ProSafe®Wireless-N VPN Firewall Data Sheet
SRXN3205
Optimal, Secure Connection for Your Network
NETGEAR’s SRXN3205 ProSafe®Wireless-N VPN Firewall offers two types of virtual private
network (VPN) tunnels, Secure Sockets Layer (SSL) and IP security (IPsec), for optimal secure
connection to your network. SSL VPN tunnels provide clientless remote access to your corporate
data for individual access anywhere and anytime without a software client. IPsec VPN tunnels
deliver both secure site-to-site tunnels and legacy remote access support, connecting multiple
offices together, as well as client-based remote access. Backed by a sophisticated firewall,
the SRXN3205 is a high-performance, SNMP-manageable security solution that furnishes
multidimensional security including denial-of-service (DoS) protection, stateful packet inspection
(SPI), URL keyword filtering, logging, reporting, and real-time alerts. Four Gigabit LAN ports
in conjunction with an integrated dual band Wireless-N Access Point keep your data moving
at top speed.
Secure The SRXN3205 Wireless-N VPN Firewall takes care of all your security needs, with support of
up to 5 SSL VPN tunnels and 5 IPsec VPN tunnels simultaneously, hacker protection via SPI
firewall, DoS attack protection, and multiple VPN pass-through. SYSLOG and email reporting
enable thorough network monitoring. The SSL VPN tunnels support industry-strength encryption
algorithms and features such as automatic cache cleanup after session termination to ensure
protection and privacy of your sensitive data. The SRXN3205 Wireless-N VPN Firewall provides
optimal value and defense against network security threats.
Wireless Access NETGEAR’s SRXN3205 Wireless-N VPN Firewall delivers the coverage and speed advantages of
802.11n wireless networks. Designed to deliver the superior wireless network that your clients
want, the SRXN3205 makes it easy to move up to 802.11n. Operating in either 2.4 GHz or
5.0 GHz radio bands, the SRXN3205 provides the flexibility to transition from legacy networks.
Select the 2.4 GHz radio band to gain superior wireless connection while maintaining support
for existing 802.11g and 802.11b networks. Wireless- N clients on this network will experience
excellent throughput and range, while legacy clients will continue to function. For the full benefits
of Wireless-N, select the 5.0 GHz radio band to create an overlay network that does not interfere
with the on-hand 802.11g and 802.11b devices such as older laptops, print servers, hand-held
inventory scanners, and IP cameras. Selected clients that are upgraded to this N network will
achieve the full capabilities such as:
- Up to 10x the coverage and 15x the speed of 802.11g networks
- Operating in 5 GHz radio band to avoid interference with b or g network devices
- Wireless access security features including WPA, WPA2, and 802.1x with RADIUS support
Easy to Use Auto Detect connects to your ISP quickly; the user-friendly Web-based ProSafe Control Center
configuration screen and install assistant reduce setup time. With SSL VPN tunnels, users can
quickly and securely access company data with just a Web browser. The IPsec VPN wizard
automates IPsec VPN configuration and secure remote makes it simple to connect to multiple
sites. Support for DHCP (client and server) as well as PPPoE allows for widespread deployment.
The SRXN3205 is compatible with Windows®, UNIX®, Macintosh®, and Linux®OS.
“Simply put, those looking to combine wireless, a SPI firewall, SSL VPN and a multitude of other
connectivity features need to look no further than the SRXN3205.”
Frank Ohlhorst, eWeek Channel Insider
*
25-user Office Wireless VPN Firewall

ProSafe®Wireless-N VPN Firewall SRXN3205
ProSafe Wireless-N
VPN Firewall
SRXN3205
Remote Access via
SSL VPN Tunnel
Protocol Redirection
Remote Access via
SSL Application Proxy
ProSafe Dual
WAN VPN Firewall
FVX538
ProSafe SSL VPN
Concentrator 25
SSL312
Users Users
Remote Office Main Office
Internet
SSL VPN tunnel built through a dissolvable browser-based client on the taskbar
Use a simple Web browser to build an SSL VPN tunnel - no separate client software needed!
“The unit works fine and the wireless range is excellent. I would recommend and install it at customer sites. The
SSL-VPN feature gives it an edge over the competition and offers an easy upgrade to clients who want to move
up from using a standard ADSL connection to wireless with firewall and MultiNAT.”
Mike Fodden, Raven Systems, United Kingdom
“I found the wireless range to be excellent, and got increased range over my previous firewall. The internet
performance is especially good for streaming video (iPlayer etc) performance was absolutely flawless, even
with other clients connected. Several of my customers will be replacing their current router with this device.”
Andy Miller, Miller Systems, United Kingdom

Technical Specifications
Client System Requirements•
2.4 GHz 802.11n draft specifications–
or 2.4 GHz 802.11b/g wireless
adapter
Microsoft Windows Vista– ®, XP, 2000,
98, Me, Apple OSX, UNIX, Linux
Internet Explorer 6.0, Mozilla–
Firefox®1.5
Wireless•
IEEE 802.11n draft 2.0 spec, 2.4 GHz–
and 5.0 GHz
IEEE 802.11a 5.0 GHz–
IEEE 802.11g, IEEE 802.11b, 2.4 GHz–
Wi-Fi Protected Access– TM (WPA, WPA2)
with TKIP and AES
Wired Equivalent Prviacy (WEP) 64 bit,–
128-biy encryptions for IEEE 802.11b
and 802.11g
IEEE 802.1x RADIUS authentication–
with EAP TLS, TTLS, PEAP
2 dipole antennas–
1 patch antenna–
Three (3) reverse SMA antenna–
connectors
SPI Firewall•
Stateful packet inspection–
- prevents DoS attacks
- stealth mode
- user support: unrestricted
Keyword filtering on:–
- address
- service (FTP, SMTP, HTTP, RPL, SNMP,
DNS, ICMP, NNTP, POP3, SSH)
- protocol
- Web UTL port / service blocking
- ActiveX, Java, Javascript
Port/Service Blocking–
IPsec VPN Functionality•
5 dedicated IPsec VPN tunnels–
Manual and Internet Key Exchange–
Security Association (IKE SA)
assignment
- preshared key signature
- RSA/DSA signature
Key life & IKE lifetimes time settings–
Perfect forward secrecy–
Diffie-Hellman groups 1 and 2–
Oakley Support–
Operating modes:–
- main
- aggressive
Fully qualified domain name–
(FQDN support) for dynamic IP
address VPN connections
IPsec Support•
DES (56 bit), 3DES(168 bit), AES–
(256 bit) encryption algorithm
MD5 or SHA-1 hashing algorithm–
ESP support–
PKI features with x.509 v.3 certificate–
support
remote access VPN (client-to-site),–
site-to-site VPN
IPsec NAT traversal (VPN pass-through)–
SSL VPN Functionality•
5 dedicated SSL VPN tunnels–
SSL version support: SSLv3 and TLS1.0–
SSL encryption support: DES, 3DES,–
ARC4, AES (ECB, CBC, XCBC, CNTR)
128/256 bit
SSL message integrity: MD5, SHA-1,–
MAC-MDS/SHA-1, HMAC-MD5/SHA-1
Certificate Support:–
- RSA
- Diffie-Hellman
- Self-signed
Routing Modes of Operation•
Many-to-one Multi-network Address–
Translation (NAT)
Classical routing–
IP Address Assignment•
Static IP address assignment–
Internal DHCP server of LAN–
DHCP client on WAN–
PPoE client support–
Throughput•
LAN-to-WAN:60 Mbps–
Connections: 20,000 concurrent–
sessions
VPN throughput: 20 Mbps–
HW Specifications•
Dimensions: 252.7 x 179.5 x 35.1 mm–
(9.95 x 7.07 x 1.38 in)
Weight: 1.34 kg (2.95 lb)–
Processor speed: 300 MHz–
Memory: 64 MB RAM, 16 MB flash–
Power supply: Output 12V/18W–
Environmental Specifications•
Operating temperature: 0° - 40° C–
(32° - 104° F)
Operating humidity: 90% maximum–
relative humidity
Physical Interfaces•
1 Gigabit Ethernet RJ45 WAN–
4 Gigabit Ethernet RJ45 LAN–
Management Features
Administration Interface•
SNMP (v2c) support–
Web graphic user interface–
Secure Sockets Layer (SSL) remote–
management
User name and password protected–
Secure remote management support–
authenticated through IP address (or IP
address range) and password
Configuration changes/upgrades–
through Web GUI
Logging•
SYSLOG–
Email alerts–
Functions•
VPN Wizard to simplify configuration–
of IPsec VPNs
Auto Detect to automatically detect ISP–
address type (static, dynamic, PPPoE)
Port range forwarding–
Port triggering–
Enable/disable WAN ping–
DNS proxy–
MAC address cloning/spoofing–
Network Time Protocol NTP support–
Diagnostic tools (ping, DNS lookup,–
trace route, other)
Port/service–
Auto-Uplink on switch ports–
L3 Quality of Service (QoS)–
LAN-to-WAN and WAN-to-LAN (ToS)–
Warranty
NETGEAR Lifetime Warranty– †
Package Contents
ProSafe Wireless-N VPN Firewall–
(SRXN3205)
Two (2) 5 dBi antennas and one (1)–
3 dBi antenna
Ethernet cable–
Power adapter–
User guide–
Resource CD with single-user ProSafe–
VPN Client Software license
Warranty/support information card–
ProSafe®Wireless-N VPN Firewall SRXN3205

350 E. Plumeria Drive
San Jose, CA 95134-1911 USA
1-888-NETGEAR (638-4327)
E-mail: [email protected]
www.NETGEAR.com
© 2009 NETGEAR, Inc. NETGEAR, the NETGEAR Logo, NETGEAR Digital Entertainer Logo, Connect with Innovation, FrontView, IntelliFi,
PowerShift, ProSafe, ProSecure, RAIDar, RAIDiator, X-RAID, RangeMax, ReadyNAS and Smart Wizard are trademarks of NETGEAR, Inc. in
the United States and/or other countries. Mac and the Mac logo are trademarks of Apple Inc., registered in the U.S. and other countries.
Other brand names mentioned herein are for identification purposes only and may be trademarks of their respective holder(s). Information
is subject to change without notice. All rights reserved.
*Basic technical support provided for 90 days from date of purchase.
†Lifetime warranty for product purchased after 05/01/2007.
This product comes with a limited warranty, the acceptance of which is a condition of sale.
D-SRXN3205-6
NETGEAR Related Products
Software•
VPN01L and VPN05L ProSafe VPN–
Client Software
Adapters•
RangeMax™ Wireless Notebook–
Adapter (WN511B)–
RangeMax™ Wireless USB 2.0–
Adapter (WN111)–
RangeMax™ Dual Band Wireless–
USB 2.0 Adapter (WNDA3100)–
Ordering Information
North America: SRXN3205-100NAS–
Asia: SRXN3205-100AUS–
Europe: SRXN3205-100EUS–
ProSupport Service Packs
Available
OnCall 24x7, Category 1•
PMB0331-100 (US)–
PMB0331 (non-US)–
XPressHW, Category 1•
PRR0331–
ProSafe®Wireless-N VPN Firewall SRXN3205
