Next GATSBY 871891 User manual

Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: [phone]
FITTINGS
•Batch No.JJ
•This product contains 4 mm glass that does not conform to BS 6206. If the glass is chipped or broken replace with
glass of the type described. Consult the manufacturer, retailer or agent with regard to obtaining a manufacturing
specification and shape for replacement glass quoting the model number and batch number or date of manufacture.
•This item contains glass. Please handle with extreme care.
• Do not place very hot or cold items against or in close proximity to the glass surface unless adequately thick
insulation material is used to prevent such items from coming into contact with the glass.
• Do not strike the glass with hard or pointed items.
• Clean using a glass cleaner and soft cloth. Do not use cleaning products containing abrasives as these will
scratch the glass.
• Do not sit or stand upon horizontal glass surfaces.
•BS 7449: 1991.
• Made in China.
• We recommend the use of the wall attachment straps for safety reasons. Wall fixings are not included.
• Care must be taken when cleaning around the product with a vacuum cleaner to prevent damage to the glass
panels.
• For general cleaning, periodically dust with a soft cloth.
GLASS INFORMATION
ASSEMBLY INSTRUCTIONS.
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Should you need to return this product, please repack in the original packaging.
CARE INSTRUCTIONS
• Do not rub or scrub the surface when cleaning.
PRODUCT INFORMATION
• Made from MDF board and mirror.
GATSBY BATHROOM CONSOLE 871891
Page 1 of 7

PARTS
(1). Top panel×
1pc
A. Cam lock
x 12pcs
B.Cam bolt
x 12pcs
(2). Base panel
×1 pc
(7). Removable glass
shelf ×1 pc
D. Glass
clamp x 4pcs
C. shelf fitting
x 4 pcs
E. Black
Screws x 25
F. Door
hinge x 4
G. Nickel
Screws x 24
H. Handle
x 2 sets
(3).Left side panel
×1 pc
(4).Right side panel
×1 pc
(5).Left back
panel ×1 pc
(6).Right back
panel ×1 pc
(8). Fixed shelf
×1 pc
I. Allen key
x 1 pc
J.Plastic cap × 2 pcs
Page 2 of 7

1. Assemble Cam bolt (B) x 8 onto Side panel (3)(4),
by using Allen Key (I)
Attach Base panel (2) and Fixed shelf (8) to both Side
panel (3) (4), by inserting Cam bolt (B) x 8 into holes
on both ends of shelves, and lock with Cam lock (A)
by turning it in colock-wise direction with Allen Key
STEP ONE
STEP TWO
(10).Left door
×1 pc
(11).Right
door ×1 pc
(9). Removable Shelf
×1 pc
Page 3 of 7

1, Asssemble the Cam bolt (B) x4 onto Top Panel (1).
2. Attach Top panel(1) to both Side panel (3) (4), by
inserting Cam bolt (B) x 4 into holes on the top end
of Side panels, and lock with Cam lock (A) by turning
it in colock-wise direction with Allen Key (I).
Attach Back panels (5)(6) on the back of the cabinet,
by using black tapping screws (E)x 25 and Allen Key
1. Insert Glass clamp (D) x 4 into the holes on top
section of Cabinet inside, ensure they are at the
position where you want to put the Removable glass
shelf(7).
2. Insert Shelf Fitting (C) x 4 into the holes on bottom
setion of Cabinet inside, ensure they are at the
position where you want to put the Removable
STEP THREE
STEP FOUR
STEP FIVE
Page 4 of 7

1. Put Removable Glass shelf (7) into the Glass
clamp (D)
2. Put Removable Shelf (9) onto the Shelf Fittings (C
Note: Make sure the Shef Fittings sits in the groove
on the bottom of the Removable shelf (9).
Assemble the Door hinges (F) x 4 onto the doors
(10)(11) and the inside of cabinet by using Nickel
Tapping Screws(G) x24 and tighten with Allen Key
After the doors are assmbled, adjust the hinges to
the best position per diagrams on the right.
LATERAL
FRONT-TO-BACK
STEP SIX
STEP SEVEN
STEP EIGHT
Page 5 of 7

VERTICAL
Assemble the handle to front side of door:
(1)the screw head and the black washer go on the
inside of the door
(2)the metal sleeve goes on the glass side of the
door and sits in the pre-drilled hole ,the clear plastic
washer then goes onto the screw thread. the handle
is then screwed onto the thread by hand.
(3)whilst holding the handle, tighten the screw inside
the door (with screw driver )until you feel the handle
lock against the glass .
NOTE:Do not over tighten the handle as this can
cause the glass to crack
STEP ELEVEN
YOUR CONSOLE IS NOW READY FOR USE
STEP NINE
1. This item comes pre-fitted with two wall
attachment straps. Attach the ends of the wall
attachment straps to the wall once the item has
been placed into the required position using
appropriate screws, washers and wall plugs for
your wall type.
WARNING: Ensure the area to be drilled is free
from hidden electrical wires and
water or gas pipes.
NOTE: Wall fixings are not included. Source
suitable fixings for your wall type, if in doubt
consult a qualified tradesperson.
Page 6 of 7

Next Retail Ltd, Desford Road, Leicester, LE19 4AT
