Ifm Sbg2 series User manual

Operating instructions

Mechatronic flow sensor

SBY2xx

SBG2xx

SBN2xx

80008231 / 00 04 / 2015

UK

2

Contents

1 Preliminary note��4

1�1 Symbols used ��4

2 Safety instructions ��4

3 Functions and features ��5

4 Function��5

4�1 Switching function��5

4�2 Analogue function ��6

4�3 IO-Link ��8

4�3�1 General information ��8

4�3�2 Device-specific information��8

4�3�3 Parameter setting tools��8

5 Installation��9

6 Electrical connection��10

7 Operating and display elements �� 11

8 Menu��12

8�1 Process value display (RUN) and main menu��12

8�1�1 Explanation main menu ��13

8�2 Extended functions – Basic settings��14

8�2�1 Explanation basic settings (CFG) ��15

8�3 Extended functions – Min/max memory – Display ��16

8�3�1 Explanation min/max memory (MEM) ��16

8�3�2 Explanation display settings (DIS)��16

9 Parameter setting ��17

9�1 Parameter setting in general ��17

9�1�1 Select submenu��17

9�1�2 Exit parameter setting or menu level ��17

9�1�3 Change to the process value display (RUN mode) ��18

9�1�4 Locking / Unlocking ��18

9�1�5 Timeout��18

9�2 Settings for consumed quantity monitoring ��18

9�2�1 Limit value monitoring with OUT1 / hysteresis function��18

9�2�2 Limit value monitoring with OUT1 / window function ��19

3

UK

9�2�3 Configure the analogue output for volumetric flow ��19

9�3 Settings for temperature monitoring ��19

9�3�1 Limit value monitoring with OUT1 / hysteresis function��19

9�3�2 Limit value monitoring with OUT1 / window function ��19

9�3�3 Configure the analogue output for temperature��19

9�3�4 User settings (optional)��20

9�3�5 Set the standard unit of measurement for volumetric flow ��20

9�3�6 Configuration of the standard display ��20

9�3�7 Configure colour change display ��21

9�3�8 Set the damping for the switching output ��21

9�3�9 Set damping for the analogue output ��21

9�3�10 Setting of the error behaviour of the outputs ��22

9�4 Service functions ��22

9�4�1 Read the min/max values for the temperature ��22

9�4�2 Resetting all parameters to factory setting ��22

10 Operation��23

10�1 Reading the process value ��23

10�2 Reading the set parameter value ��24

10�3 Error indications / self-diagnostics��24

11 Technical data ��24

12 Factory setting ��25

4

1 Preliminary note

1.1 Symbols used

►Instructions

> Reaction, result

[…] Designation of keys, buttons or indications

→Cross-reference

Important note

Non-compliance may result in malfunction or interference�

Information_Supplementary note�

2 Safety instructions

• Please read this document prior to set-up of the unit� Ensure that the product is

suitable for your application without any restrictions�

• If the operating instructions or the technical data are not adhered to, personal

injury and/or damage to property can occur�

• Improper or non-intended use may lead to malfunctions of the unit or to un-

wanted effects in your application� That is why installation, electrical connec-

tion, set-up, operation and maintenance of the unit must only be carried out by

qualified personnel authorised by the machine operator�

• In order to guarantee the correct condition of the device for the operating time it

is necessary to use the device only for media to which the wetted materials are

sufficiently resistant (→ Technical data).

• The responsibility whether the measurement devices are suitable for the

respective application lies with the operator� The manufacturer assumes no

liability for consequences of misuse by the operator� Improper installation and

use of the units result in a loss of the warranty claims�

• During installation or in case of a fault (housing damage) media under high

pressure or hot media can leak from the system�

►Install the unit according to the applicable rules and regulations�

►Ensure that the system is free of pressure during installation�

►Ensure that no media can leak at the mounting location during installation�

5

UK

►Equip the unit with suitable protection (e�g� cover) to avoid hazard to person-

nel from leaking media�

3 Functions and features

The unit monitors liquid media (water, glycol solutions, industrial oils, coolants)�

It detects the two process categories volumetric flow or medium temperature�

4 Function

• The unit detects the volumetric flow quantity based on the principle of differen-

tial pressure�

• The unit features an IO-Link interface and is designed for full bidirectional

communication�

• The unit displays the current volumetric flow quantity or temperature� It gener-

ates 2 output signals according to the parameter setting:

OUT1/IO-Link: 4 selection options Parameter setting

- Switching signal: limit values for volumetric flow

quantity

→ 9.2.1; → 9.2.2

- or switching signal: limit values for temperature → 9.3.1; → 9.3.2

OUT2: 2 selection options Parameter setting

- Analogue signal for volumetric flow quantity → 9.2.3

- or analogue signal for temperature → 9.3.3

4.1 Switching function

OUT1 changes its switching status if it is above or below the set switching limits

(flow or temperature)� Hysteresis or window function can be selected� Example of

volumetric flow monitoring:

6

Hysteresis function Window function























FL

FH

SP = set point

rP = reset point

HY = hysteresis

Hno / Fno = NO (normally open)

FH = upper limit value

FL = lower limit value

FE = window

Hnc / Fnc = NC (normally closed)

When the hysteresis function is set, the set point (SPx) is defined first and

then the reset point (rPx) which must be of a lower value� If only the set

point is changed, the reset point remains constant�

When set to the window function the set and reset points have a fixed hys-

teresis of 0�25 % of the final value of the measuring range� This keeps the

switching status of the output stable if the volumetric flow varies slightly�

4.2 Analogue function

The unit provides an analogue current signal that is proportional to the volumetric

flow quantity and the medium temperature� Within the measuring range the output

signal is between 4 and 20 mA� Outside the measured and displayed value range

or in case of a fault the signals < 4 mA or > 20 mA are provided (→ Figures).

Caption:

1: Output current in mA

2: Volumetric ow quantity (nal value of the measuring range MEW = 100 %)

3: Medium temperature

4: Measuring range

5: Display range

6: The unit is in the error state (FOU = OFF)

7: The process value transmitted in an analogue way is therefore above the display range

8: The unit is in the error state (FOU = ON)

7

UK

A� Volumetric flow monitoring:

[% MEW]

0 100

[mA]

5

7

2

8

4

1

6

B:

Temperature monitoring:

[°C/°F]

-20 -10 100 110

5

7 8

4

6

3

[mA]

1

8

4.3 IO-Link

4.3.1 General information

This unit has an IO-Link communication interface which requires an IO-Link-capa-

ble module (IO-Link master) for operation�

The IO-Link interface enables direct access to the process and diagnostic data

and provides the possibility to set the parameters of the unit during operation�

In addition communication is possible via a point-to-point connection with a USB

adapter cable�

You will find more detailed information about IO-Link at www�ifm�com/gb/io-link�

4.3.2 Device-specific information

You will find the IODDs necessary for the configuration of the IO-Link unit and

detailed information about process data structure, diagnostic information and

parameter addresses at www�ifm�com/gb/io-link�

4.3.3 Parameter setting tools

You will find all necessary information about the required IO-Link hardware and

software at www�ifm�com/gb/io-link�

9

UK

5 Installation

IN OUT

►Insert the unit into the pipe

according to the direction of flow

(arrow) and tighten�

With water containing dirt:

►horizontal installation recom-

mended�

IN = inlet

OUT = outlet

Baffled pipes on the sensor's inlet or outlet side are not necessary�

The sensor has the function of a non-return valve�

The sensor head can be rotated by 360°�

►Do not install the unit on ferromagnetic materials�

(Ferromagnetic materials are all metals exerting an attractive force on test

magnets�)

►Do not operate the unit in the vicinity of magnetic constant and alternating

fields (e�g� welding systems)�

►If the sensors are installed side by side, observe a minimum distance of 50 mm

between the sensor axes�

10

6 Electrical connection

The unit must be connected by a qualified electrician�

The national and international regulations for the installation of electrical

equipment must be adhered to�

Voltage supply according to EN 50178, SELV, PELV�

►Disconnect power�

►Connect the unit as follows:

43

2 1

BK: black

BN: brown

BU: blue

WH: white

BN

WH

BK

BU

4

1

3

2OUT2

L+

L

OUT1

Colours to DIN EN 60947-5-2

Sample circuits:

1 x positive switching / 1 x analogue 1 x negative switching / 1 x analogue

L+

L

3 BU

4 BK

2 WH

1 BN

L+

L

3 BU

4 BK

2 WH

1 BN

Pin 1 L+

Pin 3 L-

Pin 4

(OUT1)

• Switching signal: limit values for volumetric flow quantity

• Switching signal: limit values for temperature

• IO-Link

Pin 2

(OUT2)

• Analogue signal for volumetric flow quantity

• Analogue signal for temperature

11

UK

7 Operating and display elements

3

2

1

4 5

1, 2: Indicator LEDs

• LED 1 = switching status OUT1 (lights if output 1 is switched)

• LEDs 2 = flow or temperature in the indicated unit of measurement

3: Alphanumeric display, 4 digits

• Display of current process values (volumetric flow quantity, temperature)

• Display of the parameters and parameter values�

4: Button [

●

] = Enter

• Change from the RUN mode to the main menu

• Change to the setting mode

• Acknowledge the set parameter value

5: Buttons up [▲] and down [▼]

• Select parameters

• Change parameter values (hold button pressed)

• Change of the display unit in the normal operating mode (Run mode)

• Locking / Unlocking

12

8 Menu

The parameters in the display change based on the settings in the submenus� In

the illustrations, the factory set parameters have a white background� The parame-

ters with a grey background do not become visible before change to the preset

values�

8.1 Process value display (RUN) and main menu

RUN

EF_

m

3

/h

l/min

°C

rP1

SP1 FH1

FL1

CFG, MEM, DIS

gph

gpm

°F

FEP1

FrP1

1

FSP1

FEP1

FrP1

*gpm, gph,°F for SBN2xx units

1: Output functions for OUT1

13

UK

8.1.1 Explanation main menu

Switching output with hysteresis function

SP1 Set point 1 = upper limit value at which OUT1 switches

rP1 Reset point 1 = lower limit value at which OUT1 is reset

Switching output with window function

FH1 Set point 1 = upper limit value at which OUT1 switches

FL1 Reset point 1 = lower limit value at which OUT1 switches

Extended functions

EF_ Opening of the lower menu level

14

8.2 Extended functions

–

Basic settings

Main menu

ou1 Hno Hnc Fno Fnc

P-n

dAP

dAA

SEL1

SEL2

EF

RUN

CFG

CFG_

rES

MEM_

- - - -

DIS_

FLOW TEMP

nPnPnP

0.1

0

uni m3hLmin GPHGPm

FOU1

FOU2

OFFOn OU

MEdi OILH2O OIL.2

*gpm, gph for SBN2xx units

rES Restoring the factory settings

CFG_ Submenu basic settings

MEM_ Submenu min/max memory

DIS_ Submenu display settings

15

UK

8.2.1 Explanation basic settings (CFG)

ou1 Output function OUT1

• Flow and temperature: Hno, Hnc, Fno, Fnc

Hno Hysteresis normally open

Hnc Hysteresis normally closed

Fno Window normally open

Fnc Window normally closed

uni Standard unit of measurement for volumetric flow

P-n Output logic: pnp / npn

dAP Measured value damping for switching output in seconds

dAA Measured value damping for analogue output in seconds

MEDI Medium selection for volumetric flow

FOU1 Behaviour of output OUT1 in case of an error

FOU2 Behaviour of output OUT2 in case of an error

SEL1 Standard unit of measurement for evaluation by OUT1:

volumetric flow value or medium temperature

SEL2 Standard measured variable for evaluation by OUT2:

volumetric flow value or medium temperature

16

8.3 Extended functions

–

Min/max memory

–

Display

Main menu

1234

EF

MEM

DIS

CFG_

rES

MEM_

DIS_coLr

SELd FLOW TEMP

Lo.T 1234

Hi.T

GrEnrEd

diS d2 d3d1

rd1 rd2 rd3 OFF

r1ou G1ou

8.3.1 Explanation min/max memory (MEM)

Lo�T Min� value of the temperature measured in the process

Hi�T Max� value of the temperature measured in the process

8.3.2 Explanation display settings (DIS)

coLr Assignment of the display colours red and green within the measuring

range

rEd Display always red

GrEn Display always green

r1ou Display red in case of switched output OUT1

G1ou Display green in case of switched output OUT1

diS Update rate and orientation of the display

SELd Standard measuring unit of the display: volumetric flow value or medium

temperature

17

UK

9 Parameter setting

Parameters can be set before installation and set-up of the unit or during opera-

tion�

If you change parameters during operation, this will influence the function

of the plant�

►Ensure that there will be no malfunctions in your plant�

During parameter setting the unit remains in the operating mode� It continues to

monitor with the existing parameter until the parameter setting has been completed�

The parameters can also be set via the IO-Link interface (→ 4.3)�

9.1 Parameter setting in general

1� Change from the RUN mode to the main menu [●]

2� Select the requested parameter [▲] or [▼]

3� Change to the setting mode [●]

4� Modification of the parameter value [▲] or [▼] > 1 s

5� Acknowledge the set parameter value [●]

6� Return to the RUN mode → 9.1.3

If [C�Loc] is displayed when attempting to change a parameter value, a

change is made via a parameter setting software at the same time (tempo-

rary locking)�

If [S�Loc] is displayed, the sensor is permanently locked via software� This

locking can only be removed with a parameter setting software�

9.1.1 Select submenu

► Click [▲] or [▼] to select submenu (EF, CFG, MEM, DIS).

► Briefly press [●] to change to the submenu.

9.1.2 Exit parameter setting or menu level

►Press [▲] + [▼] simultaneously�

18

> Return to the next higher menu level� The changed parameter settings are not

accepted�

9.1.3 Change to the process value display (RUN mode)

There are 3 possibilities:

1� Wait for 30 seconds (→ 9.1.5 Timeout)�

2� Change from the submenu to the main menu, from the main menu to the pro-

cess value display with [▲] or [▼].

3� Press [▲] + [▼] simultaneously until the RUN mode is reached�

9.1.4 Locking / Unlocking

The unit can be locked electronically to prevent unintentional settings� On delivery:

not locked�

Locking:

►Make sure that the unit is in the normal operating mode�

► Press [▲] and [▼] simultaneously for 10 s until [Loc] is displayed.

During operation: [LOC] is briefly displayed if you try to change parameter

values�

Unlocking:

►Make sure that the unit is in the normal operating mode�

► Press [▲] and [▼] simultaneously for 10 s until [uLoc] is displayed.

9.1.5 Timeout

If no button is pressed for 30 s during parameter setting, the unit returns to the

operating mode with unchanged values�

9.2 Settings for consumed quantity monitoring

9.2.1 Limit value monitoring with OUT1 / hysteresis function

►Select [SEL1] and set [FLOW]�

►Select [ou1] and set the switching function:

- [Hno] = hysteresis function/normally open

- [Hnc] = hysteresis function/normally closed

►Select [SP1] and set the value at which the output is set�

►Select [rP1] and set the value at which the output is reset�

Menu CFG:

[SEL1]

[ou1]

Main menu:

[SP1]

[rP1]

19

UK

9.2.2 Limit value monitoring with OUT1 / window function

►Select [SEL1] and set [FLOW]�

►Select [ou1] and set the switching function:

- [Fno] = window function/normally open

- [Fnc] = window function/normally closed

►Select [FH1] and set the value at which the output switches�

►Select [FL1] and set the value at which the output is reset�

Menu CFG:

[SEL1]

[ou1]

Main menu:

[FH1]

[FL1]

9.2.3 Configure the analogue output for volumetric flow

►Select [SEL2] and set [FLOW]� Menu CFG:

[SEL2]

9.3 Settings for temperature monitoring

9.3.1 Limit value monitoring with OUT1 / hysteresis function

►Select [SEL1] and set [TEMP]�

►Select [ou1] and set the switching function:

- [Hno] = hysteresis function/normally open

- [Hnc] = hysteresis function/normally closed

►Select [SP1] and set the value at which the output is set�

►Select [rP1] and set the value at which the output is reset�

Menu CFG:

[SEL1]

[ou1]

Main menu:

[SP1]

[rP1]

9.3.2 Limit value monitoring with OUT1 / window function

►Select [SEL1] and set [TEMP]�

►Select [ou1] and set the switching function:

- [Fno] = window function/normally open

- [Fnc] = window function/normally closed

►Select [FH1] and set the value at which the output switches�

►Select [FL1] and set the value at which the output is reset�

Menu CFG:

[SEL1]

[ou1]

Main menu:

[FH1]

[FL1]

9.3.3 Configure the analogue output for temperature

►Select [SEL2] and set [TEMP]� Menu CFG:

[SEL2]

20

9.3.4

User settings (optional)

9.3.5 Set the standard unit of measurement for volumetric flow

►Select [uni] and set the unit of measurement: l/min, m3/h (SBN2xx: gpm,

gph)�

The selectable units of measurement depend on the respective unit�

Menu CFG:

[uni]

9.3.6 Configuration of the standard display

►Select [SELd] and determine the standard measuring unit:

- [FLOW] = the current volumetric flow value in the standard unit of

measurement is displayed�

- [TEMP] = the current medium temperature in °C is displayed (SBN2xx:

°F)�

►Select [diS] and set the update rate and orientation of the display:

- [d1]: update of the measured values every 50 ms�

- [d2]: update of the measured values every 200 ms�

- [d3]: update of the measured values every 600 ms�

- [rd1], [rd2], [rd3]: display as for d1, d2, d3; rotated by 180°�

- [OFF] = The measured value display is deactivated in the Run mode�

The LEDs remain active even if the display is deactivated� Error mes-

sages are displayed even if the display is deactivated�

Menu DIS:

[SELd]

[diS]

IFM SBG2 Series User manual

Popular Accessories manuals by other brands
