netvox R313FC User manual

Model：R313FC
Wireless Activity Timer
Wireless Activity Timer
R313FC
User Manual
Copyright© Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It shall
be maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written
permission of NETVOX Technology. The specifications are subject to change without prior notice.

1
Table of Content
1. Introduction..............................................................................................................................................................2
2. Appearance...............................................................................................................................................................3
3. Main Features...........................................................................................................................................................3
4. Set up Instruction .....................................................................................................................................................4
5. Data Report ..............................................................................................................................................................5
6. Installation................................................................................................................................................................9
7. Relative Devices.....................................................................................................................................................10
8. Important Maintenance Instruction........................................................................................................................10

2
1. Introduction
R313FC is a vibration alarm device for Netvox ClassA type device based on LoRaWAN open protocol. It can detect movement or
vibration duration of the device and is compatible with LoRaWAN protocol.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other
communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.
Widely used in long-distance, low-data wireless communications. For example, automatic meter reading, building automation
equipment, wireless security systems, industrial monitoring. Main features include small size, low power consumption,
transmission distance, anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and
gateways from different manufacturers.

3
2. Appearance
3. Main Features
Compatible with LoRaWAN
2 section 3V CR2450 button battery powered
Activity Timer
Compatible with LoRaWANTM Class A
Frequency hopping spread spectrum technology
Configuration parameters can be configured through third-party software platforms, data can be read and alarms can be set via
SMS text and email (optional)
Available third-party platform: Actility / ThingPark, TTN, MyDevices/Cayenne
Low power consumption and long battery life
Indicator
Function Key

4
4. Set up Instruction
On/Off
Power on
Insert two sections of 3V CR2450 button batteries and close the battery cover
Turn on
Press any function key and the green and red indicator flash once.
Turn off (Restore to factory setting)
Press and hold the function key for 5 seconds and the green indicator flashes 20 times.
Power off
Remove Batteries.
Note:
1. Remove and insert the battery; the device memorizes previous on/off state by default.
2. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor
inductance and other energy storage components.
3. Press any function key and insert batteries at the same time; it will enter engineer testing
mode.
Network Joining
Never joined the network
Turn on the device to search the network to join.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Had joined the network
Turn on the device to search the previous network to join.
The green indicator stays on for 5 seconds: success
The green indicator remains off: fail
Fail to join the network
(when the device is on)
Suggest to check the device verification information on the gateway or consult your platform
server provider.
Function Key
Press and hold for 5 seconds
Restore to factory setting / Turn off
The green indicator flashes 20 times: success
The green indicator remains off: fail
Press once
The device is in the network: the green indicator flashes once and sends a report
The device is not in the network: the green indicator remains off
Sleeping Mode
The device is on and in the network
Sleeping period: Min Interval.
When the reportchange exceeds setting value or the state changes: send a data report
according to Min Interval.
Low Voltage Warning
Low Voltage
2.4V

5
5. Data Report
Data report configuration and sending period are as following:
Min Interval
(Unit:second)
Max Interval
(Unit:second)
Reportable Change
Current Change≥
Reportable Change
Current Change＜
Reportable Change
Any number between
1~65535
Any number between
1~65535
Can not be 0.
Report
per Min Interval
Report
per Max Interval
The device will immediately send a version packet report and the attribute report data
The device sends data in the default configuration before any configuration is done.
Default setting:
MaxTime: Max Interval = 60 min = 3600s
MinTime: Min Interval = 60 min = 3600s
Battery Voltage Change = 0x01 (0.1V)
Threshold = 0x0003 (Threshold range: 0x0003-0x00FF; 0x0003 is the most sensitive.)
Deactivetime = 0x05 (Deactive time range: 0x01-0xFF)
Threshold:
Threshold = Critical value ÷ 9.8 ÷ 0.0625
*The gravitational acceleration at standard atmospheric pressure is 9.8 m/s2
*The scale factor of the threshold is 62.5 mg
R313FC vibration alarm:
The device detects sudden movement or vibration, and the quiescent state changes. The device waits for a certain period of
time (DeactiveTime) to enter the quiescent state and calculate the duration, sends a report of duration of vibrations, and
restarts the calculation for the next detection. If the vibration continues to occur within (DeactiveTime), the duration will be
continuously calculated till it enters the quiescent state.
Note:
The device report interval will be programmed based on the default firmware which may vary.
The interval between two reports must be the minimum time.
Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver
http://loraresolver.netvoxcloud.com:8888/page/index to resolve uplink data.

6
Example of data configuration:
FPort：0x07
Bytes
1
1
Var(Fix =9 Bytes)
CmdID
DeviceType
NetvoxPayLoadData
CmdID–1 byte
DeviceType–1 byte –Device Type of Device
NetvoxPayLoadData–var bytes (Max=9bytes)
(1) Configure device parameters MinTime = 1min, MaxTime = 1min, BatteryChange = 0.1v
Downlink: 0151003C003C0100000000
Description
Device
Cmd
ID
Devi
ceTy
pe
NetvoxPayLoadData
Config
ReportReq
R313FC
0x01
0x51
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
BatteryChange
(1byte Unit:0.1v)
Reserved
(4Bytes,Fixed 0x00)
Config
ReportRsp
0x81
Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
ReadConfig
ReportReq
0x02
Reserved
(9Bytes,Fixed 0x00)
ReadConfig
ReportRsp
0x82
MinTime
(2bytes Unit:s)
MaxTime
(2bytes Unit:s)
BatteryChange
(1byte Unit:0.1v)
Reserved
(4Bytes,Fixed 0x00)
SetR313F
TypeReq
0x03
R313FType (1Byte)
0x01_R313FA,
0x02_R313FB,
0x03_R313FC
Reserved
(8Bytes,Fixed 0x00)
SetR313F
TypeRsp
0x83
Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
GetR313F
TypeReq
0x04
Reserved
(9Bytes,Fixed 0x00)
GetR313F
TypeRsp
0x84
R313FType (1Byte)
0x01_R313FA,
0x02_R313FB,
0x03_R313FC
Reserved
(8Bytes,Fixed 0x00)
SetActive
ThresholdReq
0x05
Threshold
(2Bytes)
Deactivetime
(1Byte,Unit:1s)
Reserved
(6Bytes,Fixed 0x00)
SetActive
ThresholdRsp
0x85
Status
(0x00_success)
Reserved
(8Bytes,Fixed 0x00)
GetActive
ThresholdReq
0x06
Reserved
(9Bytes,Fixed 0x00)
GetActive
ThresholdRsp
0x86
Threshold
(2Bytes)
Deactivetime
(1Byte,Unit:1s)
Reserved
(6Bytes,Fixed 0x00)

7
The device returns:
8151000000000000000000 (configuration succeeded)
8151010000000000000000 (configuration failed)
(2) Read device configuration parameters
Downlink: 0251000000000000000000
The device returns:
8251003C003C0100000000 (current device configuration parameters)
(3) Configure device type = R313FB
( 0x01 = R313FA, 0x02 = R313FB, 0x03 = R313FC)
Downlink: 0351020000000000000000
The device returns:
8351000000000000000000 (configuration succeeded)
8351010000000000000000 (configuration failed)
(4) Read device type
Downlink: 0451000000000000000000
The device returns:
8451020000000000000000 (current device type R313FB)
(5) Configure the Threshold to 10, Deactive Time to 6s
Downlink: 0551000A06000000000000
The device returns:
8551000000000000000000 (configuration succeeded)
8551010000000000000000 (configuration failed)
(6) Read the current device type
Downlink: 0651000000000000000000
The device returns:
8651000A06000000000000 (current device type R313FB)
Example for MinTime/MaxTime logic:
Example#1 based on MinTime = 1 Hour, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange=0.1V
Max Time Max Time
Sleeping (Min Time) Sleeping (Min Time)
1H 2H 3H
Wake up and
collects data
REPORTS 2.8V
Wakes up and
collects data
REPORTS 2.8V
Wakes up and
collects data
REPORTS 2.8V

8
Note:
MaxTime=MinTime. Data will only be report according to MaxTime (MinTime) duration regardless BatteryVoltageChange value.
Example#2 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
Sleeping (MinTime) sleeping sleeping sleeping
0H 15th M 30th M 45th M 1H 2H
Example#3 based on MinTime = 15 Minutes, MaxTime= 1 Hour, Reportable Change i.e. BatteryVoltageChange= 0.1V.
MaxTime
sleeping sleeping ...
0H 15th M 30th M 45th M 1H 1H 10th M 1H 25th M 1H 40th M 1H 55th M 2H 10th M
Notes:
1) The device only wakes up and performs data sampling according to MinTime Interval. When it is sleeping, it does not collect
data.
2) The data collected is compared with the last data reported. If the data change value is greater than the ReportableChange value,
the device reports according to MinTime interval. If the data variation is not greater than the last data reported, the device
reports according to MaxTime interval.
3)We do not recommend to set the MinTime Interval value too low. If the MinTime Interval is too low, the device wakes up
frequently and the battery will be drained soon.
4) Whenever the device sends a report, no matter resulting from data variation, button pushed or MaxTime interval, another cycle
of MinTime / MaxTime calculation is started.
Wakes up and
collects data
2.8V
Does not report
Wakes up and
collects data
REPORTS 2.8V
Wakes up and
collects data
REPORT 2.8V
Wakes up and
collects data
REPORTS
2.8V
Wakes up and
collects data
2.7V |2.7-2.8|=0.1
REPORTS 2.7V
Wakes up and
collects data
2.7V
Does not report
Wakes up and
collects data
2.7V
Does not report
Wakes up and
collects data
2.7V
Does not report
Wakes up and
collects data 2.7V
Does not report
Wakes up and
collects data
2.7V
Does not report
Wakes up and
collects data
REPORTS
2.7V
Wakes up and
collects data
2.8V
Does not report
Users push the button,
REPORTS 2.7V.
Recalculate MaxTime.
Wakes up and
collects data
2.8V
Does not report
Wakes up and
collects data
2.8V
Does not report

9
6. Installation
8. Installation
1. Remove the 3M adhesive on the back of the Activity Timer
and attach the body to the surface of a smooth object (please
do not stick it to a rough surface to prevent the device from
falling off after a long time use).
Note：
Wipe the surface clean before installation to avoid dust on
the surface to affect the adhesion of the device.
Do not install the device in a metal shielded box or other
electrical equipment around it to avoid affecting the wireless
transmission of the device.
2. When the device detects a sudden movement or vibration of
the object (or electrical machinery).
Wait for a certain period of time (DeactiveTime- default 5
seconds , can be modified) to enter the quiescent state and it
sends a report of duration of vibrations, and restarts the
calculation for the next detection, the timer data will clear.
Note：
If the vibration continues to occur during this process
(quiescent state), the timer continue calculation until the
device enter the quiescent state.
Activity Timer (R313FC) is suitable for the following
scenarios:
Industrial Equipment
Industrial Instrument
Medical Instruments
When it necessary to detect the motor running time.

10
7. Relative Devices
8. Important Maintenance Instruction
Kindly pay attention to the following in order to achieve the best maintenance of the product:
• Keep the device dry. Rain, moisture, or any liquid, might contain minerals and thus corrode electronic circuits. If the device gets
wet, please dry it completely.
• Do not use or store the device in dusty or dirty environment. It might damage its detachable parts and electronic components.
• Do not store the device under excessive heat condition. High temperature can shorten the life of electronic devices, destroy
batteries, and deform or melt some plastic parts.
• Do not store the device in places that are too cold. Otherwise, when the temperature rises to normal temperature, moisture will
form inside, which will destroy the board.
• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate
structures.
• Do not clean the device with strong chemicals, detergents or strong detergents.
• Do not apply the device with paint. Smudges might block in the device and affect the operation.
• Do not throw the battery into the fire, or the battery will explode. Damaged batteries may also explode.
All of the above applies to your device, battery and accessories. If any device is not working properly, please take it to the nearest
authorized service facility for repair.
Model
Function
Appearance
R718MBA
Send an alarm when detecting vibration or movement
R718MBB
Count the number of vibration or movement
R718MBC
Count the time interval of vibration or movement
