NetComm NTC-40W User manual

User Guide
NTC-40WV –Industrial Indoor 3G Router with Voice

2
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Copyright
Copyright© 2014 NetComm Wireless Limited. All rights reserved.
The information contained herein is proprietary to NetComm Wireless. No part of this document may be translated, transcribed,
reproduced, in any form, or by any means without prior written consent of NetComm Wireless.
Note: This document is subject to change without notice.
Save our environment
When this equipment has reached the end of its useful life, it must be taken to a recycling centre and processed separately from
domestic waste.
The cardboard box, the plastic contained in the packaging, and the parts that make up this device can be recycled in accordance
with regionally established regulations. Never dispose of this electronic equipment along with your household waste. You may be
subject to penalties or sanctions under the law. Instead, ask for disposal instructions from your municipal government.
Please be responsible and protect our environment.
This manual covers the following products:
NetComm Wireless NTC-40WV
DOCUMENT VERSION
DATE
1.0 - Initial document release
29/01/2014
1.1 –Updated for firmware v2.0.4.1 release
11/04/2014
1.2 –Updated for firmware v2.0.11.1 release
15/07/2014
1.3 –Updated for firmware v2.0.19.1 release
16/09/2014
1.4 –Updated for firmware v2.0.21.1 release
02/12/2014
Table 1 - Document Revision History

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
3
Ver 1.4
Table of Contents
Overview ........................................................................................................................................................................................4
Introduction...................................................................................................................................................................................................4
Target audience.............................................................................................................................................................................................4
Prerequisites .................................................................................................................................................................................................4
Notation ........................................................................................................................................................................................................4
Product introduction......................................................................................................................................................................5
Product overview...........................................................................................................................................................................................5
Package contents..........................................................................................................................................................................................5
Product features............................................................................................................................................................................................6
Hardware overview ........................................................................................................................................................................7
LED indicators...............................................................................................................................................................................................7
Interfaces ......................................................................................................................................................................................................8
Configuring your Router ..............................................................................................................................................................10
Setting Up the Cellular Router ......................................................................................................................................................................10
Installation and configuration of the NTC-40WV router .............................................................................................................11
Powering the router .....................................................................................................................................................................................11
Installing the router ......................................................................................................................................................................................11
Advanced configuration ..............................................................................................................................................................12
Status ...........................................................................................................................................................................................13
Networking...................................................................................................................................................................................16
Data connection ..........................................................................................................................................................................................16
Operator settings.........................................................................................................................................................................................21
SIM security settings....................................................................................................................................................................................22
LAN ............................................................................................................................................................................................................26
Wireless settings..........................................................................................................................................................................................30
Ethernet LAN/WAN......................................................................................................................................................................................37
WAN failover................................................................................................................................................................................................39
Routing .......................................................................................................................................................................................................41
VPN ............................................................................................................................................................................................................51
Services........................................................................................................................................................................................64
Dynamic DNS..............................................................................................................................................................................................64
Network time (NTP)......................................................................................................................................................................................65
Data stream manager ..................................................................................................................................................................................66
PADD..........................................................................................................................................................................................................72
SNMP .........................................................................................................................................................................................................73
TR-069........................................................................................................................................................................................................75
Auto dial configuration .................................................................................................................................................................................77
USSD..........................................................................................................................................................................................................78
Voice...........................................................................................................................................................................................................79
Event notification .........................................................................................................................................................................................80
Email client..................................................................................................................................................................................................83
SMS messaging ..........................................................................................................................................................................................84
Diagnostics .................................................................................................................................................................................................88
Sending an SMS Diagnostic Command........................................................................................................................................................91
System .........................................................................................................................................................................................99
Log .............................................................................................................................................................................................................99
System configuration .................................................................................................................................................................................102
Administration ...........................................................................................................................................................................................107
HTTPS key management ...........................................................................................................................................................................109
SSH Key Management ..............................................................................................................................................................................112
Watchdogs................................................................................................................................................................................................115
Reboot......................................................................................................................................................................................................118
Appendix A: Tables....................................................................................................................................................................119
Appendix B: Default Settings ....................................................................................................................................................120
Restoring factory default settings ...............................................................................................................................................................121
Appendix C: Recovery mode ....................................................................................................................................................122
Accessing recovery mode..........................................................................................................................................................................122
Status .......................................................................................................................................................................................................123
Log ...........................................................................................................................................................................................................123
Application Installer....................................................................................................................................................................................124
Settings.....................................................................................................................................................................................................124
Reboot......................................................................................................................................................................................................124
Appendix D: HTTPS - Uploading a self-signed certificate.......................................................................................................125
Appendix E: Obtaining a list of RDB variables .........................................................................................................................127
Technical Data ...........................................................................................................................................................................128
Additional Product Information .................................................................................................................................................129
Using the NTC-40WV to make and receive telephone calls .........................................................................................................................129
Legal & Regulatory Information.................................................................................................................................................133

4
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Contact.......................................................................................................................................................................................135
Overview
Introduction
This document provides you all the information you need to set up, configure and use the NetComm Wireless NTC-40WV router.
Target audience
This document is intended for system integrators or experienced hardware installers who understand telecommunications
terminology and concepts.
Prerequisites
Before continuing with the installation of your NTC-40WV router, please confirm that have the following:
A device with a working Ethernet network adapter.
A web browser such as Internet Explorer, Mozilla Firefox or Google Chrome.
A flathead screwdriver if field terminated power is required.
Telephony Requirements
Standard analogue PSTN or cordless PSTN phone handset (DECT) with an RJ-11 port.
(ISDN phone handsets are not supported)
RJ-11 cable
Notation
The following symbols are used in this user guide:
The following note requires attention.
The following note provides a warning.
The following note provides useful information.

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
5
Ver 1.4
Product introduction
Product overview
The NTC-40WV is a robust 3G (HSPA+) router designed to provide real-time M2M data connectivity even in harsh environments,
and allows you to build wide area networks utilising the superior speeds supported by 3G UMTS networks.
The router integrates a powerful mobile broadband module and delivers download speeds of up to 21Mbps which is then
transmitted via Ethernet to a WiFi router inside the property.
Utilising a NetComm Wireless M2M router allows customers to significantly reduce the cost of the deployment and operation of new
products and services in remote locations. Using mobile data networks, wireless Machine-to-Machine (M2M) communication
enables the secure collection and analysis of data from remote unmanned locations.
The NTC-40WV provides the user a point-to-point or point-to-multi-point communications link in a single, compact and resilient
unit. As a fully featured cellular router, it supports a large number of communication interfaces and protocols to meet the demands
of today’s telemetry and WAN applications.
The integrated telephone adapter connects standard analogue phone handsets to the NTC-40WV. It allows for phone calls to be
made over the 3G UMTS network from inside the premise for a full landline replacement.
The device’s powerful processor delivers optimal performance and it’s embedded NetComm Linux OS and Software Development
Kit (SDK) offers the end user the capability to install custom firmware to the on-board flash memory via the programming interface.
Built in VPN clients also ensure a secure connection over a public mobile network.
Designed with remote installation in mind the NTC-40WV supports multi-level system monitoring giving the user peace of mind the
device will keep the lines of communication open.
In the event of system corruption, a built-in recovery mode provides the facility to re-install the system software to the router and
resume normal operations quickly.
Package contents
The NTC-40WV package consists of:
NetComm Wireless NTC-40 - HSPA+ M2M WiFi Router
1 x Power supply (9-28VDC)
1 x Quick Start Guide
2 x 3G Antennas (SMA connector)
2 x WiFi Antennas (SMA connector)
1 x RJ-45 Ethernet Cable
If any of these items are missing or damaged, please contact NetComm Wireless Support immediately by visiting the NetComm
Wireless Support website at: http://support.netcommwireless.com

6
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Product features
Industrial-grade fixed wireless gateway with extended temperature tolerance and wall mount option.
Designed for rugged deployments in remote environments and industrial applications.
Ideal for providing primary and backup wireless connectivity over 3G UMTS networks.
Embedded high-performance Sierra Wireless 3G cellular modem supporting HSPA+/EDGE/GPRS.
Wireless LAN 802.11n access point with 2x2 MIMO antenna technology.
Powerful processor for optimal performance on advanced 3G UMTS networks.
Ethernet 10/100 connectivity for universal deployment.
Analogue telephone connectivity (CS Voice) for complete landline replacement.
Supports SNMP with cellular specific MIB.
Flexible DC power input and to suit diverse installation environments.
Built-in VPN clients for a secure connection over a public cellular network.
Embedded NetComm Linux OS and Software Development Kit (SDK).
Remote diagnostics, configuration and firmware upgrade capabilities.
Supports PPPoE, RIP, VRRP, Dynamic DNS, MAC /NET address filtering, Open VPN, DHCP/DHCP relay.
Management and configuration via web user interface, SNMP or SMS.

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
7
Ver 1.4
Hardware overview
LED indicators
There are a total of five LED’s on the router.
Listed below are the specifications of the LEDs and their corresponding colours.
Figure 1: NTC-40WV LEDs
LED
DISPLAY
DESCRIPTION
POWER (red)
Solid ON
The red Power LED indicates power has been applied to the router from the DC
power input jack.
TX Rx (amber)
Solid ON
The amber LED will illuminate upon data being sent to or received from the cellular
network.
DCD (green)
Solid ON
The green Data Carrier Detect LED illuminates to indicate a data connection.
Service Type (green)
The green LED will illuminate when cellular network coverage is detected.
Solid ON
3G: Indicates UMTS/HSPA available coverage
Flashing
EDGE: Indicates EDGE available coverage
Off
2G: Indicates GSM/GPRS available coverage only.
RSSI (green)
This green LED shows Received Signal Strength. There are three possible states that the RSSI LED can operate
in, based upon signal level.
Solid ON
Strong: Indicates the RSSI level is -86dbm
Flashing Once a Second
Medium: Indicates the RSSI level is -110dbm and -86dbm
Off
Fair: Indicates the RSSI level is less than -110dbm
Table 2 - LED Descriptions

8
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Interfaces
The following interfaces are available on the NTC-40WV:
1 2 3 4
Figure 2 - Bottom Mounted interfaces
ITEM
INTERFACE
FUNCTION
1
Diversity Receive 3G Antenna
Connect one of the 3G antennas here
2
SIM Card Reader Tray Eject button
Push in with a paper clip to eject the SIM card reader tray.
3
SIM Card Reader Tray
Insert the SIM Card reader tray with a SIM inserted here.
4
Main 3G Antenna
Connect one of the 3G antennas here.
Table 3 - Bottom Mounted interfaces
1 2 3 4 5 6
Figure 3 - Top Mounted Interfaces
ITEM
INTERFACE
FUNCTION
1
WiFi Antenna Port
Connect one of the WiFi antennas here.
2
Captive Power Terminal
Connect the supplied power cable here.
3
RJ-11 Telephone Cable Port
Connect a PSTN telephone here in order to make calls via the 3G connection.
4
RJ-45 Ethernet Port
Connect an Ethernet cable here. The RJ-45 Ethernet port has two LEDs; a green LED
indicating the link status and an amber one indicating the speed of the link. When an
Ethernet cable is connected and the link LED is illuminated, the amber speed LED
illuminates to indicate a 100Mbps connection and extinguishes to indicate a 10Mbps
connection.
5
Reset button
The reset button has multiple functions.
Reboot the device: Press and hold the reset button down for no longer
than 5 seconds. All LEDs remain off, when the button is released the green
LEDs flash once and the router reboots.
Reboot to recovery mode: Press and hold the reset button down for
between 5 and 15 seconds. When the LEDs are flashing, release the button
and the amber LED flashes. The router reboots into recovery mode.
Factory reset the device: Press and hold the reset button down for more
than 15 seconds. When all the LEDs are off, release the button. The Red
LED flashes to confirm the factory reset process. If you change your mind
after holding the reset button down for more than 15 seconds, you can

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
9
Ver 1.4
cancel the factory reset by removing the power source before releasing the
button or by releasing the button and quickly pressing it once more.
6
WiFi Antenna Port
Connect one of the WiFi antennas here.
Table 4 - Top Mounted interfaces
Note: The amber speed LED on the RJ-45 Ethernet port remains illuminated when no Ethernet cable is attached. The
reading of the speed LED is only valid when an Ethernet cable is connected and the green link LED is illuminated.

10
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Configuring your Router
You will need the following hardware components to set up the router:
Power supply (9-28VDC)
Ethernet cable
Laptop or PC
Active SIM card
Inserting the SIM Card
Use a paperclip to press the SIM Eject button to eject the SIM card tray. Place the SIM card in the SIM card tray. Make sure the
SIM card is inserted correctly by inserting the SIM with the gold side facing down into the SIM card bay and in the direction as
shown below:
Press the SIM Eject button
Figure 4 - Inserting the SIM Card
Setting Up the Cellular Router
Attach the supplied antennas to the router by screwing them onto the antenna connectors. Connect the power adapter to the
mains and plug the output into the power jack of the router. When power is correctly supplied to the router, the red power LED on
the panel illuminates.
Polarity of DC Power Plug Screw Terminal
Figure 5 –Locking Two-way Power Terminal Block
PIN
SIGNAL
DESCRIPTION
+
V+
Voltage +
-
V-
Ground
Table 5 - Locking power block pin outs
Insert your Mobile Broadband SIM Card

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
11
Ver 1.4
Installation and configuration
of the NTC-40WV router
Powering the router
The NTC-40WV router can be powered in one of two ways:
1. DC power input via 2-pin connector (9-28V DC)
2. DC power input via field terminated power source (9-28V DC)
The red power LED on the router lights up when a power source is connected.
DC power via 2-pin connector
The DC input jack can accept power from a separately sold DC power supply. Both a standard temperature range DC power
supply and an extended temperature range DC power supply are available to purchase as accessories.
To supply the router with DC Power via the 2-pin connector, remove the attached green terminal block from your router and
connect the external DC power supply to the router’s green DC power jack.
DC power via field terminated power source
If an existing 9-28V DC power supply is available, you can insert the wires into the supplied terminal block to power your router. Use
a flathead screwdriver to tighten the terminal block screws and secure the power wires, making sure the polarity of the wires are
correctly matched for your particular unit, as illustrated below.
Installing the router
After you have mounted the router and connected a power source, follow these steps to complete the installation process.
1. Connect equipment that requires network access to the Ethernet port of your router. This may be your computer for
advanced configuration purposes, or your end equipment which requires data access via the NTC-40WV router. You can
connect one device directly, or several devices using a network switch.
2. Ensure the external power source is switched on and wait 2 minutes for your NTC-40WV router to start up. To check the
status of your router, compare the LED indicators on the device with those listed in the LED Indicators section of this
guide.

12
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Advanced configuration
The NTC-40WV router comes with pre-configured settings that should suit most customers. For advanced configuration, log in to
the web-based user interface of the router.
To log in to the web-based user interface:
1. Open a web browser (e.g. Internet Explorer, Firefox, Safari), type http://192.168.1.1 into the address bar and press Enter.
The web-based user interface log in screen is displayed.
Figure 6 –Log in prompt for the web-based user interface
2. Enter the login username and password. If this is the first time you are logging in or you have not previously configured the
password for the “root” or “admin” accounts, you can use one of the default account details to log in.
ROOT MANAGER
ACCOUNT
Username:
root
Password:
admin
Table 6 - Management account login details –Root manager
ADMIN MANAGER ACCOUNT
Username:
admin
Password:
admin
Table 7 - Management account login details –Admin manager
Note: To access all features of the router, you must use the root manager account.
For security reasons, we highly recommend that you change the passwords for the root and admin accounts upon initial
installation. You can do so by navigating to the System and then Administration page.
The Status page is displayed when you have successfully logged in.

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
13
Ver 1.4
Status
The status page of the web interface provides system related information and is displayed when you log in to the NTC-40WV router
management console. The status page shows System information, LAN details, Cellular connection status, Packet data connection
status and Advanced status details. You can toggle the sections from view by clicking the or buttons to show or hide
them. Extra status boxes will appear as additional software features are enabled (e.g. VPN connectivity).
Figure 7 - The Status page

14
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
ITEM
DEFINITION
System information
System up time
The current uptime of the router.
Board version
The hardware version of the router.
Serial number
The serial number of the router.
Firmware version
The firmware version of the router
Model
The type of phone module and the firmware version of the module.
Module firmware
The firmware revision of the phone module.
IMEI
The International Mobile Station Equipment Identity number used to uniquely identify a mobile device.
Hardware
The hardware version of the module.
LAN
IP
The IP address and subnet mask of the router.
MAC address
The MAC address of the router.
Ethernet port status
Displays the current status of the Ethernet port and its operating speed.
Cellular connection status
SIM Status
Displays the activation status of the router on the carrier network.
Signal strength (dBm)
The current signal strength measured in dBm
Network registration status
The status of the router’s registration for the current network.
Operator selection
The mode used to select an operator network.
Current operator
The current operator network in use.
Roaming status
The roaming status of the router.
Allowed bands
The bands to which the router may connect.
Current band
The current band being used by the router.
Coverage
The type of mobile coverage being received by the router.
WWAN connection status
Profile name
The name of the active profile.
Status
The connection status of the active profile.
Default profile
Indicates whether the current profile in use is the default profile.
WWAN IP
The IP address assigned by the mobile broadband carrier network.
DNS server
The primary and secondary DNS servers for the WWAN connection.
APN
The Access Point Name currently in use.
Connection uptime
The length of time of the current mobile connection session.
WLAN status
Status
Shows the current status of the wireless LAN network.
Network Name (SSID)
Shows the network name (SSID) of the wireless network.
Channel
Shows the channel that the wireless network is configured to operate on.
Network authentication
The type of security/encryption in use on the wireless network.
Station Info
Click the Station Info link to be taken to the station information page providing more information on the wireless network.
Advanced status
Mobile country code
The Mobile Country Code (MCC) of the router.
Mobile network code
The Mobile Network Code (MNC) of the router.
Signal quality (Ec/N0)
A measurement of the portion of the received signal that is usable. This is the signal strength minus the signal noise level.
Received signal code power
(RSCP)
The power level of the signal on the current connection’s particular channel.
HSUPA category
Displays the HSUPA category (1-9) for the current uplink
HSDPA category
Displays the HSDPA category (1-8) for the current downlink.
SIM ICCID
The Integrated Circuit Card Identifier of the SIM card used with the router, a unique number up to 19 digits in length.
Primary scrambling code (PSC)
The Primary scrambling code for the current signal.

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
15
Ver 1.4
Location area code (LAC)
The ID of the cell tower grouping the current signal is broadcasting from.
Routing area code (RAC)
A subdivision of the location area used with GPRS.
IMSI
The International mobile subscriber identity is a unique identifier of the user of a cellular network.
Cell ID
A unique code that identifies the base station from within the location area of the current mobile network signal.
Channel number (UARFCN)
The channel number of the current 3G/2G connection.
Module PRIID Revision
Module version used for customization.
Module PRIID PRI part number
The part number of the Module PRIID.
Table 8 - Status page item details

16
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Networking
The Networking section provides configuration options for Wireless WAN, LAN, Routing and VPN connectivity.
Data connection
The data connection page allows you to configure and enable/disable the connection profile. To access this page, click on the
Networking menu, and under the Wireless WAN menu, select the Data connection item.
Figure 8 –Data connection settings

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
17
Ver 1.4
ITEM
DEFINITION
Data connection
Transparent Bridge (PPPoE)
Toggles the transparent bridge function on and off.
Profile name list
Default
Sets the corresponding profile to be the default gateway for all outbound traffic except traffic for which there are
configured static route rules or profile routing settings.
Status
Toggles the corresponding profile on and off. If your carrier supports it, two profiles may be turned on simultaneously.
APN
The APN configured for the corresponding profile.
Username
The username used to log on to the corresponding APN.
Roaming settings
Allow data roaming
When set to ON, the router will allow local devices to access the Wireless WAN network when the it is roaming onto a
foreign network. When set to OFF, the router will deny network access to data services when roaming onto a foreign
network. This setting is OFF by default.
Table 9 - Data connection item details
Connecting to the mobile broadband network
The router supports the configuration of up to six APN profiles; these profiles allow you to configure the settings that the router will
use to connect to the 2G/3G network and switch easily between different connection settings.
For advanced networking purposes, you may activate a maximum of two profiles simultaneously (dependant on network support).
When activating two connection profiles, you should avoid selecting two profiles with the same APN as this can cause only one
profile to connect. Similarly, activating two profiles which are both configured to automatically determine an APN can cause a
conflict and result in neither profile establishing a connection. We recommend that the two active connection profiles have differing,
manually configured APNs to avoid connection issues and ensure smooth operation.
Manually configuring a connection profile
To manually configure a connection profile:
1. Click the Edit button corresponding to the Profile that you wish to modify. The data connection profile settings page is
displayed.
Figure 9 - Data connection profile settings

18
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
2. Click the Profile toggle key to turn the profile on. Additional settings appear.
Figure 10 - Data connection settings - Profile turned on
3. In the Profile name field, enter a name for the profile. This name is only used to identify the profile on the router.
4. Ensure that the Automatic APN selection toggle key is set to off. If it is not, click it to toggle it to the off position.
5. In the APN field, enter the APN Name (Access Point Name) and if required, use the Username and Password fields to
enter your login credentials.
6. If your mobile broadband carrier allows you to select a preferred IP address, select the Static IP address toggle key to turn
it to the ON position then enter your preferred IP address into the Preferred IP address field.
7. Next to Authentication type, select either CHAP or PAP depending on the type of authentication used by your provider.
8. The Reconnect delay field specifies the number of seconds to wait between connection attempts. The default setting of 30
seconds is sufficient in most cases but you may modify it to wait up to 65535 seconds if you wish.
9. The Reconnect retries field specifies the number of times to attempt a network connection if the router fails to establish a
connection. It is set to 0 by default which causes the router to attempt to reconnect indefinitely.
10. The Metric value is used by router to prioritise routes (if multiple are available) and is set to 20 by default. This value is
sufficient in most cases but you may modify it if you are aware of the effect your changes will have on the service.

www.netcommwireless.com
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
/
19
Ver 1.4
11. The MTU field allows you to modify the Maximum Transmission Unit used on the connection. Do not change this unless
instructed to by your carrier.
12. Use the NAT Masquerading toggle key to turn NAT Masquerading on or off. NAT masquerading, also known simply as
NAT is a common routing feature which allows multiple LAN devices to appear as a single WAN IP via network address
translation. In this mode, the router modifies network traffic sent and received to inform remote computers on the internet
that packets originating from a machine behind the router actually originated from the WAN IP address of the router’s
internal NAT IP address. This may be disabled if a framed route configuration is required and local devices require WAN IP
addresses.
13. For advanced networking such as using dual simultaneous PDP contexts, you may wish to configure a particular profile to
route only certain traffic via that profile by configuring a custom address and mask of traffic to send via that profile. To do
this, in the Profile routing settings section, enter the Network address and Network mask of the remote network. If you do
not want to use this feature, or are unsure, please leave these fields blank, which will not designate any particular traffic to
be routed via this profile. For more information on configuring Profile routing settings, see the Setting a default gateway
with two active connection profiles example.
14. Click the Save button when you have finished entering the profile details.
Confirming a successful connection
After configuring the packet data session, and ensuring that it is enabled, click on the Status menu item at the top of the page to
return to the Status page. When there is a mobile broadband connection, the WWAN section is expanded showing the details of
the connection and the Status field displays Connected. To see details on the connected session, you can click the Show data
usage button.
Figure 11 - WWAN connection status section
Transparently bridging the mobile broadband connection via PPPoE
If desired, you can have a client device connected to the Ethernet port initiate the mobile broadband connection using a PPPoE
session. This is particularly useful in situations where you wish to provide Wireless WAN data access to an existing router which you
want to have full public WAN IP access and have control over routing functionality.
To enable transparent bridging via PPPoE:
1. Click the Networking menu item from the top menu bar.
2. On the Data connection page, click the Transparent bridge (PPPoE) toggle key so that it is ON.

20
NetComm Wireless NTC-40WV Industrial Indoor 3G Router with Voice
www.netcommwireless.com
Ver 1.4
Figure 12 - Transparent bridge configuration
3. In the APN name field, enter the APN that you wish to use for the mobile broadband connection.
4. (Optional) In the Service name field, enter a name that allows you to easily identify the connection.
5. Click the Save button to confirm the settings.
6. Click the Status menu item from the top menu bar to see the transparent bridging status.
Figure 13 - Transparent bridge mode status
7. Next you must configure your downstream device connected via Ethernet to the NTC-40WV to initiate a network
connection using a PPPoE client. The username and password used by the downstream device for the PPPoE session will
be passed on and used by the NTC-40WV as the packet data (PDP) context authentication settings.
