New Air NMF8K7BK00 User manual

Manual v1.0
26" Outdoor Misting Fan
SKU: NMF8K7BK00

2
newair.com
READ AND SAVE THESE INSTRUCTIONS.
TABLE OF CONTENTS
Register Your Product Online............................................................................... 3
Safety Information & Warnings ........................................................................... 4
Parts List...............................................................................................................6
Assembly Instructions.......................................................................................... 9
Operating Instructions.......................................................................................15
Cleaning And Maintenance................................................................................ 16
Troubleshooting.................................................................................................17
Limited Manufacturer’s Warranty..................................................................... 18
SPECIFICATIONS
MODEL NO:
NMF8K7BK00
RATED VOLTAGE
120V
RATED POWER
300W
NOISE
57 dB
AIRFLOW
8652 CFM
FAN SPEEDS
3
SPEED
1600 RPM
MIST VOLUME
1.3 gal/h

3
newair.com
REGISTER YOUR PRODUCT ONLINE
Register Your NewAir Product Online Today!
Take advantage of all the benefits product registration has to offer:
Service and Support
Diagnose troubleshooting and service issues faster and more
accurately
Recall Notifications
Stay up to date for safety, system updates and recall notifications
Special Promotions
Opt-in for NewAir promotions and offers
Registering your product information online is safe & secure and takes less
than 2 minutes to complete:
0
Alternatively, we recommend you attach a copy of your sales receipt below and
record the following information, located on the manufacturer’s nameplate on
the rear of the unit. You will need this information if it becomes necessary to
contact the manufacturer for service inquiries.
Date of Purchase: _____________________________________
Serial Number: _______________________________________
Model Number: ______________________________________
newair.com/register

4
newair.com
SAFETY INFORMATION & WARNINGS
IMPORTANT SAFETY INFORMATION: Please carefully read this
manual before attempting to install or use this misting fan. For
your safety, comply with all safety instructions and warnings
contained in this owner's manual to prevent personal injury or
property damage.
•Use this misting fan only as instructed in this owner's manual. Other uses
may cause electric shock injury or fire.
•Close supervision is required if this fan is used near children or pets.
•To protect against electric shock, do not immerse this fan or its plug and
cord in water.
•If the fan is being transported or will not be in use, disconnect it from the
power supply by tightly gripping the fan's plug and pulling it from the
power outlet. Do not disconnect the power supply by pulling on the fan's
power cord.
•Avoid contact with any of the misting fan's moving parts.
•Place the misting fan on a level surface.
•This misting fan is intended to fit into a matching receptacle. Under no
circumstances should the grounded plug be altered in any way. An
improper connection can result in electric shock.
•If possible, avoid using extension cords with this misting fan. If an
extension cord is necessary, do not use more than one extension cord to
operate one fan.
•Do not insert objects, allow fingers or any body parts into the fan head, as
this may cause electric shock or bodily injury. Do not block or tamper the
misting fan while it is in operation.
•Do not place the fan near curtains, drapes or any other materials that can
get caught in the misting fan's grills.
•Do not run the power cord under mats or carpeting and do not cover the
power cord with runners. Arrange the power cord away from room traffic
where it can be tripped over.
•Do not operate this misting fan in the presence of flammable substances,
explosives or corrosive material.

5
newair.com
•Do not place the fan near an open flame or cooking/heating appliances.
•If the fan will not be in use, empty the tank of any remaining water.
•If the fan's plug or power cord is damaged, do not attempt to repair the
components yourself.
•This appliance is not intended for use by people (including children) with
reduced physical, sensory or mental capabilities, lack of experience or
knowledge of its operation, unless well instructed or under supervision of a
person responsible for their safety.
•This product is not a toy, small children should always be under strict adult
supervision if operating this appliance.
•Allow damaged supply cords to be replaced by the manufacturer, a service
agent or a similarly qualified person to avoid hazard to yourself.
SAVE THESE INSTRUCTIONS

6
newair.com
PARTS LIST
1. Safety cover
2. Safety grill
3. Misting plate
4. Water outlet
5. Whorl bent connector
6. Water receiving plate
7. Water receiving plate cover
8. Flexible tube
9. Plug
10. Misting motor
11. Front grill
12. Blade
13. Rear grill
14. Fan motor
15. Motor cover
16. Motor protective cover
17. Oscillating structure
18. Tube connector for stand pole
19. Stand pole
20. Handle
21. Ball valve
22. Water tank cover
23. Tank cart
24. Wheel
25. Caster
26. Water pump
27. Water tank

7
newair.com
FEATURES
1. Centrifugal misting system means there is no clogged nozzles and no need
to use filtered water.
2. Fan surface is epoxy resin coated, anti-rust and durable.
3. Waterproof electrical components.
4. Easy to move tank cart with smooth gliding wheels and castors.
5. Air supplying and misting functions are driven by different motors. Motors
have high quality ball bearings, long service life, low noise, and strong
overloading ability.
6. The misting volume is adjustable.
7. The pump is fully insulated and enclosed with a protective structure for
safe operation.
8. Easy to use with three adjustable speeds and left and right oscillation
function.
9. Designed for cooling large areas such as patios, factories, manufacturing
facilities, garages, athletic fields, greenhouses, livestock breeding farms
and more.

8
newair.com
WIRING DIAGRAM

9
newair.com
ASSEMBLY INSTRUCTIONS
DO NOT plug in the fan before assembly. This misting fan comes in 3 boxes.
Carefully remove all packing materials and keep for future storage/use. Make
sure there is no residual packaged foam left in any of the components. Check
all the components to ensure no parts are missing, were scratched or damaged
during transportation. A screwdriver and a wrench will be required to assemble
this misting fan.
STEP 1: ASSEMBLING THE STAND POLE
1. Refer to Diagram 1. Locate the tank cart and stand pole.
2. Remove the four M8X25 bolts, spring washer, flat washer, and nuts from
the tank cart.
3. Position the stand pole on the tank cart and make the ball valve switch
face the back.
4. Align the holes on the pole with the four holes on the cart.
5. Using the bolts, washers, and nuts removed in step 1, screw the stand pole
into the tank cart.
6. Make sure the stand pole is securely screwed onto the cart before
proceeding to the next step.

10
newair.com
STEP 2: FRONT COVER PLATE INSTALLATION
1. Refer to Diagram 2. The six-pin plug connects the power cord and the
water pump power cord together. Insert the six-plug into the opening at
the bottom of the stand pole and feed it through the shaft until it comes
through the opening at the top of the stand pole.
2. Insert the blue tube and black tube into the round hole of the front cover.
Insert the blue tube into the water pump connector. Ensure that the tubes
in the stand pole don’t bend or twist once inserted.
3. Mount the front cover onto the stand pole and fix with screws.
