Chapter1: Introduction |5
Introduction 1
The NETGEAR Managed Stackable Gigabit Ethernet Switch is a state-of-the-art,
high-performance, IEEE-compliant network solution. It includes powerful management features
that you can use to eliminate bottlenecks, boost performance, and increase productivity.
This guide describes hardware installation and basic troubleshooting for the following NETGEAR
switches:
• ProSafe 24-port Gigabit L2+ Managed Stackable Switch with PoE GSM7228PS
• ProSafe 48-port Gigabit L2+ Managed Stackable Switch with PoE GSM7252PS
• ProSafe 24-port Gigabit L3 Managed Stackable Switch GSM7328S
• ProSafe 48-port Gigabit L3 Managed Stackable Switch GSM7352S
These switches can be free-standing, or rack-mounted in a wiring closet or an equipment room.
For information about features for each product, see the NETGEAR website at
http://www.netgear.com.
GSM7228PS Front Panel and LEDs
The following figure shows the front panel of the GSM7228PS. The front panel contains
LEDs, a Reset button, a USB port, RJ-45 jacks, copper/fiber combo ports, and 10G SFP+
ports.
Figure 1-1 GSM7228PS Front Panel
RJ-45 jacks
LEDs Reset button SFP+ Ports
Combo Ports

6| Chapter1: Introduction
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
Table 1-1. LED Descriptions for GSM7228PS
LED Description
ID This is the stack member ID (1–8) that the software assigns to the switch.
Power • Solid green: The power module is present, is supplying power to the switch, and
is working normally.
• Solid yellow: The system is in boot-up stage.
• Blinking yellow: POS/CPU system has failed.
• Off: Power is disconnected.
Fan • Solid green: The fan is operating normally.
• Solid yellow: The fan has failed.
• Off: No fan is detected.
RPS
(redundant power
supply)
• Solid green: The redundant power supply is connected and drawing power from
the power module.
• Solid yellow: The power module power has failed or been disconnected, but the
redundant power supply is providing power to the switch.
• Blinking yellow: The redundant power supply is present, but the power has
failed.
• Off: The redundant power supply is disconnected or not present.
Stack Master • Green: The switch acts as a master unit in a stack of GSM7200PS series
switches.
• Off: The switch acts as a slave unit in a stack of GSM7200PS series switches.
PoE Max • Solid yellow: Indicates less than 7W of PoE power is available.
• Blinking yellow: Indicates the PoE MAX LED was active in the previous 2
minutes.
• Off: There is at least 7W of PoE power available for another device.
M1, M2
High-Speed I/O
Modules
(1 LED per module)
• Off: Either no module is connected, or a module is connected but not linked to
the system.
• Solid green: A module is present and is linked with the system.
• Blinking green: The port is transmitting or receiving packets.

Chapter1: Introduction |7
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
10/100/1000M Ports
(2 LEDs per port) SPD/Link/ACT LED:
• Off: No link is established on the port.
• Solid green: A valid 1000 Mbps link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 1000 Mbps.
• Solid yellow: A valid 10 Mbps or 100 Mbps link is established on the port.
• Blinking yellow: The port is transmitting or receiving packets at 10 Mbps or
100Mbps.
PoE Status LED:
• Off: No PoE powered device (PD) is connected.
• Solid green: The PoE powered device (PD) is connected and the port is
supplying power.
• Solid yellow: Indicates one of the following failures stopped power to that port:
– Short circuit on PoE power circuit.
– PoE power demand exceeds power available.
– PoE current exceeds PD's classification.
– Out of correct voltage band (44 ~ 57 VDC for af, 50~57 VDC for at).
Combo Ports
(1Link/ACT LED per
port)
• Off: No SFP module link is established on the port.
• Solid green: A valid 1000 Mbps SFP module link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 1000 Mbps.
• Solid yellow: A valid 100 Mbps SFP module link is established on the port.
• Blinking yellow: The port is transmitting or receiving packets at 100 Mbps.
Note: If port 21–24 media is changed to copper, the SFP LEDs change to Off status.
SFP+ Ports
(1 Link/ACT LED per
port)
• Off: No SFP module link is established on the port.
• Solid green: A valid 10 Gbps SFP+ module link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 10 Gbps.
Table 1-2. GSM7228PS Port PoE Power Specification
Port Power Range
1-8 0w - 30w
9-24 0w - 15.4w
Table 1-1. LED Descriptions for GSM7228PS (Continued)
LED Description

8| Chapter1: Introduction
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
GSM7228PS Rear Panel
The rear panel has two module bays, a console port, redundant power supply connector, and
a power module bay for the APS525W.
Figure 1-2 GSM7228PS Rear Panel
The module bays support any combination of the following:
• ProSafe 10-Gigabit Ethernet XFP Adapter AX741
• SFP+ Adapter AX743
• CX4 Adapter AX744
• ProSafe 24-Gigabit Stackable Module AX742.
For more information, see “Adapters and Modules Compatible with the High-Speed I/O
Module Bays” on page 2-21.
GSM7252PS Front Panel and LEDs
The following figure shows the front panel of the GSM7252PS. The front panel contains
LEDs, a Reset button, a USB port, RJ-45 jacks, copper/fiber combo ports, and 10G SFP+
ports.
Figure 1-3 GSM7252PS Front Panel
Console Stacking/XFP/SFP+/CX4 Replaceable
Power supply
module bays
connector AC Power
Connector
power supply
RJ-45 jacksLEDs Combo ports
Reset button SPF+ ports

Chapter1: Introduction |9
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
Table 1-3. GSM7252PS LED Description
LED Description
ID This is the stack member ID (1–8) that the software assigns to the switch.
Power • Solid green: The power module is present, is supplying power to the switch, and
is operating normally.
• Solid yellow: The system is in boot-up stage.
• Blinking yellow: POS/ CPU system has failed.
• Off: Power is disconnected.
Fan • Solid green: The fan is operating normally.
• Solid yellow: The fan has failed.
• Off: No fan is detected.
RPS
(redundant power
supply)
• Solid green: The redundant power supply is connected and drawing power form
the power module.
• Solid yellow: The power module has failed or been disconnected, but the
redundant power supply is providing power to the switch.
• Blinking yellow: The redundant power supply is present but the power has
failed.
• Off: The redundant power supply is disconnected or is not present.
Stack Master • Green: The switch is a master unit in a stack of GSM7200PS series switches.
• Off: The switch acts as a slave unit in a stack of GSM7200PS series switches.
PoE Max • Solid yellow: Indicates less than 7W of PoE power is available.
• Blinking yellow: Indicates the PoE MAX LED was active in the previous 2
minutes.
• Off: There is at least 7W of PoE power available for another device.
M1, M2
High-Speed I/O
Modules
(1 LED per module)
• Off: No module is present or a module is present but is not linked with the
system.
• Solid green: A module is present and linked up with the system.
• Blinking green: The port is transmitting or receiving packets.
10/100/1000M Ports
(2 LEDs per port) SPD/Link/ACT LED:
• Off: No link is established on the port.
• Solid green: A valid 1000 Mbps link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 1000 Mbps.
• Solid yellow: A valid 10/100 Mbps link is established on the port.
• Blinking yellow: The port is transmitting or receiving packets at 10/100Mbps.
PoE Status LED:
• Off: No PoE powered device (PD) is connected.
• Solid green: The PoE powered device (PD) is connected and the port is
supplying power.
• Solid yellow: Indicates one of the following failures resulted in stopping power to
that port:
– Short circuit on PoE power circuit.
– PoE power demand exceeds power available.
– PoE current exceeds PD's classification.
– Out of correct voltage band (44 ~ 57 VDC for af, 50~57 VDC for at).

10 | Chapter1: Introduction
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
GSM7252PS Rear Panel
The rear panel has two module bays, a redundant power supply connector, a console port,
and a power module bay for the APS525W.
Figure 1-4 GSM7252PS Rear Panel
The module bays support any combination of the following:
• ProSafe 10-Gigabit Ethernet XFP Adapter (AX741)
• SFP+ Adapter AX743
• CX4 Adapter AX744
• ProSafe 24-Gigabit Stackable Module AX742.
For more information, see “Adapters and Modules Compatible with the High-Speed I/O
Module Bays” on page 2-21.
ports • Off: No SFP module link is established on the port.
• Solid green: A valid 1000 Mbps SFP module link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 1000 Mbps.
• Solid yellow: A valid 100 Mbps SFP module link is established on the port.
• Blinking yellow: The port is transmitting or receiving packets at 100Mbps.
Note: If port 43~48 media is changed to copper, the SFP LEDs change to Off status.
SFP+ Ports
(1 Link/ACT LED per
port)
• Off: No SFP module link is established on the port.
• Solid green: A valid 10 Gbps SFP+ module link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 10Gbps.
Table 1-4. GSM7252PS Port PoE Power Specification
Port Power Range
1-8 0w - 30w
9-48 0w - 15.4w
Table 1-3. GSM7252PS LED Description (Continued)
LED Description
Power receptacle
Console Stacking/XFP/SFP+/CX4
Redundant
power supply
module bays connector
Replaceable
power supply

Chapter1: Introduction |11
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
GSM7328S Front Panel and LEDs
The following figure shows the front panel of the GSM7328S. The front panel contains LEDs,
a Reset button, a USB port, RJ-45 jacks, copper/fiber combo ports, and 10G SFP+ ports.
Figure 1-5 GSM7328S Front Panel
Table 1-5. LED Descriptions for GSM7328S
LED Description
ID This is the stack member ID (1–8) that the software assigns to the switch.
Master • Green: Switch acts as a master unit in a stack of GSM7300S series switches.
• Off: Switch acts as a slave unit in a stack of GSM7300S series switches.
RPS
(redundant power
supply)
• Solid green: The redundant power supply is connected (and using the power
module’s power).
• Solid yellow: The power module power has failed or been disconnected, but the
redundant power supply is providing power to the switch.
• Blinking yellow: The redundant power supply unit is present, but the power has
failed.
• Off: The redundant power supply is disconnected or not present.
Fan • Solid green: Fan operating normally.
• Solid yellow: Fan has failed
• Off: No fan detected.
PWR (power) • Solid green: Power module is present and supplies power to the switch and is
working normally.
• Solid yellow: System is in boot-up stage.
• Blinking yellow: POS/CPU system has failed.
• Off: Power is disconnected.
M1, M2
High-Speed I/O
Modules
(1 LED per module)
• Off: No module is present or a module is present but is not linked with the
system.
• Solid green: A module is present and linked up with the system.
• Blinking green: The port is transmitting or receiving packets.
RJ-45 jacks
LEDs Reset button SFP+ Ports
Combo Ports

12 | Chapter1: Introduction
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
GSM7328S Rear Panel
The rear panel has two module bays, a console port, redundant power supply connector, and
a power module for the supplied power cord.
Figure 1-6 GSM7328S Rear Panel
The module bays support any combination of the following:
• ProSafe 10-Gigabit Ethernet XFP Adapter (AX741)
10/100/1000M Ports
(2 LEDs per port) Link/ACT LED:
• Off: No link is established on the port.
• Solid green: A valid link is established on the port.
• Blinking green: The port is sending or receiving packets.
SPD LED:
• Off: No link is established on the port.
• Solid yellow: A valid 10/100 Mbps link is established on the port.
• Solid green: A valid 1000 Mbps link is established on the port.
Note: If port 21–24 media is changed to SFP, the RJ-45 LEDs change to OFF status.
SFP Ports
(1Link/ACT LED per
port)
• Off: No SFP module link is established on the port.
• Solid green: A valid 1000Mbps SFP module link is established on the port.
• Blinking green: Packet transmission or reception is occurring on the port at
1000Mbps.
• Solid yellow: A valid 100Mbps SFP module link is established on the port.
• Blinking yellow: Packet transmission or reception is occurring on the port at
100Mbps.
Note. If port 21–24 media is changed to copper, the SFP LEDs change to OFF
status.
SFP+ Ports
(1 Link/ACT LED per
port)
SPD/Link/ACT LED:
• Off: No SFP module link is established on the port.
• Solid green: A valid 10Gbps SFP+ module link is established on the port.
• Blinking green: Packet transmission or reception is occurring on the port at
10Gbps.
Table 1-5. LED Descriptions for GSM7328S (Continued)
LED Description
Power receptacle
Console Stacking/XFP/SFP+/CX4
Redundant
power supply
module bays connector
Replaceable
power supply

Chapter1: Introduction |13
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
• SFP+ Adapter AX743
• CX4 Adapter AX744
• ProSafe 24-Gigabit Stackable Module AX742.
For more information, see “Adapters and Modules Compatible with the High-Speed I/O
Module Bays” on page 2-21.
GSM7352S Front Panel and LEDs
The following figure shows the front panel of the GSM7352S. The front panel contains LEDs,
a Reset button, a USB port, RJ-45 jacks, copper/fiber combo ports, and 10G SFP+ ports.
Figure 1-7 GSM7352S Front Panel
Table 1-6. GSM7352S LED Description
LEDs Description
ID This is the stack member ID (1–8) that the software assigns to the switch.
Master • Green: The switch is a master unit in a stack of GSM7300S series switches.
• Off: The switch acts as a slave unit in a stack of GSM7300S series switches.
RPS
(redundant power
supply)
• Solid green: The redundant power supply is connected (and using the power
module’s power).
• Solid yellow: The power module’s has failed or been disconnected, but the
redundant power supply is providing power to the switch.
• Blinking yellow: The redundant power supply unit is present but the power has
failed.
• Off: The redundant power supply is disconnected or not present.
Fan • Solid green: Fan operating normally.
• Solid yellow: Fan has failed
• Off: No fan detected.
PWR (Power) • Solid green: Power module is present and is supplies power to the the switch
and is operating normally.
• Solid yellow: System is in boot-up stage.
• Blinking yellow: POS/ CPU system has failed.
• Off: Power is disconnected.
RJ-45 jacks
LEDs Reset button SFP+ Ports
Combo Ports

14 | Chapter1: Introduction
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
GSM7352S Rear Panel
The rear panel has two module bays, a redundant power supply connector, a console port,
and a power module bay for the APS135W.
Figure 1-8 GSM7352S Rear Panel
10/100/1000M Ports
(2 LEDs per port) Link/ACT LED:
• Off: No link is established on the port.
• Solid green: A valid link is established on the port.
• Blinking green: The port is sending or receiving packets.
SPD LED:
• Off: No link is established on the port.
• Solid yellow: A valid 10/100 Mbps link is established on the port.
• Solid green: A valid 1000 Mbps link is established on the port.
Note: If port 41~48 media changes to SFP, the RJ-45 LEDs change to OFF status
M1, M2
High-Speed I/O
Modules
(1 LED per module)
• Off: No module is present or a module is present but is not linked with the
system.
• Solid green: A module is present and linked up with the system.
• Blinking green: The port is transmitting or receiving packets.
SFP ports • Off: No SFP module link is established on the port.
• Solid green: A valid 1000Mbps SFP module link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 1000Mbps.
• Solid yellow: A valid 100Mbps SFP module link is established on the port.
• Blinking yellow: The port is transmitting or receiving packets at 100Mbps.
Note: If port 43~48 media is changed to copper, the SFP LEDs change to OFF
status.
SFP+ Ports
(1 Link/ACT LED per
port)
SPD/Link/ACT LED:
• Off: No SFP module link is established on the port.
• Solid green: A valid 10Gbps SFP+ module link is established on the port.
• Blinking green: The port is transmitting or receiving packets at 10Gbps.
Table 1-6. GSM7352S LED Description (Continued)
LEDs Description
Power receptacle
Console Stacking/XFP/SFP+/CX4
Redundant
power supply
module bays connector
Replaceable
power supply

Chapter1: Introduction |15
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
The module bays support any combination of the following:
• ProSafe 10-Gigabit Ethernet XFP Adapter (AX741)
• SFP+ Adapter AX743
• CX4 Adapter AX744
• ProSafe 24-Gigabit Stackable Module AX742.
For more information, see “Adapters and Modules Compatible with the High-Speed I/O
Module Bays” on page 2-21.
Safety Instructions
Use the following safety guidelines to ensure your own personal safety and to help protect
your system from potential damage.
To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment,
observe the following precautions.
• Observe and follow service markings.
- Do not service any product except as explained in your system documentation.
- Opening or removing covers that are marked with the triangular symbol with a
lightning bolt may expose you to electrical shock. Only a trained service
technician should service components inside these compartments.
• If any of the following conditions occur, unplug the product from the electrical outlet and
replace the part or contact your trained service provider:
- The power cable, extension cable, or plug is damaged.
- An object has fallen into the product.
- The product has been exposed to water.
- The product has been dropped or damaged.
- The product does not operate correctly when you follow the operating instructions.
• Keep your system away from radiators and heat sources. Also, do not block cooling
vents.
• Do not spill food or liquids on your system components, and never operate the product in
a wet environment. If the system gets wet, see the appropriate section in your
troubleshooting guide or contact your trained service provider.
• Do not push any objects into the openings of your system. Doing so can cause fire or
electric shock by shorting out interior components.
• Use the product only with approved equipment.
• Allow the product to cool before removing covers or touching internal components.
• Operate the product only from the type of external power source indicated on the
electrical ratings label. If you are not sure of the type of power source required, consult
your service provider or local power company.

16 | Chapter1: Introduction
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
• To help avoid damaging your system, be sure that the voltage selection switch (if
provided) on the power supply is set to match the power available at your location:
- 115 volts (V), 60 hertz (Hz) in most of North and South America and some Far
Eastern countries such as South Korea and Taiwan
- 100 V, 50 Hz in eastern Japan and 100 V, 60 Hz in western Japan
- 230 V, 50 Hz in most of Europe, the Middle East, and the Far East
• Also, be sure that attached devices are electrically rated to operate with the power
available in your location.
• Use only approved power cables. If you have not been provided with a power cable for
your system or for any AC powered option intended for your system, purchase a power
cable that is approved for use in your country. The power cable must be rated for the
product and for the voltage and current marked on the product's electrical ratings label.
The voltage and current rating of the cable should be greater than the ratings marked on
the product.
• To help prevent electric shock, plug the system and peripheral power cables into properly
grounded electrical outlets.
• The peripheral power cables are equipped with three-prong plugs to help ensure proper
grounding. Do not use adapter plugs or remove the grounding prong from a cable. If you
must use an extension cable, use a three-wire cable with properly grounded plugs.
• Observe extension cable and power strip ratings. Make sure that the total ampere rating
of all products plugged into the extension cable or power strip does not exceed 80
percent of the ampere ratings limit for the extension cable or power strip.
• To help protect your system from sudden, transient increases and decreases in electrical
power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).
• Position system cables and power cables carefully; route cables so that they cannot be
stepped on or tripped over. Be sure that nothing rests on any cables.
• Do not modify power cables or plugs. Consult a licensed electrician or your power
company for site modifications.
• Always follow your local and national wiring rules.

Chapter2: HardwareInstallation |17
Hardware Installation 2
This chapter explains how to install the hardware for the Managed Stackable Gigabit Ethernet
Switch models GSM7228PS, GSM7252PS, GSM7328S, and GSM7352S.
Package Contents
Each switch is packed and shipped separately. The package contains the following items:
• Managed Stackable Gigabit Ethernet Switch with preinstalled software
• Power cord
• Rubber footpads for tabletop installation
• Rubber caps for the SFP and SFP+ sockets
• Rack-mounting kit
• Null-modem serial cable (RS-232) with 9-pin connectors
• Resource CD: The CD either includes these documents or links to access them:
- ProSafe 7200PS Managed Switch CLI Manual, Version 8.0.2
- NETGEAR 7000 Series Managed Switch Administration Guide
- NETGEAR Installation Guide for the 7000 Series Stackable Managed Switch
- This Hardware Installation Guide
• ProSafe NMS100 Network Management System 30-day trial CD-ROM

18 | Chapter2: HardwareInstallation
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
Protecting Against Electrostatic Discharge
WARNING!
Static electricity can harm delicate components inside your
system. To prevent static damage, discharge static electricity
from your body before you touch any of the electronic
components, such as the microprocessor. You can do so by
periodically touching an unpainted metal surface on the switch.
You can also take the following steps to prevent damage from electrostatic discharge (ESD):
1. When unpacking a static-sensitive component from its shipping carton, leave it in the
antistatic package until you are ready to install it. Just before unwrapping the antistatic
package, discharge static electricity from your body.
2. Before moving a sensitive component, place it in an antistatic container or package.
3. Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads,
workbench pads, and an antistatic grounding strap.
Unpacking the Hardware
Check the contents of the boxes to make sure that all items are present before installing the
switch.
1. Place the container on a clean flat surface and cut all straps securing the container.
2. Unpack the hardware from the boxes.
Carefully remove the hardware and place it on a secure and clean surface. See
<pdf>“Select a Location” on page 2-19.
3. Remove all packing material.
4. Make sure that all items are present. See “Package Contents” on page 2-17.
Note: If any item is found missing or damaged, contact your local
NETGEAR reseller for replacement.
5. Inspect the products and accessories for damage. Report any damage immediately.
Installation
Install the equipment in the sequence presented in this section:

Chapter2: HardwareInstallation |19
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
1. Select a Location. See “Select a Location” on page 2-19.
2. Install the Switch. See “Install the Switch” on page 2-20.
3. Check the installation. See “Check the Installation” on page 2-20.
4. Apply power and check the LEDs. See “Connect to Power and Check the LEDs” on
page 2-21.
Select a Location
The switch can be mounted in a standard 19-inch (48.26-centimeter) rack, wall-mounted, or
left freestanding (placed on a tabletop).
The site where you install the switch may greatly affect its performance. Before installing the
switch or switches, make sure that the chosen installation location meets the following site
requirements.
Table 2-1. Site Requirements for Switch Location
Requirements
Mounting • Desktop Installations: Provide a flat table or shelf surface.
• Rack-mount Installations: Use a 19-inch (48.3-centimeter) EIA standard
equipment rack that is grounded and physically secure. You need the
rack-mount kit supplied with your switch.
Access Locate the switch in a position that lets you access the front panel RJ-45 ports,
view the front panel LEDs, and access the rear-panel power connector.
Power source Provide a power source within 6 feet (1.8 meters) of the installation location.
Power specifications for the switch are shown in Appendix A. Be sure that the
AC outlet is not controlled by a wall switch, which can accidentally turn off power
to the outlet and the switch.
Environment Install the switch in a site free from strong electromagnetic field generators (such
as motors), vibration, dust, and direct exposure to sunlight.
Temperature The ambient switch operating temperature range is 0º to 50ºC (32º and 122ºF).
Keep the switch away from heat sources such as direct sunlight, warm air
exhausts, hot-air vents, and heaters.
Operating humidity Install the switch in a dry area with a maximum relative humidity of 90%,
noncondensing.
Ventilation Do not restrict airflow by covering or obstructing air inlets on the sides of the
switch. Keep at least 2 inches (5.08 centimeters) free on all sides for cooling. Be
sure that there is adequate airflow in the room or wiring closet where you intend
to install the switch.
Cabling Route the cable to avoid sources of electrical noise such as radio transmitters,
broadcast amplifiers, power lines, and fluorescent lighting fixtures.

20 | Chapter2: HardwareInstallation
ManagedStackableSwitchesGSM7200PSandGSM7300SSeriesHardwareInstallationGuide
Install the Switch
You can install the switch on a flat surface or in a standard 19-inch rack.
Installing the Switch on a Flat Surface
The switch ships with four self-adhesive rubber footpads. Stick one rubber footpad on
each of the four concave spaces on the bottom of the switch. The rubber footpads
cushion the switch against shock and vibrations.
Installing the Switch in a Rack
To install the switch in a rack, you will need the 19-inch rack-mount kit supplied with your
switch.
1. Attach the supplied mounting brackets to the side of the switch.
2. Use the provided Phillips head screws to fasten the brackets to the sides of the
switch.
Figure 2-9 Installing the Switch in a Rack
3. Tighten the screws with a No. 1 Phillips screwdriver to secure each bracket.
4. Align the bracket and rack holes. Use two pan-head screws with nylon washers to
fasten each bracket to the rack.
5. Tighten the screws with a No. 2 Phillips screwdriver to secure the switch in the rack.
Check the Installation
Before you apply power, perform the following checks:
1. Inspect the equipment thoroughly.
mounting
bracket
