TD Tractor Specifications
TD80D TD5050 TD5050 High-Clearance
Page 1 of 3
MODEL TD80D TD5050
ENGINE
Type 4-cycle, diesel, naturally aspirated 4-cycle, diesel, turbo-charged
Number of cylinders 44
Displacement, cu. in. ( ) 238 (3.9) 274 (4.5)
Gross engine horsepower, hp (kW) 72 (53) 93 (69.4)
PTO horsepower, hp (kW) 62 (46.2) 80 (59.7)
Rated speed, RPM ....................................................................................................................................2500..........................................................................................................
Maximum torque 206 ft.-lbs. @ 1500 RPM 288 ft.-lbs. @ 1300 RPM
Torque rise 28% 44%
Fuel type...........................................................................................B20 Biodiesel (meeting ASTM 6751 standards) and/or standard diesel fuels .................................................
Air filter..................................................................................Dual element, dry type with cleanable outer element and replaceable inner safety element ......................................
ubrication..........................................................................................Full flow, pressure lubrication with vertical mount spin-on filter cartridge....................................................
Oil & filter change interval....................................................................................................................300 hours......................................................................................................
Starting aid..........................................................................................................................................Thermostart ...................................................................................................
Throttle....................................................................................................................................Hand and/or foot controlled........................................................................................
Exhaust .....................................................................................Under hood muffler w/ vertical exhaust pipe, optional under-slung horizontal exhaust..........................................
Emissionization standard Tier-II Tier-III
Fuel tank capacity, gal. ( ) ...................................................................................................................23.8 (90.1).....................................................................................................
TRANSMISSION
Base on standard tractor........................12Fx12R with synchronized mechanical shuttle (4 synchronized speeds in 3 constant mesh ranges, dedicated left hand shuttle)........
Optional transmission.......................................................................................20Fx12R creeper with synchronized mechanical shuttle..................................................................
(4 synchronized speeds in 3 non-synchronized ranges, creeper operates in lower 2 ranges)
Traction clutch, in. (mm) Dry 11 (279.4) diameter heavy duty Dry 12 (304.8) diameter heavy duty organic plate cerametallic plate
Ground speed*, mph (kph) .............................................Base transmission: Forward - 1.05 to 17.3 (1.69 to 27.8), Reverse - 1.02 to 16.9 (1.64 to 27.2).................................
.....................................................................................Optional creeper transmission: Additional 8 forward speeds between 0.2 - 1.9 (.322 - 3.06).....................................
Rear axle, in. (cm)...........................................................................................................59 - 79 (150 - 201) track adjustment ................................................................................
Rear differential lock .........................................................................................................Mechanical foot pedal engagement..................................................................................
Service brakes ..............................................................................................Hydraulically assisted wet disc, self-adjusting and equalizing .............................................................
Parking brake............................................................................................................Hand-lever engagement, locks service brakes..........................................................................
HYDRAULICS
System type ...............................................................................................................Open center, fixed displacement gear pump...........................................................................
System pressure, psi (bar)..................................................................................................................2,755 (190) ....................................................................................................
Implement pump capacity, gpm (l/m) 13.6 (51.5) 17.2 (65.1)
Steering & services system, gpm (l/m) Hydrostatic power steering 9.2 (34.8)
w/dedicated gear pump - 8.1 (30.1)
Total maximum tractor flow, gpm (l/m) 21.7 (82.1) 26.4 (99.9)
Remote valves - standard.......................................................1 open center, rear mounted, color coded lever controls with quick coupler dust covers........................................
Remote valves - optional ...................................................Up to 3 open center, rear mounted, color coded lever controls with quick coupler dust covers...................................
2 valve open center loader control valve, joystick controlled (needed for loader operations)
3-POINT HITCH
Rear .......................................................................................................................................................Standard.......................................................................................................
Category.......................................................................................................................................................II.............................................................................................................
Position control / draft sensing ......................Two levers w/ ability to blend draft and position control / mechanical, lower link sensing w/ hydraulic position control................
ower link ends.......................................................................................................................................Flexible........................................................................................................
Stabilizers .............................................................................................................................................Telescopic......................................................................................................
ASAE lift capacity @ 24 in., lbs. (kg) .................................................................................................5,025 (2280) ...................................................................................................
Fast raise / lower control......................................................................Standard equipment, mechanical push button with finger-tip operation .....................................................
Upper limit regulation......................................................................Standard equipment, adjustable mechanical stop limit on hitch upper lift arm ................................................

New Holland
TD Tractor Specifications
TD80D TD5050 TD5050 High-Clearance
Page 2 of 3
MODEL TD80D TD5050
PTO
Rear ................................................................................................................................Standard, w/ flip-up PTO shaft guard ................................................................................
Clutch type ...........................................................................................................................Independent, dry, organic plate.....................................................................................
Clutch diameter, in. (mm) 11 (279.4) 12 (304.8)
Engagement.....................................................................................................................Single lever, mechanical engagement ................................................................................
Speed, RPM 540 540 (540/1000 optional)
FRONT AXLE
2WD, track adjustment, in. (cm) ............................................................................Heavy duty, adjustable, 55 - 75 (139.7 - 190.5) ........................................................................
Maximum turn angle, degrees....................................................................................................................55............................................................................................................
FWD, track adjustment, in. (cm) ...............................................Center differential with planetary final drives in wheel hubs, 61 - 78 (154.9 - 198.1) ...........................................
Maximum wheel turn angle, degrees (FWD)..............................................................................................50............................................................................................................
Front differential lock........................................................................................................................... imited slip.....................................................................................................
FWD clutch engagement.......................................................................................................Mechanical lever engagement ......................................................................................
ELECTRICAL
Alternator..........................................................................................................................................12 volt, 65 amp .................................................................................................
Battery capacity (cold cranking amps) ......................................................................................................800...........................................................................................................
ighting ..................................................................................2 hi/lo beam headlights, 1 rear worklight, brake lights, flashing safety lights/turn signals
(cab has 2 additional front worklights and 1 additional rear worklight)
Accessory power outlets.......................................................Standard equipment, 7-pin implement outlet, 4-pin (25 Amp) outlet, 1-pin (8 Amp) outlet ......................................
Fuses...........................................................................................................................................Automotive blade type............................................................................................
APPROXIMATE SHIPPING WEIGHT
ROPS - 2WD / FWD, lb. (kg) 5,702 / 6,254 (2586 / 2837) 6,107 / 6,659 (2770 / 3021)
CAB - 2WD / FWD, lb. (kg) 6,363 / 6,915 (2886 / 3137) 6,768 / 7,320 (3070 / 3320)
APPROXIMATE DIMENSIONS
Height to Top of ROPS, in. (mm) 101.1 (2568)* 101.1 (2568)*
Height to Top of cab, in. (mm) 103.1 (2619)* 103.1 (2619)*
WHEELBASE
2WD, in. (mm) 91 (2311) 94 (2387)
FWD, in. (mm) 87 (2209) 92 (2336)
†Manufacturer's estimate *measured with 16.9x30 rear tires

Page 3 of 3
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
© 2009 CNH America LLC
New H lland is a registered trademark f CNH America LLC.
Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).
New Holland
TD Tractor Specifications
TD80D TD5050 TD5050 High-Clearance
MODEL TD5050 High-Clearan e
ENGINE†
Type 4-cycle, diesel, turbocharged intercooled
Number of cylinders 4
Displacement, cu. in. ( ) 274 (4.5)
Gross engine horsepower, hp (kW) 90 (67)
PTO horsepower, hp (kW) 80 (59.7)
Rated speed, RPM 2500
Maximum torque 346 ft.-lbs. @ 1500 RPM
Torque rise, % 44
Fuel type 100% Biodiesel approved (meeting ASTM
6751 standards, see your New Holland dealer
for guidelines) and/or standard diesel fuels
Air filter Dual element, dry type with cleanable outer
element and replaceable inner safety element
ubrication Full flow, pressure lubrication with
vertical mount spin-on filter cartridge
Oil & filter change interval, hours 300
Starting aid Thermostart
Throttle Hand and/or foot controlled
Exhaust Under hood muffler w/ vertical exhaust pipe,
optional under-slung horizontal exhaust
Emissionization standard US EPA Tier III
Fuel tank capacity, gallons ( ) 31 (118)
TRANSMISSION
Standard transmission 20Fx12R creeper with synchronized mechanical
shuttle (4 synchronized gears and 3 ranges,
creeper operates in lower 2 ranges)
Traction clutch Dry 12 inch diameter heavy duty cerametallic plate
Ground speed*, mph Forward: 0.15-17.5
Reverse: 1.01-16.8
Two creeper ranges provide minimum
groundspeed of 13.1 ft./min. (400 cm/min.)
at 2,500 egine RPM
Rear differential lock Mechanical foot pedal engagement
Service brakes Individual hydraulic wet disc, self-adjusting
and equalizing
Parking brake Hand-lever engagement, locks service brakes
HYDRAULICS
System type Open center, fixed displacement gear pump
System pressure, psi 2,755
Implement pump capacity,
gpm ( /min) 16.1 (61)
Steering & services system Hydrostatic power steering w/dedicated gear
pump - 7 gpm (26.5 /min)
Total maximum tractor flow,
gpm ( /min) 23.1 (87.5)
Remote valves - standard 1 open center, rear mounted, color coded lever
controls with quick coupler dust covers
Remote valves - optional Up to 3 open center, rear mounted, color coded
lever controls with quick coupler dust covers
MODEL TD5050 High-Clearan e
3-POINT HITCH
REAR Standard
Category II
Position control / draft sensing Two levers w/ ability to blend draft and position
control / mechanical, lower link sensing w/
hydraulic position control
ower link ends Flexible
Stabilizers Telescopic
ASAE lift capacity @ 24 in., lbs. (kg) 5,025 (2279)
Fast raise / lower control Standard ift-O-Matic, mechanical push button
with finger-tip operation
Upper limit regulation Standard equipment, adjustable mechanical
stop limit on hitch upper lift arm
PTO
REAR Standard, w/ flip-up PTO shaft guard
Clutch type Independent, dry, organic plate
Clutch diameter, in. (mm) 12 (305)
Engagement Single lever, mechanical engagement
Speed 540 RPM (540/1000 optional)
ELECTRICAL
Alternator 12 volt, 120 amp
Battery capacity
(cold cranking amps) 800
ighting 2 hi/lo beam headlights, 1 rear worklight, brake
lights, flashing safety lights/turn signals
Accessory power outlets Standard equipment, 7-pin implement outlet,
4-pin (25 Amp) outlet, 1-pin (8 Amp) outlet
Fuses Automotive blade type
APPROXIMATE SHIPPING WEIGHT
ROPS - 2WD / FWD, lbs. (kg) 7,888 / 8,818 (3578 / 4000)
APPROXIMATE DIMENSIONS
Height to top of ROPS, in. (mm) 115.7 (2940)*
WHEELBASE
2WD, in. (mm) 89.7 (2278) – narrow axle
FWD, in. (mm) 87.5 (2222) – narrow axle
2WD, in. (mm) 85.3 (2168) – wide axle
FWD, in. (mm) 83.1 (2112) – wide axle
TRACK WIDTH Minimum Maximum
Rear without spacers, in. (mm) 59.2 (1504) 79.6 (2021)
Rear with spacers, in. (mm) 72.2 (1834) 83.8 (2130)
Front 2WD, in. (mm) 61.6 (1566) 77.4 (1966)
Front 4WD, in. (mm) 61.7 (1569) 81.9 (2082)
†Manufacturer's estimate
*measured with 320/80R42 tires
