NetApp FAS2500 Use and care manual

Doc Rev -003
README FIRST

AWebserver is needed to netboot the ONTAP kernel.

is HA. Netboot_using_Partner doc is >> here.

Request customer to download the exact version of Data ONTAP from support site to their Webserver’s
root directory
http://mysupport.netapp.com/NOW/cgi-bin/software/




This AP includes "Cluster-Mode" (C-Mode) and 7-Mode ONTAP commands. 8.3 and higher is C-Mode only.
●
The login name for C-Mode systems is "admin", not "root".
●The ONTAP version and mode is listed in your dispatch!
●
●
●

Link to Statement of Volatility by Platform is:
http://support.netapp.com/info/web/ECMP1132988.html

README FIRST
C-Mode:Has two console command shells, clustershell and nodeshell. The default shell is clustershell.
IF clustershell, the console prompt includes a double colon ( ). Ex(1): cluster > Ex(2):cluster storage>
To switch from clustershell to nodeshell, enter
'run local'
at the ::> prompt, then the double colons (::)
are removed. To exit nodeshell, enter 'exit' or Ctrl-D.
From clustershell, nodeshell commands can be entered by prefacing the 7-Mode command with “run local".
Ex: cluster::>
run local sysconfig -v
Note, all 7-Mode commands are not supported in C-Mode.
Call and inform customer that the process requires a Webserver or another NetApp controller (if 7-mode)
to serve the ONTAP files that can communicate with the service processor e0M port on the TARGET.
(Have them test using ping bi-directionally from the webserver and e0M port address.) Fix it if it fails.
AP doc rev is at top of page - If using hard-copy for secure site, be sure to print all the linked documents in this AP.
If node is running
7-mode
and the system is
HA
, you can use the
PARTNER
to serve the files. Even
another NetApp controller on same subnet can be the Webserver. The dispatch informs you if the system
OR Use your own Webserver on your laptop if you have one.
For "non-disruptive" process to work, the PARTNER node has to be able to communicate to TARGET e0M port. If
not, the "disruptive" method must be used.
A
"disruptive"
procedure will speed the process up a bit but should only be used within a maintenance window as
there is an outage of about 3 minutes. The customer can inform you if they are in a maintenance window and can
sustain an outage on the TARGET node.
For NSE enabled systems, confirm with customer that they have not power cycled the controller chassis or any disk
shelves with NSE drives. If power cycled, do NOT proceed - Contact

NGS.
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
Select “Data ONTAP” in the <Select Software field> field and enter the ONTAP version in the version
field.
If controller is running “P” or “D” versions of ONTAP, Ex: 8.2.3P6, enter the complete ONTAP version
in the version field. i.e. “8.2.3P6” in this example.
::
::
::

This procedure will take approximately 2 hours.
I. Appliance / USB Boot Device Visual Checks VIII. Boot PROM Variable Checks
II. Node Pre-Checks IX. Prepare and Start the Netboot Process
III. Node State Check and Shutdown Procedure X.
Transfer the System Files using Non-Disruptive Procedure
IV. XI. Transfer the System Files using Disruptive Procedure
V. Remove Cable Tray and Cables, extract the MB Tray XII. Boot the Operating System - 'giveback' if applicable
VI. Replace the Boot Device XIII.
Send Autosupport, Enable Options, Submit logs, Part Return
VII. Partially Reinsert the Controller and reconnect the cables
I.
Step
1The FAS2552 is a 2u model and FAS2554 is a 4u model. Review Figures below.
2Continue with Section I on next page.
Action Description
Capture the Current System Configuration
Page 1 of 25
SECTION OUTLINE
FAS2500 Model : Appliance / USB Boot Device Visual Checks
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
2u
FAS2520, 2552
FAS2554
4u
PSU-1
IOIOI
(Console)
Controller Module System Serial Number: Each
Controller Module Card (A or B) has
it's own. Verify the system serial
SAS Ports:
0b, 0a
Wrench port
Management (e0M), SP
10/100/1000 Mb
"Locked" wrench
Port ACP (e0P)
10/100/1000 Mb
1 Gigabit
Ethernet:
e0a, e0b
Fig 1 Fig 3
Controller Fault LED (Amber)
PSU-2
B
A
Fig 2: FAS2520,2552 Rear
A
Controller Fault LED (Amber)
PSU-1
PSU-2
PSU-4
PSU-3
B
Fig 4: FAS2554 Rear
Fig 5
AC Power
System Shelf ID
" ! " LED is ON when hardware failures are
detected or if controller failover is disabled.
10Gb Ethernet:
e0c, e0d, e0e, e0f
FAS2520
FAS2552, 2554 (shown)
HA Configuration has 2 Controllers cards,
(A & B) as shown. A single controller
system has only one card that is in slot A.

I.
Step
II.
Step
1
2Adhere to anti-static precautions. (A paper ESD strap is included inside the RMA box if you don't have your own)
3Do not remove the Boot Device from its bag until you are ready to use it.
4Go to Section III "Node State Check and Shutdown" on next page.
FAS2500 Model : Node Pre-Checks
Action Description
Verify the "Order Reference 8xxxxxxxxx number on the RMA packing slip is the same as the Part Request (PREQ) number
listed in your dispatch notes.
Page 2 of 25
FAS2500 Model : Appliance / USB Boot Device Visual Checks (cont.)
Action Description
Fig 6: USB Boot Device
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
Base P/N is"1425A"

III.
Always capture the node’s console output to a text file,even if using the end-user's computer. To review the Job Aid on how
to connect to the console (IOIOI) port and serial emulator options, click here >
Console Attach Aid
Table-1
“A” controller is OK or powered off.
“B” controller is failed, starting up, initializing, or is in Maintenance mode.
The system is ready for service, go to step 5.
The system is ready for service, go to step 5.
Continue with Section III on next page.
Chassis has dual controllers installed and controller(s) “A”, “B” or both is failed, starting up,
initializing, or is in Maintenance mode. (NOTE: If HA is disabled, both LEDs will be ON)
“A” controller is failed, starting up, initializing, or is in Maintenance mode.
“B” controller is not installed.
Locate the Faulted Controller: Look at controller bezels that have the ( ! ) Status LED ON. LEDs: Pg-1, Fig1, 3. Will need to
examine the rear of unit to determine the chassis configuration and if it appears to be set up as a HA system. A controller with
( ! ) means the controller has some sort of FAULT.
2
Fault LEDs on Rear
What does this mean?
Both A & B controllers are functioning properly OR both powered off.
OR one controller is functioning properly and other one is powered off.
“A” controller is failed, starting up, initializing, or is in Maintenance mode.
“B” controller is OK or is powered off.
4
3
Perform a console check on each controller to determine the TARGET controller.
WARNING
HA (Active-Active) configurations: If the failure has caused the PARTNER head to takeover, you may have
been dispatched on the PARATNER's controller's serial number, not the failed one. Perform console checks.
IF Console Response is: Action:
LOADER-A|B prompt
Waiting for giveback....
Login or Password Prompt or
system-hostname>
IF HA system: Check PARATNER's console response per
WARNING above. IF both systems are UP, engage customer to
verify the s/n in your dispatch is for the controller to be serviced -
then continue.
IF non-HA: This system is still up - go to step 5.
Page 3 of 25
FAS2500 Model : Node State Check and Shutdown Procedure
Action Description
1
Contr: A
A
(LEDs in Fig 2, 4)
Contr: A
B
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

III.
Step
5
6
Note: The approximate hours required for this maintenance is given in the 'Section Outline' section on page-1.
7
8
9Continue with Section III on next page.
Send NetApp an ASUP Message from the Target/Partner node to prevent unnecessary cases from being created by ASUP
messages during this scheduled maintenance window. Use the appropriate command shown for the specified ONTAP Mode.
If 7-Mode, skip to step 17 in this section. If C-Mode, move console cable to the PARTNER node and login as "admin". Engage
end-user for password.
Enter: storage failover show and identify the different HA-Pairs in the cluster.
Page 4 of 25
FAS2500 Model : Node State Check and Shutdown Procedure (cont.)
Action Description
Connect console cable to the TARGET node and login (7-Mode=root, C-Mode=admin). Engage end-user for password. If the
Target node is not UP, connect to the PARTNER node and login.
For 7-Mode : options autosupport.doit MAINT=<n>h <n> is the number of hours required for maintenance.
Node> options autosupport.doit MAINT=2h
Example Only
For Cluster-Mode : system node autosupport invoke -node * -type all -message MAINT=<n>h
<n> is the number of hours required for maintenance.
Cluster::> system node autosupport invoke -node * -type all -message MAINT=2h
Example Only
Clustered ONTAP
cluster::> storage failover show
Takeover
Node Partner Possible State Description
----------- ------------ -------- ----------------------
Node-01 Node-02 false In takeover
Node-02 Node-01 - Unknown
HA Pair (Node-01, Node-02)
Example: 4-Node cluster
Node-03 Node-04 true Connected to Node-04
Node-04 Node-03 true Connected to Node-03
HA Pair (Node-03, Node-04)
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

III.
Step
10
a)
Enter: y to the question "Do you want to continue?".
11
Enter: cluster show to display information about the nodes in the cluster.
12
Check the "Health" and "Eligibility" values for all nodes other than target node in all HA groups. Does any one show "false"?
If no, go to step 13.
If yes, contact NGS to correct the problem in the node showing false before moving into next step.
13
Check the Epsilon value for the TARGET node to be serviced.
If "true" , go to step 14.
If "false", skip to step 15.
14
Follow steps (a-c) to reassign epsilon to a healthy node. (Also, See the example given below.)
a)
Enter: cluster modify -node <Target_node> -epsilon false to remove Epsilon from the target node.
b)
c)
Enter: cluster show to confirm that Epsilon has been re-assigned properly.
15
Enter: set -priv admin to return the privilege level to "admin".
16 Continue with Section III on next page.
NOTE: A typical 'cluster with only 1 HA-Pair (2-nodes)' uses 'cluster-
HA’ configuration and in that case Epsilon will show as "false" for
both nodes.
Enter: cluster modify -node <Different_node_in_different_HA_Pair> -epsilon true
to assign Epsilon to a node in a different HA-Pair.
Page 5 of 25
FAS2500 Model : Node State Check and Shutdown Procedure (cont.)
Action Description
Enter: set -priv advanced to set the privilege level to "advanced".
(This is a required step to see the 'Epsilon' column in the next command output.)
Cluster::*> cluster modify -node Node_02 -epsilon false
Cluster::*> cluster modify -node Node_04 -epsilon true
Cluster::*> cluster show
Node Health Eligibility Epsilon
------------ ------- ------------ ------------
Node_01 true true false
Node_02 true true false
Node_03 true true false
Node_04 true true true
In this example, Epsilon from Node_02 has been reassigned to Node_04, a
node member of another HA-Pair. Step to remove Epsilon
from TARGET node.
Step to add Epsilon to
different node.
Enter this command and verify the
Epsilon has been re-added properly.
Cluster::> set -priv advanced
Warning: These advanced commands are potentially dangerous; use them only when
directed to do so by NetApp personnel.
Do you want to continue? {y|n}: y
Cluster::*> cluster show
Node Health Eligibility Epsilon
------------ ------- ------------ ------------
Node_01 true true false
Node_02 true true true
Node_03 true true false
Node_04 true true false
Example: 4-Node cluster
Epsilon is seen on 4 or more node clusters. (A typical 2-node cluster doesn't use Epsilon.)
NOTE: A typical 'cluster with
only 1 HA-Pair (2-nodes)'uses
'cluster-HA’ configuration and in
that case Epsilon will show as
"false" for both nodes.
Enter this command to view node health and which node is holding epsilon (true).
Required step to see the 'Epsilon' column in the next command.
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

III.
Step
17
18
a)
(i)
If any option(s) shows "on", turn it "off" using the below commands. Copy-n-paste the command syntax.
b)
(i)
If any option(s) shows "true", set it to "false" using the below commands. Copy-n-paste the command syntax.
19 Continue with Section III on next page.
Check if any "auto-giveback" options are enabled. If enabled, disable the option(s) - For 7-Mode, go to step a) and for Cluster-
Mode, go to step b) below.
For 7-Mode systems: Enter the below commands to check the value of "cf.giveback.auto.enable" and
"cf.giveback.auto.after.panic.takeover" options. Copy-n-paste the command syntax.
For C-Mode systems:
Enter the below commands to check the value of "-auto-giveback" and "-auto-giveback-after-panic"
parameters. Copy-n-paste the command syntax.
Page 6 of 25
FAS2500 Model : Node State Check and Shutdown Procedure (cont.)
Action Description
IF HA config, move console cable to the PARTNER node if not already connected and continue with step 18 below.
IF non-HA, skip to step 20 in this section.
node> options cf.giveback.auto.enable
cf.giveback.auto.enable on
node> options cf.giveback.auto.after.panic.takeover
cf.giveback.auto.after.panic.takeover on
If "on", enter the below
commands to turn it "off"
node> options cf.giveback.auto.enable off
node> options cf.giveback.auto.enable
cf.giveback.auto.enable off
node> options cf.giveback.auto.after.panic.takeover off
node> options cf.giveback.auto.after.panic.takeover
cf.giveback.auto.after.panic.takeover off
off
off
Verify these
options are
set to off
before
proceeding!
cluster::> sto fa show -node local -fields auto-giveback
node auto-giveback
------------- -------------
Node-B true
cluster::> sto fa show -node local -fields auto-giveback-after-panic
node auto-giveback-after-panic
------------- -------------------------
Node-B true
If "true", enter the below
commands to turn it "false"
cluster::> sto fa modify -node local -auto-giveback false
Warning: Disabling auto-giveback under cluster HA configuration
will prevent the management cluster services from automatically
going online under alternating-failure scenarios.
Do you want to disable auto-giveback? {y|n}: y
cluster::> sto fa show -node local -fields auto-giveback
node auto-giveback
------------- -------------
Node-B false
cluster::> sto fa modify -node local -auto-giveback-after-panic false
Warning: Disabling auto giveback after takeover on panic can result
in degraded performance and availability.
Do you want to disable auto-giveback-after-panic ? {y|n}: y
cluster::> sto fa show -node local -fields auto-giveback-after-panic
node auto-giveback-after-panic
------------- -------------------------
Node-B false
false
false
Verify these
options are
set to false
before
proceeding!
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

III.
Step
20
Move the console cable to the TARGET system if not already connected and verify the console response.
a)
b)
To review the steps for performing a Manual Takeover, click >>
here.
21
a) At the "Waiting for giveback ……" prompt, Enter: Ctrl-C
b) At the message: "Do you wish to halt this node rather than wait [y/n]? " Enter: y
c) After the system drops to the LOADER-A|B> prompt, skip to step 22.
22 Go to Section IV "Capture the Current System Configuration" on next page.
IF the console response is the LOADER prompt or "Waiting for giveback", go to step 21 below.
IF HA-Pair and both nodes are up, engage end-user to “takeover” the TARGET node from the PARTNER.
IF non-HA and node is up, engage end-user to "halt" the TARGET node.
Once the "takeover" or "halt" is complete, go to step 21 below.
Move console cable to the TARGET node if not already connected. If the console response is: "Waiting for giveback…..."
follow steps (a-c) below. If console response is LOADER-A|B> skip to step 22 below.
Page 7 of 25
FAS2500 Model : Node State Check and Shutdown Procedure (cont.)
Action Description
Waiting for giveback...(Press Ctrl-C to abort wait)
^C
This node was previously declared dead.
Pausing to check HA partner status....
...............
...............
The HA partner is currently operational and in takeover mode.
...............
waiting for giveback...
Do you wish to halt this node rather than wait [y/n]? y
Halting...
.......
LOADER-A>
Enter: y
Enter: CTRL-C
Information on
Partner Status
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

IV.
Step
1
a) At the "Waiting for giveback ……" prompt, Enter: Ctrl-C
b) At the message: "Do you wish to halt this node rather than wait [y/n]? " Enter: y
c) After the system drops to the LOADER-A|B> prompt, continue with step 2.
2
From the LOADER, enter: printenv This command displays (and captures) all boot environmental variables.
3
Identify if this is a NSE disk based system:
4Continue with Section IV on next page.
Move console cable to the TARGET node if not already connected. If the console response is: "Waiting for giveback…..."
follow steps 1a-1c. If console response is LOADER-A|B> skip to step 2.
Page 8 of 25
FAS2500 Model : Capture the Current System Configuration
Action Description
Open the "printenv" output listing captured in step 2 above. Using the "Find" function search for the variables named: bootarg
The actual variable to look for is: 'bootarg.storageencryption.support'.If this variable exists and is set to 'true' then this is
an NSE system.
STOP
The "printenv" output is corrupt if there is any question marks ( ?? ) and periods in the variable names or
values. If garbaged output the printenv is considered corrupt.
If "printenv" output is corrupt, more checks will need to be performed from the PARTNER node when
executing step 6 on next page; if non-HA config, you may need to engage NGS later in this Action Plan to
verify if this is an NSE system or not.
LOADER-A> printenv
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
Waiting for giveback...(Press Ctrl-C to abort wait)
^C
This node was previously declared dead.
Pausing to check HA partner status....
...............
...............
The HA partner is currently operational and in takeover mode.
...............
waiting for giveback...
Do you wish to halt this node rather than wait [y/n]? y
Halting...
.......
LOADER-A>
Step 1b): Enter y
Step 1a): Enter: CTRL-C
Information on
Partner Status

IV.
Step
5
6If the "printenv" output listed in step 2 is corrupt, follow step (a) below. Otherwise, skip to step 7 below.
a)
On the PARTNER node, execute the following commands listed:
S
T
O
P
Example A:
Example B:
STOP
7
8Go to section V, "Remove Cable Tray and Cables, extract the MB Tray" on next page.
For NSE system, enter: key_manager status to check the status of all key management servers linked to the TARGET
system. If non-NSE system, skip to step 8.
FAS2500 Model : Capture the Current System Configuration (cont.)
Action Description
Page 9 of 25
If HA-config, move console cable to the PARTNER node and login (7-Mode=root, C-Mode=admin) and continue with step 6.
Engage end-user for password. Note: If non-HA, go to section V, "Remove Cable Tray and Cables, extract the MB Tray".
::>run local ----> Run this command from ClusterShell only if Clustered ONTAP.
> priv set advanced
>disk encrypt show
If the disk encrypt show command output is "ERROR: The system is not configured to run this
command",this is not an NSE disk based system (Ref Example A below).
If the command output list the disk details with Key ID info, this is an NSE system (Ref Example B).
Confirm with customer that they have not power cycled the controller chassis or any disk shelves with NSE drives. If power
cycled, do NOT proceed - Contact NGS.
cm2554-ks::> run local ----> Run this command only for Clustered ONTAP.
Type 'exit' or 'Ctrl-D' to return to the CLI
cm2554-ks-01> priv set advanced
Warning: These advanced commands are potentially dangerous; use
them only when directed to do so by NetApp
personnel.
cm2554-ks-01*> disk encrypt show
ERROR: The system is not configured to run this command.
cm2554-ks::> run local
Type 'exit' or 'Ctrl-D' to return to the CLI
cm2554-ks-01> priv set advanced
Warning: These advanced commands are potentially dangerous; use
them only when directed to do so by NetApp
personnel.
cm2554-ks-01*> disk encrypt show
Disk Key ID Locked?
---------- ---------------------------------------------------------------- -------
0d.01.8 080DAD83080D7DD7010000000000000002BACBCF1729496812F6A4D2E00BE925 Yes
0d.01.16 080DAD83080D7DD7010000000000000002BACBCF1729496812F6A4D2E00BE925 Yes
0d.01.21 080DAD83080D7DD7010000000000000002BACBCF1729496812F6A4D2E00BE925 Yes
0d.01.12 080DAD83080D7DD7010000000000000002BACBCF1729496812F6A4D2E00BE925 Yes
0d.01.17 080DAD83080D7DD7010000000000000002BACBCF1729496812F6A4D2E00BE925 Yes
0d.01.10 080DAD83080D7DD7010000000000000002BACBCF1729496812F6A4D2E00BE925 Yes
.......
.......
ERROR: The system is not configured to run this command.
This message indicates
that disk encryption is
not enabled and this is
not an NSE system.
cm2554-ks-01*> key_manager status
Key server 10.63.122.58 is responding
Key server 10.63.122.113 is responding
cm2554-ks-01*>
Take note of the Key server IPs that are responding.
(Maximum: 4 Key servers)
This disk listing indicates that this is an NSE system.
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

V.
Step
STOP
1
2Label each cable connector with its port number and then unplug the cabling from the connector.
3If installed, slide the Cable Management Arm out of “C” channel located on either sides of Controller module. Ref Fig 8.
NOTE: If possible keep the cables on the cable management arm to keep them in the correct position for reconnection.
4
Remove the controller from the system, Ref Fig 9.
5Go to section VI, "Replace the Boot Device" on next page.
Page 10 of 25
FAS2500 Model : Remove Cable Tray and Cables, extract the MB Tray
Action Description
DO NOT turn off the power supplies because disks are spinning in the chassis.
On the node to be serviced (TARGET node), squeeze the latch on the cam handle until it releases, ref Fig 7, and slide the
controller module towards you halfway out of the chassis.
Fig 8
"C" Channel (On both
sides of Controller)
Fig 9
Pull to extract
Controller module
Squeeze and rotate cam handle
Fig 7
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

VI.
Step
NOTE
1
Turn the controller module over and open it by pressing the button to release the cover, and then slide the cover out. Ref Fig 10.
2Fig 11 identifies the Boot Media Device location.
3
Remove the old Boot Device:
a) Push the release tab on the Boot Media holder cover and open the cover.
b) Hold the boot device by its edges at the notches and gently lift it straight up and out of the housing.
4
Install the new Boot Device:
a)
b) Close the boot device cover.
5Close the controller cover. Ref Fig 10.
6Go to section VII, "Partially Reinsert the Controller and reconnect the cables" on next page.
Page 11 of 25
FAS2500 Model : Replace the Boot Device
Action Description
Adhere to anti-static precautions. (A paper ESD strap is included inside the RMA box if you don't have your own)
Align the new boot device with the boot device socket or connector, and then firmly push the boot device straight down into
the socket or connector.
Fig 11 Boot Media Device
Fig 10
Button to release
controller module cover
I/O Panel
this side
Note: Lifting the boot device out at an angle can bend or break the connector
pins in the boot device. So, lift it straight up out of the housing.
Also, Installing the boot device at an angle or over the rear plastic pin first
can bend or damage the pins in the boot device connector. So, install it by
aligning the front of the boot device squarely over the pins in the socket at
the front of the boot device housing.
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

VII.
Step
1
2Re-attach the Cable Management Arm if removed.
3
VIII.
Step
1
2
3
4
a.
Immediately Press ^C (CTRL-C) to access the "Boot menu".
b. Next, drop to the LOADER prompt from the Boot Menu following the linked process >> here
5
IF you miss the window to abort the autoboot, look for this message: "Press CTRL-C for Boot Menu" and complete steps 4a-
4b, otherwise if at the "LOADER" prompt, skip to step 5.
Continue with Section VIII on next page.
Page 12 of 25
FAS2500 Model : Boot PROM Variable Checks
Action Description
Re-attach laptop to the console port and capture the display output even if using the end user's computer.
Fully Insert the Controller Module into the slot and latch the cam lever closed.
IMMEDIATELY after the console message "Starting AUTOBOOT press Ctrl-C to abort…" is displayed, press Ctrl-C (^C)
key a couple times to abort the autoboot. See Console output example below.
FAS2500 Model : Partially Reinsert the Controller and reconnect the cables
Action Description
With the cam handle in the open position, partially insert the controller into the slot so that the cables can be attached - DO
NOT engage the backplane yet.
Cables: Fully insert each cable that was removed to its proper port until it clicks in. Test by pulling on them. Especially the FC
and SAS ports!
Phoenix SecureCore(tm) Server
Copyright 1985-2008 Phoenix Technologies Ltd
.....
.....
.....
CPU Type: Intel(R) Xeon(R) CPU C3528 @ 1.73GHz
Starting AUTOBOOT press Ctrl-C to abort...
Autoboot of PRIMARY image aborted by user.
LOADER-A>
Step 3: IMMEDIATELY press Ctrl-C
(^C) key to abort the autoboot. If
missed, follow step 4 below.
.......
.......
*******************************
* *
* Press Ctrl-C for Boot Menu. *
* *
*******************************
^C
Boot Menu will be available.
.......
.......
Step 4a):
Press "CTRL-C"
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

VIII.
Step
6
Table-2
A)
partner-sysid <xxxxxxxxxx>
How to determine the partner-sysid value? Click here
B)
bootarg.init.boot_clustered true
How to determine a Cluster-Mode system? Click here
C)
bootarg.init.switchless_cluster.enable true
How to determine a Switchless Cluster config?
Click here
7Continue with Section VIII on next page.
Page 13 of 25
System Type, Configuration, Variable name &
Value to be validated
IF HA:
Verify this variable is set with correct partner sys-id value.
IF Cluster-Mode:
Verify this variable is set to true.
IF Cluster-Mode & configured as a Switchless Cluster:
Verify this variable is set to true.
FAS2500 Model : Boot PROM Variable Checks
Action Description
Enter:
printenv bootarg.init.switchless_cluster.enable
Validate the boot env variables:
If HA and/or Cluster-Mode config, at least the following three boortarg parameters and values listed in the Table-2 below will
need to be researched and manually entered. Follow steps (A-C) in Table-2 below.
Validate the Variable name and Value
Enter: printenv partner-sysid
Enter: printenv bootarg.init.boot_clustered
LOADER-A> printenv partner-sysid
Variable Name Value
-------------------- --------------
partner-sysid 0536900170
Example Only
LOADER-A>
printenv bootarg.init.boot_clustered
Variable Name Value
---------------------------- ---------
bootarg.init.boot_clustered true
LOADER-A>
printenv bootarg.init.switchless_cluster.enable
Variable Name Value
---------------------------- ---------
bootarg.init.switchless_cluster.enable true
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
IF this variable is missing or not set correctly, set it now using the command:
setenv variable-name <value>
LOADER-A> setenv partner-sysid 0536900170
Example:
IF this variable is missing or not set correctly, set it now using the command:
setenv variable-name <value>
LOADER-A> setenv bootarg.init.boot_clustered true
Example:
IF this variable is missing or not set correctly, set it now using the command:
setenv variable-name <value>
LOADER-A> setenv bootarg.init.switchless_cluster.enable true
Example:
(Copy-n-paste the variable name / value)

VIII.
Step
Additional Bootarg Parameter Values will need to be entered for NSE enabled systems.
Additional Bootarg Parameter Values to be fixed for NSE enabled systems:
-bootarg.storageencryption.support
-bootarg.kmip.servers.x
(x ~0, 1, 2 or 3 depending on the key management server linked)
-kmip.init.interface
-kmip.init.ipaddr
-kmip.init.netmask
-kmip.init.gateway
8
IF NSE enabled system, continue with step 9. If non-NSE system, skip to step 10 below.
Still not sure if this is an NSE system or not? Call  NGS.
9Determine the additional bootarg variables and their values for NSE enabled systems by following steps > > here
a)
10
a) Enter: savenv to save the variable(s) and value(s).
11 Go to section IX, "Prepare and Start the Netboot Process" on next page.
Page 14 of 25
FAS2500 Model : Boot PROM Variable Checks
Action Description
S
T
O
P
Once identified, copy each variable and its value using "Ctrl-C", then at the LOADER prompt enter:
setenv <(CTRL-V)to paste the variable and value>
STOP
PROM will accept improper variable names. Recheck they were entered properly by re-entering the command:
printenv <variable-name> and confirming the values you entered.
If any variable(s) and value(s) were set above in this section using setenv command, follow step (a) below. Otherwise, go to
step 11.
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

IX.
Step
a) There are two different procedures for transferring the system files:
(i) Disruptive procedure (ii) Non-Disruptive procedure
b)
c)
1Inform end-user the following:
(i) This action plan defaults to using an HTTP Webserver for sourcing the netboot kernel and ONTAP images.
(ii) End-user is to download the exact version of Data ONTAP from support site to the Webserver’s root directory.
(iii)
2
Follow procedure (A), (B) and (C) in the order listed below:
A. Download 'Netboot' and 'Software' images to the "source" HTTP server
1)
Example of images: 832RC2_q_netboot.tgz and 832RC2_q_image.tgz (approx size ~300-600 MB)
*If the End-User needs assistance in locating the proper images from the NetApp Support Site, contact NGS.
2)
(2) You may need to start or restart the HTTP Service on the "source" HTTP server.
B. Configure the local interface "e0M" on the target controller
1Attach to the console port of the TARGET node. Capture the session log file.
2Next configure the 'e0M' port on the TARGET controller - It must have an active network cable installed.
3If site using a DHCP server, enter : ifconfig e0M -auto at the LOADER prompt and skip to step 3b.
a)
b)
Page 15 of 25
FAS2500 Model : Prepare and Start the Netboot Process
Action Description
End user to download two DOT 8.x images - "Netboot image" (<version>_q_netboot.tgz) and "Software image"
(<version>_q_image.tgz) for your system model and ONTAP version- from the "NetApp Support Site" to the http root folder
of the HTTP server. See the below table for the list of images.
End-user is to provide the e0M port IP address, the netmask for the network and a gateway IP if one is needed to configure
the TARGET controller e0M port.
Test connectivity to the HTTP server using the command:
ping <HTTP-server-IP OR HTTP_server_name if "dns" options were set> If ping doesn't work,
recheck ifconfig settings and make sure the interface you configured is not on a private network or VLAN.
STOP!
and
READ Table-3 on page 17 describes the procedures to be followed based on system configuration and status.
You may experience a service outage during a Disruptive procedure, even using it with a system in an HA
configuration. Call

NGS if you have questions.
Note: Other parameters such as dns_addr, dns_domain might be necessary for your interface.
Ex:ifconfig e0M -addr=e0M_IP -mask=netmask -gw=gateway -dns=dns_addr -domain=dns_domain
"dns_addr" is the IP address of a name server on your network. "dns_domain" is the DNS domain name.
On the "source" HTTP server, extract the contents of the 'netboot.tgz' file to the target directory by using the following
methods:
(i) For Unix based system, extract the 'netboot.tgz file' using the command :
'tar -zxvf <version>_q_netboot.tgz'
(ii) For Windows system, extract the 'netboot.tgz file' using 7-Zip.
(WinZip does not extract the binary properly.)
Once step 2 is completed,
(1) The target directory on the "source" HTTP server should contain the
'<version>_q_image.tgz' file and the 'netboot' directory.
Otherwise use the end--user provided e0M IP, netmask and/or gateway info to configure the e0M interface:
Enter:
ifconfig e0M -addr=<target-e0M_IP> -mask=<netmask> -gw=<gateway>
NOTE
LOADER-A> ifconfig e0M -addr=10.61.83.35 -mask=255.255.255.0 -gw=10.61.83.1
Device e0M:
hwaddr 00-A0-98-73-59-2A, ipaddr 10.61.83.35, mask 255.255.255.0
gateway 10.61.83.1, nameserver not set
speed 1000 full duplex, loopback not supported
LOADER-A
LOADER-A> ping 10.61.69.167
10.61.69.167 (10.61.69.167) is alive
10.61.69.167 (10.61.69.167): 1 packets sent, 1 received
EXAMPLE: Sample ifconfig using 'e0M' (gw=gateway IP optional)
NOTE: "source_ip" is the HTTP server IP
serving the netboot and DOT image file
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
www.7-zip.org/download.html

IX.
Step
C. Start the Netboot Process
1Enter the following command at the LOADER prompt of the TARGET node:
LOADER-(A/B)> netboot http://path_to_HTTP-server_directory/netboot/kernel
2At the Boot Menu Selection, enter: 7to install the the new software first.
3Enter: yto the question "Do you want to continue? "
4Enter the URL path to the "image.tgz" file as:
http://path_to_HTTP-server_directory/<version>_q_image.tgz
5Continue with Section IX on next page.
Page 16 of 25
FAS2500 Model : Prepare and Start the Netboot Process (cont.)
Action Description
STOP
While the system is booting, make sure console displays booting of the correct ONTAP version kernel (See STOP
text box below). If you suspect an OS version mismatch, do NOT proceed, verify you are using the correct
ONTAP version "tgz" Image. Questions? Call NGS.
LOADER-A> netboot http://10.61.69.167/netboot/kernel
Loading 10.61.69.167/netboot/kernel:0x200000/10098640 0xba17d0/4692664 Entry at
0x80272300
Found 10.61.69.167/netboot/SB_XIX/platform.rc
......
......
NetApp Data ONTAP 8.3.2RC2
......
......
*******************************
* *
* Press Ctrl-C for Boot Menu. *
* *
*******************************
mkdir: /cfcard/cores: Read-only file system
The Boot Menu will be presented because an alternate boot method was specified.
Please choose one of the following:
(1) Normal Boot.
(2) Boot without /etc/rc.
(3) Change password.
(4) Clean configuration and initialize all disks.
(5) Maintenance mode boot.
(6) Update flash from backup config.
(7) Install new software first.
(8) Reboot node.
Selection (1-8)? 7
This procedure will replace existing Data ONTAP software with new software.
Do you want to continue? {y|n} y
What is the URL for the package? http://10.61.69.167/832RC2_q_image.tgz
What is the user name on "10.61.69.167", if any?
Checking network link... success.
Checking route to host "10.61.69.167"... success.
Attempting to reach 10.61.69.167... success.
Looking up URL "http://10.61.69.167/832RC2_q_image.tgz"... success.
Downloading package...
......
......
100%Downloading package... success.
Checking package contents... success.
Extracting install script from package... success.
......
......
STEP 1: Enter "netboot" command
STOP: Read STOP under step 1 above. If netboot
version displayed is correct,proceed to next step.
STEP 2: Select option "7"
STEP 3: Enter: y
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
STEP 4: Enter the URL for the "image.tgz"

IX.
Step
C. Start the Netboot Process (cont.)
3Read the below Table and follow the correct Action:
Table-3
Check which procedure to be followed from the two options below:
i. Follow Non-Disruptive Procedure - Go to Sec X.
ii. Follow Disruptive Procedure - Go to Sec XI.
"HA" system and the TARGET node was
successfully taken over by its PARTNER
TARGET node does not have a partner (non-HA)
OR the PARTNER did not takeover.
Page 17 of 25
FAS2500 Model : Prepare and Start the Netboot Process (cont.)
Action Description
Do you want to restore the backup configuration
now? {y|n}
After the installation of the ONTAP software, the following question will be displayed to select your option about restoring
the 'varfs' backup configuration
Do NOT answer to this question now! - The correct response to this question depends on which
procedure will be followed in Table-3.
S
T
O
P
......
......
Extracting to /cfcard/x86_64/freebsd/image2...
Installed MD5 checksums pass
Installing diagnostic and firmware files
Firmware MD5 checksums pass
Terminated
Installation complete.
**************************************************************
* Restore Backup Configuration *
* This procedure only applies to storage controllers that *
* are configured as an HA pair. *
* *
* Choose Yes to restore the 'varfs' backup configuration *
* from a SSH server. Refer to the Boot Device Replacement *
* guide for more details. *
* Choose No to skip the back up recovery and return to the *
* boot menu. *
**************************************************************
Do you want to restore the backup configuration
now? {y|n}
WAIT for this message to be displayed -Do NOT answer it before reading Table-3 below.
The correct response to this question depends on which procedure will be followed in Table-3.
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers

X.
Step
1
Enter: yto the question "Do you want to restore the backup configuration now? "
2
Enter: yif the question "/etc/ssh/ssh_host_dsa_key already exists. Overwrite (y/n)? " is asked.
3Continue with Section X on next page.
Warning! Read STOP! Text Box below.
Perform the backup procedure on the PARTNER only when you reach step 5 on next page.
Page 18 of 25
FAS2500 Model : Transfer the System Files using Non-Disruptive Procedure
Action Description
WARNING
This non-disruptive procedure can be used only if it is an "HA" system and the TARGET node was successfully
taken over by its PARTNER.
**************************************************************
* Restore Backup Configuration *
* This procedure only applies to storage controllers that *
* are configured as an HA pair. *
* *
* Choose Yes to restore the 'varfs' backup configuration *
* from a SSH server. Refer to the Boot Device Replacement *
* guide for more details. *
* Choose No to skip the back up recovery and return to the *
* boot menu. *
**************************************************************
Do you want to restore the backup configuration
now? {y|n} y
*******************************************************************
* Perform the restore backup procedure on this node's HA partner. *
*******************************************************************
/etc/ssh/ssh_host_dsa_key already exists.
Overwrite (y/n)? y
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
Step 1: Enter: y
Step 2: Enter: y
STOP!
When this message is displayed,
DO NOT perform the restore
backup procedure from the
PARNTER immediately -Perform
the backup procedure only when
you reach step 5 on next page.

X.
Step
4
5
Copy the varfs.tgz file to the TARGET node by entering the proper command below:
6
Page 19 of 25
FAS2500 Model : Transfer the System Files using Non-Disruptive Procedure (cont.)
Action Description
(1)"Was the restore backup procedure successful? {y|n}" --> This message is displayed only in some of the ONTAP versions.
IF 'restore backup' was success, continue with Section X on next page. If not success, follow disruptive method in Sec XI.
Issues? Call

NGS.
WAIT for either of these message text to be displayed - Do not answer it before executing step 4 & 5 below on the
PARTNER node. Answer it in step 7-9 on next page after step 5 is completed.
S
T
O
P(2)"The restore configuration has been copied
from the HA partner to this node,
would you like to use this restored copy
now? {y|n}"
Move console cable to the PARTNER node and login (7-Mode=root, C-Mode=admin). Engage end-user for password.
C-Mode: If at the nodeshell prompt, enter: exit to switch to clustershell first.
STOP!
For this step to work, the PARTNER node needs to have network connectivity (same subnet or through a gateway)
to the
TARGET
node (e0M). If the restore backup fails below, the disruptive method in Section XI must be used.
Was the restore backup procedure successful? {y|n}
The restore configuration has been copied
from the HA partner to this node,
would you like to use this restored copy
now? {y|n}
Boot Device Replacement for the FAS2500
For NetApp Authorized Service Engineers
This message is displayed only in
some of the ONTAP versions
STOP:
WAIT for either of these message text to
be displayed -Do not answer it before
executing step 4 & 5 below on the
PARTNER node.
Answer it in step 7-9 on next page after
step 5 is completed.
7-Mode
partner(takeover)> restore_backup <target_node.netboot_IP(e0M).address>
Example:
fas2552cl2-rtp(takeover)*> restore_backup 10.63.108.40
Start Restore Backup
mount_partner...success.
scp /partner/etc/varfs.tgz [email protected]:/var/home/root/success.
unmount /partnersuccess.
Finish restore backup
Cluster-Mode
Cluster::> system node run -node local -command restore_backup
<target_node.netboot_IP(e0M).address>
Example:
cm2554c-rtp::> system node run -node local -command restore_backup 10.61.83.35
Start Restore Backup
mount_partner...success.
scp /partner/etc/varfs.tgz [email protected]:/var/home/root/success.
unmount /partnersuccess.
Finish restore backup
