Chapter 1: Specifications of the Model 3040 40U Cabinet 1
1
Specifications of the Model 3040 40U Cabinet
The Model 3040 40U cabinet has these standard features:
A detachable rear door
Standard Electronic Industry Association (EIA) support rails that provide
mounting holes for installing devices into a standard 48.3-cm (19-in.) wide
cabinet
Four roller casters and four adjustable leveling feet that are located beneath the
cabinet for moving the cabinet and then leveling the cabinet in its final location
A stability foot that stabilizes the cabinet after it is installed in its permanent
location
Access openings for interface cables
Two AC power distribution units (PDUs) – each of which has a separate set of
power cords for each side – that allow integrated power connection and power
handling capacity for controller-drive trays and drive trays
WARNING (W05) Risk of bodily injury – If the bottom half of the cabinet is empty,
do not install components in the top half of the cabinet. If the top half of the cabinet is
too heavy for the bottom half, the cabinet might fall and cause bodily injury. Always
install a component in the lowest available position in the cabinet.
WARNING (W07) Risk of bodily injury – Only move a populated cabinet with a
forklift or adequate help from other persons. Always push the cabinet from the front to
prevent it from falling over. A fully populated cabinet can weigh more than 909 kg
(2000 lb). The cabinet is difficult to move, even on a flat surface. If you must move the
cabinet along an inclined surface, remove the components from the top half of the
cabinet, and make sure that you have adequate help.

2Model 3040 40U Cabinet Installation
Figure 1 Components of the Model 3040 40U Cabinet – Front View
and Rear View
1. Ventilation Cover
2. Interface Cable Access Openings
3. Rear Plate
4. EIA Support Rails
5. Vertical Support Rails
6. Cabinet Mounting Rails
7. Stability Foot
8. Adjustable Leveling Feet
9. Power Strip
10. AC Power Distribution Units
11. Front of the Cabinet
12. Rear of the Cabinet

Chapter 1: Specifications of the Model 3040 40U Cabinet 3
You can configure the cabinet to meet your data storage needs. Standard cabinet
configurations consist of a combination of these types of trays:
Controller-drive tray – Contains drives, redundant cooling fans and power
supplies, and, depending on the model, one or two controllers.
Drive tray – Contains drives, redundant cooling fans and power supplies, and
one or two environmental services modules (ESMs).
Power
Requirements
and Heat
Dissipation
The cabinet is rated at 200 VAC through 240 VAC at 50 Hz to 60 Hz, and it operates
to ±10 percent of that range. The cabinet contains a power strip that provides 72A of
usable power through six 12A banks of power. This power is provided by 24 ICE320
power outlets on each PDU.
For the 72A power strips, power cord C1 supplies power to the bottom eight outlets,
power cord C2 supplies power to the middle eight outlets, and power cord C3 supplies
power to the top eight outlets. Each PDU is clearly labelled C1, C2, or C3 where the
power cords connect. Each power outlet is rated at 10A maximum. A 15A circuit
breaker protects each of the six 12A banks. Each circuit breaker is labeled on each
PDU.
Table 1 Power Calculations and Heat Calculations for the Cabinet
Component kVA Watts Btu/Hr
Cabinet PDU (72A PDUs) 14.4 14400 49176
Cabinet PDU/12A bank (72A PDUs) 2.40* 2400* 8196*
E2612 controller-drive tray 0.400 399 1366
E2624 controller-drive tray 0.331 329.6 1127.1
E2660 controller-drive tray 1.268 1222 4180
E5412 controller-drive tray 0.589 589 2016
E5424 controller-drive tray 0.567 567 1935
E5460 controller-drive tray 1.246 1204 4119
E5512 controller-drive tray (200 VAC typical) .668 662 2262
E5512 controller-drive tray
(200 VAC maximum) .674 670 2293
E5524 controller-drive tray (200 VAC typical) .495 483 1653
E5524 controller-drive tray
(200 VAC maximum) .561 554 1896
E5560 controller-drive tray (200 VAC typical) 1.146 1097 3751
E5560 controller-drive tray
(200 VAC maximum) 1.191 1179 4032

4Model 3040 40U Cabinet Installation
Cabinet
Limitations Table 2 lists the limitations when populating your cabinet with DE1600 drive trays.
NOTE A 3040 40U cabinet can hold a maximum of twenty 12-drive trays. Of these
trays, a maximum of 10 can be controller-drive trays, so the remaining 10 trays must
be drive trays.
Table 2 DE1600 Drive Trays That Can Be Installed in the Cabinet
Table 3 lists the limitations when populating your cabinet with DE5600 drive trays.
NOTE A 3040 40U cabinet can hold a maximum of twenty 24-drive trays. Of these
trays, a maximum of 10 can be controller-drive trays, so the remaining 10 trays must
be drive trays.
DE1600 drive tray 0.276 276 945
DE5600 drive tray 0.241 240. 821
DE6600 drive tray 1.268 1222 4180
* The maximum ratings at 200 VAC. The Btu calculation is based on the maximum current
rating that the power distribution unit can provide.
Component kVA Watts Btu/Hr
MaximumNumberof
Controller-Drive
Trays Controller-Drive Tray
Maximum
Number of
DE1600 Drive
Trays
1 E2612 controller-drive tray or E2624
controller-drive tray 1
1 E2624 controller-drive tray (duplex
configuration) 6
2 E2612 controller-drive tray (duplex
configuration) 7
1 E5412 controller-drive tray 15
1 E5424 controller-drive tray 15
1 E5460 controller-drive tray 15
1 E5512 controller-drive tray 15
1 E5524 controller-drive tray 15
1 E5560 controller-drive tray 15

Chapter 1: Specifications of the Model 3040 40U Cabinet 5
Table 3 DE5600 Drive Trays That Can Be Installed in the Cabinet
Maximum
Number of
Controller-Drive
Trays
Controller-Drive Tray
Maximum
Number of
DE5600 Drive
Trays
1 E2600 controller-drive tray with 24 drives
(duplex configuration) 3
2 E2600 controller-drive tray with 12 drives
(duplex configuration) 4
1 E5412 controller-drive tray 7 with InfiniBand
host connections
13 without
InfiniBand host
connections
1 E5424 controller-drive tray 9 with InfiniBand
host connections
15 without
InfiniBand host
connections
1 E5460 controller-drive tray 7 with InfiniBand
host connections
13 without
InfiniBand host
connections
1 E5512 controller-drive tray 7 with InfiniBand
host connections
13 without
InfiniBand host
connections

6Model 3040 40U Cabinet Installation
1 E5524 controller-drive tray 9 with InfiniBand
host connections
15 without
InfiniBand host
connections
1 E5560 controller-drive tray 7 with InfiniBand
host connections
13 without
InfiniBand host
connections
*You can intermix DE1600 drive trays and DE5600 drive trays in a cabinet with an
E2600 controller-drive tray with either 12 drives or 24 drives, provided that the
total number of drives does not exceed 96.
Maximum
Number of
Controller-Drive
Trays
Controller-Drive Tray
Maximum
Number of
DE5600 Drive
Trays

Chapter 1: Specifications of the Model 3040 40U Cabinet 7
Table 4 lists the limitations when populating your cabinet with DE6600 drive trays.
NOTE A 3040 40U Cabinet can hold a maximum of ten 60-drive trays. Of these trays,
a maximum of five can be controller-drive trays, so the remaining five trays must be
drive trays.
Table 4 DE6600 Drive Trays That Can Be Installed in the Cabinet
Maximum Number of
Controller-Drive Trays Controller-Drive Tray Maximum Number of DE6600 Drive Trays
1 (72A PDUs are required if you
are installing DE6600 drive trays) E5412 controller-drive tray 3 with InfiniBand host connections
6 without InfiniBand
host connections
1 (72A PDUs are required if you
are installing DE6600 drive trays) E5424 controller-drive tray 3 with InfiniBand host connections
6 without InfiniBand
host connections
1 (72A PDUs are required if you
are installing DE6600 drive trays) E5460 controller-drive tray 3 with InfiniBand host connections
5 without InfiniBand
host connections
1 (72A PDUs are required if you
are installing DE6600 drive trays) E2660 controller-drive tray 2 without InfiniBand host connections
1 (72A PDUs are required if you
are installing DE6600 drive trays) E5512 controller-drive tray 3 with InfiniBand host connections
6 without InfiniBand
host connections
1 (72A PDUs are required if you
are installing DE6600 drive trays) E5524 controller-drive tray 3 with InfiniBand host connections
6 without InfiniBand
host connections
1 (72A PDUs are required if you
are installing DE6600 drive trays) E5560 controller-drive tray 3 with InfiniBand host connections
5 without InfiniBand
host connections

8Model 3040 40U Cabinet Installation

Chapter 2: Installing the Cabinet 9
2
Installing the Cabinet
Because the cabinet is a large and heavy piece of equipment, cabinet installation
requires planning with attention to detail during the installation process, which
includes these steps:
1. Gather the tools and equipment required for the installation.
2. Prepare the cabinet for moving.
3. Move the cabinet to its permanent location.
4. Complete the installation.
Gathering the
Required Tools
and Equipment
Table 5 Required for Cabinet Installation
Item Included with
the Cabinet
3/4-in. wrench (supplied in the shipping crate) – To raise and
lower the leveling glides under the cabinet.
1/4-in. Allen wrench – To raise and lower the stability foot in
the front of the cabinet.
AC power cords – To connect the cabinet to external power
sources (wall plugs).
SAS cables (optional) – Two cables are included with each drive
tray, while host side cables must be purchased separately.
Communication cables (optional) – To attach the tray to the
host.
Refer to the initial setup guide for your controller-drive tray or
drive tray for additional required items.
Mountable cable spools – Installed along both sides of the
vertical power distribution outlets to accommodate excess cable
length and cable routing. Two cable spools are included with
each controller-drive tray. Cable spools are also shipped with
standalone drive trays

10 Model 3040 40U Cabinet Installation
Preparing to
Move the
Cabinet
Before you move the cabinet from its location in your receiving area, you must
complete these tasks:
1. Estimate the total weight of the cabinet and the trays that are to be installed in it.
2. Acclimate the cabinet.
3. Remove the packing materials.
4. Check the shipping contents.
5. Remove selected components from the cabinet.
Estimating the
Cabinet Weight The cabinet reliably and safely transports more than 909.1 kg (2000 lb) of capacity.
This weight value presumes that the cabinet is empty of components. You need to
know the approximate weight of the cabinet so that you can safely move it.
ATTENTION Possibleequipmentdamage– Cabinets with DE6600 drive trays ship
without drives to reduce shipping weight. Because a fully-populated cabinet with
DE6600 drive trays can weigh more than 909.1 kg (2000 lb), make sure that you move
the cabinet into place before you load the drives and make sure that the floor load
capability of the cabinet’s destination supports that much weight.
ATTENTION Possible damage to tray components – Do not place a DE6600 drive
tray on a flat surface. Install the DE6600 drive tray in the cabinet before operating or
moving drawers
The total weight of the cabinet depends on the number and type of trays that are
installed in the cabinet. Table 6 lists the weights of the components that might be
installed in the cabinet and the weight of the empty cabinet. Use this table to calculate
the approximate total weight of your cabinet. Make sure that you have adequate
personnel and equipment to safely move the cabinet.
Shears – To cut the metal bands on the shipping crate.
Forklift (optional) – To remove the cabinet from the shipping
pallet.
Front panel kits (optional) – To cover the empty bays at the
front of the cabinet.
Antistatic bags (optional) – To protect components that are
removed during the installation procedure for the cabinet.
Item Included with
the Cabinet

Chapter 2: Installing the Cabinet 11
NOTE For more detailed descriptions of the controller-drive trays and drive trays
listed below, refer to the Storage System Site Preparation Guide or the initial setup
guide for each component.
Table 6 Cabinet, Tray, and Crate Weights
Acclimating the
Cabinet ATTENTION Possible damage to tray components – If the outdoor temperature is
below0°C (32°F) when you receive your cabinet and trays,do not immediately unpack
them or uncrate them. Exposing cold components to warm indoor temperatures can
cause condensation, which results in component damage or failures.
Make sure that the cabinet and the trays are acclimated to the indoor environment
before removing the packing materials. If the outdoor temperature is below 0°C
(32°F), leave the cabinet and trays inside of their crates indoors for at least 24 hours to
prevent condensation. Increase or decrease the 24-hour stabilization period depending
on the outside temperature upon arrival. After the cabinet and the trays have
acclimated to the indoor environment, you can unpack them.
Component Weight Notes
Cabinet 138.80 kg (306.0 lb) Empty with the rear door installed
Power distribution units (PDUs
[pair]) 19.96 kg (44.0 lb)
Mounting rails (pair) 1.59 kg (3.50 lb)
E2612 controller-drive tray 27 kg (59.52 lb) Maximum configuration
E2624 controller-drive tray 26 kg (57.32 lb) Maximum configuration
E2660 controller-drive tray 105.2 kg (232 lb) Maximum configuration
E5412 controller-drive tray 27.92 (61.52 lb) Maximum configuration
E5424 controller-drive tray 26.92 kg (59.32 lb) Maximum configuration
E5460 controller-drive tray 105.2 kg (232 lb) Maximum configuration
E5512 controller-drive tray 27.76 kg (61.22 lb) Maximum configuration
E5524 controller-drive tray 26.76 kg (59.02 lb) Maximum configuration
E5560 controller-drive tray 105.2 kg (232 lb) Maximum configuration
DE1600 drive tray 27 kg (59.5 lb) Maximum configuration
DE5600 drive tray 26 kg (57.3 lb) Maximum configuration
DE6600 drive tray 104.1 kg (229.6 lb) Maximum configuration
Shipping crate (for worldwide
shipments only) 136.08 kg (300 lb) Empty

12 Model 3040 40U Cabinet Installation
Removing the
Packing Material After the cabinet has acclimated to the indoor temperature, refer to the unpacking
instructions included on the front of the shipping crate, and remove the packing
material.
Checking the
Shipping Contents Compare the packing list against the equipment that you received to make sure that all
equipment arrived at the site. If any items are missing, contact your sales
representative.
Removing the
Components It is recommended that you remove some of the heavier components that are located
in the top of the cabinet before you move the cabinet. Removing these components
makes sure of maximum stability and keeps the center of gravity as close to the floor
as possible while the cabinet is being moved.
After the cabinet is moved to its permanent location, you will reinstall these
components in the cabinet in their original locations. It is important, therefore, to note
each component’s location prior to removing it.
Refer to the initial setup guide for each tray, as required, to identify the components
and switch locations. Refer to the Hardware Cabling Guide, as required, for common
cabling configurations.
ATTENTION Possible address conflict of loss of data access – To prevent address
conflicts and loss of data access, note the location of each tray, component, and cable
prior to its removal so that you can reinstall each item in its original location.
Complete these steps to remove the components:
1. Record the cable configuration for future reassembly if any cables must be
disconnected.
2. Remove the drive trays and controller-drive trays in the top half of the cabinet.
Keep all of the components from the same tray together.
NOTE It is not necessary to remove the power supplies or other components from the
rear of each tray.
3. Place each component in a separate antistatic bag. If the original shipping boxes
are available, use them to transport the components.
Moving the
Cabinet Shipping crates provide built-in ramps and instructions for rolling the cabinet off the
pallet without the use of a forklift. Refer to the unpacking instructions included on the
front of the shipping crate.
When you move a cabinet, you must be aware of all of the ramps between the loading
dock and the destination. You must evaluate all ramps to make sure that the cabinet’s
center of gravity (when the cabinet is on a ramp and sitting at an angle) does not
extend beyond the cabinet’s footprint.

Chapter 2: Installing the Cabinet 13
It is recommended that you remove the top-most devices in your cabinet to make sure
that the cabinet is safely transported to its final location. This is especially important
if any ramp has an incline or a decline greater than 10 degrees.
NOTE Many of the cabinets are populated with drive trays. This situation results in
most of the weight in the front portion of the cabinet, making the center of gravity
closer to the front.
1. Move the cabinet to its permanent location.
Figure 2 Incorrect Method and Correct Method for Moving the
Cabinet
2. After the cabinet is in position, lower the leveling glides, which are located near
each bottom corner of the cabinet.
83004-01
Rear of Cabinet Front of Cabinet

14 Model 3040 40U Cabinet Installation
