NetComm NWL-11 User manual

NetCommWireless
Quick Start Guide
M2M CDMA Router
NWL-11

| Wireless M2M
2
NetCommWireless
Quick Start Guide
This quick start guide is designed to get you up and running quickly
with your new NWL-11 M2M CDMA router. More advanced set up
instructions can be found in the user manual which can be downloaded
from http://www.netcommwireless.com/product/m2m/nwl-11
Package contents
This package includes
1 x NetComm Wireless NWL-11 router
1 x 1.5m Yellow Ethernet cable 8P8C
1 x DIN rail mounting bracket
1 x DC terminal block
1 x Quick start guide

| Wireless M2M
3
NWL-11 - M2M CDMA Router
Device overview
ITEM DESCRIPTION
Main antenna socket SMA female connector for an optional external antenna.
Two-way captive power Terminal block for connecting power cable.
Operates in the 8-35V DC range.
Reset button Press and hold for less than 5 seconds to reboot to normal mode.
Press and hold for 5 to 15 seconds to reboot to recovery mode.
Press and hold for 15 to 20 seconds to reset the router to factory
default settings.
RJ45 PoE Ethernet port Connect one or several devices via a network switch here. This
port can also optionally receive Power over Ethernet (802.3af PoE)
in which case the DC power supply can serve as a backup power
source if required.

| Wireless M2M
4
NetCommWireless
Getting started
Depending on your individual setup, you may need certain components
to congure your device correctly.
External power supply unit for the NetComm Wireless NWL-11
(not included).
Flathead screwdriver (no. 3) for terminating power input wires.
Notebook or PC for advanced conguration.
Additional fasteners and screwdrivers for specic wall or
rail mounting.
Mounting options
The NetComm Wireless NWL-11 router can be installed quickly and
easily in a variety of locations.
MOUNT TYPE DESCRIPTION BENEFITS
Wall mount a) Flat against the wall Slimline form factor, close to wall
b) Perpendicular to the wall Small wall footprint
c) Mount via DIN rail bracket Easy to remove
C Section DIN rail mount Slide onto a rail Simplicity
Top hat DIN rail mount Mount on a bracket and
slide onto a rail
Simplicity. Can mount in between
other devices
Desk mount Stand on a desk Simplicity, versatility

| Wireless M2M
5
NWL-11 - M2M CDMA Router
Wall mount
a) Flat against the wall
b) Perpendicular to the wall

| Wireless M2M
6
NetCommWireless
c) Mounted via DIN rail bracket
DIN Rail mounting bracket
1
2
DIN Rail mounting bracket
1Push to release
2V Bend allows you to snap the DIN bracket onto the
middle of a DIN rail, rather than sliding it onto the end.

| Wireless M2M
7
NWL-11 - M2M CDMA Router
C Section DIN rail mount
Top hat DIN rail mount
Desk mount

| Wireless M2M
8
NetCommWireless
Overview of LED indicators
LED ICON NAME COLOR STATE DESCRIPTION
Power Off Power off
Double ash Powering up
On Power on
On Power on in recovery mode
Slow ashing Hardware error
Network On Connected via WWAN
Blinking Trafc via WWAN
Slow ashing Connecting data session
On Registered network
Slow ashing Registering network
On Can’t connect
Slow ashing Not activated
Signal
strength
On EVDO coverage
On CDMA 1x coverage

| Wireless M2M
9
NWL-11 - M2M CDMA Router
Installing your device
Step 1
Mount your router in a suitable location using the options listed in the
Mounting options section of this guide.
When selecting a location to mount the NWL-11 router, keep in mind
that it houses two high performance internal antennas designed to
provide optimum signal strength in a wide range of environments. If you
nd the signal strength is weak, try moving the router to a different place
or mounting it differently. If signal strength doesn’t improve, you may
need to attach an external antenna (not included) to the router’s female
SMA connector.
Note: If you connect an external antenna to the female SMA connector, the
main internal antenna disables automatically but the auxiliary internal
antenna remains connected to provide (where possible) diversity
assistance.
Step 2
Connect power to your router using one of three options.
Power over Ethernet (802.3af PoE)
Connect your router to a PoE injector or PoE network switch using the
bundled yellow Ethernet cable 8P8C. This method uses the Ethernet
connection to power and transfer data to and from the router.
DC power via 2-pin connector
Remove the attached green terminal block from your router and connect
to the router’s power socket using a DC power supply, sold separately.

| Wireless M2M
10
NetCommWireless
DC power via eld terminated power source
If an 8-35V DC power supply is available, you can insert the wires into
the supplied terminal block to power your router. Use a no. 3 athead
screwdriver to tighten the terminal block screws and secure the power
wires, making sure the polarity of the wires are correctly matched, as
illustrated below.
Polarity for the two-way terminal block
The green power LED on the router lights up when a power source
is connected.
Tip: You can connect both the PoE and DC power sources at the same time.
When both are connected, the DC power acts as backup to the PoE input.
