Next 315870 User manual

IMPORTANT-RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd.
Version 1
Assembly Instructions
Actual product size
Need Help?
With:Assembly instructions
Missing or damaged parts
CALL:0333 777 8999
MONACO STORAGE BOX DARK GREY
Dark Grey:315870
L166 X W77 X H96cm

Assembly Instructions
MONACO STORAGE BOX DARK GREY
315870-2020-V1
1
BEFORE YOU START
Produced in China for Next Retail Ltd.
To view our full furniture range please visit www.next.co.uk
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
WARNINGS
Do’s
Do’s
Time to assemble
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit you
home to assess the fault and repair the product where possible
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
Number of people required to assemble
Two persons to assemble the unit and lift the unit into position.
We suggest you retain these instructions for future reference
Keep fittings out of children’s reach and keep children well away
from construction area.
Please periodically check all fittings and re-tighten as necessary
Please do not stand on your furniture
This product should only be used on firm, level ground.
Avoid exposing the furniture to excessive heat or direct sunlight
as this can cause deterioration of the colour
We suggest you spend a short time reading through this leaflet
before you start
When you are ready to start, make sure that you have the right
tools and plenty of space
Unwrap all packaging materials and place the components on
a clean surface to protect it from damage, We recommend that
thepackaging is used to protect the surfaces during assembly
Carefully check that you have all the parts before beginning
assembly
Unwrap all packaging materials and place the components on
top of the carton box or on a clean floor to
protect it from damage
Due to the size of the product we recommend that it is
assembled in the room intended for use
Ensure the product is fully assembled as illustrated and all
fixings fully tightened before use
Do not drag or pull your furniture
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the finish
30 minute
EASY
BUILD

Assembly Instructions
MONACO STORAGE BOX DARK GREY
2
GETTING TO KNOW YOUR PRODUCT
Components supplied. Please use this guide if you require replacement parts.
Produced in China for Next Retail Ltd.
1
3
2
5
4
7
6
（The lid is bigger than the bottom）
（The upper ends without Screw hole）
（Non woven vine）
（Lining cloth sleeve）
（ 4 and 5 are symmetrical）（ 5 and 4 are symmetrical）
（The upper ends with Screw hole）
Ref Ref Dimensions DimensionsVisual VisualQty Qty
1
2
3
4
5
6
7
1
1
1
1
1
1
1
165.5X77X3cm
161X93X3cm
161X93X3cm
155.5X70X3cm
156X69X88cm
70X90X3cm
70X90X3cm
315870-2020-V1

Assembly Instructions
MONACO STORAGE BOX DARK GREY
3
Produced in China for Next Retail Ltd.
Fixtures and fittings
supplied(actual size)
E
F
A
B
ø4x66mm
Ref Dimensions
M6x25mm
M6x40mm
ø 16x1.0mm
ø
16x6.0mm
ø
13x5.0mm
C
D
Qty
4
4
30
28
24
2
mm 605040302010 70 80 90
315870-2020-V1

Assembly Instructions
MONACO STORAGE BOX DARK GREY
5
2
4
5
4
3
Produced in China for Next Retail Ltd. 4
1
D
C
A
DC
A
2
ø16
X
1.0mm
mm66
ø4x
FX1
CX6
M6 X40mm
DX6
AX6ø13 X5.0mm
ø16
X
1.0mm
mm66
ø4 x
FX1
CX6
M6 X40mm
DX6
AX6ø13 X5.0mm
3
315870-2020-V1

Assembly Instructions
MONACO STORAGE BOX DARK GREY
D
C
A
Produced in China for Next Retail Ltd. 5
3
ø16 X6.0mm
mm66ø4x
FX1
E
E
X4
M6 X25mm
B
B A
X4
AX4ø13 X5.0mm
- Remember to fully tighten all
bolts before turning over.
- Remember to fully tighten all
bolts before turning over.
ø16X1.0mm
C
C
X6
ø16
X
1.0mm
mm66ø4 x
FX1
CX12
M6 X40mm
DX12
AX12 ø13 X5.0mm
4
6
3
E
BA C
315870-2020-V1

Assembly Instructions
MONACO STORAGE BOX DARK GREY
6
Produced in China for Next Retail Ltd.
166CM
96CM
77CM
315870-2020-V1
