New Holland Auto Command T7.220 User manual

Part Number 84361992
1st edition English
December 2010
OPERATOR’SMANUAL
ORIGINALINSTRUCTIONS
T7.220
T7.235
T7.250
T7.260
Power Command

TO THE OWNER
This manual contains information concerning the adjustment and maintenance of your New Holland T7.220,
T7.235, T7.250, T260, Tractor. You have purchased a dependable machine, but only by proper care and
operation can you expect to receive the performance and long service built into this tractor. Please have all
operators read this manual carefully and keep it available for ready reference.
This machine was designed to power and propel itself. It is intended to load and move materials with a variety
of buckets and forks. Allied attachments built and supplied by other manufacturers can be used on the tractor
where recommended and approved by New Holland.
DO NOT use this machine for any purpose or in any manner other than as described in this manual, decals, or
other product safety information provided with this machine. These materials define the machine’s intended use.
All persons who will be operating this machine shall possess a valid local vehicle operating permit and/or other
applicable local age work permits.
Your New Holland dealer will instruct you in the general operation of your tractor. (Refer to the “Delivery Report”
at the back of this manual.) Your dealer’s staff of factory-trained service technicians will be glad to answer any
questions that may arise regarding the operation of your tractor.
Your New Holland dealer carries a complete line of genuine New Holland service parts. These parts are
manufactured and carefully inspected to insure high quality and accurate fitting of any necessary replacement
parts. Be prepared to give your dealer the model and PIN number of the engine and tractor, when ordering parts.
Locate these numbers now and record them below. Refer to the “General Information” section of this manual
for the location of the model and PIN numbers of your tractor.
Model Engine Model
PIN Number Engine Serial Number
IMPROVEMENTS
CNH America LLC is continually striving to improve its products. We reserve the right to make improvements
or changes when it becomes practical and possible to do so, without incurring any obligation to make changes
or additions to the equipment sold previously.

CONTENTS
Title Page
Section 1 -- General Information and Safety
To the Owner 1--1...............................................................................
Product Identification 1--4........................................................................
Ecology and the Environment 1--7.................................................................
Safety Precautions 1--9..........................................................................
Safety Decals 1--18..............................................................................
International Symbols 1--27.......................................................................
Airborne Noise Emission 1--28....................................................................
Selective Catalytic Reduction 1--29................................................................
Section 2 -- Controls, Instruments and Operation
Cab 2--4.......................................................................................
Electrical Power Sockets 2--20....................................................................
Seats 2--24.....................................................................................
Steering Column Controls 2--32...................................................................
Analogue/Digital Instruments 2--36.................................................................
Enhanced Keypad 2--42..........................................................................
Brake Controls and Operation 2--87................................................................
Power Command Transmission 2--95..............................................................
Differential Lock and Four Wheel Drive 2--118.......................................................
Front Axle Suspension 2--122.....................................................................
Section 3 -- Field Operation
Important Information 3--1........................................................................
Boosting the Tractor Battery 3--8..................................................................
Starting the Engine 3--9..........................................................................
Stopping the Engine 3--12........................................................................
Engine Power Management 3--14.................................................................
Engine Speed Management 3--16.................................................................
Headland Turn Sequence 3--19...................................................................
Fast Steer 3--36.................................................................................
Rear Power Take--Off 3--38.......................................................................
Front Power Take--Off and Hydraulic Lift 3--55.......................................................
Electronic Draft Control 3--81.....................................................................
Hydraulic Remote Control Valves 3--96.............................................................
Three--point Hitch 3--109.........................................................................
Quick Hitch 3--115...............................................................................
Linkage Stabilisers 3--117........................................................................
Drawbars and Towing Attachments 3--123
..........................................................
Trailer Braking Systems 3--139....................................................................
Front Wheel Track Adjustment 3--146..............................................................
Dynamic Front Fenders 3--151....................................................................
Rear Wheel Track Adjustment 3--154...............................................................
Ballasting and Tyres 3--165.......................................................................

Section 4 -- Lubrication and Maintenance
General Information 4--1.........................................................................
Guard Removal 4--10............................................................................
Lubrication and Maintenance Chart 4--14...........................................................
Servicing: When Warning Lights Illuminate 4--17.....................................................
10--hour/daily service 4--20.......................................................................
50--hour service 4--21............................................................................
100--hour service 4--33...........................................................................
300--hour service 4--32...........................................................................
600--hour service 4--35...........................................................................
1200--hour/12 month service 4--43.................................................................
1200--hour/24 month service 4--50.................................................................
Every 3 years 4--57..............................................................................
General Maintenance -- as required 4--59...........................................................
Storing the tractor 4--78..........................................................................
Section 5 -- Fault Finding
Introduction 5--1.................................................................................
Engine 5--4.....................................................................................
Transmission 5--7...............................................................................
Hydraulics 5--8..................................................................................
3-point hitch 5--9................................................................................
Brakes 5--10....................................................................................
Cab 5--10......................................................................................
Electrical 5--11..................................................................................
Section 6 -- Accessories
Rotating Beacon 6--2............................................................................
Auxiliary Headlights 6--2..........................................................................
Battery Isolator Switch 6--3.......................................................................

Section 7 -- Specification
General Dimensions 7--2.........................................................................
Vehicle Weights 7--6.............................................................................
Lubricant and Fluid Capacities 7--7................................................................
Engine 7--8.....................................................................................
Fuel System 7--8................................................................................
Cooling System 7--9.............................................................................
Transmission Options 7--9........................................................................
Maximum Operating Angle 7--10..................................................................
Rear Power Take-Off 7--10.......................................................................
Front Power Take-Off 7--10.......................................................................
Hydraulic System 7--11...........................................................................
Three-Point Lift 7--11............................................................................
Remote control valves 7--15......................................................................
Front 3--Point Hitch 7--15.........................................................................
Front Remote Valves 7--15.......................................................................
Brakes 7--16....................................................................................
Steering 7--16...................................................................................
Electrical Equipment 7--17........................................................................
Hardware Torque Tables 7--18....................................................................
Section 8 -- First 50--hour Service Forms 8--5.....................................................
Section 9 -- Index 9--1...........................................................................
All data given in this manual is subject to production variations. The dimensions and weights provided are
approximate values only and some machine features shown in this manual may not correspond to standard
models. For precise information on specific models, features and specifications, please contact your authorised
dealer.

(North America Only)
(California Only)
CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of its constituents are known to the State of
California to cause cancer, birth defects, and other reproductive harm.
Battery posts, terminals and related accessories contain lead and lead
compounds. Wash hands after handling.

1--1
SECTION 1
GENERAL INFORMATION AND SAFETY
TO THE OWNER
GENERAL INFORMATION
This Manual has been prepared to assist you in the
correct procedure for running--in, driving and
operating and for the maintenance of your new
tractor. Read this Manual carefully. Your tractor is
intended for use in normal and customary
agricultural applications.
If at any time you require advice concerning your
tractor, do not hesitate to contact your authorised
dealer. He has factory trained personnel, genuine
manufacturers’ parts and the necessary equipment
to carry out all your service requirements.
Your tractor has been designed and built to give
maximum performance, economy and ease of
operation under a wide variety of operating
conditions. Prior to delivery, the tractor was carefully
inspected, both at the factory and by your dealer to
ensure that it reaches you in optimum condition. To
maintain this condition and ensure trouble--free
operation, it is important that the routine services, as
specified in Section 4 of this Manual, are carried out
at the recommended intervals.
OPERATORS MANUAL
The Operators Manual supplied with your tractor is
an important source of information and should be
stored safely.
The manual is prepared specifically for your tractor
so it is important that you make a note of the print
number and issue date which can be found on the
cover. In the event the manual is lost or damaged it
can be replaced with the correct version.
A storage pocket for the Operators Manual can be
found on the rear of the seat. The manual should be
kept in this pocket at all times when not in use.
SAFETY
Pages 1--9 to 1--16 inclusive, list the precautions to
be observed to ensure your safety and the safety of
others. Read the safety precautions and follow the
advice offered before operating the tractor.
CLEANING THE TRACTOR
Your tractor is a state-of-the-art machine with
sophisticated, electronic controls. This should be
taken into consideration when cleaning the tractor,
particularly if using a high pressure washer. Even
though every precaution has been taken to
safeguard electronic components and connections,
the pressure generated by some of these machines
is such that complete protection against water
ingress cannot be guaranteed.
When using a high pressure washer, do not stand too
close to the tractor and avoid directing the jet at
electronic components, electrical connections,
breathers, seals, filler caps, etc. Never direct a cold
water jet at a hot engine or exhaust.
ELECTRO-MAGNETIC INTERFERENCE (EMC)
This tractor complies strictly with the European
Regulations on electro-magnetic emissions.
However, interference may arise as a result of
add-on equipment which may not necessarily meet
the required standards. As such interference can
result in serious malfunction of the unit and/or create
unsafe situations, you must observe the following:
Ensure that each piece of non-New Holland
equipment fitted to the tractor bears the CE
mark.
The maximum power of emission equipment
(radio, telephones, etc.) must not exceed the
limits imposed by the national authorities of the
country where you use the tractor.
The electro-magnetic field generated by the
add-on system should not exceed 24 V/m at any
time and at any location in the proximity of
electronic components.
Failure to comply with these rules will render the New
Holland warranty null and void.

SECTION 1 -- GENERAL INFORMATION AND SAFETY
1--2
FIRST 50 HOUR SERVICE
In Section 8, at the back of this Manual, you will find
the 50--hour service reports.
IMPORTANT: It is important the 50 hour service is
carried out as recommended to ensure your tractor
provides optimum performance and efficiency.
After you have operated the tractor for 50 hours, take
your tractor, together with this Manual, to your
dealer. He will then perform the factory
recommended 50 hour service and complete the
service report sheets (pages 8--1 and 8--3). The first
sheet (page 9--1) is the dealer’s copy and should be
removed by the dealer after the service has been
carried out. The second sheet (page 8--3) is your
copy of the service performed. Ensure that you and
the dealer sign both copies.
SERVICE PARTS
It should be pointed out that genuine parts have been
examined and approved by the Company. The
installation and/or use of ‘non-genuine’ products
could have negative effects upon the design
characteristics of your tractor and thereby affect it’s
safety. The Company is not liable for any damage
caused by the use of ‘non--genuine’ parts and
accessories. Only genuine New Holland
replacement parts should be used. The use of
non-genuine parts may invalidate legal approvals
associated with this product.
It is prohibited to carry out any modifications to the
tractor unless specifically authorised, in writing, by
the After Sales Service department of the Company.
WARRANTY
Your tractor is warranted according to legal rights in
your country and the contractual agreement with the
selling dealer. No warranty shall, however, apply if
the tractor has not been used, adjusted and
maintained according to the instructions given in the
Operator’s Manual.
BIODIESEL FUELS
IMPORTANT: Before using Biodiesel fuels in your
tractor, refer to the information on page 4--4
regarding the storage and use of Biodiesel fuels.
EMISSION CONTROLS
ATTENTION:The engine and fuel system on your
machine is designed and built to government
emissions standards. Tampering by dealers,
customers, operators and users is strictly
prohibited by law. Failure to comply could result in
government fines, rework charges, invalid warranty,
legal action and possible confiscation of the machine
until rework to original condition is completed.
Engine service and/or repairs must be done by a
certified technician only!

SECTION 1 -- GENERAL INFORMATION AND SAFETY
1--3
END USER LICENCE AGREEMENT TERMS
You have acquired a device (“DEVICE”) that
includes Software licensed by CNH America LLC
from Microsoft Licensing, GP or its affiliates
(“MS”). Those installed software products of MS
origin, as well as associated media, printed
materials, and “online” or electronic documenta-
tion (“SOFTWARE”) are protected by interna-
tional intellectual property laws and treaties. The
SOFTWARE is licensed, not sold. All rights
reserved.
IF YOU DO NOT AGREE TO THIS END USER
LICENSE AGREEMENT (”EULA”0, DO NOT
USE THE DEVICE OR COPY THE SOFT-
WARE. iNSTEAD, PROMPTLY CONTACT CNH
AMERICA LLC FOR INSTRUCTIONS ON
RETURN OF THE UNUSED DEVICE(S) FOR A
REFUND. ANY USE OF SOFTWARE INCLUD-
ING BUT NOT LIMITED TO USE ON THE
DEVICE, WILL CONSTITUTE YOUR AGREE-
MENT TO THIS EULA (OR RATIFICATION OF
ANY PREVIOUS CONSENT.)
GRANT OF SOFTWARE LICENSE. This EULA
grants you the following license:
-- You may use the SOFTWARE only on the
DEVICE.
-- NOT FAULT TOLERANT. THE SOFTWARE IS
NOT FAULT TOLERANT. CNH AMERICA LLC
HAS INDEPENDENTLY DETERMINED HOW
TO USE THE SOFTWARE IN THE DEVICE,
AND MS HAS RELIED UPON CNH AMERICA
LLC TO CONDUCT SUFFICIENT TESTING TO
DETERMINE THAT THE SOFTWARE IS
SUITABLE FOR SUCH USE.
-- NO WARRANTIES FOR THE SOFTWARE.
THESOFTWAREisprovided“ASIS”andwithall
faults. THE ENTIRE RISK AS TO
SATISFACTORY QUALITY, PERFORMANCE,
ACCURACY AND EFFORT (INCLUDING LACK
OF NEGLIGENCE) IS WITH YOU. ALSO,
THERE IS NO WARRANTY AGAINST
INTERFERENCE WITH YOUR ENJOYMENT
OF THE SOFTWARE OR AGAINST
INFRINGEMENT. IF YOU HAVE RECEIVED
ANY WARRANTIES REGARDING THE
DEVICE OR THE SOFTWARE, THOSE
WARRANTIES DO NOT ORIGINATE FROM,
AND ARE NOT BINDING ON, MS.
-- No Liability for Certain Damages. EXCEPT AS
PROHIBITED BY LAW, MS SHALL HAVE NO
LIABILITY FOR ANY INDIRECT, SPECIAL,
CONSEQUENTIAL OR INCIDENTAL
DAMAGES ARISING FROM OR IN
CONNECTION WITH THE USE OR
PERFORMANCE OF THE SOFTWARE. THIS
LIMITATION SHALL APPLY EVEN IF ANY
REMEDY FAILS OF ITS ESSENTIAL
PURPOSE. IN NO EVENT SHALL MS BE
LIABLE FOR ANY AMOUNT IN EXCESS OF
U.S. TWO HUNDRED AND FIFTY DOLLARS
(U.S. $250.00)
-- Limitations on Reverse Engineering,
Decompilation, and Disassembly. You may
not reverse engineer, decompile, or disassemble
the SOFTWARE, except and only to the extent
that such activity is expressly permitted by
application law notwithstanding this limitation.
-- SOFTWARE TRANSFER ALLOWED BUT
WITH RESTRICTIONS. You may permanently
transfer rights under this EULA only as part of a
permanent sale or transfer of the DEVICE, and
only if the recipient agrees to this EULA. If the
SOFTWARE is an upgrade, any transfer must
also include all prior versions of the
SOFTWARE.
-- EXPORT RESTRICTIONS. You acknowledge
that SOFTWARE is subject to U.S. export
jurisdiction. You agree to comply with all
applicable international and national laws that
apply to the SOFTWARE, including the U.S.
Export Administration Regulations, as well as
end-user, end-use and destination restrictions
issued by U.S. and other governments. For
additional information see
http://www.microsoft.com/exporting/.

SECTION 1 -- GENERAL INFORMATION AND SAFETY
1--4
PRODUCT IDENTIFICATION
The tractor and major components are identified
using serial numbers and/or manufacturing codes.
Tractor identification data must be supplied to the
dealer when requesting parts or service and will also
be needed to aid in identifying the tractor if it is ever
stolen.
The following provides the locations of the
identification data.
1
1
Vehicle Identification Plate
The vehicle identification plate, (1) Figure 1 is
located on the left-hand radiator support. Record the
information on the sample identification plate
provided.
2
Tractor Identification
The serial number and model identification
information is stamped on the right--hand side of the
front support (1). These numbers are also repeated
on the vehicle identification plate reproduced above.
3

SECTION 1 -- GENERAL INFORMATION AND SAFETY
1--5
Engine Information
The engine serial number and date of manufacture
are stamped on the right--hand side of engine block
(1), below the manifold. Record the number below.
Engine Serial No.
4
The details are repeated on the information plate
located on the left side of the engine oil pan.
5
Further information relating to engine adjustments
and emission level compliance are also shown on the
engine information plate.
NOTE: The details displayed on the engine
information plate may change according to the
country in which the tractor is sold.

SECTION 1 -- GENERAL INFORMATION AND SAFETY
1--6
Driveline Identification
Power Command Transmission
The serial number plate (1) is located on the
right--hand side of the transmission casing behind
the the battery carrier. This number is repeated on
the vehicle identification plate. Record the
information below for quick reference.
Driveline Serial No.
6
ROPS identification plate
The ROPS identification plate can be found on the
right--hand side of the cab trim panel, below the rear
window.
7

Thank you so much for reading.
Please click the “Buy Now!”
button below to download the
complete manual.
After you pay.
You can download the most
perfect and complete manual in
the world immediately.
Our support email:
[e-mail]
