Next CORSICA User manual

Tools Needed
Helpline
If you have any problems with this product or
require any replacement fittings please contact
Customer Services Tel: [phone]
ASSEMBLY INSTRUCTIONS.
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item
is found to be faulty. Should you need to return the unassembled product, please repack in the original
packaging.
IMPORTANT
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
CORSICA CORNER TV UNIT
CORSICA CORNER TV UNITCORSICA CORNER TV UNIT
CORSICA CORNER TV UNIT
• We recommend that the packaging is used to protect the surfaces during assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
IMPORTANT
• Carefully check that you have all parts before beginning assembly.
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
• Made in China.
• A minimum of two persons is required to assemble this product.
• Made from honeycomb board , partical board & MDF with a wood effect finish.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not use furniture polish.
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
CARE INSTRUCTIONS
PRODUCT INFORMATION
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if
necessary.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking,
discolouration or warping.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Do not put hot dishes directly on the surfaces of the item.
Page 1 of 8

FITTINGS
PARTS
1.Attach panels 17 & 18 to panel 19
with 4×screws(H) by using a screwdriver
until tight.
1.Slide panel 20 into the grooves of the
drawer frame
STEP ONE
STEP TWO
X 2 UNITS
Page 2 of 8

1.Insert 2×cambolts(E) into panel 21 using a
screwdriver until tight.
2.Glue (C) and insert 2× wooden dowels (B) into
panels 18 & 17
3.Attach handle (K) to the panel 21 with screws
provided.
4.Attach panel 21 to panels 18 & 17.
5.Insert 2×camlocks (F) into panels 18 & 17.
Ensure the arrow indicator is pointing towards
the panel edge before tightening with a
screwdriver.
6.Repeat step one,two & three to assemble
the other drawer.
1.Insert 6xcambolts (E) into panel 11 & 10 by a
screwdriver until tight.
2.Insert 8xcambolts (E) into panel 1 by a
screwdriver until tight.
STEP THREE
STEP FOUR
1.Glue and insert 2x wooden dowels (A) into
panels 10&11
2.Attach panels 10 & 11 to panel 1.
3.Insert 4x camlocks (F) into panel 1 and tighten
with a screwdriver.
Ensuring the arrow indicator is pointing
towards the panel edge before tightening
with a screwdriver.
NB:We recommend that the
packaging is used to protect the
surfaces during assembly.
STEP FIVE
Page 3 of 8

1.slide panels 16 (X2) into the grooves of
panels 10 & 11
1.Glue and insert the 8
xwooden dowel (A)
into panels
14(x2)
.
1.Insert panels 14(x2) to panels 16(x2) then attach
panels 14 (x2) to panels 10 &11
STEP SIX
STEP SEVEN
STEP EIGHT
panels 14 (x2) to panels 10 &11
2.Glue and insert the 2xwooden dowel (A) into
panel 1.
3.Attach panel 13 to panel 14 ( which connect to
panel 11) & 1, make sure the panel 16 in the groove
of panel 13.
3.Attach panel 12 to panel 14 ( which connect to
panel 10) & 1, make sure the panel 16 in the groove
of panel 12.
6.Insert 2xcamlocks (F) into panels 12 & 13 and
tighten with a screwdriver.
Ensuring the arrow indicator is pointing
towards the panel edge before tightening
with a screwdriver.
Page 4 of 8

1.Glue and insert the 6
xwooden dowel (A)
into pnaels 10 & 11
2.Attach panel 7 on panel 10
3.Insert 1xcamlock (F) into panel 7and tighten with
a screwdriver.
4.Attached panel 8 on panel 11
5.Insert 1x camlock (F) into panel 8 and tighten with
a screwdriver.
Ensuring the arrow indicator is pointing
towards the panel edge before tightening
with a screwdriver.
STEP TEN
1.Tighten panel 7 to panel 12 with 2 x screws(H)
by using a screwdriver.
2.Tighten panel 8 to panel 13 with 2 x screws(H)
by using a screwdriver.
STEP NINE
STEP ELEVEN
1.Glue and insert the
2
xwooden dowel
s
(A)
into pnael 1
2.Attach panel 9 to panel 1.
3.Insert 2xcamlocks (F) into panel 9 and tighten
with a screwdriver.
Ensuring the arrow indicator is pointing
towards the panel edge before tightening
with a screwdriver.
Page 5 of 8

1.Insert 5xcambolts (E) into panels 5 & 15 by a
screwdriver until tight.
2.Glue and insert the 4
xwooden dowels (A)
into
panels 5 & 15
.
3.Attach panel 5 to panel 2 and panel 15 to panel 6
4.Insert 5xcamlocks (F) into panels 2 & 6 ,and
tighten with a screwdriver.
Ensuring the arrow indicator is pointing
towards the panel edge before tightening
with a screwdriver.
1.Attach the assembled panels 2 & 5 to panels 7,8 &
9 with 7 x screws(G) by an Allen key (D) to tighten.
STEP THIRTEEN
STEP TWELVE
1.Glue and insert
4
xwooden dowels (A)
into panel
1
.
2.Attach panels 3 & 4 to paenl 1.
3.Insert 4xcamlocks (F) into panels 3 & 4 and
tighten with a screwdriver.
Ensuring the arrow indicator is pointing
towards the panel edge before tightening
with a screwdriver.
STEP FOURTEEN
Page 6 of 8

STEP FIFTEEN
1.Tighten panels 3 & 4 to panel 2 with 4 x screws(G)
by an Allen key (D) .
STEP SIXTEEN
1.Carefully turn over the assembled unit
2.Insert 4 x fittings (I) into the required position
3.Insert panel 6 onto the fittings (I).
STEP SEVENTEEN
1. Insert the drawers 21(x2) to the assembled unit
as shown in diagram.
Page 7 of 8

STEP EIGHTEEN
1.Use 11 x stickers (J) to cover the holes on panels
3 , 4, & 8.
STEP NINTEEN
1.The assembled unit as shown.
Next Retail Ltd, Desford Road, Enderby, Leicester, LE19 4AT
Page 8 of 8
