MS260i
IMAGING ¼ M SPECTROGRAPH
MODELS 74050, 74055, 74085, 74086
`
USER MANUAL

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
TABLE OF CONTENTS
I. INTRODUCTION........................................................................................................................................3
I.1 OPTICAL CONFIGURATION..........................................................................................................................3
I.2 DESIGNED FOR MULTI-TRACK SPECTROSCOPY.....................................................................................3
I.3 NEGLIGIBLE STRAY LIGHT ..........................................................................................................................3
I.4 EXCELLENT SPECTRAL RESOLUTION.......................................................................................................3
I.5 WAVELENGTH DRIVE...................................................................................................................................3
II. UNPACKING AND SETTING UP .............................................................................................................4
II.1 SOFTWARE INSTALLATION ........................................................................................................................5
II.2 USB INSTALLATION FOR THE 74125.............................................ERROR! BOOKMARK NOT DEFINED.
II.3 UTILITY PROGRAM INSTALLATION............................................................................................................6
III. SAFETY ...................................................................................................................................................8
IV. 15 MINUTE BASICS................................................................................................................................9
IV.1 GETTING STARTED WITH THE HAND CONTROLLER .............................................................................9
IV.2 GETTING STARTED WITH IEEE-488........................................................................................................12
IV.3 GETTING STARTED WITH RS-232 COMMUNICATIONS.........................................................................13
V. FUNCTIONS AND CONTROLS.............................................................................................................15
V.1 COMMAND AND QUERY SYNTAX............................................................................................................15
V.2 HANDSHAKING MODE...............................................................................................................................16
V.3 BRIEF COMMAND REFERENCE ORGANIZED ALPHABETICALLY.........................................................17
V.4 DETAILED COMMAND REFERENCE ORGANIZED BY FUNCTION.........................................................18
V.5 ERROR CODES WITH DESCRIPTIONS....................................................................................................23
VI. MS260iUTILITY PROGRAM .............................................................................................................24
VI.1 SOURCE CODE.........................................................................................................................................25
VI.2 IEEE-488 VERSION...................................................................................................................................25
VI.3 RS-232 VERSION ......................................................................................................................................26
VI.4 USB VERSION 74085/74086 .....................................................................................................................26
VII. OPTIONAL ACCESSORIES ................................................................................................................27
VII.1 MICROMETER DRIVEN SLIT...................................................................................................................27
VII.2 FILTER WHEEL.........................................................................................................................................27
VII.3 ADDITIONAL GRATINGS- WAVELENGTH CALIBRATION......................................................................27
VII.4 MEMORY LOSS (LARGE WAVELENGTH CALIBRATION ERRORS) .....................................................31
VIII. DECLARATION OF CONFORMITY....................................................................................................32
IX. WARRANTY AND RETURNS...............................................................................................................33

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
3
I. INTRODUCTION
This new spectrograph is in answer to your requests for an economical, fully automated, multi-grating, ¼
m imaging spectrograph. For those familiar with our popular MS257¼ m Spectrograph, the MS260i
meets many of the performance standards in a simplified design, and is more economical.
The MS260ioffers the best performance to price ratio of any spectrograph on the market.
The MS260iis an F/3.9 instrument with a single flat, 28 x 10 mm output port for multichannel detectors.
Stray light is negligible, throughput is high and spatial and spectral resolution are impressive. Three
communication interfaces are available via two versions of the board; one with RS232 and IEEE488 and
one with USB only. Control via optional Hand Controller is available.
This manual applies to the:
74050 MS260 MS260 (single output port) which has RS232 and GPIB communications interface
74085 MS260 MS260 (single output port) which has a USB communications interface
74055 MS260 MS260 (dual output port) which has RS232 and GPIB communications interface
74086 MS260 MS260 (dual output port) which has a USB communications interface
I.1 OPTICAL CONFIGURATION
The MS260ifeatures an asymmetrical in-plane Czerny-Turner optical configuration.The input F/# is
F/3.9, and the input and exit focal lengths are unequal 220 and 257 mm.A set of computer designed
toroidal mirrors produce accurate images of the input slit in the flat output plane.
I.2 DESIGNED FOR MULTI-TRACK SPECTROSCOPY
Multi-track Spectroscopy is the simultaneous recording of multiple spectra. You can’t find a better
Multi-track Spectroscopy instrument combination than Oriel’s Imaging CCD Detectors and MS260i.
One of the factors limiting the number of spectra, which can be recorded simultaneously, is the
spectrograph’s magnification. MS260iuses two toroidal mirrors to achieve optimum imaging. These
mirrors have different horizontal and vertical radii. The result is a 1.1x horizontal and 1.6x vertical
magnification.
I.3 NEGLIGIBLE STRAY LIGHT
One of the design criteria for MS260iwas to eliminate light scatter inside the instrument, one of the
main contributors to stray light. It is important that diffracted light not be allowed to reflect from the
mirrors, or from the face of a focal plane detector, back onto the grating. This light could then be
re-diffracted and cause ghost images or stray light at the detector. The wide open optical layout and
exaggerated tilt of the exit focal plane of the MS260iensure that there is zero re-entrant spectra.
I.4 EXCELLENT SPECTRAL RESOLUTION
Resolution of 0.25 nm, with a 0.25 µm slit and a 1200 l/mm grating, is possible with the MS260i!
This compares to 0.4 nm with a 25 µm slit for the MS127i, 1/8 m Imaging Spectrograph.
I.5 WAVELENGTH DRIVE
The MS260iuses a high speed stepping motor drive for rapid wavelength changes.This same drive
is used to change the grating; a grating change takes only 10 seconds.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
4
II. UNPACKING AND SETTING UP
Carefully unpack the MS260iSpectrograph and its accessories. The packaging is molded to your
instrument and therefore provides optimal protection. You should save the packaging in case you ever
need to transport or ship this instrument.
Your MS260icomes completely assembled with up to three gratings installed.Your fixed slit housings, or
micrometer driven slits, are mounted at our factory. The instrument is closed and the optical ports are
covered to prevent contamination of the optics during shipment. Included with the MS260iyou should
also find:
1. this manual
2. a tabletop power supply (universal input)
3. a line cord for your country
4. any additional gratings you ordered
5. a CD-ROM containing your MS260isoftware
Since the MS260iis aligned and calibrated at our factory, there is no need to remove the top. You can
get started immediately by connecting the 5 pin DIN connector of the power supply to the MS260iback
panel, connect the line cord to both the power supply and the wall, and then turn on the MS260ipower
switch. You will hear the monochromator drive to its home position, then any accessories like Filter Wheel
and/or Motorized Slits will home, finally the wavelength drive will position to the previous grating and
wavelength position.
The external BNC on the chassis is to facilitate external TTL control of the Shutter. A TTL low (or short)
will activate (Open) the Shutter. Control can be overridden by the shutter commands from a computer or
the shutter key on the hand controller.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
5
II.1 SOFTWARE INSTALLATION
Newport provides an elementary software package with your CornerstoneMS260. To load and run
the software you must have a PC compatible computer (with CDROM drive) running Microsoft
Windows XP SP1or above. For the 74085/74086 a USB2 port is required. To successfully complete
the Install of the MS260 USB driver or the Utility software you must have Administrator
privileges on the PC which you are performing the install.
The CD contains the installation for the Utility program, LabView VIs and the USB drivers. The Utility
Program provides easy access to almost all Cornerstonefunctions and is discussed in Section VI
CORNERSTONEUTILITY PROGRAM.Additionally, you can use the LabView VIs when writing your
own LabView software for Cornerstone(National Instruments LabView 8.5 required). The source
code for both Utility program is included with the 74100 VIs to be used as an example.
There are three versions of the basic Cornerstonesoftware. The first version is for IEEE-488
communications.This version requires that you have a National Instruments IEEE-488 controller card
and the corresponding software drivers installed in your PC. The second version is for RS-232
communications. There is also a USB version for the 74125 version of the MS260, the USB driver
must be installed for that version to function. In all cases, the software looks the same, and has the
same functionality.
See the Table I below for where to find the Utility install program, the VIs and the USB drivers.
Table I(Cornerstone Utility CD 74050/74055 74085/74086 relevant directories)
Directory on
Utility CD Sub-directory containing
Install Program (Setup.exe)
for the Utility application
Sub-directory containing
LabView VIs
MS260 using RS232
Single output port \740500RS232\ \74050RS232\Utility\Installer \74050RS232\
MS260 using GPIB
Single output port \74050GPIB\ \74050GPIB\Utility\Installer \74050GPIB\
74085 CS260 USB
Single output port \74085\ \74085\ Utility\Installer \74085\
MS260 using RS232
Dual output port \74055RS232\ \74055RS232\Utility\Installer \74055RS232\
MS260 using GPIB
Dual port output port \74055GPIB\ \74055GPIB\ Utility\Installer \74055GPIB\
74086 CS260 USB
Dual output port 74086\ \74086\ Utility\Installer \74086\
74085/74086 USB
drivers and install file \USB DRIVERS
-- --

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
6
II.2 UTILITY PROGRAM INSTALLATION
IMPORTANT: Do not connect any USB Cornerstone™ to the computer unless the USB
driver has been installed, or until prompted to do so.
Note: If the Utility software will not be installed with USB Model 74085/74086, please
skip to §II.3 , p. 7.
1. Put the Cornerstone™CD-ROM into your computer drive.
2. Select Run... from the Windows Start Menu. Then click on the Browse...button. Now use the
controls in the Browse dialog box to select the Cornerstone™ CD, browse to the folder for your
instrument as shown inTable I above. Inside the folder you will find “Setup.exe”.Double-click on this
program and then press the OK button in the Run dialog box.
3. The Installation program will appear, follow the prompts to install the Utility software on you PC.The
default directories and Start Menu groups will work on most machines and should be used if
possible.This simplifies the installation as you only need to click the “Next” button a few times.
4. Another install program will run and you should be able to use the default values again. Simply click
“Finish” to complete the installation.
5. If using USB Model 74085/74086, follow the connection procedure in §II.3 , p.7 starting at Step #6.
6. You are now ready to work with the Cornerstone™. Please review the Safety section in detail
before proceeding to the 15 Minute Basics.
<< IMPORTANT NOTE >>
For the software to send proper numeric format to the instrument, Windows Regional Settings in
Control Panel must be set to English (United States).
7. Put the Cornerstone™CD-ROM into your computer drive.
8. Select Run... from the Windows Start Menu. Then click on the Browse...button. Now use the
c
ontrolsi
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
o
ntrolsi
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
n
trolsi
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
rolsi
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
r
olsi
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
o
lsi
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
l
si
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
s
i
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
i
n t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
in t he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
nthe Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
the Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
the Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
he Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
eBro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
Bro wse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
rowsedialogbox to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
owse di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
wsedi al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
se di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
edi al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
di al og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
dialogbox to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
ial og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
alogbox to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
log box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
og box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
gbox to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
box to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
ox to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
xto selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
to selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
oselec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
selec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
elec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
lec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
ec
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
c
tt
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
t
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
h
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
e
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
C
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
o
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
n
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
e
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
s
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
o
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
n
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
e
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
•
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
C
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
D
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
,
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
b
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
o
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
w
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
s
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
e
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
o
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
t
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
h
e
f
o
l
d
e
r
f
o
r
y
o
u
r
e
f
o
l
d
e
r
f
o
r
y
o
u
r
f
o
l
d
e
r
f
o
r
y
o
u
r
f
o
l
d
e
r
f
o
r
y
o
u
r
o
l
d
e
r
f
o
r
y
o
u
r
l
d
e
r
f
o
r
y
o
u
r
d
e
r
f
o
r
y
o
u
r
e
r
f
o
r
y
o
u
r
r
f
o
r
y
o
u
r
f
o
r
y
o
u
r
f
o
r
y
o
u
r
o
r
y
o
u
r
r
y
o
u
r
y
o
u
r
y
o
u
r
o
u
r
u
r
r
instrument as shown in Table I above. Inside the folder you will find “Setup.exe”. Double-click on
this program and then press the OK button in the Run dialog box.
9. The Installation program will appear, follow the prompts to install the Utility software on you PC.
The default directories and Start Menu groups will work on most machines and should be used if
possible.This simplifies the installation, as you only need to click the “Next” button a few times.
10. Another install program will run and you should be able to use the default values again. Simply
click “Finish” to complete the installation. You are now ready to work with the Cornerstone™.
Please review the Safety section in detail before proceeding to the 15 Minute Basics.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
7
II.3 DRIVER INSTALLATION FOR USB MODEL 74085/74086
IMPORTANT: Do not connect any USB Cornerstone™ to the computer unless the USB
driver has been installed, or until prompted to do so.
Note: If the monochromator(s) will be used with the optional TRACQ Basic™ software,
follow its installation procedure now and disregard the remainder of this section.
Perform the following steps to install the USB driver for use with OEM or any other applications:
1. Log into a Windows user account with Administrator privileges.
2. Insert the Cornerstone™ CD-ROM into a CD or DVD drive and locate the USB drivers folder from
Table I (§Error! Reference source not found., p. Error! Bookmark not defined.).
3. Right-click on the file “oriel_cs_usb.inf” and select the Install option from the pop-up context menu.
Note: If filename extensions are not displayed, two files will appear as “oriel_cs_usb”. If the menu
does not display the Install option for one file, use the other one.
4. If any warning dialogs appear stating that the driver is “not signed” or “has not passed Windows
Logo testing”, click “Continue Anyway” to proceed.
5. Driver installation will complete silently if successful.
Note: If an “Installation failed” dialog appears, the logged-in Windows user account may not have
Administrator privileges required for installation. Please consult with your system manager and
repeat from Step #1 before contacting Newport/Oriel Customer Service.
6. Power-on one Cornerstone™ monochromator, then connect its USB cable to the computer. Do not
connect any additional devices yet.
7. When the “Found New Hardware” wizard appears, select the option “Install the software
automatically (Recommended)”, then click the “Next >” button. (It is not necessary to have the
CD-ROM in the drive at this point.)
8. If any warning dialogs appear stating that the driver is “not signed” or “has not passed Windows
Logo testing”, click “Continue Anyway” to proceed.
9. After the wizard completes, click the “Finish” button.
10. Repeat from Step #6 for any additional monochromators.
Note: If a Cornerstone™ is connected to a different USB port on the same computer at
a later time, it may be necessary to repeat installation Steps #7 through #9.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
8
III. SAFETY
Electrical
The MS260irequires only DC voltages for operation.These voltages are provided by an external power
supply.This universal input power supply accepts 110/220 VAC for operation and has no user serviceable
parts. Do not attempt to open the external power supply. Do not attempt to work in the MS260i’s
electrical compartment without first disconnecting the power cord, since you may contact live voltage
areas inside the compartment even with the power switch in the “off” position.
MS260ihas an internal microprocessor and should be installed with appropriate surge/EMI/RFI
protection on all power lines. Dedicated power lines or line isolation may be required for some extremely
noisy sites. The circuits used in MS260iare extremely sensitive to static electricity and radiated
electromagnetic fields. Operation of MS260iclose to intense pulsed sources (lasers, xenon strobes or
arc lamps, etc.) may compromise performance, if shielding is inadequate, and may cause permanent
damage to the microprocessor. Note:This instrument conforms to European CE standards for both safety
and EMC.
Mechanical
Avoid dropping, sudden shocks, or rough handling of the spectrograph since this may cause the system to
lose its calibration and may destroy the high precision drive components or optics.
Do not use more than finger force in tightening down the grating mounts, since this may cause damage to
the drive assembly.
Optical
Do not touch any optical surfaces since this is likely to cause irreparable damage.Do not attempt to clean
any optical surface except by blowing off dust or lint particles with a stream of dry clean air or nitrogen.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
9
IV. 15 MINUTE BASICS
IV.1 GETTING STARTED WITH THE HAND CONTROLLER
The 74009 Hand Controller is a fast and easy way to begin immediate communications with the
MS260i. Although the Hand Controller does not provide access to all the functions of this
instrument, it does provide a simple interface to the most commonly used parameters and controls.
Physical Connections
Please note: None of the MS260iaccessories are designed to be connected or disconnected with
power on.Always turn off the instrument using the power switch on the back panel before you connect
or remove the filter wheel or any communications cable (including the Hand Controller).
To get started with 74009 Hand Controller, simply connect the black communications cable by
snapping the RJ-11 connector into the receptacle on top of the controller and snapping the other end
into the matching connector on the back panel of your MS260i.
Color Coding
The functional keys on the Hand Controller are divided into various color-coded groups as follows:
Red key at top left “Abort” wavelength motion in progress, also clears pending commands.
Blue keys at the top Control wavelength motion.
Red frame in row #2 Pertain to constant rate scanning.
Orange frame in row #2 Grating position and parameters.
Green frame on left side Control accessories including filter, shutter, output port (when available).
Blue frame on left side Toggle local/remote communications and sets operating units (shifted).
Activating the Hand Controller
With the Hand Controller connected, turn on power to the MS260i.You will see a horizontal cursor
in the upper left corner of the display. Press the LOCAL key to activate communications through the
Hand Controller. Please note that if the Hand Controller is active (the display is lit and information fills
the screen), you cannot command the MS260ivia either RS-232, IEEE-488 or USB. Press the
LOCAL key again to deactivate the Hand Controller, allowing PC communications.
Yellow “Shifted” Keys
Some keys are divided into top and bottom halves. The function for the yellow top half is called a
“shifted” function.To activate these commands press the SHIFT key in the bottom left corner and then
press the function key.
Entering Parameters- the Numeric Keypad
Many of the MS260icommands require a numeric parameter. First press the function key for your
command. The bottom line of the LCD display will then show an abbreviated form of the command
and the current parameter. There is no need to erase this number, simply typing the first key for your
desired parameter will overwrite the current value.To execute the command press the ENTER key in
the bottom right corner.
While entering parameters, if you mistype one digit press SHIFT and then DEL (above the decimal
point in the numeric keypad); this will move backward one display position and delete that character.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
10
Key Reference
(From Top of the Controller to the Bottom, Left to Right)
ABORT If you accidentally press a function key or enter a bad parameter you may press the
ABORT key to clear that command before it executes. The ABORT key has no effect
on most functions once the command is executed (by pressing ENTER). However,
wavelength motion will stop immediately upon ABORT and the display will update to
show the wavelength where motion was halted.
STEP DOWN Press this key once to move the MS260ito shorter wavelengths by the smallest
possible increment. Holding this key causes rapid single stepping toward lower
wavelengths. Press SHIFT and then STEP DOWN, you can use the keypad to define
a number of steps to move at once. Press ENTER to execute this larger move.
STEP UP Press this key once to move the MS260ito higher wavelengths by the smallest
possible increment. Holding this key causes rapid single stepping toward higher
wavelengths. Press SHIFT and then STEP UP, you can use the keypad to define a
number of steps to move at once. Press ENTER to execute this larger move.
GO WAVE This key induces wavelength motion to a specified position. Press GO WAVE, then
use the keypad to enter the desired wavelength, and finally press ENTER to execute
the move.
GO SCAN Pertains to constant rate motion. This function is not available in the current version.
SCAN λPertains to constant rate motion. This function is not available in the current version.
SHIFT SPEED Pertains to constant rate motion. This function is not available in the current version.
GRAT Press this key to move to the other grating position. Press GRAT, then press either 1,
2 or 3 on the numeric keypad, and finally press ENTER to execute the change. The
display will update to show the correct parameters for the new grating.
SHIFT LABEL This key (located directly above GRAT) provides access to the grating label. The
label is an eight character alpha-numeric field that is used for information only.
Newport sets the grating blaze wavelength as the label during calibration. However,
you can use the keypad to type any number, then press ENTER to accept that new
value. The Hand Controller display only shows the first four digits of the label, and
you can only enter numbers.
LINES Press this key to change the lines/mm of the grating. This value is used for
wavelength calculations and will affect your calibration. This parameter should be
changed only when adding a new grating.
SHIFT CALIB This button is used to change the wavelength calibration of the current grating. Use
the GO WAVE, STEP DOWN, and STEP UP keys to move to a known wavelength
(often the intensity peak for a spectral calibration lamp). If the wavelength shown in
the top row of the display does not match the known value, press SHIFT CALIB and
use the numeric keypad to enter the known wavelength. Then press ENTER to
change the calibration. The current grating is thus calibrated over its entire range.
SHUTTER Alternately open and close the shutter by pressing this button. The shutter position is
shown in the display as “OPN” for open and “CLS” for closed.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
11
SHIFT PORT- Use this key to alternate between the two output ports. This feature is only available
on Model 74055. The active port is shown in the upper right corner of the display; “A”
indicates the axial port (adjacent to the power switch) while “L” indicates the lateral
port (opposite the input port).
FILTE- Move the 74010 Filter Wheel accessory to the specified position. Press FILTER, then
type the number 1, 2, 3, 4, 5, or 6 indicating the desired position, then finally press
ENTER to execute the move.
SHIFT LABEL This key (located directly above FILTER) provides access to the filter label. These
labels are eight character alpha-numeric fields, used for information only. You can
use the keypad to type any number, then press ENTER to accept that new value.
The Hand Controller display only shows the first four digits of the label, and you can
only enter numbers.
LOCAL Use this key to toggle between “local” communications through the Hand Controller
and “remote” communication with a computer. Please note that if you press LOCAL
to activate the Hand Controller (the display is lit and information fills the screen), you
also lock out PC communications. You cannot command the MS260ivia either RS-
232, IEEE-488 or USB while the Hand Controller is active.
SHIFT UNITS To change the wavelength units press this key, followed by either 1, 2, or 3 and then
press ENTER. Those three number keys are labeled with the corresponding units: 1
is nanometers (nm), 2 is micrometers (µm), and 3 is wave numbers (cm-1) shown as
“”.
1 Pressing the 1 key when not in a function parameter edit mode brings ups the
“Slit1um>” prompt to edit/enter the slit 1 size, (the slit at the input port), the integer
parameter is the open size specified in microns. Slit range is 6-3000 microns, in 6
micron resolution steps; for values larger than 3000 the slit goes to 3000, for values
0-6 the slit goes to 6.
SHIFT 1- Pressing the SHIFT-1 key when not in a function parameter edit mode brings ups the
“Bandpass>” prompt. The floating point parameter is the wavelength resolution to
automatically adjust slits for. If Bandpass is not set at zero the 74100 will be adjust all
slits to maintain the Bandpass resolution at wavelength moves and grating changes.
Setting Bandpass to 0 turns off this automatic adjustment. Slit range is 6-3000
microns, in 6 micron resolution steps. For Bandpass adjustments requiring slit
openings larger than 3000 the slit goes to 3000, for values 0-6 the slit goes to 6.
Note; for Bandpass slit size calculations to function properly, Slit1 must be at the
input port.
2 Pressing the 2 key when not in a function parameter edit mode brings ups the
“Slit2um>” prompt to edit/enter the slit 2 size, the integer parameter is the open size
specified in microns. Slit range is 6-3000 microns, in 6 micron resolution steps; for
values larger than 3000 the slit goes to 3000, for values 0-6 the slit goes to 6.
3 Pressing the 3 key when not in a function parameter edit mode brings ups the
“Slit3um>” prompt to edit/enter the slit 3 size, the integer parameter is the open size
specified in microns. Slit range is 6-3000 microns, in 6 micron resolution steps; for
values larger than 3000 the slit goes to 3000, for values 0-6 the slit goes to 6.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
12
IV.2 GETTING STARTED WITH IEEE-488
IEEE-488 communication (also called GPIB) offers the greatest versatility for integrating your
MS260iinto a larger system since you may connect up to 30 different devices to the same controller
card.However, this versatility brings with it some complication in setting up each device.
Newport designs all of its IEEE-488 products to be completely compatible with National Instruments’
GPIB controller cards. Likewise, most of our IEEE-488 software requires National Instruments’ device
drivers to run on your PC.We strongly recommend National Instruments’controller cards. Since there
are differences between IEEE-488 implementations among the various manufactures, we cannot
support them all. Therefore, Newport will only provide communication and software support for IEEE-
488 systems that use National Instruments controller cards.
Physical Connections
First, install your National Instruments control card and software in your PC computer. Run their
diagnostic tools to make sure the card is working properly.
Next, be sure the MS260ipower switch is off, then attach your IEEE-488 cable to the appropriate
connector on the back panel. Attach the other end to the National Instruments’ control card and
secure the screws on both sides. Now turn on the MS260i. In order to limit possible address
conflicts, we recommend that you turn off all other IEEE-488 instruments while checking your
MS260ifor the first time. Note: the MS260idefault GPIB primary address is 4.
Verify Communications
You can check your IEEE-488 communications by running the application Cornerstone Utility Program
. See software installation ( in section II.UNPACKING AND SETTING UP)
When this application runs, a dialog box will appear asking for the GPIB board index and
CornerstoneTM 260 address.The default values, 0 and 4 respectively, should work for most systems.If
you have multiple controller cards or if you have changed the CornerstoneTM 260 address fill in the
correct values.Click the OK button to establish communication and open the main application window.
If you get an error at this point you may have a connection problem. Check all the cables (including
the line cord), make sure the CornerstoneTM 260 is turned on, and make sure the Hand Controller is
off. PLEASE NOTE: if the Hand Controller is active (the display is lit and information fills the screen),
you cannot command the CornerstoneTM 260 via either RS-232 or IEEE-488. Press the LOCAL key
on the Hand Controller to deactivate it, allowing PC communications. PLEASE ALSO NOTE:
CornerstoneTM 260 selects either RS-232 or IEEE-488 communications based upon the first
command received after power up. When you send an IEEE-488 command, or initialize your IEEE-
488 software, the RS-232 link will be ignored until CornerstoneTM 260 power is turned off and on
again.
Low Level Communications
It may be desirable to send commands directly to the CornerstoneTM 260 through the National
Instruments Interactive Control or through another simple interface. To establish low level
communications with CornerstoneTM 260 you will have to first open the device. Using the National
Instruments’drivers the correct command is:ibdev 0 9 0 13 0 0x140a
The timeout code “13” allows 30 seconds to read responses back from CornerstoneTM 260. In most
cases 300 ms is sufficient (timeout code 10), however, the longer period guarantees success on all
commands. The end of string code “0x140a” terminates a read when the linefeed character is

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
13
received from the instrument.All Cornerstone260 responses end with carriage return and linefeed.
Likewise, all messages sent to CornerstoneTM 260 must end with the linefeed character.
Again, refer to the detailed discussion of section V. FUNCTIONS AND CONTROLS for further
information on direct low level communications, message syntax, and parameters.
IV.3 GETTING STARTED WITH RS-232 COMMUNICATIONS
RS-232 connections are a simple means of communicating between your PC and your instruments.
However, you are limited in that each instrument must have its own dedicated communication port at
the computer. Most PC’s come standard with COM1 and COM2, although COM1 is occasionally used
by a serial mouse. Additional communication port hardware can be added and the corresponding
drivers must be added to your Windowssoftware. Please review your computer setup to determine
what physical connections are available to you. Again, due to the variety of hardware and software
options that are available Newport cannot provide support for PC configuration.
Physical Connections
First, make sure that the COM port you would like to use for MS260iis recognized by Windows
and is working properly.Usually a simple check can be done with a serial mouse.
Next, be sure the MS260ipower switch is off, then attach your RS-232 cable to the appropriate
connector on the back panel.Attach the other end to the COM port connection on your PC. Note that
RS-232 cables come in two types: modem and null-modem. The modem cable is a pin-to-pin cable.
That is, each pin at one end connects directly to the corresponding pin at the other end: 1 to 1, 2 to 2,
3 to 3, etc.The modem cable is the correct cable for communicating with MS260i.
Now turn on the MS260i. You are ready to communicate with the instrument. The hardware
communication parameters, including baud rate, are fixed inside MS260i, so setup your COM port
as follows:
Baud Rate: 9600
Data Bits: 8
Parity: NONE
Stop Bits: 1
Flow Control: NONE
Verify Communications
Check your RS-232 communications by running the Cornerstone Utility application. See software
installation (in section II. UNPACKING AND SETTING UP).
When this application runs, a dialog box will appear asking for the COM port number. Fill in the
correct value, then click the OK button to establish communication and open the main application
window.
If you get an error at this point you may have a connection problem. Check all the cables (including
the line cord), make sure the Cornerstoneis turned on, and make sure the Hand Controller is off.
PLEASE NOTE: if the Hand Controller is active (the display is lit and information fills the screen), you
cannot command the Cornerstonevia either RS-232 or IEEE-488. Press the LOCAL key on the
Hand Controller to deactivate it, allowing PC communications. PLEASE ALSO NOTE: Cornerstone

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
14
selects either RS-232 or IEEE-488 communications based upon the first command received after
power up. When you send an RS-232 command, or initialize your RS-232 software, the IEEE-488 link
will be ignored until Cornerstonepower is turned off and on again.
Low Level Communications
In some cases, it may be desirable to send commands directly to Cornerstonethrough a terminal
emulation program, such as the HyperTerminalprovided with Windows. Once your terminal
program is open and running you will have to first select a COM port and configure it according to the
parameters previously listed (9600, 8, N, 1, None). Additionally, you should set the terminal to “Send
line ends with line feeds”. There is no reason to turn on the local echo since Cornerstonewill
automatically echo each character as it is typed.All Cornerstoneresponses end with carriage return
and linefeed. Likewise, all messages sent to Cornerstonemust end with the linefeed character.
Again, refer to the detailed discussion of section V. FUNCTIONS AND CONTROLS for further
information on direct low level communications, message syntax, and parameters.

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
15
V. FUNCTIONS AND CONTROLS
V.1 COMMAND AND QUERY SYNTAX
For the purposes of this discussion we will divide communications with the instrument into two parts.
First, the messages that you send to MS260iwill be called “Statements”. Second, the messages
that you receive from MS260iwill be called “Responses”. When communicating with MS260iyou
will use two types of Statements: “Commands” and “Queries”. A Command causes some physical
action or sets an internal parameter. Queries ask some question of the instrument and automatically
return a Response.Fundamentally, the syntax is the same for all messages.
Termination
Both Statements and Responses end with a carriage return (ASCII character code 13 decimal) and
linefeed (ASCII character code 10 decimal). This manual will show the termination as [cr][lf]. Please
note, you may find it more convenient to end Statements with only the linefeed [lf]; this is also
acceptable.
Capitalization
Statements may be sent in upper case, in lower case, or in any combination of the two. Responses
will always be returned in upper case. For clarity throughout this manual, Statements will be shown in
upper case (ie. STATEMENT) and Responses will be shown in upper case italics (ie. RESPONSE).
Parameters
Some Statements will require a parameter. In this manual numeric parameters will be shown as “XX”;
each X will fill a numeric position and decimals are used to indicate where floating point number
should be expected. Numeric notation is not strict and integers can be substituted for floating point
numbers as desired. There are some specific cases where alpha-numeric values or exponential
notation may be required; these special Statements will be detailed in the sections that follow.
Most normal communication with MS260i, especially communication handled inside closed
application software, is done in Standard Mode. This mode follows all of the rules on the previous
page plus there are some additional features for error handling.
MS260istores errors internally in a status byte and an error byte, where each bit has a specific
meaning. Details of the status and error bytes can be found in this manual under section V-4 ERROR
CODES. For now, we will simply cover the syntax necessary to send Statements and receive
Responses in this communication mode.
In all cases, Statements must be terminated properly with [lf] for MS260ito take any action.
Statements that are not understood or parameters that are unacceptable will generate an error code
in the status byte, ie. status byte 0. Moreover, the status byte must be explicitly read, it is not
returned after general Statements.Correct Statements are handled as follows:
Commands
Under RS-232, Statements are echoed back to the PC. Thus, after sending a Command you should
read back this echo. There is no further response to a Command.
For example: Send: GOWAVE 500[lf] Receive: GOWAVE 500[lf]
Under IEEE-488, there is no echo. There is no automatic response to a Command.
For example: Send: GOWAVE 500[lf] Receive: {none}

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
16
Queries
Under RS-232, Statements are echoed back to the PC. Additionally, there will be an explicit response
to that query. Thus, after sending a Query you should read back the echo and the answer together.
For example: Send : WAVE?[lf] Receive: WAVE?[lf]500[cr][lf]
Under IEEE-488, there is no echo. Thus, you can read back the Response by itself.
For example: Send : WAVE?[lf] Receive: 500[cr][lf
V.2 HANDSHAKING MODE
This communications mode is most useful for methods development, troubleshooting, or in the early
stages of programming. Use the command: “HANDSHAKE 1[lf]” to put MS260iinto Handshake
Mode. This mode follows the command syntax listed at the start of section V-1 in this manual, but in
addition every Statement is acknowledged.The “handshake” that you receive is the status byte.
MS260istores errors internally in a status byte and an error byte, where each bit has a specific
meaning. Details of the status and error bytes can be found in this manual under section V-4 ERROR
CODES. For now, we will simply cover the syntax necessary to send Statements and receive
Responses.
In all cases, Statements must be terminated properly with [lf] for MS260ito take any action.
Statements that are not understood or parameters that are unacceptable will generate an error code
in the status byte, ie. status byte 0. This status byte will be reported immediately if it contains an
error, otherwise the status byte “00” will be returned upon completion of the Statement. Correct
Statements are handled as follows:
Commands
Under RS-232, Statements are echoed back to the PC. Thus, after sending a Command you should
read back this echo. Additionally, the status byte is reported when the action is complete.
For example: Send: GOWAVE 500[lf] Response: GOWAVE 500[lf]00[cr][lf]
Under IEEE-488, there is no echo. The only response will be the status byte.
For example: Send: GOWAVE 500[lf] Response: 00[cr][lf]
Queries
Under RS-232, Statements are echoed back to the PC. Additionally, there will be an explicit response
to that Query, and the statues byte. Thus, after sending a Query you should read back a 3 part
answer.
For example: Send : WAVE?[lf] Response: WAVE?[lf]500[cr][lf]00[cr][lf]
Under IEEE-488, there is no echo. Thus, you will read back the Response and the status byte.
For example: Send : WAVE?[lf] Response: 500[cr][lf]00[cr][lf

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
17
V.3 BRIEF COMMAND REFERENCE ORGANIZED ALPHABETICALLY
Command Query Hand Ctrl Key
ABORT [ABORT]
ADDRESS XX ADDRESS?
CALIBRATE XXX.XXX [CALIB]
ERROR?
FILTER X FILTER? [FILTER]
FILTER1LABEL TTTTTTTT FILTER1LABEL? [SHIFT LABEL]
GOWAVE XXX.XXX WAVE? [GO WAVE]
GRAT X GRAT? [GRAT]
GRAT1FACTOR XXX.XXX GRAT1FACTOR?
GRAT1LABEL TTTTTTTT GRAT1LABEL? [SHIFT LABEL]
GRAT1LINES XXXX GRAT1LINES? [LINES]
GRAT1OFFSET XXX.XXX GRAT1OFFSET?
HANDSHAKE X HANDSHAKE?
INFO? [LOCAL]
OUTPORT T OUTPORT? [PORT]
SHUTTER T SHUTTER? [SHUTTER]
STB?
STEP XXX STEP? [STEP UP]
UNITS TT [SHIFT UNITS]
SLIT1MICRONS XXXX SLIT1MICRONS? [1]
SLIT2MICRONS XXXX SLIT2MICRONS? [2]
SLIT3MICRONS XXXX SLIT3MICRONS? [3]
BANDPASS XXX.XX BANDPASS? [SHIFT 1]

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
18
V.4 DETAILED COMMAND REFERENCE ORGANIZED BY FUNCTION
Recall from section V-1 of this manual that messages that you send to MS260iwill be called
“Statements” and messages that you receive from MS260iwill be called “Responses”. There are
two types of Statements: “Commands” and “Queries”. A Command causes some physical action or
sets an internal parameter. Queries ask some question of the instrument and automatically return a
Response. Also recall that all Statements must end in [lf], and [cr][lf] is acceptable. Likewise, all
Responses will end with [cr][lf]. Refer to section V-1 for detailed general syntax instructions. This
section describes the exact syntax, acceptable parameters, and functionality for every MS260i
Command. For each corresponding Query, in braces {}, we also list the type of Response you should
expect. Where appropriate the corresponding Hand Controller key, in brakets [ ], is also listed. Finally,
there are some warnings as to possible errors that could occur if a command is not used properly.
MS260iMotion Commands:
UNITS TT {UNITS?} [UNITS]
Specifies the operational unit designated by the mnemonic parameter “TT”. Possible parameters are:
“NM” for nanometers “UM” for micrometers “WN” for wavenumbers (cm-1)
By default MS260iuses nanometers. Parameters for all motion Statements are handled in the
current units. Therefore, if you change from nanometers to micrometers GOWAVE parameters must
be entered in micrometers. Likewise, WAVE? answers will be returned in micrometers. The response
to UNITS? is always the two character mnemonic for the current units.
GOWAVE XXX.XXX {WAVE?} [GO WAVE]
Moves the wavelength drive at maximum speed to the step position closest to the specified
wavelength parameter. This parameter must be in the current units and may be either a floating point
number or an integer, ie. “GOWAVE 500.00[lf]” and “GOWAVE 500[lf]” will be understood the same
way. For each grating there is a maximum possible wavelength (approximately 1600 nm for a 1200
l/mm grating, thus 800 nm for a 600 l/mm, etc.) This command will generate an error if the parameter
is larger than the maximum wavelength. The response to WAVE? will be a floating point number
indicating the exact wavelength position. Current units are assumed and so no units are passed with
the floating point number.
CALIBRATE XXX.XXX [CALIB]
This command is used to make minor corrections to the wavelength calibration of MS260i. It is used
when installing new gratings, or at any point when the wavelength calibration is disrupted. Execute
this command to define the current position as the wavelength specified in the numeric parameter
XXX.XXX. This calculates a new OFFSET for the grating and saves it accordingly. Please Note: The
calibration is corrected for the entire range of the current grating and current output port; on a 74055
system, a separate calibration may be necessary if the output port is changed. A complete calibration
procedure is outlined in Section VII-4 ADDITIONAL GRATINGS- WAVELENGTH CALIBRATION.
ABORT [ABORT]
Simply stops any wavelength motion immediately, ie. GOSCAN, GOWAVE, STEP, etc.
STEP XXXX {STEP?} [STEP UP] / [STEP DOWN]
Move the wavelength drive by the integer number of steps indicated in XXXX. The parameter can be
positive or negative, however, one step is the smallest increment MS260ican move and so this
parameter must be an integer. The response to STEP? is the current step position as measured from

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
19
the physical home sensors.
MS260iGrating Commands:
GRATX {GRAT?} [GRAT]
Move the wavelength drive to the grating specified in the integer parameter. The parameter should be
either “1”, “2” or “3”. Please note: whenever you change gratings, the wavelength drive will sweep
past zero order on grating #2. In order to prevent saturation of a detection system, it is wise to close
the shutter temporarily while changing gratings. When changing to grating #1 the instrument stops at
the maximum wavelength for that grating. When changing to grating #3, the system stops at the zero
order position for that grating. When changing to grating #2, the system will stop at the zero order
position or the maximum wavelength, whichever is closer. Therefore, this command is usually
followed by a GOWAVE command. The response to GRAT? contains three parameters separated by
commas without spaces. The first parameters is the grating number, then the lines/mm, then the label
for that grating. For example: “1,1200,BLUE[cr][lf]”.
GRAT1LABEL TTTTTTT {GRAT1LABEL?} [SHIFT LABEL]
Sets the user defined “label” for the grating #1 to the < 9 character parameter “TTTTTTTT”. The
parameter can letters or numbers. This label is for informational purposes only. Newport uses these
labels to indicate blaze wavelength for those gratings that are installed in MS260iat the factory.
Note: that the Hand Controller only displays four characters, however all eight may be entered. Also,
the Hand Controller only changes the current grating parameters.
GRAT2LABEL TTTTTTT {GRAT2LABEL?} [SHIFT LABEL]
Sets the user defined “label” for the grating #2 to the < 9 character string parameter “TTTTTTTT”. The
parameter can letters or numbers. This label is for informational purposes only. Newport uses these
labels to indicate blaze wavelength for those gratings that are installed in MS260iat the factory.
Note: that the Hand Controller only displays four characters, however all eight may be entered. Also,
the Hand Controller only changes the current grating parameters.
GRAT3LABEL TTTTTTT {GRAT3LABEL?} [SHIFT LABEL]
Sets the user defined “label” for the grating #3 to the < 9 character string parameter “TTTTTTTT”. The
parameter can letters or numbers. This label is for informational purposes only. Newport uses these
labels to indicate blaze wavelength for those gratings that are installed in MS260iat the factory.
Note: that the Hand Controller only displays four characters, however all eight may be entered. Also,
the Hand Controller only changes the current grating parameters.
GRAT1LINES XXXX {GRAT1LINES?} [LINES]
Sets the lines per millimeter of grating #1 to the integer parameter specified as XXXX. Warning: this
value is used to calculate wavelength motion. Line/mm are usually changed only when installing a
new grating, and in that case the parameter should match the value provided by Newport. Note, the
Hand Controller only changes the current grating parameters.
GRAT2LINES XXXX {GRAT2LINES?} [LINES]
Sets the lines per millimeter of grating #2 to the integer parameter specified as XXXX. Warning: this
value is used to calculate wavelength motion. Line/mm are usually changed only when installing a
new grating, and in that case the parameter should match the value provided by Newport. Note, the
Hand Controller only changes the current grating parameters.
GRAT3LINES XXXX {GRAT3LINES?} [LINES]

M-74050
MS260i™1/4M IMAGING SPECTROGRAPH
20
Sets the lines per millimeter of grating #3 to the integer parameter specified as XXXX. Warning: this
value is used to calculate wavelength motion. Line/mm are usually changed only when installing a
new grating, and in that case the parameter should match the value provided by Newport. Note, the
Hand Controller only changes the current grating parameters.
GRAT1FACTOR XXX.XXX {GRAT1FACTOR?}
Sets the calibration factor of grating #1 to the numeric parameter specified as XXX.XXX. Warning:
this value is used to calculate wavelength motion. Factor is usually changed only when installing a
new grating, and in that case the parameter should match the value provided by Newport.
GRAT2FACTOR XXX.XXX {GRAT2FACTOR?}
Sets the calibration factor of grating #2 to the numeric parameter specified as XXX.XXX. Warning:
this value is used to calculate wavelength motion. Factor is usually changed only when installing a
new grating, and in that case the parameter should match the value provided by Newport.
GRAT3FACTOR XXX.XXX {GRAT3FACTOR?}
Sets the calibration factor of grating #3 to the numeric parameter specified as XXX.XXX. Warning:
this value is used to calculate wavelength motion. Factor is usually changed only when installing a
new grating, and in that case the parameter should match the value provided by Newport.
GRAT1OFFSET XXX.XXX {GRAT1OFFSET?}
Sets the calibration offset for grating #1 as the floating point parameter specified in XXX.XXX.
Warning: this value is used to calculate wavelength motion. Offset is usually changed only when
installing a new grating, and in that case the parameter should match the value provided by Newport.
This value is automatically changed via the CALIBRATE command. A calibration procedure is
outlined in Section VII-4 ADDITIONAL GRATINGS- WAVELENGTH CALIBRATION.
GRAT2OFFSET XXX.XXX {GRAT2OFFSET?}
Sets the calibration offset for grating #2 as the floating point parameter specified in XXX.XXX.
Warning: this value is used to calculate wavelength motion. Offset is usually changed only when
installing a new grating, and in that case the parameter should match the value provided by Newport.
This value is automatically changed via the CALIBRATE command. A calibration procedure is
outlined in Section VII-4 ADDITIONAL GRATINGS- WAVELENGTH CALIBRATION.
GRAT3OFFSET XXX.XXX {GRAT3OFFSET?}
Sets the calibration offset for grating #3 as the floating point parameter specified in XXX.XXX.
Warning: this value is used to calculate wavelength motion. Offset is usually changed only when
installing a new grating, and in that case the parameter should match the value provided by Newport.
This value is automatically changed via the CALIBRATE command. A calibration procedure is
outlined in Section VII-4 ADDITIONAL GRATINGS- WAVELENGTH CALIBRATION.
MS260iAccessory Commands:
SHUTTER T {SHUTTER?} [SHUTTER]
Closes or opens the shutter depending upon the single letter mnemonic parameter “T”. Closing the
shutter requires “C”, whereas opening it requires “O”. The response to SHUTTER? is simply the one
character parameter describing the current state. When using the Hand Controller key [SHUTTER] no
parameter is necessary. Pressing this key toggles the shutter out of the current state into the other
state. Look to the display to check shutter position.
