NeurOptics PLR-4000 User manual

PLR®
-4000
Pupillometer
Quick Start Guide
Power Up
Charging the PLR-4000 Pupillometer
1. Connect the PLR-4000 Power Adapter to the PLR-4000 Charging Station
and plug into a power outlet. The indicator light at the base of the Charging
Station will display a white color to indicate power has been established to
the Charging Station.
2. Place the PLR-4000 into the Charging Station. The Charging Station
indicator light will turn blue, and the LCD screen will display within the
battery icon, indicating the PLR-4000 is charging. The indicator light will turn
green when fully charged.
NOTE: Prior to first-time use, ensure the PLR-4000 is fully charged and
Date/Time are set accurately (refer to Setting Date and Time section).
1
2
3. The PLR-4000 Pupillometer goes to sleep in the Charging Station to
eciently charge:
•The PLR-4000 will initially turn ON (or remain on) upon being placed in the
Charging Station.
•After 2 minutes in the Charging Station, the PLR-4000 will go to sleep to
eciently charge. The screen will go dark. If any button is pressed or the
screen is touched within this 2-minute window, the time period before the
PLR-4000 goes to sleep is extended by an additional 2 minutes.
•To use the PLR-4000 after it has gone to sleep in the Charging Station,
simply remove from the Charging Station, and it will wake up automatically.
4. If the PLR-4000 Pupillometer is not in the Charging Station, to
conserve battery life it will:
•Go into sleep mode after 4 minutes. To turn ON, touch the screen or push
any button.
•Power down after an additional 6 minutes.
Turning On the PLR-4000 Pupillometer
5. If the PLR-4000 is out of the Charging Station and has powered down, press
(do not hold) the On/O button on the side of the device.
5
3

Scan Barcode Using Incorporated Barcode
Scanner
12 .From the Home Screen select , then Scan
Code. The PLR-4000 will emit a white light from
the top of the device. Center the light over the
barcode until you hear an audible beep.
13 .The Patient ID will now appear on the PLR-4000
touchscreen. Confirm the patient information is correct and select Accept.
8
6
7
9-10 .Two components are required to initiate a bilateral pupil measurement:
•PLR-4000 Pupillometer (Ex. 9)
•Eye Cup (Ex. 10)
The PLR-4000 should not be used without the eye cup positioned
correctly (Ex. 10) It is very important that the eye cup be correctly
fitted. A snug fit helps reduce the possibility of stray light entering the
eye while the scan is taking place. The eye cup has a tab in the rim
which fits into the indentation in the lens shield of the Pupillometer.
Setting Date and Time
6. To modify the date and time, from the Home Screen, select the Settings icon
and then select Date or Time. Follow the prompts to input the current date and
time using 24-hour time configuration and select .
7. Customers in the United States have the option to enable Automatic Daylight
Savings Time (DST) in the Time settings. Automatic DST is disabled by default.
Automatic adjustments occur based only on US DST regulations and are not
updated according to geographic location.
Date and Time Maintenance:
•Regular quarterly maintenance is necessary to ensure date and time are
correct. The set date and time will aect the timestamp listed for subsequent
patient pupil measurements. Changing the date and time will not alter the
timestamps on previous measurements.
•Immediately adjust the time after any time change if Automatic DST is disabled.
Returning to the Home Screen
8. Press the LEFT or RIGHT buttons (green circles) to return to the Home Screen.
Measuring Pupils Using the PLR-4000 Pupillometer
Attaching the Eye Cup to the Pupillometer
Position the tab in the eye cup rim into the indentation in the lens
shield of the Pupillometer and press into place. The tabs on either
side of the lens shield should also snap into the holes on either side
of the eye cup.
9
10
Enter a New Patient ID
11 .There are two options for associating the Patient ID to the Pupillometer:
1) Scanning the patient’s wristband barcode using the PLR-4000
Incorporated Barcode Scanner; or
2) Manually entering the Patient ID with entering alpha or numeric
characters.
11
12 13

Manual Entry of the Patient ID
14 .From the Home Screen select , then Manual ID. Using the touchscreen
or keypad, enter the alpha or numeric Patient ID and select . Confirm
the patient information on the screen is correct and select Accept.
Measure Pupils
16. Position the PLR-4000 with at a right angle to
the patient’s axis of vision, minimizing any
tilting of the device.
17-18. Press and hold either the LEFT or RIGHT
button until the pupil is centered on the
touchscreen and the display shows a green circle
around the pupil. A green frame around the
screen indicates the pupil is properly targeted
(Ex. 17), while a red frame indicates the pupil
needs to be re-centered on the screen before
the measurement is initiated (Ex. 18). Once the
green frame appears, release the button, holding
the PLR-4000 in place for approximately three
seconds until the results screen is displayed.
19 .When the pupil exam is complete, the PLR-4000
measurement results will be displayed in green
for the Right eye and in yellow for the Left eye.
20 .From the Results screen, select the Video icon
to view the playback of the reading.
14
15
19 20
16
17 18
Set Measurement Protocol
15. From the Home Screen, select the Settings icon and then the top right
icon to set protocol parameters.Then press RIGHT or LEFT to return to
the Home Screen. Refer to pg. 6 of Instruction Manual for more details
Browse Records
To review records stored on the PLR-4000:
21 .•From the Home Screen: Select the Records icon (Ex. 21).
• To browse records by Patient ID, select the ID from the list or use the
UP and DOWN arrows on the screen to browse additional IDs
available in the list. The IDs of the most recent measurements taken on
the PLR-4000 will appear at the top of the list.
21
22. • To search for a specific Patient ID, select (Ex. 22), then type in the
Patient ID and select .
• To browse all pupil measurements stored on the PLR-4000 in chronological
order (including all Patient IDs), select the All Records icon (Ex. 22)
and press the DOWN Arrow button on the keypad to scroll through all
previous measurements stored on the PLR-4000.
• When the “No more records” message appears, the earliest pupil
measurement stored has been reached.
The pupillometer stores at least 1,200 measurement in its memory. Once the memory is full, it begins to
write over the oldest measurements first.
22

To turn the PLR-4000 Pupillometer OFF, either:
•Navigate to the Home Screen and select the Power icon , then confirm Yes to power OFF.
•Press and hold the On/O button on the side of the PLR-4000.
The PLR-4000 may occasionally require a System Reboot. To reboot, simply press and hold the On/O
button on the side of the PLR-4000 until it powers OFF and then power it back on.
Power O
Isopropyl alcohol (IPA)-based cleaning solutions, in formula concentrations up to 70% IPA, are
recommended for use in cleaning the PLR-4000, Charging Station, and eye cup. Please refer to the
Cleaning and Maintenance Instructions included in the Instructions For Use, which can be found at
https://neuroptics.com/resource-center-applied-research/
Cleaning and Maintenance
24
9223 Research Drive | Irvine, CA 92618 | USA
p: 949.250.9792 | Toll Free North America: 866.99.PUPIL
[email protected]om | NeurOptics.com
QSG-0003-00 - Rev B
For additional information regarding our product, please refer to the Instructions For Use, which can be
found at https://neuroptics.com/resource-center-applied-research/
Ordering Information
PLR-4000-SYS PLR®-4000 Pupillometer System
NEUR-2059-01 Eye Cup
CBL-0006-00 Data Download Cable
NEUR-PRTS445 Wireless Printer Kit
Print Data
24. Attach the power supply to the printer. Turn the printer on and a green light
will illuminate. From a measurement results screen (either last measurement
taken or “Browse Records” to find a dierent measurement), select the Print
icon on the bottom of the screen (Ex. 24).
Download Data
23. From the Home Screen, select the Settings Icon , then select Upload
Data . Two choices will appear “Data” or “Video”. If you choose “Data” a
text message will appear on the screen instructing the user to “connect USB
cable & copy R_#####_######.xls.” If you choose “Video” an AVI file will
be saved, and a text message will appear on the screen instructing the user
to “connect USB cable & copy V_#####_######.avi.” Connect the USB
cable from the pupillometer to the computer (Ex 23). The computer will show as “Neuroptics” drive on
the computer. Click on the drive, copy the XLS file or the AVI file and paste it on your computer. Press
“DONE” in the small window on the pupillometer screen only after the copy has been completed, as the
file will then be erased.
Note: Only the last measurement can be downloaded as a video, and it must be done immediately
after a measurement is captured.
23
The system will only print a record when a measurement result is displayed on
the screen. If you want to print a measurement other than the last measurement taken, refer to the “Browse
Records” section above. Consult the printer’s instruction manual for specific printer operation instructions.
