DS4243 and DS4246 Disk Shelf Overview
Drive
Bays
0-3
4-7
8-11
12-15
16-19
20-23
Left mounting flange Right mounting flange
03
7
11
15
19
23
4
8
12
16
20
DS4243
Shelf LEDs:
- power
- shelf fault
- activity
Shelf ID
digital
display
window
Left ear cover Disk drive bay numbering 0-23 Right ear cover
Tab for changing the shelf ID
Operator display panel Up to 24 disk drives
(See the
Hardware Universe for supported disk drives)
Front view
SLOT
MAP PSU 1
PSU 3
PSU 2
PSU 4
SBB A
SBB B
Slot A
Slot B
IOM3
IOM3
IOM3
IOM3
LNK
LNK
LNK
LNK
ACP ports SAS ports
2 I/O blanks
2 or 4 power supplies (each
with two integrated fans) 2 I/O modules (IOMs)
Rear view
Note: Disk shelves with
two power supplies
occupy the PSU 1 and
PSU 4 locations, as
shown in the following
slot map label.
Note: The ACP and
SAS ports on the
IOMs are designated
as circle and square
ports.
IOM fault LED
Power supply LEDs:
power
DC fault
fan fault
AC fault
Note: DS4243 shelves
ship with two or four
power supplies,
depending on the type
of disk drives.
Alternate Control Path (ACP) capability
For maximum storage availability and stability, storage systems with disk shelves have
the option to use the ACP capability. ACP is a protocol that enables Data ONTAP
®
to
manage and control the disk shelf storage subsystem. It uses a separate network from
the data path so that it can independently perform recovery whenever certain
interruptions are detected in the data path.
To use the ACP capability, you must cable the ACP ports on the disk shelves and connect
the disk shelves to the dedicated network interface on each storage system controller. At
system setup, you enable ACP functionality by configuring ACP parameters. If your
storage system does not have a dedicated onboard network interface for ACP, you assign
one at system setup.
Standard ACP cabling rules apply to all storage systems and can be found in the Univer-
sal SAS and ACP Cabling Guide. ACP functionality, configuration, and enabling informa-
tion can be found in the Data ONTAP Storage Management Guide.
Note: If at initial storage system setup you choose not to use the ACP capability, you can
use it later by cabling the ACP connections and enabling ACP by running setup again.
Component replacement map
Front
Up to 24
disk drives
Power supplies and disk drives are hot-swappable.
(Replace the power supply within two minutes of removal to
minimize disruption to the disk shelf’s airflow.)
Shelf IOMs are not hot-swappable in storage systems that
are single-controller single-path configurations.
For component replacement instructions, LED behavior, and SES
error messages, see the DS4243, DS2246, DS4486, and
DS4246 Installation and Service Guide.
Back
Two or four
power supplies
Two IOMs
Note: New DS4243 and DS4246 disk shelves are visually distinguished by the following labeling:
The disk shelf model, DS4243 or DS4246, appears on the front right ear cover of the disk shelf.
IOM3 appears on the IOM face for DS4243 disk shelves. IOM6 appears on the face of the IOM
for DS4246 disk shelves.
Two-digit shelf ID digital display
Mixing IOM3 and IOM6 in the same disk shelf is not supported.
The illustrations in this document show a DS4243 disk shelf.
Hot-adding disk shelves
If you are hot-adding disk shelves to an existing storage system, see the applicable document
for the system requirements and procedure:
These documents can be found on the NetApp Support Site at support.netapp.com.
For storage systems, see the DS4243, DS2246, DS4486, and DS4246 Disk Shelf Installa-
tion and Service Guide
.
For MetroCluster systems using SAS optical cables, see Configuring a stretch MetroCluster
system with SAS disk shelves and SAS optical cables
.
For MetroCluster systems using FibreBridge 6500N bridges, see
Configuring a MetroCluster
system with SAS disk shelves and FibreBridge 6500N bridges
.
210-04675+E0

DS4243 and DS4246 Disk Shelf Installation and Setup
Copyright © 2013 NetApp, Inc. All rights reserved.
1. Cable controllers.
See the documentation that came with your storage system for how to cable the controllers.
2. Cable disk shelves.
Following are steps to cable two common configurations. For SAS and ACP rules, and more cabling configurations, see the Universal SAS and ACP Cabling Guide.
Controller 1
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
1Daisy-chain SAS ports 2Cable first shelf SAS connections 3Cable last shelf SAS connections 4Cable ACP connections
Controller 1
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
Controller 1
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
Controller 1
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
Controller 2
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
Controller 1
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
1Daisy-chain SAS ports 2Cable first shelf SAS connections 3Cable last shelf SAS connections 4Cable ACP connections
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
Controller 2
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
Controller 1
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
ACP SAS
Stack 1
ACP SAS
Stack 2
IOM A
IOM B
First
shelf
Last
shelf
Controller 2
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
Controller 1
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
Controller 2
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
Controller 1
Ethernet port
B
A
C
D
HBA 1
B
A
C
D
HBA 2
High availability (HA pair) with two quad-port SAS HBAs supporting two stacks of disk shelves
Multipath HA connectivity
Single controller with two quad-port SAS HBAs supporting two stacks of disk shelves
Dual-path connectivity
4
Set disk shelf IDs
1. Connect power cords to the disk shelf and turn on the power to the disk shelf.
Note: Depending on the disk drive type, your disk shelf might have two or four
power supplies. Connect power supplies in slots 1 and 3 to one power
source and power supplies in slots 2 and 4 to a different power source.
2. Visually verify that the ID for each disk shelf is unique. If not, set the disk shelf ID:
a. Remove the left ear cover.
b. Press and hold the U-shaped tab or button until the first digit blinks.
c. Press the tab or button until the correct number is displayed.
d. Repeat steps band cfor the second digit.
e. Press and hold the tab or button until the second number stops blinking.
Result: Both numbers blink and the operator display panel fault LED illuminates in about five
seconds.
f. Power-cycle the disk shelf to make the new disk shelf ID take effect.
!
!
!Shelf ID
tab or
button
3
Note: A valid shelf ID is 0-98.
FAS20xx and FAS22xx
systems have the internal
shelf ID preset to 00.
Note: A unique shelf ID is required for each SAS shelf within the entire
storage system. If your storage system has SAS and FC shelves, shelf
IDs do not need to be unique between the SAS and FC shelves. (FC
shelf IDs continue to be unique within each FC loop. SAS shelf IDs
continue to be unique to all other SAS shelves in the storage system,
including internal shelf IDs for FAS20xx and FAS22xx systems.)
System requirements
All documentation can be found on the NetApp
Support Site at support.netapp.com .
Documentation
For more disk shelf and safety information, see the
DS4243, DS2246, DS4486, and DS4246 Disk Shelf
Installation and Service Guide
.
For the most current information about supported Data ONTAP releases, platforms, SAS disk shelves, disk drives,
and SAS cables, see the Hardware Universe
on the NetApp Support Site at support.netapp.com .
Note: To cable MetroCluster systems with SAS optical cables or
FibreBridge 6500N bridges, see the applicable guide: Configuring a
stretch MetroCluster system with SAS disk shelves and SAS optical
cables
or Configuring a MetroCluster system with SAS disk shelves
and FibreBridge 6500N bridges
.
If you are using HBAs, they must already be installed in the storage system.
Note: You do not need to ground disk shelves; grounding is done through the power cords.
Boot the system and proceed with setup
- See the Installation and Setup Instructions that came with your storage system for booting your storage system and for system setup.
- To take advantage of the ACP capability, you can enable it at setup or later. See the Data ONTAP Software Setup Guide for the setup worksheet and other setup information.
5
Ground yourself
Ground yourself to the storage system chassis using the grounding leash that came with your storage system.
1
Installing the disk shelf in a rack
If the disk shelf did not come in a system cabinet, you must install it in an equipment rack using the four-post rail kit or the two-post telco tray kit that came with
your disk shelf. See the rack installation flyer that came with the rack kit for detailed instructions.
LIFTING HAZARD
CAUTION
To reduce the weight of the
disk shelf, remove the
power supplies and IOMs
before lifting.
110 lbs (49.9 kg)
Note: If you are installing the disk shelf in a
two-post mid-mount installation, you must use
the mid-mount telco kit, which includes brackets,
in addition to the two-post telco tray kit.
2
Note: One power outlet is required for each
power supply in a disk shelf.
NetApp
4U
Cable the system
