New Holland
T4000 Series Utility Tractor Specifications
T4020 T4030 T4040 T4050
Page 1 of 3
MODEL T4020 T4030 T4040 T4050
ENGINE*
Type 4-cycle, diesel 4-cycle, diesel 4-cycle, diesel 4-cycle, diesel
Make New olland New olland New olland New olland
Model F5C F5C NEF NEF
Cylinders / aspiration ..............................................................4 / Turbocharged air to air intercooled..............................................................
Displacement, cu. in. (L) 195 (3.2) 195 (3.2) 274 (4.5) 274 (4.5)
Block type Parent bore Parent bore Parent bore Parent bore
Rated speed, RPM 2300 2300 2300 2300
Gross engine horsepower 64 76 84 95
PTO horsepower 50 62 70 80
Emission legislation Tier III Tier III Tier III Tier III
FUEL, AIR AND LUBRICATION S STEM
Injection pump Bosch / rotary Bosch / rotary Bosch / rotary Bosch / rotary
Fuel filter type ........ Dual stage fuel filtering system with water/sediment separator followed by a paper filter element cartridge........
Fuel tank capacity - standard, gal. (L) Standard – 21.6 (82) Standard – 21.6 (82) Standard – 21.6 (82) Standard – 21.6 (82)
– Deluxe, gal. (L) Deluxe – 19.8 (75) Deluxe – 19.8 (75) Deluxe – 23.2 (88) Deluxe – 23.2 (88)
– SuperSteer™, gal. (L) N/A 19.8 (75) N/A 23.2 (88)
Air filter type Dry / dual element Dry / dual element Dry / dual element Dry / dual element
Oil and filter services*** 600 hours 600 hours 600 hours 600 hours
Muffler Under hood Under hood Under hood Under hood
Exhaust outlet, ROPS Right side of hood Right side of hood Right side of hood Right side of hood
Exhaust outlet, cab Right side A-pillar Right side A-pillar Right side A-pillar Right side A-pillar
ELECTRICAL
Battery, volts 12 12 12 12
Battery, cca 730 730 800 800
Alternator, amps 85 85 120 120
Cold start aid Grid heater Grid heater Grid heater Grid heater
TRANSMISSION
Choice of transmissions
.......................16F x 16R Synchro Command transmission with your choice of mechanical shuttle or.......................
clutchless power shuttle (all models)
Clutch type / size (mechanical), in. (mm) ............................................. Dry / 11 (280) diameter, heavy-duty cerametallic material.............................................
Clutch type / size (electrohydraulic), in. (mm) ......................................................... Wet / six plates 5.2 (133), organic material ........................................................
Gears: 2 – 8 mph working range** ..............................................................12 x 12 – 7 gears | 16 x 16 – 9 gears ..............................................................
Gears: <1 mph** ..............................................................12 x 12 – 0 gears | 16 x 16 – 3 gears ..............................................................
Maximum speed**, mph (kph) ........................................12 x 12 – 18.73 (30.14) | 16 x 16 – 18.73 (30.14) or 23.5 (37.8) ........................................
PTO
Type Fully independent Fully independent Fully independent Fully independent
Base equipment PTO speed, RPM 540 540 540 540
Optional PTO speed, RPM N/A N/A 540/1000 540/1000
Operator control ....................................................................T4000 Standard – mechanical ....................................................................
...................................................T4000 Deluxe / Deluxe Supersteer™ – Servo-assist...................................................
PTO clutch .......................................................... Dry, mechanical, 11-in. dry, organic plate ..........................................................
Engine speed ................................................................ 2196 engine rpm at 540 PTO rpm ................................................................
3-POINT HITCH
Category II / I II / I II / I II / I
Draft sensing ...................................................................Mechanical, lower link sensing ...................................................................
Std. ASAE lift capacity @ 24 in., lbs. (kg) 3962 (1800) 3962 (1800) 3962 (1800) 3962 (1800)
Link arms Flexible Flexible Flexible Flexible
Stabilizers Telescoping Telescoping Telescoping Telescoping
Upper / lower limit setting Lift-O-Matic Lift-O-Matic Lift-O-Matic Lift-O-Matic

New Holland
T4000 Series Utility Tractor Specifications
T4020 T4030 T4040 T4050
Page 2 of 3
MODEL T4020 T4030 T4040 T4050
HDRAULICS
System type Open center Open center Open center Open center
System pressure, psi (bar) 2755 (190) 2755 (190) 2755 (190) 2755 (190)
Implement pump flow (base), gpm (L/min.) ...................T4000 Standard – 12.8 (48.6) .................... ....................................16.1 (61)....................................
..................... T4000 Deluxe – 16.1 (61).......................
Implement pump flow (optional), gpm (L/min.) ....................T4000 Standard – 16.1 (61) ..................... N/A N/A
Steering & services pump, gpm (L/min.) ...............with mechanical shuttle – 7.4 (28)................. ....................................9.4 (35.6) ...................................
..................with power shuttle – 9.4 (35.6) ...................
Remotes - base / optional ........................................................ Standard – 1 / 2, 3 (4 & 5 with loader valve)........................................................
...................................................Deluxe / SuperSteer 1 / 2, 3, 4 (5 with loader valve)...................................................
REAR AXLE
Type Flange Flange Flange Flange
Diff lock engagement Mechanical Mechanical Mechanical Mechanical
Track adjustment, in. (mm) 49.6 – 76.1 (1260 – 1932) 49.6 – 76.1 (1260 – 1932) 49.6 – 76.1 (1260 – 1932) 49.6 – 76.1 (1260 – 1932)
Dimension across flange, in. (mm) 61.5 (1562) 61.5 (1562) 61.5 (1562) 61.5 (1562)
Axle capacity, lbs. (kg) 8157 (3700) 8157 (3700) 8157 (3700) 8157 (3700)
FRONT AXLE
2WD
Track adjustment, in. (mm) 53.7 – 79.9 (1365 – 2031) 53.7 – 79.9 (1365 – 2031) 53.7 – 79.9 (1365 – 2031) 53.7 – 79.9 (1365 – 2031)
Axle capacity (restricted), lbs. (kg) 6613 (3000) 6613 (3000) 6613 (3000) 6613 (3000)
Axle capacity, lbs. (kg) 4630 (2100) 4630 (2100) 4630 (2100) 4630 (2100)
Maximum steering angle, degrees 55 55 55 55
Oscillation, degrees 11 11 11 11
FWD
FWD engagement – T4000 Standard Mechanical Mechanical Mechanical Mechanical
FWD engagement – T4000 Deluxe ............................w/mechanical shuttle – mechanical engagement.............................
............................w/power shuttle – electrohydraulic engagement ............................. Electrohydraulic
SuperSteer front axle N/A Auto FWD management N/A Auto FWD management
Track adjustment, in. (mm) .......................................................................60.8 – 76.6 (1545 – 1945).......................................................................
Diff lock engagement ....................................................................T4000 Standard – limited slip ....................................................................
.....................................................T4000 Deluxe – electrohydraulic differential lock .....................................................
Axle capacity (restricted), lbs. (kg) 7937 (3600) 7937 (3600) 7937 (3600) 7937 (3600)
Axle capacity, lbs. (kg) 5511 (2500) 5511 (2500) 5511 (2500) 5511 (2500)
Maximum steering angle – FWD, degrees 55 55 55 55
Maximum steering angle – SuperSteer, degrees N/A 76 N/A 76
Oscillation, degrees 11 11 11 11
DIMENSIONS
Operator’s station ..............................................................T4000 Series Standard – open station..............................................................
.......................................................................T4000 Series Deluxe – cab.......................................................................
......................................T4000 Series Supersteer - open station / cab (T4030 & T4050 only) .....................................
Platform type, cab / ROPS ...................................................................ISO mounted, straddle platform...................................................................
Wheelbase (2WD), in. (mm) ........................Standard – 83.3 (2115) ......................... .........................Standard – 86.7 (2202) ........................
..........................Deluxe – 85.6 (2175) ........................... ...........................Deluxe – 89.0 (2262) ..........................
Wheelbase (FWD), in. (mm) ........................Standard – 80.2 (2038) ......................... .........................Standard – 83.7 (2125) ........................
..........................Deluxe – 82.6 (2098) ........................... ...........................Deluxe – 86.0 (2185) ..........................
Wheelbase (Supersteer), in. (mm) N/A 94.8 (2408) N/A 98.2 (2495)
Overall length - standard, in. (mm) 135.2 (3433) 135.2 (3433) 138.6 (3520) 138.6 (3520)
– Deluxe, in. (mm) 137.5 (3493) 137.5 (3493) 140.9 (3580) 140.9 (3580)
– Supersteer, in. (mm) N/A 137.5 (3493) N/A 140.9 (3580)
ROPS height (folded)**, in. (mm) 77.8 (1976) 77.8 (1976) 77.8 (1976) 77.8 (1976)
Cab height**, in. (mm) 91.4 (2322) 91.4 (2322) 91.4 (2322) 91.4 (2322)

New Holland
T4000 Series Utility Tractor Specifications
T4020 T4030 T4040 T4050
Page 3 of 3
MODEL T4020 T4030 T4040 T4050
APPROXIMATE SHIPPING WEIGHT
Less Cab (ROPS)
– 2WD, lbs. (kg) 5776 (2620) 5776 (2620) 5953 (2700) N/A
– FWD, lbs. (kg) 6327 (2870) 6327 (2870) 6503 (2950) 6614 (3000)
Cab
– 2WD, lbs. (kg) 6217 (2820) 6217 (2820) 6393 (2900) N/A
– FWD, lbs. (kg) 6768 (3070) 6768 (3070) 6944 (3150) 7055 (3200)
*Manufacturer's estimate, **with 16.9x30 rear tires, *** affected by sulfur content of the fuel
TIRE OPTIONS
R1 “General Farming” – great for a wide variety of agricultural applications.
R3 “All Weather” – great for highway mowing, parks, orchards and light industrial applications.
R4 “Industrial” – great for light industrial applications, rental yards, contractors and municipalities.
Galaxy “Turf Special” – great for golf courses and stadium grounds maintenance.
*Approximate weights for base tractor with full fuel tank; 16.9 x 28R1 rear tires and 9.5L x 15 (2WD) or 12.4R20 (FWD) front tires; mechanical shuttle transmission; without front weights or
rear wheel weights; or rear wheel weights; single rear remote valve
OPTIONAL EQUIPMENT
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
© 2008 CNH America LLC
New H lland is a registered trademark f CNH America LLC.
Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).
• Second rear remote valve (lever controlled)
• Third rear remote valve (lever controlled)
• Fourth rear remote valve (lever controlled —
available on T4000 Deluxe and Deluxe SuperSteer
• Mid-mount valve with joystick control
• Back-up alarm wiring kit
• orn
• Front weight bracket kit
• Rear wheel weights
• 88 lb. front weights
• 540/1000 rpm PTO (T4040/T4050 only)
• Grill guard
• Fixed external mirrors (cab only)
• Telescoping external mirrors (cab only)
• orizontal exhaust kit
• Blue fiberglass canopy
• White fiberglass canopy
• Steel FOPS canopy
• Front fenders for FWD front axle
• Air ride seat (cab only)
• Seat armrests
• Rotary beacon (cab only)
• Engine block heater
• Offset drawbar for Galaxy turf
• Drawbar clevis
• Low profile 2WD front axle
• Carbon filters
• Full width coverage fenders extension
(Deluxe SuperSteer only)
• Rear window wiper and washer
