NetComm NTC-400 Series User manual

Quick Start Guide
NTC-400 Series Router

| Industrial IoT
2
This quick start guide is designed to get you up and running quickly and familiarise
you with the NTC-400 Series router. More advanced set up instructions are
provided in the user guide which can be downloaded from
http://www.netcommwireless.com/product/m2m/ntc-400

| Industrial IoT
3
NTC-400 Series Router
Package contents
The NTC-400 Series package includes:
1 x NTC-400 Series Router
2 x Wall mounting
brackets
1 x Quick Start Guide
2 x 2.4GHz / 5GHz
WiFi antennas
4 x Wall mounting
bracket screws
1 x 8-pin Terminal block
Pre-requisites
To complete the installation, you may require certain items such as screwdrivers
and fasteners.
2 x Cellular antennas

| Industrial IoT
4
Terminal block
The 8-pin Terminal block provides the following interfaces:
1 3 5 7
2 4 6
1. Power (PWR)
2. Ground (GND)
3. Ignition (IGN)
4. Digital Input 1 (DI-1)
5. Digital Input 2 (DI-2)
6. Digital Output (DO)
7. RS232 Serial (TX/RX)

| Industrial IoT
5
NTC-400 Series Router
I/O specications
MODE SPECIFICATIONS
Digital Input
(DI-1 and DI-2)
Trigger voltage (high) Logic level 1: 5 V to 30 V
Normal voltage (low) Logic level 0: 0 V to 1.0 V
Digital Output
(DO)
Voltage (Relay mode)
Logic level 1: Depends on external device.
Maximum voltage is 36 V.
Logic level 0: Floating, External pull-down
resister (10 k Ω, 0.5 W) is required.
Note: DO power is relayed from the PWR
pin on the 8-pin terminal block connector.
Maximum current 1 Amp @ 12 V, or 0.33 Amp @ 36 V
Power requirements
The NTC-400 Series router accepts DC power in the range of 9 V to 36 V. Follow
the above illustration to ensure that the power source is connected with the
correct polarity.

| Industrial IoT
6
SIM cards
SIM cards are inserted into the SIM slots located on the front panel of the device.
To access the SIM card slots, remove the protective plate using a screwdriver.
NOTE: SIM B is disabled on units purchased through Telstra. On these units,
insert the SIM card into slot A.

| Industrial IoT
7
NTC-400 Series Router
Conguring the router
The web interface can be accessed via WiFi or Ethernet.
Connecting via WiFi
1. Connect and power up the NTC-400 Series router.
2. On your client device (e.g. laptop, tablet), connect to the SSID labelled
“NetComm_2.4GHz_XXXX” or “NetComm_5GHz_XXXX” where “XXXX” is four
randomly generated digits. The unique SSID and password for the wireless
networks are printed on the back cover of this Quick Start Guide and on the
label afxed to the bottom of the device. Enter the WiFi password and then
continue to the “Accessing the web interface” section.
Connecting via Ethernet cable
1. Connect and power up the NTC-400 Series router.
2. Connect a standard straight-through Ethernet cable to your client PC and the
other end to any of the LAN ports on the back of the NTC-400 Series router.
Continue to the “Accessing the web interface” section.
Accessing the web interface
3. In a web browser on your client device, navigate to http://192.168.20.1
4. Enter the username and password printed on both the back cover of this
Quick Start Guide and on the label afxed to the bottom of the device, then
press Enter or the click the Login button. Refer to the User Guide for further
conguration instructions.
NOTE: We highly recommend that you secure the WiFi networks
upon initial installation and change the password used to access
the web interface.

| Industrial IoT
8
Unlocking the SIM card
If the inserted SIM card is PIN locked, navigate to Basic Network >
WAN & Uplink > WAN Interface IPv4 Network Status > WAN-1 > Edit >
Internet Setup > WAN-1 > Edit > Connection with SIM-A / SIM B card >
PIN Code to enter the PIN Code. Click the Save button to save your changes.
NOTE: SIM B is disabled on units purchased through Telstra. On these units,
congure the SIM card in slot A.

| Industrial IoT
9
NTC-400 Series Router
Updating the APN
The default connection proles for both SIM-A and SIM-B are congured for
automatic conguration. If you wish to congure the APN manually, navigate to
Basic Network > WAN & Uplink > WAN Interface IPv4 Network Status
> WAN-1 > Edit > Internet Setup > WAN-1 > Edit > Connection with
SIM-A / SIM B card, set Dial-Up Prole to “Manual-conguration” and enter
the APN into the APN eld. Click the Save button to save your changes.
NOTE: SIM B is disabled on units purchased through Telstra. On these units,
congure the SIM card in slot A.

| Industrial IoT
10
Verifying the
connection status
When the NTC-400 Series router is connected to the Internet, the “HIGH” or “LOW”
LED on the front of the device lights up to indicate the current signal strength.
To check the connection status from the web interface, navigate to Status >
Dashboard and conrm that there is a 3G/4G Interface displayed under the
Network Interface Status table.

| Industrial IoT
11
NTC-400 Series Router
Mounting the router
Attach the mounting brackets to the sides of the NTC-400 Series router with the
supplied screws as shown below.

Product Warranty
For warranty information please visit
https://support.netcommwireless.com/warranty-info
Safety and product care
Please refer to the user guide for safety and product care information.
NETCOMM WIRELESS LIMITED ABN 85 002 490 486
Head Ofce, 18-20 Orion Road
Lane Cove, Sydney, NSW 2066, Australia
p: [phone] f: [phone]
e: [email protected]
www.netcommwireless.com
QSG-00108 rev13
