NEURONIC NEURADIANT 1070 User manual

USER MANUAL

USER MANUAL

3
Content
Page
1. Overview 4
2. Getting Started 5
3. Consultation 6
4. Programs 7
5. Safety Guidelines 12
6. Service Guarantee 13
7. Disclaimers 13
8. Appendix 14
Please note this is not a medical device. This product is not
intended to diagnose, treat, cure or prevent any disease. These
statements have not been evaluated by the Food and Drug
Administration.

4
1. Overview
Thank you for purchasing our product. We are excited
for you to use our latest device, the Neuradiant 1070.
Our device is unique in that it uses the 1070nm near-
infrared wavelength and is the fi rst device that gives the
user the option to control each quadrant of the helmet
in correlation to four brain quadrants (front, back, left,
right).
Research[1] shows that photobiomodulation, which is
the term used to express the therapeutic use of light on
the body, has many benefi cial effects such as improving
the energy production in cells, accelerating blood fl ow,
enabling more oxygen circulation in the brain, and
enhancing neuroprotective proteins and growth factors.
Neuronic has partnered with the Quietmind Foundation,
a nonprofi t research and consultation organization in
the USA, that has spent the last 25 years conducting
clinical and applied research[2] involving the use of
neurofeedback and photobiomodulation. Neuronic
is providing this state of the art photobiomodulation
device, along with an hour’s brain health consultation
with a qualifi ed clinician, for instruction on how to get
the best from your device.
Marvin H. Berman, Ph.D
Co-Founder and Clinician at Neuronic

5
2. Getting Started
Packing List & Accessories
Fixation Sponges
Quick Start Guide
Instruction Manual
Connection Cables
Helmet
Power Adapters
Handbag
Control Box
Set up
Remove the helmet and
components from the case.
Take the velcro strips from the
adhesive paper and apply onto
the inside of the helmet as
shown in the diagram.
Apply the sponges or foam
headpiece onto the velcro so
the unit is fi tted during use.
Do not place any velcro on
the clear plastic inside the
helmet.
Fitting Guide
Sponges Foam
Headpiece
Velcro
1
Bottom View
Foam Headpiece Velcro

6
After connecting the cables,
you can turn on the device via
the button on the top right.
Connect the helmet with
the controller, connect the
controller with the fi rst power
adapter.
Turn on the Device
2
3. Consultation
A 1-hour consultation is offered to those who purchased
the Neuradiant 1070 and is designed to ensure safe and
effective use of the device for improving general health
and wellness. We will answer questions on the use of the
different programs, answer specifi c questions you may
have, and construct a ‘real world’ set of metrics that
will defi ne clinical progress. To book your consultation,
please email us at:
te[email protected]
Customers who purchased the Neuradiant 1070 with
the 4 quadrant function will be provided with a code
(see page 9) to access the clinical protocols and an
appointment link to arrange your 90-day personalized
consultation.
Connect the controller with
the second power adapter.
First
Adapter
Second
Adapter

7
4. Programs
The four default programs are designed to provide
specifi c types of stimulation to support the establishment
of specifi c physical and mental states. We recommend
using the device twice a day, morning and evening.
We do not recommend exceeding this daily use.
Time
The amount of time the program will run
from start to fi nish. The unit will make a
beep at the start and end of the chosen
program. The maximum time for a
program is 30 minutes.
Pulse Rate
The pulse rate is the frequency that the
light fl ashes every second. At 10Hz the light
will fl ash 10 times per second, similarly at
40Hz it will be 40 times per second. The
maximum pulse rate is 9999 Hz.
Intensity
This refl ects the duty cycle of the light or
the amount of time in which the light will
be on for every pulse. For example, if the
light pulses at an intensity of 25% once a
second, it means that the light will remain
on for only 0.25 seconds. With full intensity
of 100%, no pulse rate can be set.
Each program is unique and made up of three main
inputs; time, pulse rate, and intensity which are outlined
below.
Program Inputs

8
Understanding the default Programs
Each default program
has been developed with
different inputs. After running
the program, we recommend
turning off the device. Notice
the effects from the device,
if you feel positive effects
and wish to continue the
therapy, you can increase in
increments of 2 minutes each
day, up to a maximum of 20
minutes.
Peace
This program uses a 10Hz pulse rate associated with
alpha brain waves, fostering a relaxed and restful state
of consciousness. The light intensity is low so that you
can enjoy a longer exposure time of 9 minutes. This
program can be used with meditation activities or other
integrative mind-body awareness practices to calm the
central nervous system further.
Time
Pulse Rate
9 min
10 Hz
Intensity 25%
Focus
The Focus program uses a 40Hz pulse rate associated with
gamma brain waves. Gamma brain waves have shown
improved cognitive functioning, including short-term
memory, reaction time, mental fl exibility, and positive
neurophysiological effects. The recommended duration
is 6 minutes. We encourage starting with 3 minutes,
pausing to notice how you feel before continuing with
the second 3-minute session.
Program Descriptions

9
Time
Pulse Rate
3 min
20 Hz
Intensity 75%
Energize
The Energize program boosts cortical blood fl ow, giving
more oxygen to the brain. The 20Hz Beta brain waves
help to increase attention and clarity. This pulse rate is
also associated with increased adenosine triphosphate
(ATP) production. The duration of this program is slightly
shorter as the intensity is higher, giving you a short burst
of energy.
Glow
Encourages renewal and revitalization of cellular health,
increasing blood fl ow and aiding removal of waste
products. This program can be used for supporting
general brain wellness, and for recovery after a period
of ill health. This program also has cosmetic and
dermatological applications as it improves the blood
fl ow to the skin by stimulating elastin that improves skin
appearance and enhancing blood fl ow to the scalp and
thus promoting hair growth resulting in a truly healthy
glow. This program does not use pulsing as the intensity
is set to 100%.
Time
Pulse Rate
10 min
- Hz
Intensity 100%
Time
Pulse Rate
6 min
40 Hz
Intensity 50%

10
Custom Program
These are individualized programs developed in consul-
tation with a qualifi ed clinician. Each program is custom-
ized to effi ciently achieve your personal wellness goals.
Clinical Protocols & 4 Quadrant Functionality
Clinical Protocols are exclusively for use with the 4
quadrant feature which can only be used when purchased
with 3 months of consultation with a qualifi ed clinician.
If you have bought the Neuradiant 1070 and wish to
upgrade the device, please contact Neuronic at team@
neuronic.online
There is growing recognition in the neuroscience
community regarding the role of brain networks as
being a primary driver in overall brain performance.
Effi cient communication among and between brain
networks is a principal focus in developing effective
digital neurotherapeutic (DN) applications. Neuronic is
contributing to the advancement of DN applications with
the introduction of the Neuradiant 1070 with 4 quadrant
function, by providing independently programmable
pulse frequency, intensity, and duration to four key
brain quadrants (front, back, left, right) and thereby
allowing users to defi ne specifi c regions for customized
stimulation protocols.
Time
Pulse Rate
- min
- Hz
Intensity - %
Clinical Protocol Passcode:
Note: Only available with 4 quadrant device.

11
In order to optimize the benefi t for each user, we include
a personalized consultation process. The consultation
process has 3 basic components; assessment, protocol
design and implementation, as well as continuous
integration. Each individual has their own case history,
resources, and expectations and therefore the goal of
the consultation is to understand and incorporate those
factors into the Neuradiant 1070 protocol(s) they’ll be
using.
The initial consultation will include a thorough review
of the personal assessment materials the user will have
previously completed and returned to Neuronic. The
review of past experiences and concerns will support
the consultant in advising on the photobiomodulation
protocol design, establish ‘real world’ metrics for
evaluating progress, and suggestions for obtaining
further consultation or support. At this time, users will be
instructed and practice the safe and effi cient use of the
Neuradiant 1070 and how to modify a protocol.
The image below is the control settings for the 4 quadrant
feature and should be used under the guidance of a
qualifi ed clinician.

12
• More is not necessarily better. We’ve seen many
instances wherein the best results come after relatively
small amounts of stimulation, especially when it is
delivered with the right pulse frequency and intensity.
• Indications that you have had too much light
stimulation can occur during or shortly after (30
seconds to 10 minutes) completing a protocol. They
can also appear after a few hours. If you know you are
particularly sensitive to energetic or pharmaceutical
stimulation in general, then we suggest that you use
the device for a few minutes initially and build up the
usage gradually. If indications persist, consult your
healthcare professional and contact Neuronic for
additional support.
Photobiomodulation demonstrates a dose-response
curve which means that there is a ‘sweet spot’ wherein
the stimulation has the most positive impact on our cells
and tissues. Too little stimulation provides little benefi t,
and too much stimulation can cause a diminishment of
response.
We therefore strongly suggest that users accept two
basic principles:
5. Safety Guidelines
General Guidelines
Please only use the adapter and transformer provided
by the manufacturer to ensure the normal operation of
the device. The company is not responsible for product
failure caused by self-assembly or disassembly of the
product. Please discontinue using the device if wet or
there is visible damage to the helmet, adapter or cables,
this includes usage in conditions of high humidity or
temperature.
Our company does not bear any responsibility for the
damage or any accidents caused by improper use.
Helmet & Adapter Use Precautions

13
6. Service Guarantee
You can return the device within the fi rst 30 days for free.
Additionally, we have an 80% refund policy, valid for
three months from the time of purchase if our devices
do not help you. Our product is covered with a 12-month
warranty.
7. Disclaimers
Our product cannot guarantee the same effects on each
individual. There are no known side effects of using
our device. Still, we advise you to consult your local
doctor and conduct your independent research before
purchasing our device.
These statements have not been evaluated by the Food
and Drug Administration. This product is not intended to
diagnose, treat, cure or prevent any disease.
Please note this is not a medical device.
The focus of our consultation(s) is on the
safe and effective use of the Neuradiant 1070
photobiomodulation device and is not to be considered
medical advice, nor is it in any way to be considered a
replacement for consultation with your current medical
or other qualifi ed healthcare providers.

14
Product Parameters
Product Name Neuradiant 1070nm
Model Number GY-PDT1 Wave Length 1070nm
LED Numbers 256 pcs
Input Voltage 100-240 V
Total Power 15W
Input Current 800mA
Power 50mw/pc
Work Voltage 5V ~ 6A
Optical Power 24mw/cm2
Frequency 0-9999 Hz
8. Appendix
[1] Treatment of Neurodegeneration:
Integrating Photobiomodulation and
Neurofeedback in Alzheimer’s Dementia and
Parkinson’s
by Marvin H. Berman and Trent W Nichols
[2] Therapeutic Effects of Near Infrared Light
Stimulation on Cognitive and Behaviour
Symptoms of Dementia
by Marvin H. Berman, Damir Nizamutdinov,
Xiaoming Qi, Jason Huang and Gordon
Dougal.

Neuronic Devices Limited
Lacka, Carrig, Birr, Co. Offaly
Ireland
Neuronic Devices Operations GmbH
Am Kindergarten 1, 57482 Wenden
Germany
neuronic.online
te[email protected]

neuronic.online
