NexAIoT APPD 1206T User manual

NexAIoT Co., Ltd.
NexAIoT Co., Ltd.
Published November 2021 www.nexaiot.com
IoT Automation Solutions Business Group
Applied Panel Display
APPD 1206T/1501T/1701T/1901T
User Manual

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. ii APPD 1206T/1501T/1701T/1901T User Manual
Content
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Safety Information ................................................................................. ix
Installation Recommendations................................................................ ix
Safety Precautions................................................................................... x
Technical Support and Assistance........................................................... xi
Conventions Used in this Manual........................................................... xi
Global Service Contact Information........................................................xii
Package Contents.................................................................................xiv
Ordering Information .............................................................................xv
Chapter 1: Product Introduction
Overview - APPD 1206T..........................................................................1
Key Features ...........................................................................................1
Overview - APPD 1501T..........................................................................2
Key Features ...........................................................................................2
Overview - APPD 1701T..........................................................................3
Key Features ...........................................................................................3
Overview - APPD 1901T..........................................................................4
Key Features ...........................................................................................4
Specifications..........................................................................................5
APPD 1206T........................................................................................5
Specifications..........................................................................................6
APPD 1501T........................................................................................6
Specifications..........................................................................................7
APPD 1701T........................................................................................7
Specifications..........................................................................................8
APPD 1901T........................................................................................8
Knowing Your APPD Series .....................................................................9
Front Top View of APPD 1206T............................................................9
Front Top View of APPD 1701T............................................................9
Front Top View of APPD 1501T............................................................9
Front Top View of APPD 1901T............................................................9
Rear View..........................................................................................10
Power & OSD Menu Button Description.............................................10
Rear Bottom View of APPD 1206T.....................................................11
Rear Bottom View of APPD 1701T.....................................................11
Rear Bottom View of APPD 1501T.....................................................11
Rear Bottom View of APPD 1901T.....................................................11
Rear Bottom View ............................................................................12
External I/O Description .....................................................................12
Rear View of APPD 1206T .................................................................13
Rear View of APPD 1501T .................................................................14

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. iii APPD 1206T/1501T/1701T/1901T User Manual
Content
Rear View of APPD 1701T .................................................................15
Rear View of APPD 1901T .................................................................16
Mechanical Dimensions.........................................................................17
APPD 1206T......................................................................................17
APPD 1501T......................................................................................18
APPD 1701T......................................................................................19
APPD 1901T......................................................................................20
Chapter 2: Connector Pin Definitions
External I/O Interfaces ...........................................................................21
VGA Port...........................................................................................22
DVI Port (DVI-D).................................................................................22
USB Port............................................................................................23
Chapter 3: System Setup
Panel Mounting ....................................................................................24
Chapter 4: Adjusting the Display
OSD Menu Functions ............................................................................26
Appendix A: Extended Display Identification Data
Timing Support.......................................................39
Appendix B: Power Consumption.........................41

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. iv APPD 1206T/1501T/1701T/1901T User Manual
Preface
PrefaCe
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NexAIoT
Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NexAIoT Co., Ltd. However, users may
update their knowledge of any product in use by constantly checking its manual
posted on our website: http://www.nexaiot.com. NexAIoT shall not be liable for
direct, indirect, special, incidental, or consequential damages arising out of the
use of any product, nor for any infringements upon the rights of third parties,
which may result from such use. Any implied warranties of merchantability or
fitness for any particular purpose is also disclaimed.
Acknowledgements
APPD 1206T, APPD 1501T, APPD 1701T and APPD 1901T are trademarks of
NexAIoT Co., Ltd. All other product names mentioned herein are registered
trademarks of their respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class B devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. vAPPD 1206T/1501T/1701T/1901T User Manual
Preface
RoHS Compliance
NexAIoT RoHS Environmental Policy and Status
Update
NexAIoT is a global citizen for building the digital
infrastructure. We are committed to providing green
products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in
Electronic Equipment) directive 2011/65/EU, to be your trusted green
partner and to protect our environment.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, NexAIoT has established an
engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
NexAIoT development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NexAIoT are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NexAIoT RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2013 will be RoHS compliant.
They will use the usual NexAIoT naming convention.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. vi APPD 1206T/1501T/1701T/1901T User Manual
Preface
Warranty and RMA
NexAIoT Warranty Period
1. NexAIoT makes products in accordance with the Industry standard and,
NexAIoT warrants that all her Industry-grade IPC and System products
will be free from defect in neither material nor workmanship for twenty-
four (24) months from the day of invoice issued.
2. For NexAIoT Panel PC product lines (the APPC, MPPC series), they are also
guaranteed against defect in materials and workmanship for the period
of twenty-four (24) months in their motherboard design. For 3rd party
parts, it follows with original suppliers’ standard: 12 months for battery
pack and LCD, 24 months for adapter / add on modules (including GSM
module, RFID module, and antenna).
3. If NexAIoT determines customer’s warranty claim is valid, NexAIoT will
repair or replace product(s) without additional charge for parts and
labor. An extended Warranty Program will extend the warranty period of
the product accordingly.
Warranty Coverage
The warranty applies only to products manufactured or distributed by
NexAIoT and her subsidiaries. This warranty covers all the products/
shipments except for:
1. Any claimed defect, products that have been repaired or modified by
persons who have not been authorized by NexAIoT or, products which
have been subjected to misuse, abuse, accident, improper installation,
or usage not in accordance with the product instruction. NexAIoT
assumes no liability as a consequence of such events under the term of
this warranty.
One example is the replacement of Tablet’s or Hand-held’s LCD display
due to scratching stains or other degradation; these will not be covered
under this warranty.
2. Damages caused by customers’ delivery/shipping of the product
or, product failure resulted from electrical power/voltage shock, or,
installation of parts/components which are not supplied/approved by
NexAIoT in advance.
3. Third-party products:
a. Software, such as the device drivers,
b. External devices such as HDD, printer, scanner, mouse, LCD panel,
battery, and so on,
c. Accessory/parts that were not approved by NexAIoT and,
d. Accessory/parts were added to products after they were shipped
from NexAIoT.
Product will be treated as “Out of Warranty “ if:
a. It expires the warranted 24 months period from the day it was purchased.
b. It had been altered by persons other than an authorized NexAIoT service
person or, which have been subjected to misuse, abuse, accident, or
improper installation.
c. It doesn’t have the original NexAIoT Serial Number labeling for NexAIoT’s
warranty period identification or, tracking.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. vii APPD 1206T/1501T/1701T/1901T User Manual
Preface
RMA that NexAIoT has determined not to be covered by the warranty will
be charged the NexAIoT Standard Repair Fee for the repairing. If a RMA is
determined to be not repairable, customer will be notified and product(s)
may be returned to customer at their request; a minimum service fee may
be charged however.
NexAIoT Return Merchandise Authorization (RMA) Procedure
For the RMA (Return Merchandise Authorization) shipment, customer
is responsible for packaging and shipping the product to the designated
NexAIoT service sites, with shipping charges prepaid by the customer. The
original NexAIoT shipping box should be used whenever possible. NexAIoT
shall pay for the return of the product to the customer’s location. In case of
expedited shipping request, an extra service charge shall be assessed and
the customer is responsible for this extra return shipping charge.
1. Customers should enclose the “NexAIoT RMA Service Form” with the
returned products.
2. Customers need to write down all the information related to the
problem on the “ NexAIoT RMA Service Form “ when applying for the
RMA service; information will help to understand the problem, including
the fault description, on-screen messages, and pictures if possible.
3. Customers could send back the faulty product with or without the
accessories and key parts such as the CPU and DIMM. If the key parts are
included, please be noted clearly within the return form. NexAIoT takes
no responsibility for the parts which are not listed in the return form.
4. Customers hold the responsibility to ensure that the packing of defective
products is durable enough to be resistant against further damage due
to the transportation; damage caused by transportation is treated as “
Out of Warranty “ under our Warranty specification.
5. RMA product(s) returned by NexAIoT to any location other than the
customer registered delivery address will incur an extra shipping charge,
the customer is responsible for paying the extra shipping charges, duties,
and taxes of this shipment.
Product Repairing
1. NexAIoT will repair defective products covered under this limited warranty
that are returned to NexAIoT; if products do prove to be defective, they
will be repaired during their warranty period unless other warranty terms
have been specified.
2. NexAIoT owns all parts removed from repaired products.
3. NexAIoT will use parts made by various manufacturers in performing the
repair.
4. The repaired products will be warranted subjected to the original
warranty coverage and period only.
5. For products returned as defective but, proved to be no defect/fault after
the RMA process, NexAIoT reserves the right to claim for a NDF (No
Defect Found) Service Charge.
6. NexAIoT will issue RMA Report which included Repair Detailed
Information to the customer when the defective products were repaired
and returned.
7. In addition to the above, NexAIoT may authorize Independent/Third-
party suppliers to repair the defective products for NexAIoT.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. viii APPD 1206T/1501T/1701T/1901T User Manual
Preface
Out Of Warranty Service
There will be a service charge from NexAIoT for the “Out Of Warranty”
product service; they are the Basic Diagnostic Service Fee and the Advanced
Component Replacement Fee respectively. And, if the product can not be
repaired, NexAIoT will either return the product to the customer or, just
scrap it, followed by customer’s instruction.
1. Testing and Parts Replacement
NexAIoT will have the following Handling Charges for those OoW
products that returned:
a. Basic Labor Cost and Testing Fee: as Table listed.
b. Parts Fee: NexAIoT will charge for main IC chipsets such as the N.B.,
S.B., Super-IO, LAN, Sound, Memory, and so on.
c. 3rd-party Device Fee: products replacement for CPU, DIMM, HDD,
Chassis, and UPS.
2. Out of Warranty product will have a three months warranty for the fixed
issues. If the product failed with different problem within 3 months, they
will still incur the service charge of “Out of Warranty”.
3. Out of Warranty “products will not be repaired without a signed PI from
the customer, the agreement of the repair process.
Add-on card, 3rd Party Device and board level repair cost higher than
new product prices, customer can abandon to sign PI to repair and,
please contact with sales to buy new products.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. ix APPD 1206T/1501T/1701T/1901T User Manual
Preface
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xAPPD 1206T/1501T/1701T/1901T User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. Do not place heavy objects on the equipment.
16. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xi APPD 1206T/1501T/1701T/1901T User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NexAIoT products, visit NexAIoT’s
website at www.nexaiot.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xii APPD 1206T/1501T/1701T/1901T User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
9F, No. 920, Chung-Cheng Rd.,
ZhongHe District, New Taipei City, 23586,
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com
America
USA
NEXCOM USA
46665 Fremont Blvd.,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomusa.com
Asia
Taiwan
NEXCOM Intelligent Systems
Taipei Office
13F, No.920, Chung-Cheng Rd.,
ZhongHe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
NEXCOM Intelligent Systems
Taichung Office
16F, No.250, Sec. 2, Chongde Rd.,
Beitun Dist.,
Taichung City 406, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
Japan
NEXCOM Japan
9F, Tamachi Hara Bldg.,
4-11-5, Shiba Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
China
NEXCOM China
Floor 5, No.4, No.7 fengxian middle Rd.,
(Beike Industrial Park), Haidian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xiii APPD 1206T/1501T/1701T/1901T User Manual
Preface
Europe
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu
Italy
NEXCOM ITALIA S.r.l
Via Lanino 42,
21047 Saronno (VA), Italia
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomitalia.it
NEXCOM Shanghai
Room 603/604, Huiyinmingzun Plaza Bldg., 1,
No.609, Yunlin East Rd.,
Shanghai, 200333, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM Surveillance Technology Corp.
Room202, Building B,
the GuangMing Industrial Zone Zhonghua Rd.,
Minzhi Street, Longhua District,
Shenzhen 518131, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM United System Service
Hui Yin Ming Zun Building Room 1108,
Building No. 11, 599 Yunling Road, Putuo District,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xiv APPD 1206T/1501T/1701T/1901T User Manual
Preface
Package Contents
Before continuing, verify that the package you received is complete. The
APPD series package, APPD 1206T/1501T/1701T/1901T, should have all the
items listed in the table.
Note: Package contents may vary depending on your country
region, some items may be optional. Please contact your local
distributor for more information.
Item Description Qty
1 USB Touch Cable (1.8m) 1
2 VGA Cable (1.8m) 1
3 Terminal blocks 3-pin Phoenix Contact Plug 1
4 Panel Mounting Kit 12
5 Touch Pen 1
6 Serial Cable (1.8m) 1
Terminal blocks
3-pin Phoenix
Contact Plug
VGA Cable
Panel Mount Kit Touch Pen USB Cable
Serial Cable

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. xv APPD 1206T/1501T/1701T/1901T User Manual
Preface
Ordering Information
The following provides ordering information for the Applied Panel Display
series.
• Barebone
APPD 1206T (P/N: 10IA1206T00X0)
12.1” XGA industrial 4:3 TFT LED backlight flush touch monitor with
VGA, DVI-D and DisplayPort, 12~24VDC input, RS-232 and USB touch
screen interfaces
APPD 1501T (P/N: 10IA1501T00X0)
15” XGA industrial 4:3 LED backlight flush touch monitor with VGA, DVI-D
and DisplayPort, 12~24VDC input, RS232 and USB touch screen interfaces
APPD 1701T (P/N: 10IA1701T00X0)
17” SXGA industrial 4:3 LCD flush touch monitor with VGA, DVI-D and
DisplayPort, 12~24VDC input, RS-232 and USB touch screen
APPD 1901T (P/N: 10IA1901T00X0)
19” SXGA industrial 4:3 LED backlight flush touch monitor with VGA,
DVI-D and DisplayPort, 12~24VDC input, RS232 and USB touch screen
interfaces
Optional
• 12V, 60W AC/DC power adapter w/o power cord
((P/N: 7400060048X00)
• 1.8m DVI-D male to DVI-D male cable (P/N: 603DVI0007X00)

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 1
Chapter 1: Product Introduction
APPD 1206T/1501T/1701T/1901T User Manual
ChaPter 1: ProduCt IntroduCtIon
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Triple display input interface: analog VGA/DVI-D/DisplayPort
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD multi-language function
Overview - APPD 1206T
Photo is for reference. Please refer to the mechanical engineering drawing for final
appearance.
Note:

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 2
Chapter 1: Product Introduction
APPD 1206T/1501T/1701T/1901T User Manual
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Triple display input interface: analog VGA/DVI-D/DisplayPort
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD multi-language function
Overview - APPD 1501T
Photo is for reference. Please refer to the mechanical engineering drawing for final
appearance.
Note:

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 3
Chapter 1: Product Introduction
APPD 1206T/1501T/1701T/1901T User Manual
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Triple display input interface: analog VGA/DVI-D/DisplayPort
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD multi-language function
Overview - APPD 1701T
Photo is for reference. Please refer to the mechanical engineering drawing for final
appearance.
Note:

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 4
Chapter 1: Product Introduction
APPD 1206T/1501T/1701T/1901T User Manual
Key Features
▪IP65 compliant plastic front bezel with flush panel by 5-wire touch screen
▪Triple display input interface: analog VGA/DVI-D/DisplayPort
▪Shares identical appearance with APPC series
▪Dual touch screen interface: RS232 and USB
▪Ultra slim in depth
▪OSD multi-language function
Overview - APPD 1901T
Photo is for reference. Please refer to the mechanical engineering drawing for final
appearance.
Note:

Copyright © 2021 NexAIoT Co., Ltd. All Rights Reserved. 5
Chapter 1: Product Introduction
APPD 1206T/1501T/1701T/1901T User Manual
Specifications
APPD 1206T
Panel
▪LCD size: 12.1”, 4:3
▪Resolution: XGA 1024 x 768
▪Luminance: 500cd/m2
▪Contrast ratio: 700
▪LCD color: 16.7M
▪Viewing angle: 70 (U), 70 (D), 80 (L), 80 (R)
▪Backlight: LED
Touch Screen
▪5-Wire resistive (flush panel type)
▪Light transmission: 80%
▪Interface: USB and RS232
Rear I/O
▪Touch screen interface port: RS-232 (1x DB9)/USB type A
▪Video port: VGA (1 x DB15)/DVI-D (1 x DVI-D connector)/DisplayPort
▪DC power input connector: 3-pin Phoenix terminal block
OSD Function
▪OSD keypad
▪Multilanguage OSD
Mechanical & Environment
▪Color: Pantone black and black silver chassis box
▪IP protection: IP65 front
▪Mounting: panel/wall/stand/VESA 100mm x 100mm
▪Power input: 12V~24VDC
▪Power adapter: optional AC to DC power adapter (+12V, 60W)
▪Vibration:
- IEC 68 2-64
- 2Grms @ sine, 5~500Hz, 1hr/axis (operating)
- 2.2Grms @ random condition, 5~500Hz, 0.5hr/axis (non-operating)
▪Shock:
- IEC 68 2-27
- 20G@wall mount, half sine, 11ms
- Operating temperature: -5°C to 50°C
- Storage temperature: -20°C to 75°C
▪Operating humidity: 10%~90% relative humidity, non-condensing
▪Dimension: 317 x 243 x 53.5mm
▪Weight: 2.8kg
Certifications
▪CE approval
▪FCC Class B
