NEFF E12M22 3 Series User manual

[en] Instruction manual
Built-in cooker E12M22.3

3
ÚTable of contents [en]Instructionmanual
Important safety information..................................................... 3
Causes of damage .............................................................................4
Energy and environment tips....................................................5
Saving energy......................................................................................5
Environmentally-friendly disposal.....................................................5
Your new appliance.................................................................... 5
Control panel .......................................................................................5
Operating modes ................................................................................5
Your accessories........................................................................6
Accessories .........................................................................................6
Inserting accessories .........................................................................6
Shelf positions .....................................................................................6
Optional accessories .........................................................................6
Before using the appliance for the first time ...........................7
Operating the appliance ............................................................ 7
Switching on the appliance...............................................................7
Switching off the appliance...............................................................7
Switching the hob on and off ...........................................................7
Baking ......................................................................................... 7
Baking in tins and on trays ...............................................................7
Baking on two or more levels ..........................................................8
Baking table for basic doughs/cake mixtures ..............................8
Baking table for dishes and pre-prepared frozen products .......9
Tips and tricks .................................................................................. 10
Roasting .................................................................................... 11
Open roasting................................................................................... 11
Closed roasting................................................................................ 11
Roasting table .................................................................................. 11
Tips and tricks .................................................................................. 12
Grilling....................................................................................... 13
Circo-roasting ................................................................................... 13
Radiant grilling ................................................................................. 13
Defrosting ................................................................................. 14
Defrosting with CircoTherm®........................................................ 14
Defrost ............................................................................................... 14
Yoghurt...................................................................................... 14
Preserve .................................................................................... 15
Cleaning and care .................................................................... 15
Cleaning the appliance exterior .................................................... 16
Cleaning the cooking compartment............................................. 16
Removing and fitting the appliance door.................................... 16
Cleaning the door panels............................................................... 17
Cleaning the hook-in racks............................................................ 17
Faults and repairs .................................................................... 18
Replacing the oven light bulb ....................................................... 18
Changing the door seal.................................................................. 18
After-sales service ................................................................... 18
E number and FD number ............................................................. 18
Test dishes................................................................................ 19
Produktinfo
Additional information on products, accessories, replacement
parts and services can be found at www.neff-
international.com and in the online shop www.neff-
eshop.com
: Important safety information
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for
future use or for subsequent owners.
This appliance is only intended to be fully
fitted in a kitchen. Observe the special
installation instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance
if it has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused
by incorrect connection is not covered
under warranty.
This appliance is intended for domestic use
only. The appliance must only be used for
the preparation of food and drink. The
appliance must be supervised during
operation. Only use this appliance indoors.
This appliance may be used by children
over the age of 8 years old and by persons
with reduced physical, sensory or mental
capacity or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with the appliance.
Children must not clean the appliance or
carry out general maintenance unless they
are at least 8 years old and are being
supervised.
Keep children below the age of 8 years old
at a safe distance from the appliance and
power cable.
Always slide accessories into the cooking
compartment correctly. See "Description of
accessories in the instruction manual.

4
Risk of fire!
■Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off
the appliance and unplug it from the
mains or switch off the circuit breaker in
the fuse box.
Ris k of fire!
■A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating
element and catch fire. Do not place
greaseproof paper loosely over
accessories during preheating. Always
weight down the greaseproof paper with a
dish or a baking tin. Only cover the
surface required with greaseproof paper.
Greaseproof paper must not protrude over
the accessories.
Risk of burns!
■The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Ris k of burns!
■Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Ris k of burns!
■Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with
care.
Risk of scalding!
■The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Ris k of scalding!
■When you open the appliance door, hot
steam may escape. Open the appliance
door with care. Keep children at a safe
distance.
Ris k of scalding!
■Water in a hot cooking compartment may
create hot steam. Never pour water into
the hot cooking compartment.
Risk of injury!
Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, or sharp or abrasive cleaning aids
or detergents.
Risk of electric shock!
■Incorrect repairs are dangerous. Repairs
may only be carried out by one of our
trained after-sales engineers. If the
appliance is faulty, unplug the mains plug
or switch off the fuse in the fuse box.
Contact the after-sales service.
Risko felectric shock!
■The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact
with hot parts of the appliance.
Risko felectric shock!
■Penetrating moisture may cause an
electric shock. Do not use any high-
pressure cleaners or steam cleaners.
Risko felectric shock!
■When replacing the cooking compartment
bulb, the bulb socket contacts are live.
Before replacing the bulb, unplug the
appliance from the mains or switch off the
circuit breaker in the fuse box.
Risko felectric shock!
■A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in
the fuse box. Contact the after-sales
service.
Causes of damage
Caution!
■Accessories, foil, greaseproof paper or ovenware on the
cooking compartment floor: do not place accessories on the
cooking compartment floor. Do not cover the cooking
compartment floor with any sort of foil or greaseproof paper.
Do not place ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will cause heat
to accumulate. The baking and roasting times will no longer
be correct and the enamel will be damaged.
■Water in a hot cooking compartment: do not pour water into
the cooking compartment when it is hot. This will cause
steam. The temperature change can cause damage to the
enamel.
■Moist food: do not store moist food in the cooking
compartment when it is closed for prolonged periods This will
damage the enamel.
■Fruit juice: when baking particularly juicy fruit pies, do not
pack the baking tray too generously. Fruit juice dripping from
the baking tray leaves stains that cannot be removed. If
possible, use the deeper universal pan.
■Cooling with the appliance door open: only allow the cooking
compartment to cool when it is closed. Even if the appliance
door is only open a little, front panels of adjacent units could
be damaged over time.
■Very dirty door seal: If the door seal is very dirty, the
appliance door will no longer close properly when the
appliance is in use. The fronts of adjacent units could be
damaged.Always keep the door seal clean.
■Appliance door as a seat, shelf or worktop: Do not sit on the
appliance door, or place or hang anything on it. Do not place
any cookware or accessories on the appliance door.
■Inserting accessories: depending on the appliance model,
accessories can scratch the door panel when closing the

5
appliance door. Always insert the accessories into the
cooking compartment as far as they will go.
■Carrying the appliance: do not carry or hold the appliance by
the door handle. The door handle cannot support the weight
of the appliance and could break.
Energy and environment tips
Here you can find tips on how to save energy when baking and
roasting and how to dispose of your appliance properly.
Saving energy
Only preheat the oven if this is specified in the recipe or in the
operating instruction tables.
Use dark, black lacquered or enamelled baking tins. They
absorb the heat particularly well.
Open the appliance door as little as possible during cooking,
baking or roasting.
It is best to bake several cakes one after the other. The cooking
compartment is still warm. This may reduce the baking time for
the second cake.
For longer cooking times, you can switch the oven off
10 minutes before the end of the cooking time and use the
residual heat to finish cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly manner.
Your new appliance
In this section, you will find information on
■the control panel
■the operating modes
Control panel
Operating modes
Here is an overview of the operating modes of your appliance.
This appliance complies with European Directive
2002/96/EC on Waste Electrical and Electronic
Equipment (WEEE). The directive gives a framework for
the collection and recycling of old appliances, which is
valid across the EU.
Control element Use
Operating mode selector Selects the desired operating mode
Temperature selector Sets the desired temperature
Control knob for hobs ~indicator lamp is not lit: hotplates off
~ indicator lamp lit: at least one hotplate is on
&RQWURONQREVIRUKREV
,QGLFDWRUODPSIRU
WHPSHUDWXUHVHOHFWRU
,QGLFDWRUODPS
IRUKRWSODWHV
2SHUDWLQJ
PRGH
VHOHFWRU
7HPSHUDWXUH
VHOHFWRU
Operating mode Used for
3CircoTherm® For baking and roasting on one or more levels
%Top/bottom heating For baking and roasting on one level. Ideal for cakes with moist toppings (e.g. cheese-
cake)
4Circo-roasting For poultry and larger pieces of meat

6
Your accessories
In this section, you will find information on
■Your accessories
■the correct way to insert the accessories into the cooking
compartment
■the shelf positions
■the optional accessories
Accessories
The following accessories are included with your appliance:
Note: The baking tray and universal pan may become distorted
when the appliance is in operation. This is caused by the
considerable temperature differences acting on the
accessories. These differences may occur if only a part of the
accessory is covered with food, or if frozen items such as pizza
are placed on the accessory.
Inserting accessories
The accessories are equipped with a locking function. The
locking function prevents the accessories from tilting when they
are pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection to work
properly.
When inserting the wire rack, check
■that the lug (a) is pointing downwards
■that the lug (a) is in the rear part of the wire rack
When inserting the baking tray or the universal pan, check
■that the lug (a) is in the rear part of the of the accessory
■that the sloping edge of the accessory faces towards the
appliance door when it is inserted
Shelf positions
The cooking compartment has four shelf heights. The shelf
heights are counted from the bottom up.
Note: Do not use shelf height 2 when baking and roasting
with 3CircoTherm®. This will adversely affect air circulation
and your baking and roasting results will not be as good.
Optional accessories
You can purchase optional accessories from the after-sales
service or specialist retailers. A comprehensive range of
products for your appliance can be found in our brochures or
on our home page.
(Full-surface grill For large amounts of flat, small items for grilling (e.g.steaks, sausages)
$Bottom heat For food and baked goods which should form a crust or need more browning on the
underside.
Only activate bottom heat for a short while at the end of the baking time.
ADefrost setting For gently defrosting pieces of meat, bread and delicate pastries (e.g. cream gateau)
\Interior lighting Provides assistance when maintaining and cleaning the cooking compartment
Operating mode Used for
Wire rack
for baking in baking tins, roasting in
roasting dishes and grilling
Universal pan, enamelled
for baking moist cakes, roasting,
grilling and collecting drops of
liquid during cooking
D
D
Optional accessories Order no.
Mega system steamer N8642X3
Universal pan, enamelled Z1232X3
Universal pan, non-stick Z1233X3
Universal pan with wire insert Z1242X3
Wire insert for roasting and grilling, to be
used in the universal pan 740766
Extra-deep roasting pan, enamelled Z1272X0
Baking tray, aluminium Z1332X0
Baking tray, enamelled Z1342X0
Baking tray, non-stick Z1343X0
Pizza tray Z1352X0
Baking and roasting wire rack Z1432X3
DD

7
Before using the appliance for the first time
In this section, you can read how to clean your appliance
before you use it for the first time.
1. Remove the accessories from the cooking compartment.
2. Completely remove any residual packaging (e.g. chips of
polystyrene) from the cooking compartment.
3. Clean the accessories and cooking compartment with hot
soapy water (see section: Cleaning and care).
4. Heat with %Top/bottom heat at 240 °C for 60 minutes.
5. Afterwards, wipe the cooled cooking compartment with hot,
soapy water.
6. Clean the outside of the appliance with a soft, damp cloth
and soapy water.
Operating the appliance
In this section, you can read about
■how to switch your appliance on and off
■how to select an operating mode and temperature
Switching on the appliance
1. Turn the operating mode selector until the desired operating
mode is selected.
2. Turn the temperature selector until the desired temperature is
selected.
The rindicator lamp lights up while the appliance is heating
up and during any subsequent heating.
Switching off the appliance
1. Turn the operating mode selector back to the Ûposition.
2. Turn the temperature selector back to the Úposition.
After the appliance is switched off, the cooling fan may
continue to run.
Switching the hob on and off
Your hob comes with its own instructions for use. This contains
important safety information, detailed set-up instructions and a
lot of information on care and cleaning.
Hotplate knobs
You can use the four hotplate knobs to set the heat output of
the individual hotplates.
Baking
In this section, you will find information on
■Baking tins and trays
■Baking on two or more levels
■Baking basic doughs and cake mixtures (baking table)
■Baking pre-prepared frozen products and freshly prepared
meals (baking table)
■Tips and tricks for baking
Note: Do not use shelf height 2 when baking with 3
CircoTherm®. The air circulation would be impaired and this
will have a negative effect on your baking.
Baking in tins and on trays
Baking tins
We recommend dark-coloured metal baking dishes.
Roasting tray, enamelled, two-piece Z1512X0
CLOU® 3x telescopic shelf Z1742X2
CLOU® 4x telescopic shelf with full exten-
sion Z1755X2
Bread-baking stone Z1913X0
Optional accessories Order no.
Setting Meaning
ýOff position The hotplate is turned off
Heat settings 1 9 The heat output of the hotplate.
1=lowestoutput
9 = highest output
The intermediate settings between
heat setting 2 and 5 are indicated with
a•dot.
öZone activation Activates the large dual-circuit hot-
plate or the extended cooking zone
(not available on all hotplates).

8
Tinplate and glass dishes increase the baking time required
and the cake will not brown evenly. If you wish to bake using
tinplate tins and %Top/bottom heat, you should use shelf
position 1.
If you wish to use silicone baking tins, use the information and
recipes provided by the manufacturer as a guide. Silicone
baking tins are often smaller than normal tins. The amount of
mixture and recipe instructions may differ.
If you are baking on one level with 3CircoTherm®, always
place a loaf tin diagonally (Fig. A) and a round tin in the centre
of the wire rack (Fig. B).
Baking trays
We recommend that you only use original baking trays, as
these have been optimally designed for the cooking
compartment and the operating modes.
Always slide the baking tray or the universal pan in carefully as
far as it will go and make sure that the sloping edge is facing
the appliance door.
Use the universal pan if you are baking moist cakes, so that the
cooking compartment does not get dirty.
Baking on two or more levels
If you are baking on several levels, you should preferably use
baking trays and insert these at the same time.
Bear in mind that your items may brown at different rates on
each level. The items on the top level will brown more quickly
and can be taken out earlier.
If you wish to bake on two levels using a baking tray and a
universal pan, you should insert the baking tray at shelf
height 3 and the universal pan at shelf height 1.
Baking table for basic doughs/cake mixtures
The values in the table are guidelines and apply to enamelled
baking trays and dark baking tins. The values may vary
depending on the type and amount of dough/mixture and on
the baking tin.
The values for bread dough apply to both dough placed on a
tray and dough placed in a loaf tin.
We recommend that you set the lower of the specified
temperatures the first time. Lower temperatures will generally
allow more even browning.
If you are baking according to your own recipe, use similar
recipes in the table as a guide.
Observe the notes in the table about preheating.
$%
CircoTherm® 3Top/bottom heat %
Basic dough Shelf
height Tempera- ture in °C Baking time in minutes Shelf height Tempera- ture in °C
Rich sponge mixture
Tray bakes with topping 1 160 - 170 30 - 45 3 170 - 180
1 + 3 150 - 160 40 - 50 - -
Springform cake tin/loaf tin 1 150 - 160 60 - 80 2 160 - 170
Flan tin 1 160 - 170 20 - 35 2 170 - 180
Shortcrust pastry
Tray bake with dry topping, e.g. crumble 1 160 - 170 45 - 70 3 180 - 190
1 + 3 160 - 170 60 - 80 - -
Tray bake with moist topping, e.g. egg custard 1 150 - 170 60 - 80 - -
Springform cake tin, e.g. sponge base cheesecake 1 150 - 160 50 - 90 2 160 - 180
Flan tin 1 150 - 160* 20 - 35 2 170 - 180*
Sponge mixture
Swiss roll 1 180 - 190* 10 - 15 3 190 - 200*
Flan tin 1 160 - 170 20 - 30 2 160 - 170
Sponge (6 eggs) 1 150 - 160 30 - 45 2 160 - 170
Sponge (3 eggs) 1 150 - 160* 20 - 30 2 160 - 170*
Yeast dough
Tray bake with dry topping, e.g. crumble 1 160 - 170 40 - 55 3 170 - 180
1 + 3 160 - 170 45 - 65 - -
Savarin/plaited loaf (500 g) 1 160 - 170 30 - 40 3 170 - 180
Springform cake tin 1 160 - 170 30 - 40 2 160 - 170
Ring cake tin 1 160 - 170 35 - 45 2 170 - 180
* Preheat oven

9
Baking table for dishes and pre-prepared
frozen products
Notes
■Use the universal pan for frozen products
■Line the universal pan with greaseproof paper or with special
grease absorbing paper if you are baking frozen potato
products
■Only use greaseproof paper that is suitable for the selected
temperature
■Spread chips out in a single layer
■Turn frozen potato products half way through the baking time
■Only season frozen potato products after they have finished
baking
■Leave a little space between bread rolls when crisping them
up. Do not place too many on a baking tray
■Do not use frozen products with freezer burn
■Do not use frozen products that are heavily frosted
■Follow the manufacturer's instructions.
The values in the table are guidelines and apply to enamelled
baking trays. The values may vary depending on the type and
amount of dough and on the baking tin.
We recommend that you set the lower of the specified
temperatures the first time. Lower temperatures will generally
allow more even browning.
If you are baking according to your own recipe, use similar
recipes in the table as a guide.
Observe the notes in the table about preheating.
CircoTherm® 3Top/bottom heat %
Small baked items Shelf
height Tempera- ture in °C Baking time in minutes Shelf height Tempera- ture in °C
Yeast dough 1 160 - 170 20 - 25 3 170 - 180
1 + 3 160 - 170 20 - 30 - -
Meringue mixture 1 80 100 - 130 3 80
1 + 3 80 150 - 170 - -
Puff pastry 1 190 - 200* 20 - 30 3 200 - 210*
1 + 3 190 - 200* 25 - 35 - -
Choux pastry 1 190 - 200* 25 - 35 3 200 - 210*
1 + 3 190 - 200* 30 - 40 - -
Sponge mixture, e.g. muffins 1 150 - 160* 25 - 35 3 160 - 170*
1 + 3 150 - 160* 25 - 35 - -
Shortcrust pastry, e.g. butter biscuits 1 140 - 150* 15 - 20 3 140 - 150*
1 + 3 130 - 140* 20 - 30 - -
1 + 3+ 4 130 - 140* 20 - 35 - -
* Preheat oven
CircoTherm® 3Top/bottom heat %
Bread/bread rolls Shelf
height Tempera- ture in °C Baking time in minutes Shelf height Tempera- ture in °C
Bread rolls 1 220* 10 - 20 2 240*
Flatbread 1 220* 15 - 20 2 240*
Pasty 1 180* 30 - 40 3 200*
Bread dough 750 - 1,000 g
Final baking 1 220* 35 - 40 2 220*
Bread dough 1,000 - 1,250 g
Initial baking 1 220* 10 - 15 2 240*
Final baking 1 180 40 - 45 2 200
Bread dough 1,250 - 1,500 g
Initial baking 1 220* 10 - 15 2 240*
Final baking 1 180 40 - 50 2 200
* Preheat oven

10
Tips and tricks
CircoTherm® 3%Top/bottom heat
Meals Shelf posi-
tion Tempera- ture in °C Baking time in minutes Shelf posi- tion Tempera- ture in °C
Pizza, fresh 1 190 - 210* 20 - 30 2 210 - 230*
1 + 3 170 - 190 35 - 45 - -
Savoury flan 1 190 - 210* 15 - 25 2 210 - 230*
Quiche 1 180 - 200 50 - 60 2 200 - 220
Tart 1 180 - 200* 30 - 45 1 200 - 220*
Swiss flan 1 170 - 190* 45 - 55 2 180 - 200*
Potato gratin made from raw potatoes 1 180 - 200 50 - 60 2 200 - 220
Strudel, frozen 1 190 - 210 35 - 45 3 180 - 200
Pizza, frozen
Pizza with thin base 1 180 - 200 10 - 20 3 210 - 230
1 + 3 170 - 190 20 - 30 - -
Pizza with deep-pan base 1 180 - 200 20 - 30 3 180 - 200
1 + 3 170 - 190 25 - 35 - -
Potato products, frozen
Chips 1 190 - 210 15 - 25 3 190 - 210
1 + 3 170 - 190 25 - 35 - -
Croquettes 1 180 - 200 15 - 25 3 180 - 200
Rösti (stuffed potato pockets) 1 180 - 200 15 - 25 3 180 - 200
Baked goods
Part-baked bread rolls/baguettes 1 180 - 200 5 - 15 3 190 - 210
Bread rolls/baguette, frozen 1 180 - 200 5 - 15 3 180 - 200
Bread rolls/baguette, part baked, frozen 1 180 - 200 10 - 20 3 190 - 210
Pretzel dough, frozen 1 170 - 190 15 - 20 3 170 - 190
Meat portions, frozen
Fish fingers 1 180 - 200 15 - 20 3 200 - 220
Veggie burgers 1 180 - 200 20 - 30 3 180 - 200
* Preheat oven
The cake is too light in colour Check the shelf height.
Check whether you have used the bakeware that we have recommended.
Place your tin on the wire rack and not on the baking tray.
If the shelf height and the bakeware are correct, then you should either extend the bak-
ing time or increase the temperature.
The cake is too dark Check the shelf height.
If the shelf height is correct, you should either shorten the baking time or reduce the
temperature.
The cake is unevenly browned in the bak-
ing tin Check the shelf height.
Check the temperature.
Make sure that your baking tin is not placed directly in front of the air outlets in the rear
wall of the cooking compartment.
Check that the baking tin is in the correct position on the wire rack.
The cake on the baking tray is unevenly
browned Check the shelf height.
Check the temperature.
If you are baking on several levels, take out the baking trays at different times.
When baking small items, make sure that they are the same size and thickness.
The cake is too dry Set a slightly higher temperature and a slightly shorter baking time.
The cake is too moist in the centre Set a slightly lower temperature.
Note: Higher temperatures do not necessarily mean shorter baking times (cooked on
the outside, but not on the inside). Select a longer baking time and allow the cake mix-
ture to prove for longer. Add less liquid to the mixture.
