NETGEAR AV Series User manual

Audio Video User Manual
AV Line of Fully Managed Switches
M4250 Series
NETGEAR, Inc.
350 E. Plumeria DriveOctober 2022
San Jose, CA 95134, USA202-12148-06

Support and Community
Visit netgear.com/support to get your questions answered and access the latest
downloads.
You can also check out our NETGEAR Community for helpful advice at
community.netgear.com.
Regulatory and Legal
Si ce produit est vendu au Canada, vous pouvez accéder à ce document en français
canadien à https://www.netgear.com/support/download/.
(If this product is sold in Canada, you can access this document in Canadian French at
https://www.netgear.com/support/download/.)
For regulatory compliance information including the EU Declaration of Conformity, visit
https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy-policy.
By using this device, you are agreeing to NETGEAR’s Terms and Conditions at
https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the
device to your place of purchase within your return period.
Do not use this device outdoors. The PoE source is intended for intra building connection
only.
Applicable to 6 GHz devices only: Only use the device indoors. The operation of 6 GHz
devices is prohibited on oil platforms, cars, trains, boats, and aircraft, except that
operation of this device is permitted in large aircraft while flying above 10,000 feet.
Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or
communications with unmanned aircraft systems.
Trademarks
© NETGEAR, Inc., NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
Revision History
CommentsPublish DatePublication Part
Number
We added new templates for Shure, and support for Extron NAV and
Wyrestorm products to Overview of preconfigured AV profile templates
on page 15.
October 2022202-12148-06
We changed Supported Switches on page 9.May 2022202-12148-05
2
AV Line of Fully Managed Switches M4250 Series

(Continued)
CommentsPublish DatePublication Part
Number
We added the following chapters:
Multicast on page 41
Port Configuration on page 56
December 2021202-12148-04
We added the following sections in existing chapters:
Log in to the AV UI using the management interface default IP address
on page 10
Log in to the AV UI over the OOB port on page 11
About audio video bridging on page 16
About PTP residency time stamping on page 17
Configure PTP residency time stamping on page 29
Configure the IGMP querier for a network profile on page 30
Display the total PoE consumption for the switch on page 55
Management interface IP address on page 78, including Set a fixed IP
address for the management interface on page 78
and Enable the DHCP client for the management interface on page 79
OOB port IP address on page 80, including Set a fixed IP address for the
OOB port on page 80 and Enable the DHCP client for the OOB port on
page 81
Display or clear the port statistics on page 94
Access the CLI through the terminal in the AV UI on page 99
We changed the following sections:
Overview of preconfigured AV profile templates on page 15
Set the STP network redundancy for the switch on page 82
We made other minor changes throughout the manual.
3
AV Line of Fully Managed Switches M4250 Series

(Continued)
CommentsPublish DatePublication Part
Number
We added the following chapters:
Security on page 62
Diagnostics and Troubleshooting on page 91
March 2021202-12148-03
We added the following sections to existing chapters:
Auto-Trunk overview on page 27
Enable or disable Auto-Trunks on page 29
Auto-LAG overview on page 34
Enable or disable Auto-LAGs on page 35
Configure the hash mode for Auto-LAGs on page 36
Save the running configuration on page 73
Download the running configuration on page 74
Restore the configuration on page 75.
Set the STP network redundancy for the switch on page 82
Display the status of the ports and switch on page 86
Display the neighboring devices on page 90
We changed the following sections:
Supported Switches on page 9
Use an AV profile template to configure and assign a network profile on
page 19
Create a custom AV profile template on page 23
Manage PoE interface settings on page 47
Save the running configuration on page 73
We added the following chapters:
Link Aggregation on page 33
Power over Ethernet on page 46
November 2020202-12148-02
We added a DHCP server option to Use an AV profile template to
configure and assign a network profile on page 19.
First publication.September 2020202-12148-01
4
AV Line of Fully Managed Switches M4250 Series

Contents
Chapter 1 Getting Started with the AV UI
Supported Switches..............................................................................9
Available publications..........................................................................9
AV local browser UI overview..............................................................9
Use a web browser to log in to the AV UI........................................10
Log in to the AV UI using the management interface default IP
address............................................................................................10
Log in to the AV UI over the OOB port.......................................11
Log in to the AV UI with a known IP address..............................12
Save the running configuration to the startup configuration........12
Register your switch...........................................................................12
Chapter 2 Audio-Video Profile Templates and Network Profiles
Overview of preconfigured AV profile templates..........................15
About audio video bridging.............................................................16
About PTP residency time stamping................................................17
Network profiles.................................................................................18
Change the Default VLAN profile................................................18
Use an AV profile template to configure and assign a network
profile..............................................................................................19
Change a network profile.............................................................21
Remove a network profile.............................................................22
Custom AV profile templates............................................................23
Create a custom AV profile template..........................................23
Change a custom AV profile template........................................25
Remove a custom AV profile template........................................27
Auto-Trunk overview..........................................................................27
Enable or disable Auto-Trunks.........................................................29
Configure PTP residency time stamping.........................................29
Configure the IGMP querier for a network profile.........................30
Chapter 3 Link Aggregation
Auto-LAG overview............................................................................34
Enable or disable Auto-LAGs............................................................35
Configure the hash mode for Auto-LAGs........................................36
Create a LAG.......................................................................................37
5

Change a LAG.....................................................................................38
Remove a LAG....................................................................................39
Chapter 4 Multicast
Configure the multicast mode for one or more ports...................42
Add or remove blocked multicast address ranges........................43
Display the multicast groups in your network.................................44
Chapter 5 Power over Ethernet
Manage PoE interface settings.........................................................47
Disable PoE for one or more interfaces...........................................50
PoE schedules.....................................................................................51
Create a PoE schedule..................................................................51
Change a PoE schedule................................................................54
Remove a PoE schedule................................................................54
Display the total PoE consumption for the switch..........................55
Chapter 6 Port Configuration
Administratively enable or disable one or more interfaces..........57
Add a description to one or more interfaces..................................58
Set the frame size for one or more interfaces.................................58
Configure flow control for one or more interfaces.........................59
Display detailed information about the physical ports and LAGs.61
Chapter 7 Security
Port authentication.............................................................................63
Manage port authentication for individual ports............................63
Manage 802.1X authentication.........................................................64
Remove port authentication from individual ports........................65
RADIUS servers...................................................................................66
Configure the basic settings for a RADIUS server..........................66
Remove a RADIUS server...................................................................67
Chapter 8 Manage and monitor the switch
Licenses................................................................................................70
Add a license online......................................................................70
Add a license offline......................................................................71
Delete a license..............................................................................72
Update the firmware..........................................................................72
Startup configuration.........................................................................73
Save the running configuration....................................................73
Download the running configuration..........................................74
Restore the configuration.............................................................75
Date and time settings.......................................................................75
6
AV Line of Fully Managed Switches M4250 Series

Manually set the date and time....................................................76
Configure one or more SNTP servers.........................................76
Add a system name............................................................................77
Management interface IP address....................................................78
Set a fixed IP address for the management interface...............78
Enable the DHCP client for the management interface............79
OOB port IP address..........................................................................80
Set a fixed IP address for the OOB port......................................80
Enable the DHCP client for the OOB port..................................81
Set the STP network redundancy for the switch.............................82
Restart the switch from the AV UI.....................................................84
Reset the switch to factory default settings.....................................84
Manually control the fans...................................................................85
Display the status of the ports and switch.......................................86
Display the neighboring devices......................................................90
Chapter 9 Diagnostics and Troubleshooting
Manage the switch log, console log, and command log..............92
Display or download the message log............................................93
Display or clear the port statistics.....................................................94
Send a ping, traceroute, or DNS lookup request to an IP address or
host name............................................................................................96
Perform a cable test...........................................................................97
Configure port mirroring...................................................................98
Access the CLI through the terminal in the AV UI..........................99
Download diagnostics files for technical support........................100
7
AV Line of Fully Managed Switches M4250 Series

1
Getting Started with the AV UI
This user manual is for the AV Line of Fully Managed Switches M4250 Series and covers
all M4250 switch models.
This chapter provides an overview of how you can use your switch and access the
audio-video (AV) local browser user interface (UI), in short AV UI.
The chapter contains the following sections:
• Supported Switches
• Available publications
• AV local browser UI overview
• Use a web browser to log in to the AV UI
• Save the running configuration to the startup configuration
• Register your switch
Note: For more information about the topics that are covered in this manual, visit the
support website at netgear.com/support/.
Note: Firmware updates with new features and bug fixes are made available from time
to time at netgear.com/support/download/. You can check for and download new
firmware manually. If the features or behavior of your product does not match what is
described in this guide, you might need to update your firmware.
8

Supported Switches
This AV user manual is for the NETGEAR AV Line of Fully Managed Switches M4250
Series models. For a list of M4250 switch models, visit kb.netgear.com/000064904.
Available publications
You can download the following publications for the AV Line of Fully Managed Switches
M4250 Series by visiting netgear.com/support/download.
•Installation guide
•Hardware installation guide
•Main user manual
•Audio-video user manual (this manual)
•Software administration manual
•CLI command reference manual
AV local browser UI overview
Your switch contains an embedded web server and management software for managing
and monitoring the switch. The switch functions as a simple switch without the
management software. However, you can use the management software to configure
many advanced features that can improve AV flows, switch efficiency, and overall network
performance.
The switch software includes a set of comprehensive management features for
configuring and monitoring the switch through one of the following methods:
•Audio-video local browser user interface (AV UI), either over an Ethernet network
port or over the out-of-band (OOB) port (also referred to as the service port).
•Main local browser user interface (main UI), either over an Ethernet network port or
over the OOB port.
•Simple Network Management Protocol (SNMP)
•Command-line interface (CLI)
Each of the standards-based management methods allows you to configure and monitor
the components of the switch. The method you use to manage the system depends on
your network size and requirements, and on your preference.
Audio Video User Manual9Getting Started with the AV UI
AV Line of Fully Managed Switches M4250 Series

This manual describes how to use the audio-video (AV) local browser user interface (UI)
to manage and monitor the switch. We abbreviate the audio-video local browser UI as
the AV UI.
The AV UI is a web-based management tool that lets you configure and manage
audio-video and other types of network profiles remotely using a standard web browser.
Note: To configure all available switch features, including VLANs, QoS, and ACLs, use
the main UI.
Use a web browser to log in to the AV UI
If this is the first time that you log in to the switch and you must use the default IP address
of the switch, see the information in the installation guide. You can use a web browser
to access the switch and log in. You must be able to ping the IP address of the
management interface or out-of-band (OOB) port from your computer for web access
to be available.
Note: The first time that you log in as an admin user to either the AV UI or the main UI,
no password is required (that is, the password is blank). After you log in for the first time,
you are required to specify a local device password that you must use each subsequent
time that you log in to either the AV UI or the main UI. (Using the main UI, you can change
the password again.)
Log in to the AV UI using the management interface default
IP address
Any Ethernet interface can function as the management interface.
To use the default IP address of the management interface to access the switch
over the AV UI:
1. Prepare your computer with a static IP address in the 169.254.0.0 subnet with subnet
mask 255.255.0.0.
For example, use 169.254.100.201 for your computer.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet
network port on the switch.
3. Launch a web browser.
4. Enter http://169.254.100.100 in the web browser address field:
The login page displays.
Audio Video User Manual10Getting Started with the AV UI
AV Line of Fully Managed Switches M4250 Series

5. In the Login Name field, enter admin as the user name, in the Password field, enter
your local device password, and click the AV UI Login button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The Overview page displays.
Log in to the AV UI over the OOB port
You can configure network information on the IPv4 service port, also referred to as the
out-of-band (OOB) port. The OOB port is a dedicated Ethernet port for out-of-band
management of the switch. Traffic on this port is segregated from operational network
traffic on the switch ports and cannot be switched or routed to the operational network.
By default, no IP address is set for the OOB port, but its DHCP client is enabled so that
the port can receive an IP address from a DHCP server in your network.
If the OOB port does not receive an IP address from a DHCP server in your network,
the IP address for the port is set to 192.168.0.239 with 255.255.255.0 as the subnet
mask. The same occurs if you connect the OOB port directly to a computer and reboot
the switch.
For information about setting a fixed IP address for the OOB port, see Set a fixed IP
address for the OOB port on page 80.
To use IP address 192.168.0.239 of the OOB port to access the switch over the AV
UI:
1. Prepare your computer with a static IP address in the 192.168.0.0 subnet with subnet
mask 255.255.0.0.
For example, use 192.168.0.201 and 255.255.255.0 for your computer.
2. Connect an Ethernet cable from an Ethernet port on your computer to the OOB port
on the switch.
3. Reboot the switch so that the OOB port is set to its default IP address.
4. Launch a web browser.
5. Enter http://192.168.0.239 in the web browser address field:
The login page displays.
6. In the Login Name field, enter admin as the user name, in the Password field, enter
your local device password, and click the AV UI Login button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The Overview page displays.
Audio Video User Manual11Getting Started with the AV UI
AV Line of Fully Managed Switches M4250 Series

Log in to the AV UI with a known IP address
If you did not assign a static IP address to the switch but let a DHCP server in your
network assign an IP address to switch, determine the IP address by accessing the DHCP
server or by using an IP scanner utility.
The procedures in this manual assume that you know the IP address of your switch.
To use a known IP address to access the switch over the AV UI:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. In the Login Name field, enter admin as the user name, in the Password field, enter
your local device password, and click the AV UI Login button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The Overview page displays.
Save the running configuration to the startup
configuration
After you make changes on a page of the AV UI and click the Apply button (or, in some
windows, the Save button), your changes are saved for the current session but are not
retained when you restart the switch. That is, your running configuration is not saved to
the startup configuration (the startup-config file), which means that it is not yet
permanently saved.
For information about saving your current changes (your running configuration) to the
startup configuration, see Save the running configuration on page 73.
Register your switch
To qualify for product updates and product warranty, we encourage you to register
your product.
Registration confirms that your email alerts work, lowers technical support resolution
time, and ensures your shipping address accuracy. We would also like to incorporate
your feedback into future product development. We never sell or rent your email address
and you can opt out of communications.
Audio Video User Manual12Getting Started with the AV UI
AV Line of Fully Managed Switches M4250 Series

To register your switch with NETGEAR:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. In the Login Name field, enter admin as the user name, in the Password field, enter
your local device password, and click the AV UI Login button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The Overview page displays.
4. At the top of page, from the Question/Help menu, select Register.
The NETGEAR Account Login page displays. If the page does not display, visit the
following website:
my.netgear.com/registration/login.aspx
5. Enter your NETGEAR account email address and password and click the NETGEAR
Sign In button.
If you did not yet create a NETGEAR account, click the Create an account link, follow
the directions onscreen to create an account, and then register the switch with your
NETGEAR email address and password.
Audio Video User Manual13Getting Started with the AV UI
AV Line of Fully Managed Switches M4250 Series

2
Audio-Video Profile Templates and
Network Profiles
The switch provides preconfigured audio-video (AV) profile templates that you can
configure and assign to switch ports and VLANs, thereby creating network profiles.
You can also set up your own AV profile templates.
These are the essential differences between an AV profile template and a network
profile:
•AV profile template: A preconfigured or custom template with QoS, multicast, or
PTP settings, or a combination of these settings, that you can apply to multiple
network profiles.
•Network profile: An AV profile template that you configured and assigned to one
or more switch ports, to a VLAN, and as an option, to a specific IP address.
The chapter contains the following sections:
• Overview of preconfigured AV profile templates
• About audio video bridging
• About PTP residency time stamping
• Network profiles
• Custom AV profile templates
• Auto-Trunk overview
• Enable or disable Auto-Trunks
• Configure PTP residency time stamping
• Configure the IGMP querier for a network profile
14

Overview of preconfigured AV profile
templates
An AV profile template integrates NETGEAR proprietary settings, allowing you to
optimize specific audio and video environments. You can use an AV profile template
to create one or multiple network profiles. For example, you could use the same AV
profile template to set up three network profiles based on a location within a building:
one network profile for the lobby, one for the theater, and one for the patio.
The switch provides the following preconfigured AV profile templates:
•Audio AES67: Use this template to connect the switch to AES67 audio IP devices
and their controller.
•Audio Video AVB: Use this template to connect the switch to IP audio devices that
support Audio Video Bridging (AVB).
•Audio Dante: Use this template to connect the switch to Dante audio devices and
their controller.
•Audio Q-SYS: Use this template to connect the switch to IP audio Q-SYS devices
and their controller.
•Data: Use this template to connect the switch to streaming ACN (sACN), Art-Net,
mobile ad hoc network (MANET), and other network devices as well as to computers.
•Lighting: Use this template to connect the switch to streaming ACN (sACN), Art-Net,
and MANET lighting devices.
•Shure Converged Audio and Control Network: Use this template to connect the
switch to Shure devices requiring audio and control traffic on a single VLAN.
Compatible with Dante, AES67, QSYS, and Biamp Dante devices.
•Shure Split Audio and Control Network: Use this template to connect the switch
to Shure devices requiring separation of audio and control traffic into different VLANs.
Compatible with Dante, AES67, QSYS, and Biamp Dante devices.
•Video: Use this template to connect the switch to IP video devices and their controller
when audio can be sent and received using another VLAN tag in another profile
simultaneously.
This template can support devices such as Crestron DM NVX systems, AMX SVSI
products, ZeeVee products, Aurora Multimedia products, Kramer products, Atlona
products, products that support Libav, Visionary Solutions products, Wyrestorm
products, Extron NAV products, Dante video products, and products that comply
with standardization by the SDVoE Alliance.
Audio Video User Manual15Audio-Video Profile Templates
and Network Profiles
AV Line of Fully Managed Switches M4250 Series

•Video NDI4: Use this template to connect the switch to video devices and cameras
that support Network Device Interface (NDI) version 4 with multi-TCP (mTCP)
transport.
•Video NDI5 with Dante, Q-Sys or AES67 audio: Use this template to connect the
switch to video devices and cameras that support NDI version 5 with Reliable User
Datagram Protocol (RUDP). Audio Dante, Q-SYS, or AES67 is supported at the same
time in the same VLAN.
•Video with AES67 audio: Use this template to connect the switch to IP video devices
and their controllers when AES67 audio is supported in the same VLAN.
This template can support devices such as Crestron DM NVX systems, AMX SVSI
products, ZeeVee products, Aurora Multimedia products, Kramer products, Atlona
products, products that support Libav, Visionary Solutions products, Wyrestorm
products, Extron NAV products, Dante video products, and products that comply
with standardization by the SDVoE Alliance.
•Video with Dante audio: Use this template to connect the switch to IP video devices
and their controllers when Dante audio is supported in the same VLAN.
This template can support devices such as Crestron DM NVX systems, AMX SVSI
products, ZeeVee products, Aurora Multimedia products, Kramer products, Atlona
products, products that support Libav, Visionary Solutions products, Wyrestorm
products, Extron NAV products, Dante video products, and products that comply
with standardization by the SDVoE Alliance.
•Video with Q-SYS audio: Use this template to connect the switch to IP video devices
and their controllers when Q-SYS audio is supported in the same VLAN.
This template can support devices such as Crestron DM NVX systems, AMX SVSI
products, ZeeVee products, Aurora Multimedia products, Kramer products, Atlona
products, products that support Libav, Visionary Solutions products, Wyrestorm
products, Extron NAV products, Dante video products, and products that comply
with standardization by the SDVoE Alliance.
About audio video bridging
802.1AS timing and synchronization is an audio video bridging (AVB) feature. AVB (also
referred to as 802.1AS) requires a license. For information about purchasing a license,
contact NETGEAR or your local NETGEAR reseller.
The IEEE 802.1AS standard specifies the protocol and procedures used to ensure that
the QoS requirements are guaranteed for time-sensitive applications, such as audio
and video.
The IEEE 1588 Precision Time Protocol (PTP) forms the basis of the IEEE 802.1AS
standard. PTP specifies a precise clock synchronization protocol that relies on
time-stamped packets.
Audio Video User Manual16Audio-Video Profile Templates
and Network Profiles
AV Line of Fully Managed Switches M4250 Series

Note: Another PTP feature that the switch supports, PTP residency time stamping, is
incompatible with 802.1AS on the same switch. For more information, see About PTP
residency time stamping on page 17. If you must support both AVB and PTP residency
time stamping in your network, we recommend that you use two separate switches.
About PTP residency time stamping
Precision Time Protocol (PTP, IEEE 1588) is a protocol that enables precise
synchronization of clocks with a sub-microsecond accuracy across a packet-based
network. PTP lets network devices of different precision and resolution synchronize to
a grandmaster clock through an exchange of packets across the network.
The switch supports a PTP end-to-end transparent clock that is used in the PTP residency
time stamping feature, which, by default, is enabled globally on the switch. You can
configure PTP residency time stamping globally only (see Configure PTP residency time
stamping on page 29).
Note: Another feature that the switch supports, 802.1AS (audio video bridging, or
AVB), is incompatible with PTP residency time stamping on the same switch. For more
information, see About audio video bridging on page 16 and the information below. If
you must support both PTP residency time stamping and AVB in your network, we
recommend that you use two separate switches.
Note how PTP residency time stamping and AVB function on the switch:
•Mutual exclusion between PTP residency time stamping and AVB: If you add a
network profile that is incompatible with PTP residency time stamping, such as Audio
AVB, PTP residency time stamping is globally disabled.
•AVB takes precedence over PTP residency time stamping:
-If you add a network profile that uses AVB (such as Audio AVB), you cannot
manually enable PTP residency time stamping.
-If PTP residency time stamping is enabled for a network profile (such as the Audio
Dante profile) on one port and then you enable a network profile that uses AVB
(such as Audio AVB) on another port, PTP residency time stamping is automatically
disabled.
•PTP residency time stamping can be automatically reenabled: By default, PTP
residency time stamping is globally enabled but you can disable it globally. If you
disable it and no network profile is using AVB, and then you add a network profile
Audio Video User Manual17Audio-Video Profile Templates
and Network Profiles
AV Line of Fully Managed Switches M4250 Series

that can use PTP residency time stamping (such as Audio Dante), PTP residency time
stamping is automatically and globally reenabled.
•PTP residency time stamping is not a strict requirement: Whether you need to
use PTP residency time stamping depends on your network setup rather than the
network profile that you use. Therefore, PTP residency time stamping is not a strict
requirement for the network profiles that can use it, so you can manually disable PTP
residency time stamping (see Configure PTP residency time stamping on page 29).
This flexibility lets you, for example, use Audio AVB with Audio Dante on the same
switch.
Network profiles
You can use either a preconfigured AV profile template (for example, Dante Audio) or
a custom AV profile template that you created to set up one or multiple network profiles.
Change the Default VLAN profile
The default network profile is the Default VLAN profile, which uses the Data AV profile
template and VLAN 1. All ports are untagged members of VLAN 1. You can change the
AV profile template and the member ports. For each port, you can either remove the
port from VLAN 1 or change the port to a tagged port.
To change the Default VLAN profile:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. In the Login Name field, enter admin as the user name, in the Password field, enter
your local device password, and click the AV UI Login button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The Overview page displays.
4. Select Configure > Network Profiles.
The Network Profiles page displays.
5. In the Configured Profiles table, to the right of the Default VLAN, click the 3 dots
icon and select Edit.
The Edit Profile Default window displays.
6. Select the ports to which the profile must apply.
Audio Video User Manual18Audio-Video Profile Templates
and Network Profiles
AV Line of Fully Managed Switches M4250 Series

By default, all ports are selected as untagged ports for the profile. That is, each port
is marked with a green icon.
To configure ports, do the following:
•Change a port to a tagged port: Click the port once. The port is marked with a
T icon (for tagged).
•Remove a port from the profile: Click the port twice to remove it from the
profile. The port is not marked with a green icon or T icon.
7. To change the AV profile template, from the Profile Template menu, select another
template.
The default AV profile template is the Data template.
8. To change the color for the Default VLAN for visual representation, click the box in
the Color field, and select a color.
9. Click the Apply button.
Your settings are saved. The window closes. The Network Profiles page displays
again.
10. To save the settings to the running configuration, at the top of the page, click the
Save icon or text.
Use an AV profile template to configure and assign a
network profile
When you configure a network profile, you must give the profile a name and assign it
to a VLAN. You can also assign a specific IP address to the profile and add a color for
visual representation.
To use an AV profile template to configure and assign a network profile:
1. Launch a web browser.
2. In the address field of your web browser, enter the IP address of the switch.
The login page displays.
3. In the Login Name field, enter admin as the user name, in the Password field, enter
your local device password, and click the AV UI Login button.
The first time that you log in, no password is required. However, you then must
specify a local device password to use each subsequent time that you log in.
The Overview page displays.
4. Select Configure > Network Profiles.
The Network Profiles page displays.
Audio Video User Manual19Audio-Video Profile Templates
and Network Profiles
AV Line of Fully Managed Switches M4250 Series

5. In the Profile Templates table, to the right of the AV profile template that you want
to use, do one of the following:
•Preconfigured AV profile template: Click the gear icon.
•Custom AV profile template: Click the 3 dots icon and select Configure.
The Profile Configure window displays.
6. Select the ports to add them to or exclude them from the VLAN to which the network
profile must apply:
•Untagged port: Click the port once. The port is added as an untagged port and
is marked with a green icon. To untag all ports, click the Untag all button.
•Tagged port: Click the port twice. The port is added as a tagged port and is
marked with a T icon (for tagged). To tag all ports, click the Tag all button.
•Excluded port: Do not click the port. The port is excluded and is not marked
with a green icon or T icon. To exclude all ports, click the Remove all button.
7. In the Profile Name field, enter a name for the profile.
Note: You cannot change the selection from the Profile Template menu.
8. From the VLAN ID menu, select the VLAN ID to which the template must apply.
9. To add a color to the network profile for visual representation, click the box in the
Color field, and select a color.
10. To assign a specific IP address to the network profile, and as an option, use the
network profile as a DHCP server, do the following:
a. Turn on the Edit VLAN Routing / DHCP Server toggle so that it displays green
and is positioned to the right.
The IP address menu and fields become available.
b. From the VLAN IP Settings menu, select Static or DHCP client.
By default, None is selected. If you select Static, you must specify the IP address
settings manually and you can also configure the network profile as a DHCP
server. (See the following step.)
If you select DHCP client, the network profile functions as a DHCP client and a
DHCP server in your network assigns an IP address to the network profile.
Audio Video User Manual20Audio-Video Profile Templates
and Network Profiles
AV Line of Fully Managed Switches M4250 Series
