Nexo PS8 User manual

- Read this document before using.
- Keep this document.
- Observe all warnings and cautions.
PAGE 1 OF 4
VNI-WS8
DP3419/Rev01 - DI
PS8 Wall Bracket
Contents:
X1 (Arm)
X1 (Adapter)
X2
X1
X2
X1
X1
X2
Weight: 1.2 kg / 2.7 lb

- Read this document before using.
- Keep this document.
- Observe all warnings and cautions.
PAGE 2 OF 4
Dimensions:
Adapter mounting
•Remove 2 screws from the PS8 and use the 2 screws and
the 2 washers provided to fix the adapter.
•Please, do not push on the 2 screws while screwing
them, to avoid disengaging the bolt that is inside the
cabinet.
•WARNING: Screws must be secured using Loctite 243TM
Tilt in vertical position

- Read this document before using.
- Keep this document.
- Observe all warnings and cautions.
PAGE 3 OF 4
Tilt in horizontal position
Adapter / Arm mounting
For the wall mount of VNI-WS8, please select screws and mounting location supporting 4 times the system
weight.
Tighten well to cancel any float between the arm and the adapter.

- Read this document before using.
- Keep this document.
- Observe all warnings and cautions.
PAGE 4 OF 4
Safety device
Use the parts provided
•NEXO cannot accept responsibility for accidents caused by any factor other than defects in this product itself.
•Please check the web site nexo-sa.com for the latest update.
