TN-A Series Tractor Specifications
TN60A/TN60DA TN70A/TN70DA TN75A/TN75DA/TN75SA TN85A/TN85DA TN95A/TN95DA
Page1of 3
TN60A TN70A TN75A TN85A TN95A
TN60DA TN70DA TN75DA TN85DA TN95DA
MODEL TN75SA
ENGINE
Gross engine hp (kW)* 57 (42.5) 70 (52.2) 75 (55.9) 80 (59.7) 90 (67.1)
PTO hp (kW)* 45 (33.6) 57 (42.5) 62 (46.3) 69 (51.5) 77 (57.4)
Cylinders ...........................................................3........................................................... ......................................4......................................
Aspiration Natural Turbocharged Turbocharged Natural Turbocharged
Displacement, cu. in. (L) ....................................................179 (2.9) .................................................... ...............................274 (4.5) ...............................
Rated speed, rpm .................................................................................................2300 .................................................................................................
Maximum Torque, ft.-lbs. (Nm) 159 @ 1400 rpm 213 @ 1400 rpm 220 @ 1400 rpm 236 @ 1400 rpm 269 @ 1400 rpm
(216 @ 1400 rpm) (289 @ 1400 rpm) (298 @ 1400 rpm) (320 @ 1400 rpm) (365 @ 1400 rpm)
Engine torque rise, % 26 32 36 32 37
Fuel capacity, gal. (L) ................................23 (87) on TN-A Standard models ................................ ...............................23.5 (89) ...............................
...............................19.5 (74) TNS-A and TND-A models...............................
*mfg’s estimate
TRANSMISSIONS
Choice of transmission
•8x8constant mesh transmission with synchronized mechanical shuttle (available on select TN-A models only)
•12 x 12 Synchro Command™ transmission with synchronized mechanical shuttle (available on TN-A models only)
•12 x 12 Synchro Command™ transmission with power shuttle (available on TN95A and TN95DA)
•16 x 16 Synchro Command™ transmission with your choice of synchronized mechanical or electro-hydraulic, no-clutch power shuttle (Except TN95A and TN95DA)
TRACTION CLUTCH
w/ mechanical shuttle, in. (mm) 11 (280) ........................................................................11 (280)........................................................................
Dryorganic plate ............................................................. Dry cerametallic plate.............................................................
w/ electro-hydraulic power shuttle, in. (mm) ............................................................................Six 5.2 (113) wet organic plates............................................................................
Differential lock (front/rear) .....................Limited slip, mechanically engaged (electro-hydraulically engaged on TN75SA SuperSteer™ models).....................
ELECTRICAL
Alternator (amps)
Less cab ..........................................................65.......................................................... ....................................120....................................
With cab ..........................................................85.......................................................... ....................................120....................................
Cold cranking amps ..................................................................................................730 ..................................................................................................
BRAKES
Type ...............................................................................Wet, two disc, self-adjusting...............................................................................
Parking brake ..........................................................................Independent, four 3.5 in. wet disc ..........................................................................
INDEPENDENT PTO
Speed ..................................................................................................540 ..................................................................................................
PTO clutch, in. (mm) .............................................................................11 (280) dry cerametallic plate.............................................................................
HYDRAULICS
Pump type ..................................................................................................Gear..................................................................................................
System ............................................................................................Open center............................................................................................
Nominal system pressure, PSI (bar) ............................................................................................2755 (190) ............................................................................................
Standard pump flow, gpm (lpm) 12.8 (48) 12.8 (48) 16.9 (64) 15.0 (56.9) 15.0 (56.9)
Optional pump flow,gpm (lpm) 16.9 (64) 16.9 (64) NA NA NA
STEERING SYSTEM
Steering Pump Type ..................................................................................................Gear..................................................................................................
provides flow for power steering, FWD engagement, differential lock engagement and lubricating the transmission
Pump flow,gpm (lpm)
with mechanical shuttle ....................................7.4 (28.0).................................... .........................................9.4 (35.6) ...................................................
with power shuttle .............................................................................................9.4 (35.6) .............................................................................................

New Holland
TN-A Series Tractor Specifications
TN60A/TN60DA TN70A/TN70DA TN75A/TN75DA/TN75SA TN85A/TN85DA TN95A/TN95DA
Page 2 of 3
TN60A TN70A TN75A TN85A TN95A
TN60DA TN70DA TN75DA TN85DA TN95DA
MODEL TN75SA
3-POINT HITCH
Category ...................................................................................................II, I...................................................................................................
Draft control sensing ...................................................................................Mechanical, lower link ...................................................................................
Fast raise/lower ..............................................................................................Standard ..............................................................................................
Link ends ...............................................................................................Flexible ...............................................................................................
Lift capacity, SAE @ 24", lb. (kg) ...........................................................................................3960 (1800) ...........................................................................................
TURNING WITHOUT BRAKES, ft. (mm)
2WD turning radius ..................................................11.9 (3628) .................................................. 12.1 (3678) NA
2WD turnaround diameter ..................................................14.0 (4255) .................................................. 14.1 (4305) NA
FWD turning radius ..................................................12.5 (3810) .................................................. .............................12.7 (3860) .............................
FWD turnaround diameter ..................................................14.1 (4288) .................................................. .............................14.2 (4340) .............................
FWD SuperSteer™ turning radius NA NA 11.2 (3415) NA NA
FWD SuperSteer turnaround diameter NA NA 6.7 (2043) NA NA
VEHICLE WEIGHT* lbs. (kg)
TN-A 2WD 4980 (2260) 5020 (2275) 5020 (2275) 6008 (2725) NA
TN-A FWD 5375 (2440) 5415 (2455) 5415 (2455) 6118 (2775) 6118 (2775)
TND-A 2WD 5565 (2525) 5605 (2545) 5605 (2545) 6449 (2925) NA
TND-A FWD 5960 (2705) 6000 (2720) 6000 (2720) 6559 (2975) 6559 (2975)
TNS-A FWD, ROPS NA NA 5585 (2535) NA NA
TNS-A FWD, Cab NA NA 6050 (2745) NA NA
TIRE OPTIONS
R1 "General Farming"- great for a wide variety of agricultural applications.
R3 "All Weather"- great for highway mowing, parks, orchards and light industrial applications.
R4 "Industrial"- great for light industrial applications, rental yards, contractors and municipalities.
Galaxy "TurfSpecial"- great for golf courses and stadium grounds maintenance.
*Approximate weights for base tractor with full fuel tank; 16.9x28R1 rear tires and 9.5Lx15 (2WD) or 12.4R20 (FWD) front tires; mechanical shuttle transmission; without front weights or rear
wheel weights; or rear wheel weights; single rear remote valve
TN60A TN60DA TN75SA TN85A TN85DA
TN70A TN70DA TN95A TN95DA
DIMENSIONS* TN75A TN75DA
Wheelbase, in. (mm)
2WD 81.5 (2070) 83.9 (2131) NA 86.7 (2202) (TN85A) 89.1 (2262) (TN85DA)
NA (TN95A) NA (TN95DA)
FWD 78.9 (2005) 81.3 (2065) 93.5 (2375) 83.7 (2125) 86.0 (2185)
Height, in. (mm)
Top of ROPS, up 95.1 (2416) NA 95.1 (2416) 95.1 (2416) NA
Top of ROPS, down 75.1 (1908) NA 75.1 (1908) 75.1 (1908) NA
Top of cab NA 90.8 (2307) 90.8 (2307) NA 90.8 (2307)
Overall length (front weight to end of 3-pt. lift arms), in. (mm)
2WD 153.3 (3894) 155.7 (3954) NA 157.5 (4000) (TN85A) 159.8 (4059) (TN85DA)
NA (TN95A) NA (TN95DA)
FWD 151.6 (3852) 154 (3912) 154.9 (3935) 157.5 (4000) 159.8 (4059)
Min/Max. overall width .................................................................................67.2 (1708) / 92.7 (2355).................................................................................
*Base tractor with: 14.9x28 rear tires, 9.5x15 front (2WD), 11.2x20 (FWD)

New Holland
TN-A Series Tractor Specifications
TN60A/TN60DA TN70A/TN70DA TN75A/TN75DA/TN75SA TN85A/TN85DA TN95A/TN95DA
Page 3 of 3
•Second rear remote valve
(lever controlled)
•Third rear remote valve
(lever controlled)
•Fourth rear remote valve (lever
controlled — available on TND-A and
TN75SA models when a mid-mount
valve is not installed)
•Mid-mount valve with joystick control
•Back up alarm wiring kit
•Special tires
•7pin implement (trailer) electrical
plug
•Horn
•Front weight bracket kit
•Grill guard
•88 lb. front weights
•4pin power outlet (25 amp) electrical
plug
•Fixed external mirrors (cab only)
•Rear wheel weights
•Telescoping external mirrors
(cab only)
•Hydraulic filter protection kit
•Single pin male 8 amp electrical plug
•Horizontal exhaust kit
•Blue fiberglass canopy
•Front fenders for FWD front axle
•White fiberglass canopy
•Seat armrests
•Steel FOPS canopy
•Drawbar clevis
•Rotary beacon (cab only)
•Engine block heater
•Offset drawbar for Galaxy turf
OPTIONAL EQUIPMENT
Safety begins with a thorough understanding of
the equipment. Always make sure you and
your operators read the Operator’s Manual
beforeusing the equipment. Pay close
attention to all safety and operating
decals and never operate machinery
without all shields, protective devices
and structures in place.
