netvox RA08D Series User manual

RA08D Series
Wireless Multifunction CO2 Sensor
Wireless Multifunction CO2 Sensor
RA08D Series
User Manual
Copyright©Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It shall be
maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written
permission of NETVOX Technology. The specifications are subject to change without prior notice.

1
Table of Contents
1. Introduction......................................................2
2. Appearance.......................................................2
3. Features ............................................................3
4. Setup Instruction ..............................................3
4.1 On/Off.........................................................3
4.2 Network Joining .........................................3
4.3 Function Key ..............................................4
4.4 Sleeping Mode............................................4
5. Data Report ......................................................5
5.1 Example of ReportDataCmd ......................6
5.2 Example of ConfigureCmd.........................9
5.3 ReadBackUpData ..................................... 11
5.4 Example of GlobalCalibrateCmd .............12
5.5 Set/GetSensorAlarmThresholdCmd.........13
6. RA08D Series and Sensors Configuration.....15
7. Important Maintenance Instructions ..............16

2
1. Introduction
RA08D series is a Class A device based on LoRaWAN open protocol. It could be used for temperature, humidity, CO2, PIR, air
pressure, illuminance, TVOC, PM2.5, CH2O, O3, and CO detection. Data collected by sensors would be shown on the E-ink
display. Users are able to know the data through one quick peek.
Note:
For more information of RA08D series and its sensors, please refer to 6. RA08D and Sensor Configuration.
2. Appearance
PIR
Light Sensor
E-ink Display
Indicator
Function Key
Mounting Bracket

3
3. Features
SX1262 wireless communication module.
Powered by DC 12V adapter.
Compatible with LoRaWANTM Class A device.
Frequency hopping spread spectrum.
Support third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne.
4. Setup Instruction
4.1 On/Off
Power on Connect to power supply
Turn on
The green indicator flashes once.
Reboot
Press and hold the function key for 5 seconds until green indicator flashes once.
Then release the function key. The device will automatically shut down after the indicator flashes
10 times.
Reset to factory setting
Press and hold the function key for 10 seconds until green indicator flashes fast for 20 times.
The device will reset to factory setting and automatically shut down.
Power off Disconnect the power supply
Note
1. 5 seconds after power on, the device will be in engineering test mode
2
. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor
inductance and other energy storage components.
4.2 Network Joining
Never joined the network
Turn on the device to search the network to join.
The green indicator stays on for 5 seconds: Success
The green indicator remains off: Fail
Had joined the network
(without factory resetting)
Turn on the device to search the previous network to join.
The green indicator stays on for 5 seconds: Success
The green indicator remains off: Fail
Fail to join the network User is recommended to check the device verification information on the gateway or consult your
platform server provider.

4
4.3 Function Key
Press and hold for 5 seconds
Turn off and Restart
Long press the function key for 5 seconds and the green indicator flashes 10 times.
Release the function key and the green indicator flashes 10 times.
The green indicator remains off: Fail
Press and hold for 10 seconds
Reset to factory setting / Turn off
The green indicator flashes 20 times: Success
The green indicator remains off: Fail
Short press The device is in the network: green indicator flashes once, screen refreshes once, and send a data
report.
The device is not in the network: screen refreshes once and the green indicator remains off
4.4 Sleeping Mode
The device is on and
in the network
Sleeping period: Min Interval.
When the reportchange exceeds the setting value or the state changes, the device will send a data
report based on the Min Interval.
The device is on but
not in the network
Note:
1. Users should disconnect the power supply when the device is not in use.
2. Users are recommended to check the device verification information on the gateway

5
5. Data Report
After powering on, the device would refresh the information on the screen and send a version packet report along with an uplink
packet.
The device sends data based on the default configuration before any configuration is done. Please do not send commands without
turning on the device.
CO2:
Fluctuation of CO2data caused by delivery and storage time could be calibrated.
Please refer to 5.2 Example of ConfigureCmd for detailed information.
TVOC:
(1)Two hours after powering on, the data sent by devices with TVOC sensors are for reference only.
(2) If the data is way higher or below the setting, the device should be placed in an environment with fresh air for 24 to 48 hours
until the data is back to normal value.
(3) TVOC level:
Very good
< 150 ppm
Good
150-500 ppm
Medium
500-1500 ppm
Poor
1500-5000 ppm
Bad
> 5000 ppm
The information shown on the E-ink display:
The information shown on the screen is based on user’s choice of sensor. It would be refreshed by pressing the function key,
triggering
the PIR, or refreshed based on the report interval.
// FFFF of reported data and “—” on the screen means the sensors are turning on or disconnection and errors of sensors.

6
Default Setting:
Max Interval: 0x0384 (900s)
Min Interval: 0x0384 (900s)
// The Max and Min Intervals shall not be less than 5 minutes for devices with CH2O and O3 sensors.
// The Max and Min Intervals shall not be less than 3 minutes for the rest of the devices.
IRDisableTime: 0x001E (30s)
IRDectionTime: 0x012C (300s)
Data collecting and transmission:
(1)Join the network:
Press the function key (indicator flashes once) / trigger PIR, read data, refresh screen, report detected data (based on the report
interval)
(2)Without joining the network:
Press the function key / trigger PIR to get data and refresh the information on the screen.
// The interval of data packets would be 10 seconds by default.
// When the ack = 0x01, the intervals would be 30 seconds.
Note:
Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver
http://www.netvox.com.cn:8888/cmddoc to resolve uplink data.
Data report configuration and sending period are as follows:
Min. Interval
(Unit: second)
Max. Interval
(Unit: second) Detection Interval Report Interval
180 to 65535 180 to 65535 MinTime Exceed the setting value: report based on the
MinTime or the MaxTime interval
5.1 Example of ReportDataCmd
FPort: 0x06
Bytes 1 Byte 1 Byte 1 Byte Var (Fix = 8 Bytes)
Version DevieType ReportType NetvoxPayLoadData
Version– 1 bytes –0x01——the Version of NetvoxLoRaWAN Application Command Version
DeviceType– 1 byte – Device Type of Device
ReportType –1 byte–the Presentation of the NetvoxPayLoadData，according the devicetype
NetvoxPayLoadData– Fixed bytes (Fixed =8bytes)

7
Tips
1. Battery Voltage:
If the battery is equal to 0x00, it means that the device is powered by a DC power supply.
2. Version Packet:
When Report Type=0x00 is the version packet, such as 01A0000A01202307030000, the firmware version is 2023.07.03.
3. Data Packet:
When Report Type=0x01 is data packet.
(If the device data exceeds 11 bytes or there are shared data packets, the Report Type will have different values.)
4. Signed Value:
When the temperature is negative, 2's complement should be calculated.
Device
Device
Type
Report
Type NetvoxPayLoadData
RA08D 0xA0
0x01
Battery
(1Byte)
unit:0.1V
Temperature
(Signed 2Bytes)
unit:0.01°C
Humidity
(2Bytes)
unit:0.01%
CO2
(2Bytes)
Unit:1ppm
Occupy
(1Byte)
0:Un Occupy
1: Occupy
0x02
Battery
(1Byte)
unit:0.1V
AirPressure
(4Bytes)
unit:0.01hPa
Illuminance
(3Bytes)
unit:1Lux
0x03
Battery
(1Byte)
unit:0.1V
PM2.5
(2Bytes)
Unit:1 ug/m3
PM10
(2Bytes)
Unit: 1ug/m3
TVOC
(3Bytes)
Unit:1ppb
0x04
Battery
(1Byte)
unit:0.1V
HCHO
(2Bytes)
unit:1ppb
O3
(2Bytes)
unit:0.1ppm
CO
(2Bytes)
unit:0.1ppm
Reserved
(1Byte)
fixed 0x00
0x05
Battery
(1Byte)
unit:0.1V
ThresholdAlarm (4Bytes)
Bit0:TemperatureHighThresholdAlarm,
Bit1: TemperatureLowThresholdAlarm,
Bit2:HumidityHighThresholdAlarm,
Bit3: HumidityLowThresholdAlarm,
Bit4:CO2HighThresholdAlarm,
Bit5:CO2LowThresholdAlarm,
Bit6: AirPressure HighThresholdAlarm,
Bit7: AirPressure LowThresholdAlarm,
Bit8: illuminanceHighThresholdAlarm,
Bit9: illuminanceLowThresholdAlarm,
Bit10: PM2.5HighThresholdAlarm,
Bit11: PM2.5LowThresholdAlarm,
Bit12: PM10HighThresholdAlarm,
Reserved
(3Byte)
fixed 0x00

8
Uplink:
Data #1 01A00100097A151F020C01
1st byte (01): Version
2nd byte (A0): DeviceType 0xA0 －RA08D Series
3rd byte (01): ReportType
4th byte (00): Battery－DC power supply
5th 6th byte (097A): Temperature－24.26℃, 97A (Hex)= 2426 (Dec), 2426*0.01℃ = 24.26℃
7th 8th byte (151F): Humidity－54.07%, 151F (Hex) = 5407 (Dec), 5407*0.01% = 54.07%
9th 10th byte (020C): CO2－524ppm , 020C (Hex) = 524 (Dec), 524*1ppm = 524ppm
11th byte (01): Occupy－1
Data #2 01A002000001870F000032
1st byte (01): Version
2nd byte (A0): DeviceType 0xA0 －RA08D Series
3rd byte (02): ReportType
4th byte (00): Battery－DC power supply
5th - 8th byte (0001870F): Air Pressure－1001.11hPa, 0001870F (Hex) = 100111 (Dec), 100111 * 0.01 hPa = 1001.11 hPa
9th - 11th byt e(000032): illuminance－50Lux, 000032 (Hex) = 50 (Dec), 50 * 1Lux = 50Lux
Data #3 01A00300FFFFFFFF000007
1st byte (01): Version
2nd byte (A0): DeviceType 0xA0 －RA08D Series
3rd byte (03): ReportType
4th byte (00): Battery－DC power supply
5th-6th (FFFF): PM2.5 －FFFF (N/A)
7th-8th byte (FFFF): PM10－FFFF (N/A)
9th-11th byte (000007): TVOC/VOC－7ppb, 000007 (Hex) = 7 (Dec), 7*1ppb = 7ppb
Bit13: PM10LowThresholdAlarm,
Bit14: TVOCHighThresholdAlarm,
Bit15: TVOCLowThresholdAlarm,
Bit16: HCHOHighThresholdAlarm,
Bit17: HCHOLowThresholdAlarm,
Bit18:O3HighThresholdAlarm,
Bit19: O3LowThresholdAlarm,
Bit20:COHighThresholdAlarm,
Bit21: COLowThresholdAlarm,
Bit22-31:Reserved

9
Data #4 01A00400000AFFFFFFFF00
1st byte (01): Version
2nd byte (A0): DeviceType 0xA0 －RA08D Series
3rd byte (04): ReportType
4th byte (00): Battery－DC power supply
5th-6th (000A): HCHO－10ppb, 000A (Hex) = 10 (Dec), 10 * 1ppb = 10ppb
7th-8th byte (FFFF): O3－FFFF (N/A)
9th-10th byte (FFFF): CO－FFFF (N/A)
11th byte (00): Reserved
Data #5 01A0050000000001000000
1st byte (01): Version
2nd byte (A0): DeviceType 0xA0 －RA08D Series
3rd byte (05): ReportType
4th byte(00): Battery－DC power supply
5th-8th (00000001): ThresholdAlarm－1 = 00000001(binary), bit0 = 1 (TemperatureHighThresholdAlarm)
9th-11th byte (000000): Reserved
5.2 Example of ConfigureCmd
FPort: 0x07
Bytes 1 1 Var (Fix = 9 Bytes)
CmdID DeviceType NetvoxPayloadData
CmdID– 1 byte
DeviceType– 1 byte – Device Type of Device
The devicetype is listed in Netvox LoRaWAN Application Devicetype.doc
NetvoxPayLoadData– var bytes (Max=9bytes)
Description Device Cmd
ID
Device
Type NetvoxPayloadData
ConfigReport
Req
RA08D
0x01
0xA0
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
Reserved
(2Bytes,Fixed 0x00)
ConfigReport
Rsp 0x81
Status
(0x00_suA0ess)
Reserved
(8Bytes,Fixed 0x00)
ReadConfig
ReportReq 0x02 Reserved (9Bytes,Fixed 0x00)
ReadConfig
ReportRsp 0x82 MinTime (2bytes Unit:s)
MaxTime
(2bytes Unit:s)
Reserved
(2Bytes,Fixed 0x00)
