2, Enterprise x64 Edition
1 TB
32 GB
Microsoft Windows Server 2008 Enterprise (x64)
Microsoft Windows Server 2008 R2 Enterprise
2 TB
32 GB
Microsoft Windows Server 2012 Standard
Microsoft Windows Server 2012 Datacenter
4 TB
32 GB
Red Hat Enterprise Linux 5
Red Hat Enterprise Linux 6
16 GB
16 GB
Red Hat Enterprise Linux 5 (EM64T)
1 TB
32 GB
Red Hat Enterprise Linux 6 (x86_64)
2 TB
32 GB
VMware ESXi 5.0 1
VMware ESXi 5.1 1
2 TB
32 GB
1Up to 1 TB of the main memory is available to each virtual machine.
4 Internal Hard Disk Drives
4.1 RAID Configuration
Refer to the section in accordance with your disk form factor and RAID configuration
4.1.1 3.5-inch Drive
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
All hard drives within a RAID array should be of the same capacity.
Non-RAID
128 MB Cache
512 MB Cache
Refer to 4.2.1
Refer to 4.2.3
Refer to 4.2.4
RAID 0/1
SATA
SATA
SATA
Available Interface
Embedded SATA
RAID Controller
Optional RAID
Controller
Refer to 4.2.2
SATA

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 13
4.1.2 2.5-inch Drive
Up to three drives
Up to five drives
NOTE:
The RAID controller with 1GB Cache / CacheVault does not support on Pentium G2020 processor
systems.
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
All hard drives within a RAID array should be of the same capacity and rotation speed.
Mixing SAS and SATAhard drives in the same system is not supported.
All hard drives within a system should be of the same rotation speed.
Hot plug insertion/removal is not supported with the embedded SATA non-RAID controller.
Non-RAID
RAID 5
128 MB Cache
1GB Cache
/ Battery
512 MB Cache
Refer to 4.3.1
Refer to 4.3.3
Refer to 4.3.5
Refer to 4.3.6
RAID 0/1
SATA
SAS, SATA
SAS, SATA
SAS, SATA
Available Interface
Embedded SATA
RAID Controller
Optional RAID
Controller
Refer to 4.3.2
SATA
512 MB Cache
Refer to 4.3.4
SAS, SATA
1GB Cache
/ CacheVault
Refer to 4.3.7
SAS, SATA
RAID 5/6
1GB Cache
/ Battery
512 MB Cache
Refer to 4.3.10
Refer to 4.3.11
512 MB Cache
Refer to 4.3.9
RAID 0/1
Refer to 4.3.8
SAS, SATA
SAS, SATA
SAS, SATA
Available Interface
SAS, SATA
128MB Cache
1GB Cache
/ CacheVault
Refer to 4.3.12
SAS, SATA

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 14
4.2 3.5-inch Drive Configuration
4.2.1 Embedded SATA non-RAID Controller
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA,
(Standard)
Cable
Internal SATA Cable
Single-SATA to Single-SATA , 2 sets
(Standard)
Drive Cage
3.5-inch Drive Cage
2 x 3.5-inch non hot plug (fixed) hard drive bays
(Standard)
Drive
2 slots available
500GB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-359
1TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-360
2TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-361
4.2.2 Embedded SATA RAID Controller
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA, RAID 0/1 capable
(Standard)
Cable
Internal SATA Cable
Single-SATA to Single-SATA , 2 sets
(Standard)
HDD Cage
3.5-inch Drive Cage
2 x 3.5-inch non hot plug (fixed) hard drive bays
(Standard)
Drive
2 slots available
500GB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-359
1TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-360
2TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-361
3TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 3TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-362
4TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-396
NOTE:
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
All hard drives within a RAID array should be of the same capacity.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 15
4.2.3 RAID 0/1 Controller with 128 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (128MB, RAID 0/1)
Promise SuperTrak TX8760T-128
RAID 0/1/10, 128MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA
3Gb/s
N8103-128
RAID BBU
Recommended
RAID Battery Backup Unit
for Promise SuperTrak EX8760T
N8103-141
Cable
Required
Internal SATA Cable
mini-SAS to 2x Single SATA
K410-253(00)
HDD Cage
3.5-inch HDD Cage
2 x 3.5-inch non hot plug (fixed) hard drive bays
(Standard)
Drive
2 slots available
500GB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-359
1TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-360
2TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-361
3TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 3TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-362
NOTE:
All hard drives within a RAID array should be of the same capacity.
4.2.4 RAID 0/1 Controller with 512 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID 0/1, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA 6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-155
Cable
Required
Internal SATA Cable
mini-SAS to 2x SATA
K410-253(00)
HDD Cage
3.5-inch HDD Cage
2 x 3.5-inch non hot plug (fixed) hard drive bays
(Standard)
Drive
2 slots available
500GB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 500 GB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-359
1TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 1 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-360
2TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 2 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-361
3TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 3TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-362
4TB 7.2K non-Hot Plug 3.5-inch SATA HDD
1 x 4 TB SATA HDD, 3.5-inch, 6Gb/s, 7,200 rpm
N8150-396
NOTE:
All hard drives within a RAID array should be of the same capacity.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 16
4.3 2.5-inch Drive Configuration
4.3.1 Embedded SATA non-RAID Controller
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA, 2x 3Gb/s SATA
(Standard)
Cable
Required
Internal SATA Cable
3x Single-SATA to mini-SAS
K410-241(00)
Drive Cage
2.5-inch Drive Cage
3 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
3 slots
available
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
NOTE
Hot plug insertion/removal is not supported with the embedded SATA non-RAID controller.
4.3.2 Embedded SATA RAID Controller
Category
Product Name / Description
Part Number
Storage Controller
Embedded SATA Controller
2x 6Gb/s SATA, 2x 3Gb/s SATA, RAID 0/1 capable
(Standard)
Cable
Required
Internal SATA Cable
3x Single-SATA to mini-SAS
K410-241(00)
Drive Cage
2.5-inch Drive Cage
3 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
3 slots
available
SATA
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1 x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
NOTE
Embedded SATA RAID controller is supported only on Windows operating systems. An optional RAID
controller is required to configure RAID array for other operating systems.
All hard drives within a RAID array should be of the same capacity and rotation speed.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 17
4.3.3 Up to three Drives with RAID 0/1 Controller with 128 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (128MB, RAID 0/1)
Promise SuperTrak TX8760T-128
RAID 0/1/10, 128MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA
3Gb/s
N8103-128
RAID BBU
Recommended
RAID Battery Backup Unit
for Promise SuperTrak EX8760T
N8103-141
Cable
Required
Internal SAS Cable
mini-SAS to mini-SAS
K410-180(00)
Drive Cage
2.5-inch Drive Cage
3 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
3 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
73.2GB 15K Hot Plug 2.5-inch SAS HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed..

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 18
4.3.4 Up to three Drives with RAID 0/1 Controller with 512 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID 0/1, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA 6Gb/s
N8103-149
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-155
Cable
Required
Internal SAS Cable
mini-SAS to mini-SAS
K410-180(00)
Drive Cage
2.5-inch Drive Cage
3 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
3 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
73.2GB 15K Hot Plug 2.5-inch SAS HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 19
4.3.5 Up to three Drives with RAID 5 Controller with 512 MB Cache
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (512MB, RAID 0/1)
LSI MegaRAID SAS 9267-8i
RAID 0/1/5, 512 MB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s, SATA
6Gb/s
N8103-150
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-155
Cable
Required
Internal SAS Cable
mini-SAS to mini-SAS
K410-180(00)
Drive Cage
2.5-inch Drive Cage
3 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
3 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
73.2GB 15K Hot Plug 2.5-inch SAS HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 200 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, eMLC, 2.5-inch, 6Gb/s
N8150-712
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed.

CONFIGRATION GUIDE –NEC Express5800/GT110e-S / Air cooling model
NEC Corporation Revision 5.0 –July 17, 2013 20
4.3.6 Up to three Drives with RAID 5 Controller with 1 GB Cache/Battery
Category
Product Name / Description
Part Number
Storage Controller
Required
RAID Controller (1GB, RAID0/1/5/6)
LSI MegaRAID SAS 9267-8i
RAID 0/1/5, 1 GB, Int. 8, PCIe 2.0(x8), SAS 6Gb/s,
SATA 6Gb/s
N8103-151
RAID BBU
Recommended
RAID Battery Backup Unit
for LSI MegaRAID SAS 9267-8i
N8103-155
SSD Caching
Recommended
MegaRAID CacheCade
for LSI MegaRAID SAS
NOTE:
- SSD used for cache is required
- The SSD capacity which can be used as read cache is up to
512 GB.
N8103-156
Cable
Required
Internal SAS Cable
mini-SAS to mini-SAS
K410-180(00)
Drive Cage
2.5-inch Drive Cage
3 x 2.5-inch hot plug hard drive bays
(Standard)
Drive
3 slots
available
SAS
HDD
300GB 10K Hot Plug 2.5-inch SAS HDD
1 x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-301
450GB 10K Hot Plug 2.5-inch SAS HDD
1 x 450 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-322
600GB 10K Hot Plug 2.5-inch SAS HDD
1 x 600 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-304
900GB 10K Hot Plug 2.5-inch SAS HDD
1x 900 GB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-332
1.2TB 10K Hot Plug 2.5-inch SAS HDD
1x 1.2TB SAS HDD, 2.5-inch, 6Gb/s, 10,000 rpm
N8150-408
73.2GB 15K Hot Plug 2.5-inch SAS HDD
1x 73.2 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-302
146.5GB 15K Hot Plug 2.5-inch SAS HDD
1x 146.5 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-303
300GB 15K Hot Plug 2.5-inch SAS HDD
1x 300 GB SAS HDD, 2.5-inch, 6Gb/s, 15,000 rpm
N8150-331
SATA
HDD
250GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 250 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-356
500GB 7.2K Hot Plug 2.5-inch SATA HDD
1x 500 GB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-357
1TB 7.2K Hot Plug 2.5-inch SATA HDD
1x 1 TB SATA HDD, 2.5-inch, 6Gb/s, 7,200 rpm
N8150-358
SAS
SSD
200GB Hot Plug 2.5-inch SAS SSD
1x 100 GB SAS SSD, 2.5-inch, 6Gb/s
N8150-711
400GB Hot Plug 2.5-inch SAS SSD
1x 400 GB SAS SSD, 2.5-inch, 6Gb/s
N8150-712
NOTE:
All drives within a RAID array should be of the same type, capacity and rotation speed..
