Netvue Belle User manual

Belle Quick Guide
Hey there󺺀I’m Belle.
The A.I. home assistant.
How can I serve you?

Warning
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to
radio communications.
The antennas used for this transmitter must be installed to provide a separa-
tion distance of at least 20 cm from all persons and must not be co-located for
operating in conjunction with any other antenna or transmitter.
FCC (USA) 15.9 prohibition against eavesdropping except for the operations of
law enforcement officers conducted under lawful authority, no person shall
use, either directly or indirectly, a device operated pursuant to the provision of
this part for the purpose of overhearing or recording the private conversations
of other unless such use is authorized by all of the parties engaging in the
conversation.
CE RED
This product can be used across EU member states.

What’s In The Box
DoorbellQuick GuidePower Kit Drilling Template
Belle Quick Guide
Hey there󺺀I’m Belle.
The A.I. home assistant.
How can I serve you?
Wires
Wire Nuts Security Screw Mounting Screws
X 2X 2
Drill BitScrewdrivers Hex Key
Anchors
X 2
X 2
Wire Harness

1. More about Netvue Belle
2. Read Before Installation
3. Power Kit Installation
4. Physical Installation
5. Set Up With Netvue App
6. Status Light
7. Troubleshooting
P. 1-2
P. 3
P. 4-7
P. 8-15
P. 16-22
P. 23
P. 24-25
Installation Guide Catalogue

More About Belle
Light Sensor
Front
Lens
Button
Status Light
Speaker
Microphone
1

Back
Wi-Fi Configuration
Button
NC
Normally Closed Signal
Door Port
GND
Common Port
Power
AC 16-24V
NO
Normally Open Signal
Door Port
Security Screw
Note: Port are for door unlock.
2

1. Keep the doorbell and all accessories out of reach of children and pets.
2. Please note that Netvue Belle is only compatible with wired doorbell chime.
3. Netvue Belle requires doorbell wires or transformer which has the voltage
range from 16 to 24 VAC (≥500mA).
4. Installation tools such as drill bit and screwdriver are included in the package.
5. Please try to avoid placing doorbell close to the metal frame or electronic
devices such as microwave oven since they would interfere with Wi-Fi signal.
6. The product can only be used in proper temperature and humidity:
7. Please do not expose the camera lens to direct sunlight.
Read Before Installing
Operating temperature: -20°C - 50°C (-4°F-122°F)
Operating humidity: 0-90%
3

Power Kit Installation
The Power kit is required to ensure Netvue Belle working with your existing
doorbell chime.
Components that you need:
Power Kit Wire Harness Screwdriver
4

Step 1:
Shut off power at the breaker.
Remove the cover of your
doorbell chime.
Step 2:
Connect the wire harness
to the power kit.
5

Step 3:
Look for terminals labeled “Front” and
“Transformer”. Loosen the screws on
“Front” and “Transformer” but
do not disconnect the wires.
Step 4:
Connect the end of the wire
harness to “Front” and
“Transformer” terminals on
doorbell chime.
Note: It does not matter which
wire goes to which terminal.
6

Step 5:
Adhere the Power kit to the
side of the doorbell chime.
Step 6:
Replace the cover of your
doorbell chime.
7

Physical Installation
Components that you need:
Wires
Wire Nuts Security Screw Mounting Screws
X 2X 2
Drill BitScrewdrivers Hex Key
Anchors
X 2
X 2
8

Step 1:
Shut off the power at breaker. Remove your
existing doorbell and disconnect the wires.
Step 2:
Use the provided drilling template to mark the location
of drill holes. Then use the drill bit to drill two holes. Use
anchors if you install Netvue Belle on brick or concrete.
If you are installing on wood or siding, you would not
need those.
1. Replace Your Existing Doorbell
9

Step 3:
Push downward to detach the backplate from
Netvue Belle. Install it on the wall by mounting
screws.
10

Step 4:
Attach the provided wires to Netvue
Belle's power ports, and secure the
wires in position by tightening screws.
Then connect Netvue Belle to wires
that come out from your door by wire
nuts.
Voltage requirement󺺎
16-24VAC
11

is the common port(GND)and is required for all electronic locks. Use
and for normally open signal door ports(NO); and for normally closed
signal door ports(NC). Please choose the corresponding combination base
on the type of your door lock.
Step 5:
Read this step if you have an electromagnetic lock and want to connect it with
Netvue Belle for unlocking purpose. Otherwise, jump to Step 6.
NC
Normally Closed Signal
Door Port
GND
Common Port
NO
Normally Open Signal
Door Port
12

Step 6:
Restore the power. It may take few
minutes for Netuve Belle to power
on. Press the Wi-Fi configuration
button on its back after you hear
“ding-dong.” Then it is in the Wi-Fi
configuration mode once you see the
status light flashing blue.
13

Step 7:
Slide Netvue Belle into its backplate and start to set it up with Netvue App.
Note: Do not tighten the security screw at this moment in case you need to
make any adjustment.
14

Shut off the power supply. Run two conductor wires (#22-18ASG US standard
wire size) connecting to an AC power transformer (16-24VAC). The following
are options for Netvue Belle’s power supply:
Once you are done with Netvue Belle’s power supply, please repeat prior Step
2-7 in Replace Your Existing Doorbell section(Page 9) to finish the entire
physical installation process.
2. If You Don’t Have a Existing Doorbell
Existing facility/house Alarm Control using the AUX 16VDC
(≥500mA) power.
Standard CCTV Camera 24VAC (≥500mA) power supply/transformer.
A 16-24 VAC (≥500mA) power wall adapter/transformer outlet.
15

Set Up With The Netvue App
Download Netvue App
1. Download the Netvue App from App Store or
Google Play.
16
