NEXhome IS-E20s User manual

INTERCOM
DH-E20S is a SIP-based with two-way intercom, access
control, and video surveillance functions. With a small
and thin body, DH-E20S can be installed in most scenes,
even with a narrow door frame.
 1 big call button with 16.77 million-color backlit,
card access integrated
 Independent camera and fill-in light design,
ensure clear and accurate image
 wall-mount Snap-fit bracket, simple one hand
installation
 With tamper-proof alarm
 IP65 dust and water protection
 With Wiegand interface
 Support Bluetooth access
 Support PoE
 Easy to integrated with SIP systems and services
 panel: Plastic
 Camera: 1M pixels
 White light LED: Auto
 Button: 1 call button
 Microphone: -42dBV
 Speaker: 4Ω / 2W
 Ethernet: 1×RJ45, 10/100Mbps self-adaptive
 802.3af Power-over-Ethernet
 DC12V/1A connector (if not using PoE)
 Wiegand: Support
 RS485: Support
 RF card reader: 13.56MHz
 Relay out: 1
 DI Inputs: 2
 IP Level: IP65
 Installation: Wall-mounted
 Dimension: 145×70×25.5mm
 Working Humidity: ≤95%RH
 Working Temperature: -30°C ~ +70°C
 Storage Temperature: -40°C ~ +70°C
Multifunctional SIP doorphone
IS-E20sISESAR
Highlights
HIGHLIGHTS
Physical & Power
PHYSICAL&POWER
XI`AN ISESAR TECHNOLOGY CO., LTD. 
ADD:Room2306,LingxianTimesplaza,GaoxinRoad,Xian
Web:www.isesar.com

 Sensor: 1/4", CMOS
 Pixels: CIF, QCIF, VGA
 Video codec: H.264
 Video resolution: up to VGA
 Viewing angle: 110°(FOV)
Networking
Protocols: IPv4, HTTP, HTTPS, FTP, TFTP,
SNMP, DNS, SNTP, RTSP, SRTP, RTP, TCP,
UDP, TLS, ICMP, DHCP, ARP
Deployment & Maintenance
 Auto-Provisioning
 Web management portal
 Web-based packet dump
 Confifiguration backup / restore
 Entry log export
 Credentials export/import
 Firmware upgrade
 System logs (include door access logs)
Scenarios
 Door of office, floor and authorized areas
 Door of villa or apartment unit
 Entrance and spot in remote site
 Emergency tower
Door Entry Feature
 Unlock methods: IC card/keyfob and Bluetooth LE
 Auto-night mode with LED fill-in light
 White balance: Auto
 Minimum illumination: 0.1LUX
IS-E20sISESAR
 SIP v2 (RFC3261)
 Audio Codec: G.771a, G.711u, G.729 (Narrowband)
G.722 (Broadband)
 DTMF: In-band, RFC2833, SIP Info
 Echo Cancellation
Audio
Video

70.0mm
145.0mm
25.5mm
MAKE PROPERTIES SAFER
AND SMARTER

Please make sure the package contains the following items.
IS-E20s Series Quick Guide
2
|
Product Overview
PRODUCT OVERVIEW
1
|
Preparation
PREPARATION
DH-E20S Back cover
×1
Wall bracket 10-Pin cable 5-Pin cable Hexagonal
wrench
×1 ×1 ×1 ×1 ×1
Screw(M2.5×4) Screw(ST4×20) Screw(M4×30)Screw(M4×10) Drywall anchor
×2 ×4 ×2×4 ×4
① MIC ② Camera ③ White light LED ④ Loudspeaker
⑤ RF card reader & Call button
70.0mm
145.0mm
25.5mm
27.2mm
①
②
④
③
⑤
MAKE PROPERTIES SAFER
AND SMARTER
1

The device can be installed in both indoor and outdoor environment.
Outdoor installation: Avoid to exposing the device to direct sunlight, which will cause damage to device
and components due to high temperature.
Indoor installation: The device should be installed on somewhere 2 meters (6 feet) away from light or 3
meters (9 feet) away from window/door.
3
|
Installation Environment
INSTALLATION ENVIRONMENT
4
|
Installation
INSTALLATION
IS-E20s Series Quick Guide
Backlight Direct sunlight Close to light
STEP1
①
②
③
Place the bracket against the wall, make sure the drilling position in the bottom align right below to the
cable outlet (marked as gray), then mark the position of drilling hole on the wall.
Take the bracket off the wall and use 6mm impact drill to drill holes in the marked locations.
Drive 3 expansion tubes into drilling positions.
Pull all cables and cords through the bracket, then lock the wall bracket by three ST4×20 screws.
NOTE: For installation on wooden walls, you can skip ② and ③.
A. Without Type 118 Junction Box
④
*
MAKE PROPERTIES SAFER
AND SMARTER
2

IS-E20s Series Quick Guide
Connect the cable and cords to the corresponding interfaces of device.
Attach the wiring cover and lock it by two M2.5×4 screws.
Attach the device onto the bracket on the wall, press down to lock by hooks.
Use hexagonal wrench to fully lock the device by M4×10 screw. Installation is completed.
NOTE: With ratchet wrench will improve the efficiency of installation.
①
②
③
④
*
STEP2
① ② ③ ④
Pull all cables and cords through junction box and the
bracket, then lock the bracket onto the Type 118 box by
two M4×30 screws.
B. With Type 118 Junction Box (recommended)
① ② ③ ④
18mm
34mm
8mm
112mm
17.7mm
18mm
5mm
8mm
18mm
8mm
17.7mm
18mm
5mm
8mm
18mm
8mm
17.7mm
MAKE PROPERTIES SAFER
AND SMARTER
3

IS-E20s Series Quick Guide
6
|
Status Lights
STATUS LIGHTS
485B
485A
GND
DOOR1
GND
DOOR0
GND
WG1
WG0
GND
CONTACT
12V
GND
NO
COM
NC
Elevator Control Device
Exit Button
Wiegand Card Reader
Power Adaptor
Door Lock
Ethernet(POE)
5
|
Interfaces
INTERFACES
OFF
white Breathing Light
white Light Always On
Red Breathing Light
Blue Breathing Light
Green Breathing Light 3 seconds
Red/Blue Light Flashing
Green Light on for 10 minutes
Normal(Idle)
Calling
Receiving a call
Talking
Network is unavailable(Oine)
Network is available, but SIP account isn't registered
Booted up
Firmware upgrading
Alarm zones armed
Red Light Always On Indoor unit alarm zones or E20 tamper alarm triggered
Status Description
MAKE PROPERTIES SAFER
AND SMARTER
4

IS-E20s Series Quick Guide
XI`AN ISESAR TECHNOLOGY CO., LTD.
ADD.: Room 2306, Lingxian Times plaza, Gaoxin Road, Xi`an
Web: www.isesar.com
8
|
Functions
FUNCTIONS
Attach the saved access card or keyfob on the card reader area of DH-E20S to unlock the door.
 DTMF Unlock
Incoming calls to DH-E20S will be answered automatically by default.
 Card/Keyfob Unlock
Press the configured DTMF code on keypad of device answering the call, the lock connected on DH-E20S
will be unlocked remotely.
 Auto answer
7
|
Configurations
CONFIGURATIONS
Select DTMF mode and confifigure the code in SYSTEM-RELAY page of Web confifiguration portal.
NOTE: You can refer to device user manual for more details.
 Set DTMF Code
Press on the device call button and hold for 5 secs, the device will broadcast the IP address digits by
voice.
 Check IP Address
Log into Web confifiguration portal of device, set up and register SIP accounts in INTERCOM-ACCOUNT
page.
 Set SIP Account
*
