Nedap WIM User manual

WIM
quick reference guide
201
5-08-24 | v4.3 | 5279470

WIM | QUICK REFERENCE GUIDE
2/4
SAFETY PRECAUTIONS
The following safety precautions must be observed during normal use, service and repair.
•Disconnect the power supply before opening the device.
•The WIM shall only be installed and serviced by qualified and trained personnel.
•The WIM can be powered from a low power, Class 2 power supply, in compliance with local regulations.
•To be sure of safety, do not modify or add anything other than mentioned in this manual or indicated by
NEDAP N.V.
KEY FEATURES
The Wiegand Interface Module (WIM) is developed to be used in combination with the License Plate Reader. The
WIM will convert the license plate string into a Wiegand output message. The Wiegand interface is supported by
many access control systems.
•Converts a license plate into a Wiegand output message.
•Contains a match-list in which license plates and corresponding Wiegand output numbers are found.
•Supports a sophisticated algorithm to convert license plates into "unique" Wiegand output numbers.
•RS485 interface to connect the NEDAP ANPR.
•LAN – TCP/IP interface to configure the device and manage the match-list

WIM | QUICK REFERENCE GUIDE
3/4
CONNECTIONS
Front side
RS485 Connect the RS485 to the License Plate Reader (9600, 8N1).
B: RS485-B (green)
A: RS485-A (yellow)
GND: RS485-GND (purple)
Wiegand Connect the Wiegand output to your access control system.
D1: Wiegand data-1 (white)
D0: Wiegand data-0 (green)
GND: Ground (black)
Magstripe Magstripe Clock and Data output. Select with the plate conversion mode switches. See below.
D1: Data
D0: Clock
CLS: Card Loaded
GND: Ground
Barcode Barcode wand emulation data output in code39 format. Select with conversion mode
switches. See below.
D1: Wand emulation data output (black=high)
D0: Wand emulation data output (black=low)
GND: Ground (black)
STS LED
Status LED (green)
ERR LED
Error LED (red)
LAN The LAN connection (RJ45 socket) is used to configure the device and manage the match-list.
Link LED (left): Off=No link, Amber=10Mbps,
Green=100Mbps.
Activity LED (right): Off=No activity, Amber=HDX Activity,
Green=FDX Activity.
RS485
connection
WIEGAND
output
LED
indications
LAN
connection
GND CLS D0
D1
GND A
B

WIM | QUICK REFERENCE GUIDE
4/4
Rear side
Power input Use the supplied 24VDC power adapter. Power supplies must be able to supply 12 – 24
VDC / 5 Watt (positive voltage at center pin).
Switches
Plate conversion mode switches.
DIMENSIONS
Plate conversion mode switches
1
2
3
4
Wiegand 26-bit SHA-1
ON
ON
ON
ON
Wiegand 64-bit
OFF
ON
ON
ON
Magstripe ISO7811 track 1
ON
OFF
OFF
ON
Magstripe ISO7811 track 2
OFF
OFF
OFF
ON
Barcode wand emulation code39
ON
OFF
OFF
OFF
Wiegand match-list mode (EEPROM 1008 plates)
OFF
OFF
OFF
OFF
Wiegand match-list XL mode (FLASH 20480 plates)
OFF
OFF
ON
OFF
125 mm [ 4.9 " ]
35 mm [ 1.4 " ]
130 mm [ 5.1 " ]
Switches
Power input
