ProSafe®Plus 5-port Gigabit Ethernet Switch Data Sheet
GS105E
*
1000
Mbps
More Capabilities beyond Plug-and-play Connectivity
Today’s growing businesses are both placing more demands on and relying more on
their network. Companies are putting more applications and demands on their Ethernet
Infrastructure. Using VoIP phones and IP cameras require more than simple plug-and-play
connectivity. Additionally, Internet-based applications such as Hotmail and Google Calendaring
have made keeping the network up a business-critical need. However, companies do not
necessarily have more money or advanced training to deal with complex managed switches.
NETGEAR’s new ProSafe Plus Switches meet this growing need by providing easy to use visibility
and limited configuration capabilities. To provide more insight into the network behavior,
ProSafe Plus Switches offer traffic monitoring for users to observe traffic behavior. Additionally,
if there are connectivity issues, these switches offer a cable diagnostic test capability that can
identify and even locate problems in the cables. To optimize traffic through the switches, ProSafe
Plus Switches offer both port and tag-based prioritization to keep latency-sensitive traffic moving
ahead of less critical packets. Also, as a means of improving security or managing collision
domains, ProSafe Smart Switches offer VLAN technology. ProSafe Plus Switches offering these
monitoring and configuration capabilities at a slight cost premium over un anaged switches,
delivering great value to the end user.
Additionally, furthering NETGEAR’s support of the environment, ProSafe Plus Switches have
power-saving Green Ethernet technology. The GS105E switch comes in a sturdy metal case
with a fan-less design for silent operation.
Features
• Use as a plug-and-play switch or use the conguration utility for
simple setup
• 5 ports deliver up to 2000 Mbps bi-directional bandwidth on each port
• Quality of Service (QoS) for prioritizing network trafc
• Virtual LAN (VLAN) support for network segmentation and security
• Troubleshoot connection problems via cable test
• Port mirroring
• Bandwidth management to avoid network congestions
• Network trafc monitoring
• Broadcast storm control
NETGEAR Green
• Up to 60% lower power consumption
• Auto power-down mode conserves energy when a port is not connected
• Less transmit power when the cable is short (under 10 m)
• Packaging manufactured with at least 80% recycled material
Quick
Configuration

ProSafe®Plus 5-port Gigabit Ethernet Switch GS105E
Features FS116 JFS524 GS105 FS116E JFS524E GS105E
10/100 Mbps Ports 16 24 16 24
10/100/1000 Mbps Ports 5 5
Auto Uplink™ ••••••
Divide network into groups (VLAN) •••
Set traffic Priority (QoS) •••
Bandwidth Control •••
Cable Test •••
Green Ethernet ••••
Rack Mountable ••
Warranty‡Lifetime Lifetime Lifetime Lifetime Lifetime Lifetime
The NETGEAR Difference
GS105E
Configurable with simple set up
Prioritize video/voice
Monitor network traffic
Create network groups
ProSafe Plus 5-port
Gigabit Ethernet Switch
(GS105E)
Connects to PCs
with Gigabit Ethernet
PCI Adapters
(GA311)
Connects to servers
with Gigabit Ethernet
PCI Adapters
(GA311)
ProSafe 8-port
Gigabit VPN Firewall (FVS318G)
ProSafe Wireless-N
Access Point
(WNAP210)
Connects to laptops
with internal Wireless-N
or Wireless-N adapters
Internet
Key
VLAN 1
VLAN 2
Connects to
broadband
modem
ReadyNAS NVX
(RNDX4250)

350 E. Plumeria Drive
San Jose, CA 95134-1911 USA
1-888-NETGEAR (638-4327)
E-mail: [email protected]
www.NETGEAR.com
Technical Specifications
Network Ports•
Five (5) 10/100/1000 Mbps–
Ethernet RJ-45 ports
Power Adapter•
12V, 1.0A power adapter, localized–
to country of sale
Power consumption: 4W–
Physical Specifications•
Dimensions (h x w x d):–
94 x 104 x 28 mm
(3.7 x 4.1 x 1.1 in)
Weight: 0.3 kg (0.66 lb)–
Switch Environmental Specifications•
Operating temperature: 32° to 122° F–
(0° to 50° C)
Operating humidity: 90% maximum –
relative humidity, non-condensing
Acoustic noise level: 0–
Mean time between failures (MTBF): –
5,905,968 hours (~ 674 years)
Status LEDs•
Power–
Link, speed, and activity indicators built–
into each RJ-45 port
Performance•
MAC address: 4 K–
Bandwidth: 10 Gpbs–
Standards Compliance•
IEEE 802.3i 10BASE-T Ethernet–
IEEE 802.3u 100BASE-TX Fast Ethernet–
IEEE 802.3ab 1000BASE-T Gigabit –
Ethernet
IEEE 802.3x full-duplex flow control–
Honors IEEE 802.1p priority tags–
Honors IEEE 802.1Q VLAN tags–
Compatible with all major–
network software
Safety Agency Approvals•
UL listed (UL 1950)/CUL, CB–
Electromagnetic Compliance•
CE mark (commercial), FCC Part 15–
Class B, EN 55022 (CISPR 22)Class B,
VCCI Class B, C-Tick
System Requirements
Ethernet Category 5 cable–
Network card for each PC–
Microsoft– ®Windows® XP or Vista for
running Configuration Utility
Warranty
NETGEAR Lifetime Warranty– ††
ProSupport Service Packs Available
OnCall 24x7, Category 1•
PMB0331-100 (US)–
PMB0331 (non-US)–
XPressHW, Category 1•
PRR0331–
Package Contents
ProSafe– ®Plus 5-port Gigabit Ethernet
Switch (GS105E)
Wall-mount kit–
12V, 1.0A power adapter–
Quick install guide–
Installation CD with configuration–
utility software
Related Products
ProSafe Plus 16-port Fast Ethernet–
Switch (FS116E)
ProSafe Plus 24-port Fast Ethernet–
Switch (JFS524E)
Ordering Information
GS105E•
North America: GS105E-100NAS–
Europe - General: GS105E-100PES–
UK: GS105E-100UKS–
Asia: GS105E-100AUS–
ProSafe®Plus 5-port Gigabit Ethernet Switch GS105E
© 2009 NETGEAR, Inc. NETGEAR, the NETGEAR Logo, NETGEAR Digital Entertainer Logo, Connect with Innovation, FrontView, IntelliFi,
PowerShift, ProSafe, ProSecure, RAIDar, RAIDiator, RangeMax, ReadyNAS, Smart Wizard, X-RAID, and X-RAID2, are trademarks and/or
registered trademarks of NETGEAR, Inc. and/or subsidiaries in the United States and/or other countries. Mac and the Mac logo are
trademarks of Apple Inc., registered in the U.S. and other countries. Other brand names mentioned herein are for identification purposes
only and may be trademarks of their respective holder(s). Information is subject to change without notice. All rights reserved.
This product comes with a limited warranty, the acceptance of which is a condition of sale. This product has been tested for quality assurance
and this product or its components may have been recycled.
*Basic technical support provided for 90 days from date of purchase.
††Lifetime warranty for product purchased after 05/01/2007.
D-GS105E-2
