Wi-Fi Smart Air Conditioner
Article number: WIFIACMB3WT9
Nedis BV
De Tweeling 28, 5215 MC ’s-Hertogenbosch, The Netherlands 02/22
Preface
Thank you for purchasing the Nedis WIFIACMB3WT9.
This document is the user manual and contains all the information for correct, ecient and
safe use of the product.
This user manual is addressed to the end user. Read this information carefully before
installing or using the product.
Always store this information with the product for use in the future.
Product description
Intended use
The Nedis WIFIACMB3WT9 is a mobile air conditioner used for cooling and dehumidifying
rooms.
The product is exclusively intended as a mobile air conditioner for domestic, indoor use.
Any modication of the product may have consequences for safety, warranty and proper
functioning.
This product can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the product in a safe way and
understand the hazards involved. Children shall not play with the product. Cleaning and
user maintenance shall not be done by children without supervision.
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
2/17
The product is intended for use in household environments for typical housekeeping
functions that may also be used by non-expert users for typical housekeeping functions,
such as: shops, oces other similar working environments, farm houses, by clients in
hotels, motels and other residential type environments and/or in bed and breakfast type
environments.
The product is not intended for professional use.
Specications
Product Wi-Fi Smart Air Conditioner
Article number WIFIACMB3WT9
Dimensions (d x w x h) 320 x 310 x 715 mm
Weight 22.0 kg
Input voltage 220 – 240 V ~ 50 Hz
Required power 1010 W
Energy class A
Energy eciency ratio (EER) 2.6
Noise level ≤ 65 dB(A)
Cooling capacity 9000 BTU
Room size capacity 18 - 27 m²
room coverage* 80 m3
Air circulation 350 m3 / h
Dehumidication 24 l/day
Refrigerant R290 / 195 g
Power plug Schuko CEE 7/7
Battery type 2 x AAA (not included)
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
3/17
Permissible excessive operating
pressure
Suction 0.6 MPa
Discharge 1.8 MPa
Max. allowable pressure 3.0 MPa
Operation modes Cooling / Dehumidifying / Fan
Fan speed levels high / low
Max. radio transmit power
802.11b 17.5 dBm
802.11g 14.5 dBm
802.11n 13.5 dBm
Antenna gain 2.5 dBi
Used frequency band 2412 - 2472 MHz
Modulation method DSSS, OFDM, 64QAM
* The performance of the air conditioner is subjected to many factors like oor space,
ceiling height, level of isolation and number of windows. The data mentioned is based on a
space with low heat loads.
Main parts (image A)
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
4/17
A
1Control panel
2Handle
3Swing louvers
4Exhaust nozzle
5Exhaust hose
6Window kit
7Window kit fasteners
8Power cable storage
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
5/17
Display and remote control (image B )
9Air outlet
qDrainage outlet
wPower cable
eExhaust hose connector
rRemote control
tExhaust nozzle screw
B
1Display screen
2Full indicator
3WIFI indicator
4Timer button
5Speed button
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
6/17
Safety instructions
WARNING
• Ensure you have fully read and understood the instructions in this document before
you install or use the product. Keep the packaging and this document for future
reference.
• Only use the product as described in this document.
• Install the product in accordance with national wiring.
• Do not use a damaged or defective product, but return it for repair or replacement.
• Close supervision is necessary when the product is used by or near children, animals
or inrm persons. Do not allow children to play with it or touch it.
• Only move the product in an upright position.
• Keep the product out of reach from children.
• Place the product on a stable and at surface.
• Leave a minimum of 0.5 m free space around the air outlet and swing louvers to allow
a good circulation of airow.
• If the product has been tilted, allow it to stand upright for 2 hours before plugging it in.
• Do not drop the product and avoid bumping.
• This product may only be serviced by a qualied technician for maintenance to reduce
the risk of electric shock.
• Do not expose the product to water or moisture.
• If the product is immersed in water, do not touch the product or the water.
• Shut off the main power grid and carefully remove the plug from the power outlet.
• After the product has been immersed or covered in water or other liquids, do not use
the product again.
• Do not place the product in environments with high humidity, like a bathroom or
laundry.
• Keep the product away from heat sources. Do not place the product on hot surfaces or
near open ames.
6Up button
7Down button
8Sleep button
9Mode button
qPower button
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
7/17
• Do not use the product near explosive or ammable materials.
• Do not insert any objects into the product.
• Do not obstruct or cover ventilation openings.
• Always disconnect the product from the power outlet when cleaning or moving the
product
• Do not pull the power cable to move the product.
• Unplug the product from the power source and other equipment if problems occur.
• Switch off the main power switch before unplugging the power cord.
• Do not use the product when the cord or plug is damaged.
• Do not unplug the product by pulling on the cable. Always grasp the plug and pull.
• Make sure that the electrical supply in your area matches a voltage of 220 – 240 VAC
and a frequency of 50 Hz.
• Connect to a grounded socket only.
• If necessary, use an earthed extension cable of a suitable diameter.
• Fully extend the power cord and make sure the power cord does not contact the
product.
• When using an extension cord, use one which is as short as possible and fully
extended.
• Do not use external timers or remote control systems to switch the product on or off.
• Do not use mechanical products or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
• Ensure people do not trip over the cord.
• Do not leave the product unattended when switched on.
• R290 is a refrigerant gas that complies with the European directives on the
environment.
• Be aware that refrigerants can be odorless.
• Place the product in an area without any continuous sources of ignition (for example:
open ames, gas or electrical appliances in operation).
• Keep the product at a distance from ammable objects such as furniture, curtains and
similar.
•Only install, operate and store the product in a room with a oor area above 9 m2.
• Do not block ventilation openings and make sure that there is enough space around
the product.
• Only use the provided exhaust hose.
• Do not block the exhaust hose. Blocking the exhaust hose may cause overheating.
• Do not twist the exhaust hose.
• Ensure that the exhaust hose does not kink.
• Do not use aggressive chemical cleaning agents such as ammonia, acid or acetone
when cleaning the product.
• Only store the product in a well-ventilated area.
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
8/17
• When the product is installed, operated or stored in a non-ventilated area, make sure
the room is designed to prevent the accumulation of refrigerant leaks resulting in a risk
of re or explosion due to ignition of the refrigerant caused by electric heaters, stoves,
or other sources of ignition.
• Only persons with a current valid certicate from an industry-accredited assessment
authority, which authorizes their competence to handle refrigerants safely in
accordance with an industry recognized assessment specication, can work on or
break into a refrigerant circuit.
• Servicing can only be performed as recommended by the equipment manufacturer.
Maintenance and repair requiring the assistance of other skilled personnel can only be
carried out under the supervision of the person competent in the use of ammable
refrigerants.
• When defrosting and cleaning the product, do not use any means other than those
recommended by the manufacturing company.
• Do not puncture or heat any part of the refrigerant circuit.
Explanation of the safety symbols on the product
Icon Description
• Contains one or more (extremely/highly) ammable
components.
Explanation of the symbols on the product or
packaging
Icon Description
Electronic equipment needs to bear the CE mark in order to be
marketed in the EU. CE marking shows that a product is assessed
before being placed on the market and that it meets EU safety, health
and environmental protection requirements. CE marking is also
sometimes accepted as a means of compliance with type-approval
requirements; for example, electronic components that require type-
approval and also CE marking for electromagnetic compatibility (EMC)
or low-voltage equipment.
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1MjA…
9/17
Indication to explain that the product needs to be collected separately
when disposed. Do not throw in the trash bin.
Installation
Check the contents of the package
Check that all parts are present and that no damage is visible on the parts. If parts are
missing or damaged, contact the Nedis B.V. service desk via the website: www.nedis.com.
Installing the product
4
Place the product on a stable and at surface.
4
Only move the product in an upright position.
4
Leave a minimum of 0.5 m free space around the air outlet and swing louvers to allow
a good circulation of airow.
4
If the product has been tilted, allow it to stand upright for 2 hours before plugging it in.
4
Keep the product at a distance from ammable objects such as furniture, curtains and
similar.
4
Do not block ventilation openings and make sure that there is enough space around
the product.
4
Only install, operate and store the product in a room with a oor area above 9 m2.
1. Plug the power cable Aw into the power outlet.
Assembling the exhaust (image C)
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
10/17
4
Only use the provided exhaust hose.
4
Do not block the exhaust hose. Blocking the exhaust hose may cause overheating.
1. Assemble the exhaust hose A5, the exhaust nozzle A4 and the exhaust hose
connector Ae.
2. Slide Ae over the air outlet A9.
3. Extend A5 up to 1500 mm.
4
Do not twist the exhaust hose.
4
Ensure that the exhaust hose does not kink.
4. Assemble the window kit A6 with the window kit fasteners A7.
5. Install A6 in the window opening.
6. Tighten A7.
7. Snap A4 into A6 and fasten with the exhaust nozzle screw At.
Assembling the continuous drainage (optional)
1. Open the drainage outlet Aq.
2. Connect Aq to a water container or drainage system (not included).
Placing the batteries in the remote control
1. Slide the battery cover off the back of the remote control Ar
2. Insert 2 type AAA batteries.
3. Slide the battery cover back in place on Ar
C
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
11/17
Installing the Nedis SmartLife app
1. Download the Nedis Smartlife app for Android or iOS on your phone via Google Play or
the Apple App Store.
2. Open the Nedis Smartlife app on your phone.
3. Create an account with your mobile phone number or your e-mail address and tap
Continue .
4
You will receive a verication code on your mobile phone or e-mail address.
4. Enter the received verication code.
5. Create a password and tap Done .
6. Tap Add Home to create a SmartLife Home.
7. Set your location, choose the rooms you want to connect with and tap Done .
Adding a product to the Nedis SmartLife app
1. Switch on the product.
2. Tap + in the Nedis SmartLife app.
3. Select the device type you want to add from the list.
4. Conrm the Wi-FI indicator LED B3 is blinking fast.
4
If B3 is not blinking fast, press the Speed button B5 on the product for 5 seconds
during standby mode to reset the product.
5. Follow the instructions in the Nedis SmartLife app.
6. Rename the product after it has been found and added.
7. After conrming you can control the product with your smartphone.
To connect your SmartLife account to Amazon Alexa and/ or Google Home, set it up using
the “Smart Life” action or skill. For more details check the instruction on either Amazon or
Google.
Use
Using the control panel and remote control
Button Function
Timer button B4 Press to set the timer. Use B6 and B7 to set the
duration of cooling.
Speed button B5 Press the speed button during COOL or FAN mode
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
12/17
to switch between high and low fan speed
operation.
In DRY mode, it is not possible to switch between
fan speed operation.
Up button B6 Increase values.
Down button B7 Decrease values.
Sleep button B8
Activate sleep mode. Only works in COOL mode.
After one hour the set temperature increases 1 °C
and again after 2 hours.
Mode button B9 Repeatedly press the mode button the select the
mode: FAN / DRY (dehumidifying) / COOL.
Power button B10 Switch the product on or off.
Frost protection function
The product automatically enters the frost protection status if the temperature of the
exhaust pipe is too low (only works in COOL and DRY mode).
The product automatically reverts to the normal operation if the temperature of the exhaust
pipe rises to a certain temperature.
Protection function of the compressor
To increase the lifetime of the compressor, it has a 3 minute delay booting protection
function after the compressor is switched off.
The overow protection function
If water exceeds the warning level, the product emits a tone, and the ‘water full’ indicator
starts ashing.
(See next paragraphs how to empty the water reservoir of the product.)
Manual drainage
The FULL indicator B2 ashes and the product emits an alarm sound to indicate that the
water reservoir is full.
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
13/17
1. Switch off the product using Bq
2. Unplug Aw.
3. Place a water container underneath Aq.
4. Remove the water plug of Aq
5. Slightly tilt the product backwards to ensure all water leaves the reservoir.
6. Put the water plug back on Aq
Troubleshooting
Problem Possible cause Possible solution
The product does not work.
The power outlet has no
power.
Plug the power cable into a
power outlet with power.
The FULL indicator ashes. Drain the water from the
reservoir of the product.
The ambient temperature
is too low or too high.
Use the product in a room
with a temperature
between 7-35 °C (44-95
°F).
In COOL mode; the room
temperature is below the
set temperature.
Change the set
temperature.
In DRY mode, the ambient
temperature is low.
Use the product in a room
with an ambient
temperature higher than 17
°C (62 °F).
The product does not cool. There is direct sunlight at
the product.
Avoid heat and direct
sunlight.
Doors or windows are
open.
There are a lot of people in
the room.
In cooling mode; There are
other sources of heat.
Close doors and windows.
Keep the product away
from the heat source.
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
14/17
The lter is dirty. Clean the lter
The air inlet or outlet is
blocked. Clear obstructions.
The product makes
abnormal noises.
The product is not placed
on a at surface.
Place the product on a at
and hard surface to reduce
the noise.
The compressor does not
work.
The overheat protection
starts.
Wait 3 minutes until the
temperature has
decreased.
The remote control does
not work.
The distance between the
product and the remote
control is too far.
Aim the remote control
directly at the receiver.
The remote control is not
aligned with the receiver.
Aim the remote control
directly at the receiver.
Aim the remote control
directly at the receiver.
The batteries are empty. Replace the batteries.
The product displays ‘E2’. The pipe temperature
sensor is abnormal.
Contact a qualied
technician for
service/repair.
The product displays ‘E1’. The room temperature
sensor is abnormal.
Contact a qualied
technician for
service/repair.
Maintenance
Clean the product regularly with a soft, clean, dry cloth. Avoid abrasives that can damage
the surface.
Do not use aggressive chemical cleaning agents such as ammonia, acid or acetone when
cleaning the product.
Cleaning the product (image D)
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
15/17
Clean the product regularly as follows:
1. Switch off and unplug the product when not in use or before maintenance.
2. Pull off the grids D1.
3. Remove the lter screens D2 from D1.
4. Clean D2 in warm water (about 40 °C) with a neutral detergent.
5. Rinse and dry D2 in the shade.
6. Put back D2 in D1.
7. Put back D1 together with D2.
8. Clean the outside of the product with a soft, clean, lightly damp cloth.
4
Do not use aggressive chemical cleaning agents such as ammonia, acid or acetone
when cleaning the product.
D
1Grids
2Filter screens
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
16/17
Storing the product
Store the product as follows:
1. Drain the product.
2. Press Bq to switch on the product.
3. Press B5 to switch to low fan speed operation.
4. Wait until Aq is dry.
5. Switch off the product and put the drainage plug back.
6. Unplug the product.
7. Remove A5.
8. Remove the batteries from Ar during long periods of disuse to avoid possible
leakage.
9. Cover the product with a plastic bag.
10. Store the product in a dry place away from sunlight and protect it against excessive
dust and dirt.
Warranty
Any changes and/or modications to the product will void the warranty. We accept no
liability for damage caused by improper use of the product.
Disclaimer
Designs and specications are subject to change without notice. All logos, brands and
product names are trademarks or registered trademarks of their respective owners and are
hereby recognized as such.
Disposal
This symbol indicates that this product should not be thrown away
with other household waste throughout the EU. To prevent possible
harm to the environment or human health by uncontrolled waste
disposal, you are responsible for recycling it so that it can promote the
sustainable reuse of raw materials. To return your used product, you
can use the regular return and collection systems or contact the store
where the product was purchased. They can recycle this product for
the environment.
User manual EN 

09-05-2022 13:00
User manual
https://cdn.nedis.com/manuals/html/WIFIACMB3WT9/?_gl=1*1fr8j43*_ga*MTA0ODQzOTI0OS4xNjMzMzU1MjI3*_ga_49LWESJ80M*MTY1Mj…
17/17
User manual EN 
