Next BRONX SUPERWIDE TV 721143 User manual

Assembly instructions
IMPORTANT - RETAIN FOR FUTURE REFERENCE
Actual product size
Need Help?
CALL: 0333 777 8999
With: Assembly instructions
Missing or damages parts
H50.6 x W180 x D39.1cm
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675

PH2
30min
1
Number of people required to assemble
Time to assemble
Tools required
Do’s
Two people are required to assemble this item
We suggest you spend a short time reading through this leaflet before you start
When you are ready to start, make sure that you have the right tools and plenty of space
Unwrap all packaging materials and place the components on a clean surface to protect it from damage,
we recommend that the packaging is used to protect the surfaces during assembly
Carefully check that you have all the parts before beginning assembly
Due to the size of the product we recommend that it is assembled in the room intended for use
Ensure the product is fully assembled as illustrated and all fixings fully tightened before use
Wipe occasionally with a soft cloth slightly dampened with water. Then buff with a dry clean soft cloth
Wood will mellow and change colour over time, we recommend that ornaments and items placed on the surface are
moved regularly for the first few months to prevent uneven mellowing
Don’ts
Do not drag or pull your furniture
Do not rub or scrub the surface when cleaning
Do not use silicone based furniture polish. Silicone in furniture polishes can break down the finish
Never allow any kind of liquid to remain on your furniture. Absorption can cause wood to warp or finishes to de-laminate
Do not place hot items (e.g. hot drinks) directly on tothe wood surface. Please make sure you use a placemat or coaster
Assembly instructions
BEFORE YOU START
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675

2
1
9
18
16
15
17
14
13
10
3
3
7
5
6
8
4
7
19
2
11
16 14
17
15 12
18
GETTING TO KNOW YOUR PRODUCT
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675

3
Ref Dimensions Visual Qty
1
Ctn
Components supplied. Please use this guide if you require replacement parts
.
2
3
4
5
6
180 x 39cm
180 x 39cm
33.8 x 37cm
33.8 x 37cm
33.8 x 37cm
89.2 x 35.3cm
41.6 x 35.2cm
11
7
16 x 35.3cm
16 x 17.4cm
45 x 33cm
8
9
10
1 1
1 1
2 1
1
1
1
1
2 1
1 1
1 1
1 1
Ref Dimensions Visual Qty
11
Ctn
12
13
14
15
16
45 x 33cm
44.2 x 17.4cm
44.2 x 17.4cm
34 x 10.1cm
34 x 10.1cm
41.2 x 10.1cm
39.7 x 34.9cm
11
17
42.3 x 34.5cm
89.9 x 34.5cm
18
19
2 1
1 1
1 1
1
1
2
2
2 1
2 1
1 1
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675

4
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
Ref Dimensions Qty Visual
Spare
Qty
N/A 1n9 10
N/An5 5
N/A N/A
N/A
n6
n7
1
N/A N/A1
N/A N/Au 6
N/A N/Av 4
Fixtures and fittings supplied (not to scale)
Ref Dimensions Qty Visual
Spare
Qty
N/A N/Ai
k
8
N/A N/A18
N/A N/Ap 4
N/A N/A
n1 2
N/A N/An2 2
x 2
x 2

5
2Ø5 x 50mm 1
Ø8 x 38mm 2
a
c
N/A
N/A
Ø6 x 30mm 2d
4
Ø6 x 16mm 1n3
n4
n8
10
Ø6 x 43mm 1
1
N/A
N/A
Ø6 x 47mm 1
2
2
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty Spare
Qty
Ø15 x 12.7mm
Ø15 x 9.5mm
f
f1
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675

6
n1
n1
n2
n2
n1
n3
n5
n5 n3
n5
n1
n1
n1
n3
n3
n3
n6
n4
n9
n6
n3
n5
n1
n1
n2
n2
n4
n9
2
1
2
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
n6 x 1
n2 x 2
n1 x 2
n3 x 4
6 x 16mm
n9 x 10 n4 x 10 6 x 43mm
n5 x 4
x 2

7
n7
n7 n8
n5
n7
a
a
PH2 n8 x 1
n7 x 1
6 x 47mm
n5 x 1
2
82
3
4
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
PH2 a x 2
5 x 50mm

8
TURN THE CAM IN A CLOCKWISE DIRECTION
PUSH THE TWO PANELS TOGETHER ALLOWING THE
DOWEL TO ALIGN WITH THE HOLE
k
k
5
4
6
4
6
2
5
k
6
5
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
With edge banding
k x 4
WHEN TIGHTENING THE CAM
TURN THE CAM IN A CLOCKWISE DIRECTION UNTIL THE
ARROW POINTS IN THE POSITIONS SHOWN IN THE
DIAGRAMS BELOW
START MAXIMUM
LOCK

k
k
k
k
3
2
9
6
3
18
19
2
18
3
5
4
3
9
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
8
7
k x 5

k
k
k
k
k
kk
k
k
i
i
i
i
1
3
18
19
18
3
4
9
5
10Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
10
9
k x 9
i x 8
With edge banding
7
7
3
4
5
3

14
15
17
14
15
12
17
15
14
13
16
16 x 2
x 2
x 2
11Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
12
13
11
Without lamination
~

P
PP
P
10 11
13
12
12Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
15
14
PH2 p x 4
v x 4

Note :
Lock the hinge
after adjustment !
3
10
11
3
10
11
13
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
17
16

u
We recommend the use of the wall attachment bracket/strap provided for safety reasons.
Secure the other end of the strap to the wall with an appropriate screw and wall plug for your wall
type (not provided).
To hide the strap behind the unit, drill the hole lower than the top of unit.
Warning: Always ensure intended wall area to be drilled is free from hidden electrical wires, water,
and gas pipes.
If in doubt please consult a qualified trades person.
1
318
19
18
TOP
WALL
STRAP
SCREW
WASHER
14
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
19
18
PH2 u x 6

1800mm
892mm
437mm
416mm
391mm
15Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
Actual product size
H50.6 x W180 x D39.1cm
167mm
160mm
153mm
506mm

16
Assembly instructions
Produced in Indonesia for Next Retail Ltd.
721143/182675-2017-V1
BRONX SUPERWIDE TV
BRONX LIGHT SUPERWIDE TV
721143
182675
