Neoway N58 Installation manual

Hardware User Guide
Issue 2.5 Date 2021-10-29

N58 Hardware User Guide
Copyright
Copyright © Neoway Technology Co., Ltd. All rights reserved.
ii
Copyright © Neoway Technology Co., Ltd. 2021. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Neoway Technology Co., Ltd.
is the trademark of Neoway Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
This document provides a guide for users to use N58.
This document is intended for system engineers (SEs), development engineers, and test engineers.
THIS GUIDE PROVIDES INSTRUCTIONS FOR CUSTOMERS TO DESIGN THEIR APPLICATIONS.
PLEASE FOLLOW THE RULES AND PARAMETERS IN THIS GUIDE TO DESIGN AND COMMISSION.
NEOWAY WILL NOT TAKE ANY RESPONSIBILITY OF BODILY HURT OR ASSET LOSS CAUSED BY
IMPROPER OPERATIONS.
THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE DUE TO
PRODUCT VERSION UPDATE OR OTHER REASONS.
EVERY EFFORT HAS BEEN MADE IN PREPARATION OF THIS DOCUMENT TO ENSURE ACCURACY
OF THE CONTENTS, BUT ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS
DOCUMENT DO NOT CONSTITUTE A WARRANTY OF ANY KIND, EXPRESS OR IMPLIED.
Neoway provides customers complete technical support. If you have any question, please contact your
account manager or email to the following email addresses:
[e-mail]
[e-mail]
Website: http://www.neoway.com

N58 Hardware User Guide
Contents
Copyright © Neoway Technology Co., Ltd. All rights reserved.
iii
Contents
About This Document................................................................................viii
Scope............................................................................................................................................... viii
Audience .......................................................................................................................................... viii
Change History................................................................................................................................. viii
Conventions ........................................................................................................................................x
Related Documents............................................................................................................................xi
1 Safety Recommendations ......................................................................12
2 About N58 ..............................................................................................13
2.1 Product Overview....................................................................................................................... 13
2.2 Block Diagram............................................................................................................................ 14
2.3 Basic Features ........................................................................................................................... 15
3 Reference Standards .............................................................................17
4 Module Pins ...........................................................................................18
4.1 Pin Layout .................................................................................................................................. 18
4.2 Pin Description........................................................................................................................... 19
5 Application Interfaces.............................................................................28
5.1 Power Interface.......................................................................................................................... 28
5.1.1 VBAT.................................................................................................................................. 28
5.1.2 VDD_1P8........................................................................................................................... 33
5.2 Control Interface......................................................................................................................... 33
5.2.1 PWRKEY_N ...................................................................................................................... 33
5.2.2 RESET_N.......................................................................................................................... 37
5.2.3 SLEEP............................................................................................................................... 38
5.3 Peripheral Interface.................................................................................................................... 41
5.3.1 USB ................................................................................................................................... 41
5.3.2 UART................................................................................................................................. 43
5.3.3 USIM.................................................................................................................................. 46
5.3.4 SDIO.................................................................................................................................. 49
5.3.5 SPI..................................................................................................................................... 50
5.3.6 I2C..................................................................................................................................... 51
5.4 Audio Interfaces ......................................................................................................................... 52
5.4.1 Analog Audio Input Interfaces............................................................................................ 52
5.4.2 Analog Audio Output Interfaces......................................................................................... 53
5.5 Video Interfaces ......................................................................................................................... 55
5.5.1 LCD ................................................................................................................................... 55
5.5.2 Camera.............................................................................................................................. 56
5.6 Other Interfaces ......................................................................................................................... 56
5.6.1 ADC ................................................................................................................................... 56
5.6.2 NET_LIGHT....................................................................................................................... 56

N58 Hardware User Guide
Contents
Copyright © Neoway Technology Co., Ltd. All rights reserved.
iv
5.6.3 RING.................................................................................................................................. 57
5.6.4 USB_BOOT....................................................................................................................... 58
5.6.5 VBACKUP and VRTC........................................................................................................ 59
5.6.6 GPIO.................................................................................................................................. 60
5.6.7 GNSS_LNA_EN ................................................................................................................ 60
5.6.8 Keypad .............................................................................................................................. 61
5.6.9 1PPS ................................................................................................................................. 62
5.6.10 VCC_GNSS_BIAS .......................................................................................................... 62
5.7 RF Interfaces.............................................................................................................................. 63
5.7.1 ANT_MAIN Antenna Interface........................................................................................... 63
5.7.2 ANT_GNSS Interface ........................................................................................................ 65
5.7.3 ANT_BT Interface.............................................................................................................. 68
5.7.4 Antenna Assembly............................................................................................................. 68
6 Electrical Characteristics and Reliability.................................................71
6.1 Electrical Characteristics............................................................................................................ 71
6.2 Temperature Characteristics...................................................................................................... 72
6.3 ESD Protection Characteristics.................................................................................................. 72
7 RF Characteristics..................................................................................73
7.1 Operating Bands ........................................................................................................................ 73
7.2 TX Power and RX Sensitivity..................................................................................................... 74
7.3 GNSS Parameters ..................................................................................................................... 75
7.4 WLAN/BT Characteristics .......................................................................................................... 76
8 Mechanical Characteristics.....................................................................77
8.1 Dimensions................................................................................................................................. 77
8.2 Label........................................................................................................................................... 78
8.3 Packaging................................................................................................................................... 78
8.3.1 Reel and Tape ................................................................................................................... 79
8.3.2 Moisture............................................................................................................................. 80
9 Assembly................................................................................................81
9.1 Module PCB Package................................................................................................................ 81
9.2 Application PCB Package .......................................................................................................... 82
9.3 Stencil......................................................................................................................................... 82
9.4 Solder Paste............................................................................................................................... 83
9.5 SMT Furnace Temperature Curve.............................................................................................. 83
Abbreviations .........................................................................................85

N58 Hardware User Guide
Figures
Copyright © Neoway Technology Co., Ltd. All rights reserved.
v
Figures
Figure 2-1 Block diagram................................................................................................................. 14
Figure 4-1 Pin layout of the N58 module (top view)......................................................................... 18
Figure 5-1 Voltage drop of the power supply................................................................................... 29
Figure 5-2 Recommended design 1................................................................................................. 29
Figure 5-3 Recommended design 2................................................................................................. 30
Figure 5-4 Recommended design 3................................................................................................. 31
Figure 5-5 Recommended design 4................................................................................................. 31
Figure 5-6 Reference design of module startup controlled by button.............................................. 34
Figure 5-7 Reference design of module startup controlled by MCU................................................ 34
Figure 5-8 Reference design of automatic startup once powered on.............................................. 35
Figure 5-9 Startup process............................................................................................................... 36
Figure 5-10 Hard shutdown process................................................................................................ 36
Figure 5-11 Module reset controlled by button................................................................................. 37
Figure 5-12 Reference reset circuit in which a triode is used for isolation ...................................... 37
Figure 5-13 Reset process of the N58 module................................................................................ 38
Figure 5-14 Process of entering the sleep mode............................................................................. 39
Figure 5-15 Process of call service processing in sleep mode........................................................ 39
Figure 5-16 Process of exiting from the sleep mode ....................................................................... 40
Figure 5-17 Reference design of the module sleep and wake-up control circuit............................. 41
Figure 5-18 Reference design of the USB connection circuit.......................................................... 42
Figure 5-19 Reference design of UART connections ...................................................................... 44
Figure 5-20 Recommended level shifting circuit 1........................................................................... 44
Figure 5-21 Recommended level shifting circuit 2........................................................................... 45
Figure 5-22 Recommended level shifting circuit 3........................................................................... 46
Figure 5-23 Reference design of USIM card (with the hot plug function) interfaces....................... 47
Figure 5-24 Reference design of USIM card (without the hot plug function) interfaces .................. 48
Figure 5-25 SDIO reference design................................................................................................. 49

N58 Hardware User Guide
Figures
Copyright © Neoway Technology Co., Ltd. All rights reserved.
vi
Figure 5-26 SPI reference design.................................................................................................... 51
Figure 5-27 I2C reference design .................................................................................................... 51
Figure 5-28 Reference design of differential MIC input ................................................................... 52
Figure 5-29 Reference design of the built-in power amplifier .......................................................... 53
Figure 5-30 Reference design of the external power amplifier........................................................ 54
Figure 5-31 Reference design of driving an LED indicator by controlling a triode........................... 57
Figure 5-32 RING prompt for an incoming voice call....................................................................... 58
Figure 5-33 RING prompt for an SMS message.............................................................................. 58
Figure 5-34 Reference design of forcible download ........................................................................ 59
Figure 5-35 Reference design of VBACKUP and VRTC power supply........................................... 60
Figure 5-36 Keypad reference design.............................................................................................. 61
Figure 5-37 1PPS output waveform................................................................................................. 62
Figure 5-38 Reference design of GNSS active antenna power supply and detection circuit.......... 63
Figure 5-39 L-type matching network .............................................................................................. 64
Figure 5-40 T-type matching network............................................................................................... 64
Figure 5-41 π-type matching network.............................................................................................. 64
Figure 5-42 Recommended RF PCB design ................................................................................... 65
Figure 5-43 GNSS structure inside the module............................................................................... 66
Figure 5-44 Reference design of an active GNSS antenna............................................................. 67
Figure 5-45 Reference design of a passive GNSS antenna............................................................ 68
Figure 5-46 Package specifications of Murata's GSC RF connector............................................... 69
Figure 5-47 Module RF connection method..................................................................................... 69
Figure 5-48 Antenna layout example ............................................................................................... 70
Figure 5-49 Layout around the antenna........................................................................................... 70
Figure 8-1 N58 top and side dimensions (unit: mm)........................................................................ 77
Figure 8-2 N58 label examples........................................................................................................ 78
Figure 9-1 Bottom view of the N58 module PCB package (unit: mm)............................................. 81
Figure 9-2 Top view of the recommended N58 application PCB package (unit: mm) ..................... 82
Figure 9-3 SMT furnace temperature curve..................................................................................... 83

N58 Hardware User Guide
Tables
Copyright © Neoway Technology Co., Ltd. All rights reserved.
vii
Tables
Table 2-1 Variants and frequency bands supported......................................................................... 13
Table 4-1 IO type description and DC characteristics...................................................................... 19
Table 4-2 Pin description.................................................................................................................. 19
Table 5-1 Description of LCD function pins...................................................................................... 55
Table 5-2 Description of camera function pins................................................................................. 56
Table 6-1 Electrical characteristics of the N58 module.................................................................... 71
Table 6-2 Current consumption of the N58 module (typical)............................................................ 71
Table 6-3 ESD protection characteristics......................................................................................... 72
Table 7-1 Operating bands of the N58 module................................................................................ 73
Table 7-2 RF TX power of the N58 module...................................................................................... 74
Table 7-3 RF RX sensitivity of the N58 module ............................................................................... 74
Table 7-4 GNSS parameters............................................................................................................ 75
Table 7-5 WLAN/BT TX power and RX sensitivity ........................................................................... 76

N58 Hardware User Guide
About This Document
Copyright © Neoway Technology Co., Ltd. All rights reserved.
viii
About This Document
Scope
This document is applicable to the N58 series. It describes N58 information and functional interface
characteristics, and provides a reference design for each functional interface.
The reference design in this document is for reference only, and user applications must be designed
according to actual scenarios and conditions. If you have any questions, pleasecontact Neoway FAEs.
Audience
This document is intended for system engineers (SEs), development engineers, and test engineers.
Change History
Issue
Date
Change
Author
1.0
2019-11
Initial release.
Zhang Gang
2.0
2020-05
Changed the definitions of pins 13, 78, 80, and 83.
Updated the GNSS characteristics and added the
support for BDS.
Updated the frequency bands of EA and LA variants.
Added the 1PPS pin description of the N58 module
with the GNSS function.
Updated the MIC-related design description.
Zhang Gang
2.1
2020-07
Updated the figure of N58 dimensions and adjusted the
direction of the PCB package figure.
Liu Pengbin
2.2
2020-08
Updated the ADC voltage detection range.
Updated the DC characteristics description P3 and
the 1.8V digital IO voltage type.
Added the description of VBAT Vmin and Vnorm.
Updated the DC characteristics description of
RESET_N and PWRKEY_N pins.
Updated the function of the UART1 interface. This
interface is disabled after the BT function is enabled.
Updated the DC characteristics description of
Walter Wu

N58 Hardware User Guide
About This Document
Copyright © Neoway Technology Co., Ltd. All rights reserved.
ix
USIM1_DET and USIM2_DET pins.
Updated the SDIO reference design.
Updated the resistance value of the pull-up resistor of
the 12C bus.
Deleted the UART level shifting circuit.
Updated the power supply range of VRTC_GPS.
Updated the anode power supply range of LED_K.
Changed the PWRKEY_N startup time to be greater
than 1.8s and less than 3s.
Updated the description and function definitions of
PSM_WAKEUP.
Updated the voltage domain of the LCD and SDIO
interfaces.
2.3
2020-11
Updated the RING pin description and figures.
Updated the UART1 interface description.
Updated the PSM_WAKEUP description and deleted
the DTR description.
Walter Wu
2.4
2021-06
Updated the USB pin name in Figure 4-1 (that is, "HS"
is removed).
Updated the recommended circuit of a USIM card to
explain the handling method of the USIM_DET pin
when a user uses hot plug or does not use hot plug.
Deleted the description of "adaptive" because an SD
card does not support adaptive 1.8 V and 3.0 V
(configured based on the software version).
Updated the dimensions figure and added the "PIN1"
identifier.
Changed the maximum drive current of the RGB LED
to 50 mA.
Wu Yongqiang
2.5
2021-09
Updated the variants, frequency bands, and regions
of N58 modules in Table 2-1.
Updated the block diagram in Figure 2-1.
Updated the description of the application interfaces
in the table of basic features.
Updated the power consumption data in sleep mode,
idle mode, and operating mode.
Added chapter 3 "Reference Standards" to describe
the reference standards of the N58 module design.
Added the VCC_GNSS_BIAS pin description of the
N58 module with the GNSS function.
Updated the N58 module startup, shutdown, and
reset flowcharts.
Added the reference design of the module sleep and
wake-up control circuit.
Wu Yongqiang

N58 Hardware User Guide
About This Document
Copyright © Neoway Technology Co., Ltd. All rights reserved.
x
Added the software (standard/open) version UART
instructions.
Updated the reference design of the UART level
shifting circuit.
Updated the reference design of the USIM interface
circuit.
Added the reference design of the I2C interface
circuit.
Added the 1PPS output waveform diagram.
Updated the description of GNSS technical
parameters.
Added the reference design of the passive GNSS
antenna circuit.
Updated the label diagram.
Updated the table of abbreviations.
Optimized the document to improve its quality.
Conventions
Symbol
Description
Indicates danger or warning. This information must be followed. Otherwise, a
catastrophic module or user device failure or bodily injury may occur.
Indicates caution. This symbol alerts the user to important points about using the
module. If these points are not followed, the module or user device may fail.
Indicates instructions or tips. This symbol provides advices or suggestions that
may be useful when using the module.

N58 Hardware User Guide
About This Document
Copyright © Neoway Technology Co., Ltd. All rights reserved.
xi
Related Documents
Neoway_N58_Datasheet
Neoway_N58_Product_Specifications
Neoway_N58_AT_Command_Mannual
Neoway_N58_EVK_User_Guide

N58 Hardware User Guide
Chapter 1 Safety Recommendations
Copyright © Neoway Technology Co., Ltd. All rights reserved.
12
1 Safety Recommendations
Ensure that this product is used in compliance with the requirements of the country and environment.
Read the following safety recommendations to avoid bodily injuries or damages of the product or
workplace:
Do not use this product at any places with a risk of fire or explosion.
If this product is used in a place with flammable gas or dust, such as propane gas, gasoline, and
flammable spray, it will cause an explosion or a fire.
Disable the wireless communication function in places where wireless communication is
prohibited.
Do not use this product that can interfere with other electronic devices in environments, such as
hospitals and airplanes.
Follow the requirements below during the application design and use of this product:
Do not disassemble this product without permission from Neoway. Otherwise, we are entitled to
refuse to provide further warranty.
Design your application correctly based on the hardware user guide. Connect this product to a
stable power supply and route traces following fire safety standards.
Avoid touching the pins of this product to prevent damages caused by ESD.
Do not insert or remove a USIM card or mobile memory card if it is not powered off.

N58 Hardware User Guide
Chapter 2 About N58
Copyright © Neoway Technology Co., Ltd. All rights reserved.
13
2 About N58
N58 is an industrial LTE module that is developed based on the UNISOC UIS8910DM platform. Its
dimensions are (30.00±0.15) mm ×(28.00±0.15) mm ×(2.60±0.20) mm. This module supports GSM,
FDD-LTE (Cat 1), and TDD-LTE (Cat 1) network modes. It provides a variety of hardware interfaces,
supports audio and video functions, Wi-Fi positioning, and BT/BLE wireless connectivity, and supports
GNSS (optional). This module is applicable to IoT communications devices, including wireless meter
reading terminals, in-vehicle terminals, handheld POS terminals, and industrial routers.
N58 has the following characteristics:
ARM Cortex-A5 processor, 500 MHz main frequency, 32 KB L1 cache
Supported network modes: GSM/GPRS&LTE Cat 1
Support for USB2.0, USIM,ADC, UART, SDIO, SPI, I2C, and GNSS (optional)
2.1 Product Overview
N58 series include multiple variants. The following table lists the variants and frequency bands
supported.
Table 2-1 Variants and frequency bands supported
Variant
Region
Category
Frequency Band
GNSS1)
Codec
CA
Chinese
mainland
Cat 1
FDD-LTE: B1, B3, B5, B8
TDD-LTE: B34, B39, B40, B41
GSM/GPRS: 900/1800 MHz
Supported
Supported
EA
Europe,
Middle
East,
Africa
Cat 1
FDD-LTE: B1, B3, B5, B7, B8, B20,
B28
TDD-LTE: B38, B40, B41
GSM/GPRS: 900/1800 MHz
Supported
Supported
LA
Latin
America
Cat 1
FDD-LTE: B1, B2, B3, B4, B5, B7, B8,
B28, B66
TDD-LTE: B38, B40, B41
GSM/GPRS: 850/900/1800/1900 MHz
Supported
Supported
CA-F1
India
Cat 1
FDD-LTE: B1, B3, B5, B8
TDD-LTE: B40, B41
GSM/GPRS: 900/1800 MHz
Supported
Supported

N58 Hardware User Guide
Chapter 2 About N58
Copyright © Neoway Technology Co., Ltd. All rights reserved.
14
GNSS1) indicates that the configuration is optional.
2.2 Block Diagram
N58 consists of the following functional units:
Baseband chip unit
26 MHz crystal
Power manager
RF functional unit
Digital interfaces (including USIM, I2C, SPI, KEYPAD, UART, USB, and SDIO)
Analog interfaces (ADC, MIC, and SPK)
Figure 2-1 Block diagram
VBAT
Power
manager
26 MHz
crystal
RF front-end
I2C
Digital interface
USBUART
USIM
PC
ANT_MAIN ANT_BT ANT_GNSS
PWRKEY_N
RESET
KEYP
ADUSIM SPI SDIO
MIC, SPK
GNSS
ADC RF transceiver
Baseband
NOR flash (64 Mb) +
PSRAM (128 Mb)

N58 Hardware User Guide
Chapter 2 About N58
Copyright © Neoway Technology Co., Ltd. All rights reserved.
15
2.3 Basic Features
Parameter
Description
Physical features
Dimensions: (30.00±0.15) mm ×(28.00±0.15) mm ×(2.60±0.20) mm
Package: LGA+LCC
Weight: 4.63 g
Temperature
range
Operating temperature range: -30°C to +75°C
Extended temperature range: -40°C to +85°C
Storage temperature range: -40°C to +90°C
Operating voltage
VBAT: 3.4 V to 4.2 V, typical value: 3.8 V
Operating current
Sleep mode2): < 3 mA
Idle mode3): < 16 mA
Operating mode4) (LTE mode): < 600 mA
Application
processor
ARM Cortex-A5 processor, 500 MHz main frequency, 32 KB L1 cache
Memory
RAM: 128 Mb
ROM: 64 Mb
Frequency band
See Table 2-1.
Wireless rate
GPRS: Max 85.6 kbps (DL)/Max 85.6 kbps (UL)
FDD-LTE: Cat 1, Max 10 Mbps (DL)/Max 5 Mbps (UL)
TDD-LTE: Cat 1, Max 8 Mbps (DL)/Max 2 Mbps (UL)
Power class
GSM850: +33 dBm (Power Class 4)
EGSM900: +33 dBm (Power Class 4)
DCS1800: +30 dBm (Power Class 1)
PCS1900: +30 dBm (Power Class 1)
LTE: +23 dBm (Power Class 3)
Application
interface
2G/4G antenna, GNSS antenna, BT antenna. The characteristic impedance of
each antenna is 50 Ω.
Three UART interfaces, with the maximum baud rate of 921600 bps.
Two USIM interfaces, adaptive 1.8 V/3 V.
One USB2.0 interface, supporting only the slave mode.
Three SPI interfaces. One standard SPI interface, supporting only the master
mode; one dedicated SPI interface, supporting only the LCD function; one
dedicated SPI interface, supporting only the camera function.
Matrix keyboard interfaces with 3 rows and 4 columns.
One 12-bit ADC interface, voltage detection range: 0.1 V to VBAT.
One SDIO interface, used for an SD card.
One 1PPS interface.

N58 Hardware User Guide
Chapter 2 About N58
Copyright © Neoway Technology Co., Ltd. All rights reserved.
16
One MIC interface, built-in bias voltage ranging from 2.2 V to 3 V.
One SPK interface, module built-in class AB/class D power amplifier, maximum
output power of 800 m[email protected] V/8 Ω.
One I2C interface, supporting only the master mode.
AT command
3GPP Release 13
Neoway extended commands
SMS
PDU, TXT
Data
PPP, RNDIS, ECM
Protocol
TCP, UDP, MQTT, FTP, HTTP/HTTPS, SSL, TLS
Certification
approval
CCC, SRRC, RoHS, CE, CTA
Sleep mode2): indicates that the module enters the low power consumption state. In this state, the peripheral
interface of the module is disabled, but the radio frequency function is normal. The module will exit the sleep
mode when there is an incoming call or an SMS message, and will re-enter the sleep mode when the incoming
call and voice end.
Idle mode3): indicates the status of the module when the module is functioning properly and there is no data
service.
Operating mode4) current indicates the operating current of the module when there is data communication. In
operating mode4), only an example of the current in LTE mode is provided. For details about the current in non-
LTE modes, see the N58 current test report.

N58 Hardware User Guide
Chapter 3 Reference Standards
Copyright © Neoway Technology Co., Ltd. All rights reserved.
17
3 Reference Standards
The N58 module design references the following standards:
3GPP TS 36.521-1 V13.0.0 User Equipment (UE) conformance specification; Radio transmission
and reception; Part 1: Conformance Testing
3GPP TS 21.111 V13.0.0 USIM and IC card requirements
3GPP TS 51.011 V4.15.0 Specification of the Subscriber Identity Module -Mobile Equipment
(SIM-ME) interface
3GPP TS 31.102 V13.0.0 Characteristics of the Universal Subscriber Identity Module (USIM)
application
3GPP TS 31.111 V13.0.0 Universal Subscriber Identity Module (USIM)Application Toolkit
(USAT)
3GPP TS 27.007 V13.0.0 AT command set for User Equipment (UE)
3GPP TS 27.005 V13.0.0 Use of Data Terminal Equipment–Data Circuit terminating Equipment
(DTE-DCE) interface for Short Message Service (SMS) and Cell Broadcast Service (CBS)

N58 Hardware User Guide
Chapter 4 Module Pins
Copyright © Neoway Technology Co., Ltd. All rights reserved.
18
4 Module Pins
The N58 module has 192 pins and uses the LGA (100 pins)+LCC (92 pins) package. It supports the
functional interfaces, including the power, USB, USIM, UART,ADC, I2C, and SDIO interfaces.
4.1 Pin Layout
Figure 4-1 shows the pin layout of the N58 module.
Figure 4-1 Pin layout of the N58 module (top view)
GND
USB_ID
LCC PIN
LGA PIN
GND
GPIO_3
SLEEP
GPIO_2
I2C_SDA
1PPS
UART2_RXD
UART2_TXD
ANT_MAIN
GND 101
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
73
27
72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
102 103 104 105 106 107 108 109 110 111 112 113 114
156
155
154
153
152
151
150
149
148
147
146
145
144
143
142 141 140 139 138 137 136 135 134 133 132 131 130 129
115
116
117
118
119
120
121
122
123
124
125
126
127
128
SDC_PWR_EN
SDC_DATA2
RING
GND
USIM2_RESET
LCD_SPI_SEL
CAM_SPI_DATA1
GND
GND
GND
GND
I2C_SCL
SPI_MOSI
GPS_LNA_EN
GND
SDC_DET
USB_BOOT
VDD_1P8
USB_VBUS
VBAT
RESERVED
GND
GND
GND
GND
NET_LIGHT
SPI_CLK
SPI_MISO
SPI_CS_N
ADC
ANT_GNSS
GND
ANT_BT
USB_DP
USB_DM
USIM1_DET
USIM1_RESET
USIM1_CLK
USIM1_DATA
USIM1_VCC
RESERVED
PWRKEY_N
RESET_N
GND
GND
VBAT
VBAT
SDC_DATA3
SDC_CMD
SDC_CLK
SDC_DATA0
SDC_DATA1
RESERVED RESERVED
UART3_RXD
UART3_TXD
GND
SPK_P
SPK_N
MIC_P
MIC_N
GND
USIM2_VCC
USIM2_DATA
USIM2_CLK
USIM2_DET
UART1_RTS UART1_CTS
UART1_RXD
UART1_TXD
LCD_SPI_SIO
LCD_SPI_SDC
LCD_SPI_CLK
LCD_SPI_CS
LCD_TE
LCD_RST_N
AVDD_CAM
CAM_MCLK
CAM_PWDN
CAM_I2C_SCL
CAM_I2C_SDA
CAM_SPI_CLK
CAM_SPI_DATA0
CAM_RST_N
VDD_CAM
UART2_RTS UART2_CTS
GPIO_0
VDD_SDCPULL
GND
VBACKUP
RESERVED
GND
RESERVED
RESERVED
RESERVED
GND
RESERVED
RESERVED
LED_K0
VDD_LCD
LED_K1
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
KEYOUT3
KEYOUT2
KEYOUT1
KEYOUT0
GND
LED_K2
GND
KEYIN3
KEYIN2
KEYIN1
RESERVED
GND
Power
ADC
ControlUSB ReserveUARTLCD
GND
SDIO
Audio
GPIO
Camera
Antenna Keypad SPI I2C Other
USIM
1
172 171 170 169 168 167
173 186 185 184 183 166
174 187 192 191 182 165
175 188 189 190 181 164
176 177 178 179 180 163
157 158 159 160 161 162
GND
GND
GND
GND GND
GND
GND
GND
VRTC
GND
RESERVED
RESERVED
GND
RESERVED
GND
GND
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
VCC_GNSS_BIAS
GND
GND
GND
97 98
26
99
49
100
74

N58 Hardware User Guide
Chapter 4 Module Pins
Copyright © Neoway Technology Co., Ltd. All rights reserved.
19
4.2 Pin Description
The following table provides the IO type description and DC characteristics.
Table 4-1 IO type description andDC characteristics
IO Type Description
B
Digital input/output, COMS logic level.
DO
Digital output, COMS logic level.
DI
Digital input, COMS logic level.
PO
Power output.
PI
Power input.
AO
Analog output.
AI
Analog input.
AIO
Analog input/output.
DC characteristics description
Pin type
Pin type description
DC characteristics
P1
Dual voltage USIM interface
voltage type, 1.8 V or 3 V
1.8 V DC characteristics:
VIH = 1.26 V to 1.98 V
VIL = 0 V to 0.54 V
VOH = 1.44 V to 1.98 V
VOL = 0 V to 0.36 V
3 V DC characteristics:
VIH = 2.1 V to 3.3 V
VIL = 0 V to 0.9 V
VOH = 2.4 V to 3.3 V
VOL = 0 V to 0.6 V
P3
1.8 V digital I/O voltage type
VIH min = 1.26 V
VIL max = 0.54 V
VOH min = 1.44 V
VOL max = 0.36 V
Table 4-2 Pin description
Pin Name
Pin No.
I/O Type
Function
DC Characteristics
Remarks
Power interface
VBAT
27, 28,
29
PI
Main power
supply input
of the
module
Vmin = 3.4 V
Vnorm = 3.8 V
Vmax = 4.2 V
The external power
supplies at least 2.5 A
current to VBAT.
VDD_1P8
45
PO
1.8 V power
output
Vnorm = 1.8 V
Imax = 50 mA
Used only for level
shifting. Leave this pin
floating if it is not used.

N58 Hardware User Guide
Chapter 4 Module Pins
Copyright © Neoway Technology Co., Ltd. All rights reserved.
20
GND
1, 14, 17, 20, 26, 30, 31, 44, 49, 74, 75, 77, 91, 93, 95, 97-
102, 104, 106, 112, 114, 115, 121-123, 128, 129, 137, 142,
143, 146, 147, 155-192
All GND pins must be
grounded.
Control interface
RESET_N
32
DI
Modulereset
input
-
Triggered by a low
level to control the
module reset. This pin
is connected to VBAT
by using a 20 kΩ pull-
up resistor in the main
chip of the module.
PWRKEY_N
33
DI
Module
power-
on/power-off
control
-
Triggered by a low
level to control the
module power-
on/power-off. This pin
is connected to VBAT
by using a 20 kΩ pull-
up resistor in the main
chip of the module.
SLEEP
79
DI
Sleep mode
control
P3
See section 5.2.3
"SLEEP."
UART1 interface
UART1_TXD
69
DO
Data
sending
P3
Software (standard)
version: These pins
are used for data
transmission.
Software (open)
version: These pins
are used for data
transmission.
Note: UART1_CTS
(pin 71) can be used to
capture the CP-side
logs of the module.
UART1_RXD
70
DI
Data
receiving
P3
UART1_CTS
71
DI
User
allowing the
module to
send data
P3
UART1_RTS
72
DO
Module
requesting
the user to
send data
P3
UART2 interface
UART2_TXD
46
DO
Data
sending
P3
Software (standard)
version: These pins
are used for AT
command
communications.
UART2_RXD
47
DI
Data
receiving
P3
UART2_CTS
51
DI
User
P3
