NETGEAR DS104 User manual

NETGEAR’s DS100 Series 10/100 Mbps Dual Speed Stackable Hubs
connect PCs to share e-mail, Internet access, printers, and files.Their
exceptional adaptability enables you to mix and match 10 and 100 Mbps
PCs, servers, and peripherals on the same network with ease and without
any configuration required. Every hub in the DS100 family offers multiple
capabilities in a very compact and affordable unit, particularly designed for
small business use.
ALERT
Auto-sensing dual-speed ports individually sense and adjust to run at 10 or 100 Mbps,
allowing you to upgrade your network speed effortlessly.
SELF-RELIANT
Every port automatically operates at the proper speed, while the built-in 10 to
100 Mbps bridge automatically discovers where each user is and filters or forwards
traffic accordingly.
EXPLICIT
Network ports with built-in LEDs provide clear and intuitive status for instant
feedback on hub connections and of network activity.
MIX & MATCH
All devices on the same network—whether connected at 10 Mbps or 100 Mbps—operate
at maximum performance.
NEAT
Compact metal case design gives you an uncluttered desktop and enables
wall-mount installation.
NETGEAR’s Dual Speed hubs—
highly capable and very compact
DS104 DS106 DS108 DS116
Dual Speed Hub
10/100 Mbps
Help is there when you need it!
NETGEAR provides free, 24x7
telephone and e mail technical
support in English with selected
local language support during
office hours.
www.NETGEAR.com
DS104/DS108 shown

TECHNICAL SPECIFICATIONS
DS104
Network Ports
4 RJ-45 ports
Dimensions
W 158 mm (6.2”)
D 101 mm (4.0”)
H 27 mm (1.1”)
Weight
0.4 kg (.87 lb)
AC Power
10 W
Standards Compliance
IEEE 802.3i 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
Built-in 10-to-100 Mbps bridge
Compatible with all popular network software, including Windows®,
NetWare, and Unix
Status LEDs
Unit: power
10 Mbps segment
100 Mbps segment
Per network port: 10 or 100 Mbps operations link, receive data
Power Adapter
12VDC 1.2A (DS104/106/108)
5VDC 5.0A (DS116)
Localized plug for North America, Japan, UK, Europe, Australia
Environmental Specifications
Operating temperature: 0 to 40° C
Operating humidity: 90% maximum relative humidity, noncondensing
DS106
6 RJ-45 ports
W 235 mm (9.3”)
D 101 mm (4.0”)
H 27 mm (1.1”)
0.58 kg (1.3 lb)
12 W
DS108
8 RJ-45 ports
W 235 mm (9.3”)
D 101 mm (4.0”)
H 27 mm (1.01”)
0.74 kg (1.7 lb)
13 W
Electromagnetic Compliance
CE mark, commercial
FCC Part 15 Class A
EN 55 022 (CISPR 22), Class A
VCCI Class A
C-Tick
Safety Agency Approvals
(power adapter)
UL listed (UL 1950), cUL
TUV licensed (EN 60 950)
T-Mark
Warranty
Hub: 5 years
AC adapter: 2 years
PACKAGE CONTENTS
Dual speed hub
2-piece power switcher and cord
Wall-mount kit
User guide and Warranty card
www.NETGEAR.com
NETGEAR Inc.
4500 Great America Parkway
Santa Clara, CA 95054
USA
Phone: 1-888-NETGEAR
E-mail: [email protected]
www.NETGEAR.com
In Country Phone Support
(24x7 phone support in English, local language support during office hours.) NETGEAR™ is a trademark of
NETGEAR, Inc.Windows® is
a registered trademark of
Microsoft Corporation. Other
brand and product names are
trademarks or registered
trademarks of their respective
holders. Information is subject
to change without notice.
All rights reserved. October 2000
Korea 00308-11-0319
Netherlands 0800-023-0981
New Zealand 00800-1233-4566
Norway 800-12041
Singapore 001-800-1233-4566
Sweden 0200-298-298
Switzerland 00800-0638-4327
(00800-0-NETGEAR)
United Kingdom 020-7216-0014
United States 1-888-NETGEAR
All Other Countries [phone]
Australia 1800-787-638
Austria 00800-06384327
(00800-0-NETGEAR)
Denmark 808-82179
Canada 1-888-NETGEAR
Finland 0800-111-036
France 0800-77-17-53
Germany 00800-06384327
(00800-0-NETGEAR)
Hong Kong 001-800-1233-4566
Japan 0120-66-5402
DS116
16 RJ-45 ports
W 286 mm (11.3”)
D 101 mm (4.0”)
H 27 mm (1.1”)
0.9 kg (2.0 lb)
18 W
D-DS100-001
