netvox ZB11D User manual

ZB11D
ZigBeeTM- Occupancy Sensor
User Manual
Occupancy Sensor
Model: ZB11D
Version History
Date Description Version
2015-11-17 Added Netvox App control interface 0.1
Firmware: V2.1/V2.2/V2.3
Hardware: V1.0
20151117

1
Table of Contents
1. Introduction.............................................................................................................................................................. 2
2. Product Appearance.................................................................................................................................................3
3. Specification.............................................................................................................................................................. 4
4. Features..................................................................................................................................................................... 4
5. Set up......................................................................................................................................................................... 5
5-1. Turn On/ Off ZB11D...................................................................................................................................... 5
5-2. Join the ZigBee Network................................................................................................................................ 5
5-3. Infrared Sensor Detection............................................................................................................................... 5
5-4. Infrared Sensor Report....................................................................................................................................6
5-5. Wake up ZB11D............................................................................................................................................. 6
5-6. Battery Power and Low Voltage Alarm......................................................................................................... 7
5-7. Restore to Factory Setting...............................................................................................................................7
5-8. Testing Mode Set-up.......................................................................................................................................7
5-9. Sleeping Mode................................................................................................................................................ 7
5-10. Binding..........................................................................................................................................................7
6. Home Automation Clusters for ZB11D................................................................................................................. 8
7. Netvox App control................................................................................................................................................ 10
8. Installation...............................................................................................................................................................12
9. Important Maintenance Instructions................................................................................................................... 16

2
1. Introduction
Netvox ZB11D, an infrared radiation (IR) occupancy sensor, acts as an End Device in ZigBee network. It does not
perform permit-join function as a coordinator or a router for other devices to join the network. When ZB11D
detects movement, it reports the message to the ZigBee network.
What is ZigBee?
ZigBee is a short range wireless transmission technology based on IEEE802.15.4 standard and supports multiple
network topologies such as point-to-point, point-to-multipoint, and mesh networks. It is defined for a
general-purpose, cost-effective, low-power-consumption, low-data-rate, and easy-to-install wireless solution for
industrial control, embedded sensing, medical data collection, smoke and intruder warning, building automation
and home automation, etc.

3
2. Product Appearance
Indicator (Red/ Green)
Binding Key
Infrared Sensor
Auxiliary Key
Sensor Sensitivity Adjuster
Release Button

4
3. Specification
Fully IEEE 802.15.4 compliant (ZigBee Pro)
Utilizes 2.4GHz ISM band; up to 16 channels
Power supply: 2 ER14505 3.6V batteries
Up to 70 meters wireless transmission range in non-obstacle space
Easy installation and configuration
4. Features
A mounting height between 2 and 2.2 meters is recommended.
Do not aim the passive infrared sensor to a heat or cold source.
The sensor should not face open door/windows as sunlight will affect its operation.
The sensor must be mounted on a vibration-free surface.

5
5. Set up
5-1. Turn On/ Off ZB11D
(1) Load Battery: push down release button to open the case. Load two ER14505 3.6V AA batteries and then
close the case.
(2) Default state is “off” after batteries loaded. Short press binding key, two indicator flash once to show “on”
status.
(3) Press and hold binding key for 15 seconds till green light flashed slowly, release binding key to turn off.
(4) It is recommended to wait for 10 seconds between turning on and off ZB11D to prevent interruption
between energy storage elements.
5-2. Join the ZigBee Network
After ZB11D is turned on, it will search for an existing ZigBee network and send a request to join the network
automatically. While ZB11D is under the coverage of a coordinator or a router that permit-join feature is
enabled, ZB11D will join the network.
(1) Enable the permit-join function of a coordinator or a router (please refer to the user manual of the
coordinator or the router to enable the permit-join feature).
(2) Turn on ZB11D. It will start to search and join the network.
(3) The indicator will flash green once when it finds out a network to join.
(4) The indicator will flash green 5 times after it is joined successfully. Otherwise, the indicator will not flash.
(5) Support to join Zigbee network in a manner of commissioning.
(6) ZB11D will go to sleeping mode in 3 seconds if it does not join Zigbee network.
5-3. Infrared Sensor Detection
While IR detection is on, any living object triggers the sensor. ZB11D will then detect status once per second
according to (attribute: 0x0011PIRUnoccupiedToOccupiedDelay, default 1 second.) When ZB11D reaches the
threshold (attribute: 0x0012 PIRUnoccupiedToOccupiedThreshold, default 1 time), ZB11D will be “occupied”
(attribute 0x0000 Occupancy) and red indicator flashes once. Otherwise, ZB11D will return to IR detection status.
In the mean time, users are able to process customized operation by programming or configurating according to
IRDetectionTime（IRDetectionTime >= IRDisableTime，default 120 seconds).
1)、IRDetectionTime: 1~0xFFFF
Once ZB11D turns to “occupied”, ZB11D will enter IRDetectionTime duration. IR detection closes for
IR delay*70%（=PIROccupiedToUnoccupiedDelay*70%). ZB11D starts to detect from IR delay*70% to full
IR delay. If it detects events in this time, IR delay（attribute 0x0010 PIROccupiedToUnoccupiedDelay）will
extend again till there is no more IR event and IRDetectionTime is due. “Occupied” status will turn to
“Unoccpied ”. ZB11D will report to bind device the “Occupancy” status according to report time setting.
Note: default IR delay=30 seconds.
.

6
2)、IRDetectionTime: 0
Once ZB11D turns to “occupied”, IR detection closes for IR delay*70%. ZB11D starts to detect from IR
delay*70% to full IR delay. If it detects events in this time, IR delay will extend again till there is no more IR
event . “Occupied” status will turn to “Unoccpied ”. ZB11D will report to bind device the status according to
report setting.
Note:
1.During the time of “PIRUnoccupiedToOccupiedDelay”, PIR detects once per second, make sure
PIRUnoccupiedToOccupiedDelay >= PIRUnoccupiedToOccupiedThreshold.
2. Once IRDetectionTime <PIROccupiedToUnoccupiedDelay，it will automatically default to
IRDetectionTime=PIROccupiedToUnoccupiedDelay
3. PIROccupiedToUnoccupiedDelay must >= 5 seconds.
4. (APP control interface) Infrared detection means “IRDetectionTime” > = “IRDisableTime”.
(APP control interface) IR delay means “PIROccupiedToUnoccupiedDelay” must >= 5 seconds.
5-4. Infrared Sensor Report
This device supports “Voltage status” and “Occupancy status” report.
For “Voltage status” report:
(1) If ZB11D does not bind any device (ClusterId: 0001), it will not send report.
(2) After binding, ZB11D will send voltage status to bind device.
Default configuration: Min: 3600s, Max: 3600s, Report change:1
For “Occupancy status” report:
(1) If ZB11D does not bind any device (ClusterId: 0406), it will not send report.
(2) After binding, ZB11D will send voltage status to bind device.
Default configuration: Min: 0s, Max: 3600s, Report change:0
Note: it is recommended to set MinInterval as small as possible such like “0” for immediately detection and
avoid missing IR detection report.
5-5. Wake up ZB11D
When users would like to setup or acquire data from the device which is in sleeping mode, we have to wake
up the device as the following steps:
Step1. Press the Auxiliary Key.
Step2. The indicator flashes green 5 times when ZB11D is online.
Step3. ZB11D will broadcast the device data to the ZigBee network.
ZB11D would be in active status for 2 minutes for communication.

7
5-6. Battery Power and Low Voltage Alarm
ZB11D will send a low-power report to the ZigBee network when the operating voltage is lower than 3.2V by
default.
The related data:
Power configuration cluster (ID: 0x0001)
Battery voltage attribute (ID: 0x0020)
The reporting voltage can be adjusted. There are 4 voltages for choosing: 3.5V / 3.4V / 3.3V / 3.2V.
It is recommended that the minimal reporting internal is longer than 5-minute.
5-7. Restore to Factory Setting
To restore it to factory setting, please follow the steps:
Step1. Press and hold the Auxiliary Key for 10 seconds.
Step2. Release the button after the indicator shows fast green flashes to complete the restore.
5-8. Testing Mode Set-up
5-9. Sleeping Mode
ZB11D is designed to go into sleeping mode for power-saving in some situations:
A. While the device is in the network → the sleeping period is 5 minutes; it will wake up every 5
minutes to keep online.
B. When it doesn’t find a network to join → ZB11D will go to sleeping mode. It will wake up every 15
minutes to search a network to join.
C. Once ZB11D was joined to a network and by any chance the network is no longer existed or the
device is out of the network → ZB11D will wake up every 15 minutes to find the network it joined
before.
It never keeps in sleeping mode and continues to find out a network every 15 minutes. This condition would
consume up to 30 times power spending compared to normal-operating status. To prevent this unwanted power
consumption, we recommend that users remove the batteries to power off the device.
5-10. Binding
To bind ZB11D with other devices which support attribute 0x0000 (occupancy) of Occupancy Sensing Cluster
(0x0406),

8
6. Home Automation Clusters for ZB11D
A cluster is a set of related attributes and commands which are grouped together to provide a specific function. A
simple example of a cluster would be the On/Off cluster which defines how an on/off switch behaves. This table
lists the clusters which are supported by ZB11D.
1、End Point(s)：0x01:
2、Device ID：ZCL_HA_OCCUPANCY_SENSOR--(0x0107)
3、EndPoint Cluster ID
Server side
Client side
Mandatory
Basic (0x0000)
Power Configuration(0x0001)
Identify (0x0003)
Commissioning(0x0015)
Occupancy Sensing（0x0406）
Poll control(0x0020)
Diagnostics Cluster(0x0B05)
This lists the attributes of the basic information.
Identifier
Name
Type
Range
Access
Default
Mandatory
/ Optional
0x0000
ZCLVersion
Unsigned
8-bit integer
0x00 –
0xff
Read only
0x03
M
0x0001
ApplicationVersion
Unsigned
8-bit integer
0x00 –
0xff
Read only
-------
O
0x0002
StackVersion
Unsigned
8-bit integer
0x00 –
0xff
Read only
--
O
0x0003
HWVersion
Unsigned
8-bit integer
0x00 –
0xff
Read only
--
O
0x0004
ManufacturerName
Character
string
0 – 32
bytes
Read only
netvox
O

9
Identifier
Name
Type
Range
Access
Default
Mandatory
/ Optional
0x0005
ModelIdentifier
Character
string
0 – 32
bytes
Read only
--
O
0x0006
DateCode
Character
string
0 – 16
bytes
Read only
--------
O
0x0007
PowerSource
8-bit
Enumeration
0x00 –
0xff
Read only
-------
M
0x0010
LocationDescription
Character
string
0 – 16
bytes
Read/write
--------
O
0x0012
DeviceEnabled
Boolean
0x00 –
0x01
Read/write
0x01
M

10
7. Netvox App control
1. Add device to Netvox control system as below; an EP device shows up in the device management page.
Fig. 1
2. EP 01 is “Occupancy Sensor” type，click EP 01 to control interface：
Fig. 2

11
Infrared detection: “IRDetectionTime” > = “IRDelayTime”. (Refer to Chapter 5.3)
IR delay: “PIROccupiedToUnoccupiedDelay” > = 5 seconds. (Refer to Chapter 5.3)
Status: current status
Idle: ZB11D is not triggered.
Occupancy: ZB11D is triggered.
Note: Infrared detection and IR delay are recommended to be default value due to the power saving issue.
2. Click “About” to check device information as below:
Fig. 3

12
8. Installation
1. Indoor use only, please check the installation places.

13
2. Detection coverage

14
Horizontal projected area Space projected area
IR coverage range:
The coverage area A- Distance: 11 meters; sensing angle: 30°.
The coverage area B- Distance: 8 meters; sensing angle: 60°.
The coverage area C- Distance: 5 meters; sensing angle: 120°.
Double-sided stickers tips:
1. Clean two surfaces to stick with.
2. Tear sticker on one side; stick to the position shown product base, and smoothly press it.
3. Rip the remaining side and stick to the clean side of the wall (the direction of arrow shows up )
and press firmly around 20 seconds.

15

16
9. Important Maintenance Instructions
Please keep the device in a dry place. Precipitation, humidity, and all types of liquids or moisture can contain
minerals that corrode electronic circuits. In cases of accidental liquid spills to a device, please leave the device
dry properly before storing or using.
Do not use or store the device in dusty or dirty areas.
Do not use or store the device in extremely hot temperatures. High temperatures may damage the device or
battery.
Do not use or store the device in extremely cold temperatures. When the device warms to its normal
temperature, moisture can form inside the device and damage the device or battery.
Do not drop, knock, or shake the device. Rough handling would break it.
Do not use strong chemicals or washing to clean the device.
Do not paint the device. Paint would cause improper operation.
Handle your device, battery, and accessories with care. The suggestions above help you keep your device
operational. For damaged device, please contact the authorized service center in your area.

17
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.

18
