NETGEAR FS108P - ProSafe Switch User manual

FS108P
ProSafe 8 Port 10/100 Switch
with 4 Port Power over Ethernet
Affordable Power over Ethernet Switching
The ProSafe FS108P provides power and data from a single point, using Power over Ethernet
(PoE) over a single Cat-5 cable. The eight Fast Ethernet ports can be used for any 10/100
Mbps link and four of these ports can supply industry-standard IEEE 802.3af power. Advanced
auto-sensing algorithm gives power only to 802.3af end devices, so no need to worry about
damaging proprietary PoE or non-PoE equipment. In addition, it discontinues the power
when PoE devices are disconnected. Easy and reliable, the ProSafe FS108P automatically
determines PoE requirements, speed, duplex, and cable type using AutoUplink™.
The affordably priced ProSafe FS108P delivers PoE to any small business network that wants
to simplify the installation of wireless access points and IP-based surveillance cameras.
These devices are optimally installed on a ceiling or high on a wall, away from most electrical
outlets. PoE eliminates the requirement for a dedicated electrical outlet to power these
devices. This allows for flexibility in situating devices where AC power is difficult to access and
lowers installation costs. Compact and flexible, the ProSafe FS108P is ideal for small business
network that want to inexpensively use PoE to deploy wireless access points and IP-based
network surveillance cameras.
Choose to plug in up to eight Ethernet or Fast Ethernet devices and mix in up to four 802.3af
IP-based devices like wireless access points or IP-based network surveillance cameras. Place these
802.3af-compliant devices where they belong – high up on walls and ceiling for maximum coverage
– or anywhere else you need them. Power and data are carried over standard Cat-5 cabling.
The standards-based ProSafe FS108P senses and adjusts for network speed and cabling type auto-
matically, for easy integration into your existing 10/100 Ethernet network. For PoE, the switch
automatically detects 802.3af-compliant devices, and supplies power as needed. Front panel LEDs
keep you informed of switch and PoE status.
Engineered for compact convenience, it features a 9-inch, durable metal case that is easily
positioned on your desktop or a wall, using the included mounting hardware. The fan-less design
quietly integrates in your small office environment.
With data switching and Power over Ethernet integrated into one unit, the FS108P saves space,
reduces cables and eliminates the requirement for dedicated electrical outlets – lowering installation
costs, simplifying installation of PoE-capable devices, and eliminating the need for electricians or
extension cords. All in all a great benefit for a modest price.
Flexible
Plug and Play
Quiet and Compact
Great Value
• Help is there when you need it!
NETGEAR provides 24x7
technical support* in English,
with selected local language
support during office hours.
FVS318 VPN Firewall FS108P ProSafe Switch
WG102 AP
WG102 AP
Desktop PCs Surveillance Camera
Internet Notebook PC with
WG511T 108 Mbps
Wireless PC Card
Notebook PC with
WG511T 108 Mbps
Wireless PC Card
ProSafe802.11g Wireless Access Point
ProSafe802.11g Wireless Access Point
LAN WLAN
ProSafe802.11g Wireless Access Point
ProSafe802.11g Wireless Access Point
LAN WLAN

Everybody’s Connecting. ™
Technical Specifications
• Network Ports:
-8 auto speed-sensing 10/100 RJ-45 ports
• Network Protocol and Standards:
-IEEE 802.3i 10BASE-T
-IEEE 802.3u 100BASE-TX
-IEEE 802.3x Flow Control
-IEEE 802.3af DTE Power via MDI
• Performance Specifications:
-Forwarding modes: Store-and-forward
-Bandwidth: 1.6 Gbps
-Network latency: Less than 20 µs for 64-byte
frames in store-and-forward mode for 100 Mbps
to 100 Mbps transmission
-Buffer memory: 96 KB embedded memory
per unit
-Address database size: 1,000 media access
control (MAC) addresses per system
-Addressing: 48-bit MAC address
-Mean Time Between Failure (MTBF): 190,000
hours (~ 21 years)
•Status LEDs:
-System: Power, PoE Maximum Power
-Per Port: Link, Activity, Speed, PoE Active,
PoE Fault
• Power Supply:
-Total Power Consumption: 44 W maximum
-802.3af Power Consumption: 32 W maximum
(Ports 1 – 4)
-48VDC, 0.8A power output; plug is localized to
country of sale
•Physical Specifications:
-Dimensions (H x W x D): 1.1 x 9.3 x 4.1 in.
(27 x 235 x 103 mm)
-Weight: 1.7 lbs. (0.74 kg)
•Environmental Specifications:
-Operating temperature: 32 to 104°F (0 to 40° C)
-Storage temperature: 14 to 158°F (-10 to 70°C)
-Operating humidity: 90% maximum relative
humidity, non-condensing
-Storage humidity: 95% maximum relative
humidity, non-condensing
-Operating altitude: 10,000 ft (3,000 m)
maximum
-Storage altitude: 10,000 ft (3,000 m) maximum
•Electromagnetic Emissions:
-CE mark, commercial
-FCC Part 15 Class B
-VCCI Class B
-EN 55022 (CISPR 22), Class B
-C-Tick
FS108P ProSafe 8 Port 10/100 Switch
• Electromagnetic Immunity:
-EN 55024
• Safety:
-CE mark, commercial
-CE/LVD EN60950
• Warranty:
-5 years for switch
-2 years for power supply
Package Contents
-ProSafe 8 Port 10/100 Switch with Power over
Ethernet FS108P
-AC Adapter
-Wall-mount kit
-Installation guide
-Warranty/Support Information card
NETGEAR Related Products
-ProSafe 802.11g Wireless Access Point WG302
-ProSafe 802.11g Wireless Access Point WG102
-FA311 NIC 10/100 Low Profile PCI Network
Interface Card
