Omnik Omniksol-2k-TL3-S User manual

User Manual V1.5
User Manual
-Installation
-Operation
Omniksol-2k-TL3-S
Omniksol-2.5k-TL3-S
Omniksol-3k-TL3-S
Omnik New Energy Co.,ltd

1
Catalog
1. Notes on this manual....................................................................................................................3
1.1 Scope of Validation................................................................................................................................3
1.2 Symbols Used.........................................................................................................................................3
1.3 Target Group............................................................................................................................................4
2. Preparation....................................................................................................................................5
2.1 Safety Instructions.................................................................................................................................5
2.2 Explanations of Symbols on Inverter................................................................................................6
3. Product Information......................................................................................................................8
3.1 Overview...................................................................................................................................................8
3.2 Major Characteristics............................................................................................................................9
3.3 Datasheet................................................................................................................................................10
4. Packing checklist........................................................................................................................12
4.1 Assembly parts.....................................................................................................................................12
4.2 Product Appearance............................................................................................................................13
4.3 Product Identification..........................................................................................................................14
4.4 Further Information..............................................................................................................................14
5. Installation...................................................................................................................................15
5.1 Safety.......................................................................................................................................................15
5.2 Mounting Instructions.........................................................................................................................16
5.3 Safety Clearance...................................................................................................................................17
5.4 Mounting Procedure............................................................................................................................17
5.5 Safety lock..............................................................................................................................................19
6. Electrical Connection.................................................................................................................20
6.1 Safety.......................................................................................................................................................20
6.2 AC Side Connection ............................................................................................................................20
6.3 DC Side Connection ............................................................................................................................23
7. Display.........................................................................................................................................28
7.1 LCD Panel...............................................................................................................................................28
7.2 LCD Display ...........................................................................................................................................29
7.3 Instructions of Safety Standard selection when power-up.......................................................30

2
7.4 State Information..................................................................................................................................31
8. Recycling and Disposal..............................................................................................................32
9. Troubleshooting .........................................................................................................................33
10. Abbreviation................................................................................................................................34
11. Contact........................................................................................................................................35

3
1.Notes on this manual
1.1 Scope of Validation
The main purpose of this User’s Manual is to provide instructions and detailed
procedures for installing, operating, maintaining, and troubleshooting the following three
types of Omnik New Energy-Solar Inverters:
Omniksol-2k-TL3-S
Omniksol-2.5k-TL3-S
Omniksol-3K-TL3-S
Please keep this user manual all time available in case of emergency.
1.2 Symbols Used
CAUTION
CAUTION indicates a hazardous condition which, if not avoided,
can result in minor or moderate injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, can result in death or serious injury or moderate injury.
DANGER
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.

4
1.3 Target Group
•Chapter 1, 2, 3, 4, 7, 8, 9, 10 and Chapter 11 are intended for anyone who is intended
to use Omnik Grid Tie Solar Inverter. Before any further action, the operators must first
read all safety regulations and be aware of the potential danger to operate high-voltage
devices. Operators must also have a complete understanding of this device’s features
and functions.
•Chapter 5 and Chapter 6 are only for qualified personnel who are intended to install
Or uninstall the Omnik Grid Tie Solar Inverter.
NOTICE
Hereby qualified personnel means he/she has the valid license
from the local authority in:
•
Installing electrical equipment and PV power systems
(up to 1000 V).
•Applying all applicable installation codes.
•
Analyzing and reducing the hazards involved in
performing electrical work.
•Selecting and
using Personal Protective Equipment
(PPE).
WARNING
Do not use this product unless it has been successfully installed
by
qualified personnel in accordance with the instructions in
Chapter 5, “Installation”.
NOTICE
NOTICE indicates a situation that can result in property
damage, if not avoided.

5
2.Preparation
2.1 Safety Instructions
NOTICE
Public utility only
The PV inverter designed to feed AC power directly into the
public utility power grid，do not connect AC output of the
device to any private AC equipment.
WARNING
The installation，service ，
recycling and disposal of the
inverters must be performed by qualified personnel only in
compliance with national and local st
andards and
regulations. Please contact your dealer
to get the
information of authorized repair facility for any maintenance
or repairmen.
Any unauthorized actions including modification of product
functionality of any form will affect the validation of warranty
service; Omnik may deny the obligation of warranty service
accordingly.
DANGER
DANGER due to electrical shock and high voltage DO
NOT touch the operating component of the inverter, it might
result in burning or death. TO prevent risk of electric shock
during installation and maintenance, please make sure that
all AC and DC terminals are plugged out. DO NOT stay close
to the instruments while there is severe weather conditions
including storm, lighting etc.

6
2.2 Explanations of Symbols on Inverter
Symbol
Description
Dangerous electrical voltage
This device is directly connected to public grid, thus all
work to the inverter shall only be carried out by
qualified personnel.
DANGER to life due to high electrical voltage!
There might be residual currents in inverter because
of large capacitors. Wait 10 MINUTES
before you
remove the front lid.
NOTICE, danger!
This device directly connected with electricity
generators and public grid.
Danger of hot surface
The components inside the inverter will release a log
of heat during operation, DO NOT touch aluminum
housing during operating.
An error has occurred
Please go to Chapter 9 “Trouble Shooting” to remedy the
error.
This device SHALL NOT be disposed of in
residential waste
Please go to Chapter 8 “Recycling and Disposal” for
proper treatments.
CAUTION
The PV inverter will become hot during operation; please
don’t touch the heat sink or peripheral surface during or
shortly after operation。Risk of damage due to improper
modifications. Never modify or manipulate the inverter or
other components of the system.

7
Without Transformer
This inverter does not use transformer for the isolation
function.
German mark of conformity
The inverter complies with the requirement of the
German Grid Regulations.
Certified Safety
The inverter complies with the requirements of the
Equipment and Product Safety Act in Europe.
Standards Association of Australian
The inverter complies with the requirement of the
AS4777.
CE Mark
Equipment with the CE mark fulfils the basic
requirements of the Guideline Governing Low-Voltage
and Electromagnetic Compatibility.
No unauthorized perforations or modifications
Any unauthorized perforations or modifications are
strictly forbidden, if any defect or damage
(device/person) is occurred, Omnik shall not take any
responsibility for it.

8
3.Product Information
3.1 Overview
•Industrial Layout
、
•Excellent Heat Elimination

9
3.2 Major Characteristics
Omnik inverter has following characteristics which make Omnik inverter “High Efficiency,
High Reliability, High Cost Effective Ratio”
•Wide DC input voltage and current ranges, enables more PV panels connected.
•Wide MPP voltage range ensure high yield under various weather conditions.
•High MPP tracking accuracy, ensure the minimum power loses during converting.
•Complete set of protection methods.
Also, following protection methods are integrated in Omnik inverter:
•Internal overvoltage
•DC insulation monitoring
•Ground fault protection
•Grid monitoring
•Ground fault current monitoring
•DC current monitoring
•Integrated DC switch (Optional)

10
3.3 Datasheet
Omniksol-2k-TL3-S/ Omniksol-2.5k-TL3-S/Omniksol-3k-TL3-S
Type
Omniksol-2k-TL3-S
Omniksol-2.5k-TL3-S
Omniksol-3k-TL3-S
Input (DC)
Max. PV Power 2100W 2650W 3200W
Max DC Voltage 500V 500V 500V
Operating MPPT Voltage Range 120-450V 120-450V 120-450V
MPPT Voltage Range at Nominal Power 210-450V 260-450V 320-450V
Start up DC Voltage 150V 150V 150V
Turn off DC Voltage 120V 120V 120V
Max. DC Current 10A 10A 10A
Max. Short Circuit Current for each
MPPT
14A 14A 14A
Number of MPP trackers 1 1 1
Number of DC Connection for each
MPPT
1 1 1
DC Connection Type MC4 Connector MC4 Connector MC4 Connector
Output (AC)
Nominal AC Power(cos phi = 1) 2000W 2500W 3000W
Nominal Grid Voltage 220V/230V/240V 220V/230V/240V 220V/230V/240V
Nominal Grid Frequency 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz
Max. AC Current 10.0A 12．5A 15.0A
Grid Voltage Range* 185-276V 185-276V 185-276V
Grid Frequency Range* 45-55Hz/55-65Hz 45-55Hz/55-65Hz 45-55Hz/55-65Hz
Power Factor 0.9i_1_0.9c 0.9i_1_0.9c 0.9i_1_0.9c
Total Harmonic Distortion (THD) <3% <3% <3%
Feed in Starting Power 30W 30W 30W
Night time Power Consumption <1W <1W <1W
Standby Consumption 6W 6W 6W
AC Connection Type Plug-in connector Plug-in connector Plug-in connector
Efficiency
Max. Efficiency (at 360Vdc) 97.2% 97.2% 97.2%
Euro Efficiency (at 360Vdc) 96.6% 96.6% 96.6%
MPPT Efficiency 99.9% 99.9% 99.9%
Safety and Protection
DC Insulation Monitoring Yes
DC Switch Optional
Residual Current Monitoring Unit
(RCMU)
Integrated
Grid Monitoring with Anti-islanding Yes
Protection Class I (According to IEC 62103)
Overvoltage Category PV II / Mains III (According to IEC 62109-1)
*The AC voltage and frequency range may vary depending on specific country grid

11
Type
Omniksol-2k-TL3-S
Omniksol-2.5k-TL3-S
Omniksol-3k-TL3-S
Reference Standard
Safety Standard EN 62109，AS/NZS3100
EMC Standard EN 61000-6-1, EN 61000-6-3, EN 61000-6-2, EN 61000-6-4, EN61000-3-2, EN61000-3-3
Grid Standard VDE 0126-1-1，RD1663，C10/11，G83/2，UTE C15-712-1，AS4777，CQC,CEI0-
21，EN50438
Physical Structure
Dimensions (WxHxD) 245x346x123mm
Weight 8kg
Environmental Protection Rating IP 65 (According to IEC 60529)
Cooling Concept Natural convection
Mounting Information Wall bracket
General Data
Operating Temperature Range -25°C to +60°C(derating above 45℃)
Relative Humidity 0% to 100%, no condensation
Max. Altitude (above sea level) 2000m
Noise Level < 40dB
Isolation Type Transformerless
Display 2 LED，Backlight，16*2 Character LCD
Data Communication Interfaces RS485 / WIFI / GPRS optional
Guarantee
5 - 25 years optional

12
4.Packing checklist
4.1 Assembly parts
After you receive the Omnik inverter, please check if there is any damage on the carton,
and then check the inside completeness for any visible external damage on the inverter
or any accessories. Contact your dealer if anything is damaged or missing.
A
B
C
D
E
F
G
H
Object
Quantity
Description
A
1
Omnik inverter
B
1 pair
DC connector
C
1
AC connector
D
1
Mounting bracket
E
4
Screw (ST6×50)
F
4
Expansion tube
G
1
Installation and operating instructions
H
1
DC Switch(Optional)

13
4.2 Product Appearance
•Front
Object Description
A LED light(Green) – RUN
B LED light(Red) – FAULT
C Function key for displays and choice of language
•Bottom
Object Description
A Plug connectors for DC input.
B WiFi/GPRS/RS485 interface
C Terminal for grid connection (AC output)
D DC switch (optional)
A
B
C
C
A
B
D

14
4.3 Product Identification
You can identify the inverter by the side nameplate. Information such as type of the
inverter and inverter specifications are specified on the sidename plate. The name plate
is on the middle part of the right side of the inverter housing. And the following figure is
the sidename plate example as on Omniksol-3k-TL3-S.
4.4 Further Information
If you have any further questions concerning the type of accessories or installation,
please check our website www.omnik-solar.com or contact our service hotline.

15
5.Installation
5.1 Safety
NOTICE
NOTICE due to the inappropriate or the harmonized
installation environment may jeopardize the life span of
the inverter.
Do not expose to direct sunlight to avoid power derating due to
increase in the internal temperature of the inverter.
Do not expose to rain and snow cover to enhance inverter life time.
The installation site MUST have good ventilation condition.
DANGER
DANGER to life due to potential fire or electricity shock.
DO NOT install the inverter near any inflammable or
explosive items. This inverter will be directly connected with
HIGH VOLTAGE power generation device; the installation
must be performed by qualified personnel only in
compliance with national and local standards and
regulations.

16
5.2 Mounting Instructions
•
•Omnik inverter is designed for indoors and outdoors installation
•Please mount the inverter in the direction as illustrated above
•Install the inverter in the vertical direction is recommended, with a max.15 degrees
backwards.
•For the convenience of checking the LCD display and possible maintenance
activities, please install the inverter at eye level.
•Make sure the wall you selected is strong enough to handle the screws and bear the
weight of the inverter
•Ensure the device is properly fixed to the wall
•It is not recommended that the inverter is exposed to the strong sunshine, because
the excess heating might lead to power reduction
•The ambient temperature of installation site should be between -25 °C and +60 °C
•Make sure the ventilation of the installation spot, not sufficient ventilation may reduce
the performance of the electronic components inside the inverter and shorten the life
of the inverter
M
Ma ax x 1 15 5
°
°

17
5.3 Safety Clearance
Observe the following minimum clearances to walls, other devices or objects to
guarantee sufficient heat dissipation and enough space for pulling the electronic solar
switch handle.
5.4 Mounting Procedure
1. Mark 4 positions of the drill holes on the wall according to the wall mounting bracket in the
carton box.
Direction Minimum clearance
Above 30 cm
Below 40 cm
Sides 10 cm

18
2. First, according to the marks, drill 4 holes in the wall. Then, place 4 expansion tubes in the
holes using a rubber hammer. Next, make 4 screws through the mounting holes in the
bracket, then tighten the screws into the expansion tubes. So far, the wall mounting bracket
is fixed already.
3. Align both sides of the radiator on the hooks of the back panel, move the inverter until the
hooks completely into the slot of the radiator.
