Next LOUIS 540040 User manual

540040
540040-2019-V1.
LOUISWIDECHEST
H85 x W120x D39cm
Actualproductsize
Assembly instructions
IMPORTANT-RETAINFORFUTUREREFERENCE
Produced in China forNext Retail Ltd.
Need Help?
With: Assemblyinstruction
Missing ordamaged parts
CALL:0333777 8999
All manuals and user guides at all-guides.com

LOUISWIDECHEST
540040
30min
Assembly instructions
TONO TIME
All manuals and user guides at all-guides.com

540040
LOUISWIDECHEST
540040-2019-V1.
Assembly instructions
2
GETTINGTOKNOWYOUR PRODUCT
Produced in China forNext Retail Ltd.
6
8
7
7
4
1
2
3
5
10
10 10
10
9
9
11
12
13
14
15
16
17
15
18
19
20
21
22
All manuals and user guides at all-guides.com

4
1
2
8x58cm
1
39x69cm
1
8x58cm
5x13cm
5x13cm
540040
LOUISWIDECHEST
540040-2019-V1.
1 1
21
31
16 113x58cm
19 4
17x30cm
20 4
17x30cm
2
1
1
18 4
17x53cm 2
14 2
9x30cm 1
15 6
29x53cm 2
71
Assembly instructions
3
Components supplied. Please use this guide ifyou require replacement parts.
Produced in China forNext Retail Ltd.
Ref Dimensions Visual Qty Ctn Ref Dimensions Visual Qty Ctn
22 2
27x58cm 2
21 2
27x58cm 2
17 1
13x58cm 2
All manuals and user guides at all-guides.com

2
N/A
LOUISWIDECHEST
540040
15 x 10mm 2
N/A
8x38mm 2
B16 6x65mm N/A
T1 N/A 2N/A
N/A
D3 6x30mm 2
N/A
D6 8x30mm 2
W41 41
N/A
B8
B2
Fixturesandfittingssupplied(nottoscale)
Ref Dimensions Visual Qty
Fixturesandfittingssupplied(nottoscale)
Spare Qty
Assembly instructions
Ref Dimensions Qty SpareQty
4
15 x 12mm 2B3
8x35mm
All manuals and user guides at all-guides.com

5
LOUISWIDECHEST
540040-2019-V1.
Assembly instructions
1
Produced in China forNext Retail Ltd.
540040
6
N/A
1
2
2
6
Adjustable in length
1
All manuals and user guides at all-guides.com

6
540040-2019-V1.
2
540040
LOUISWIDECHEST
Assembly instructions
Produced in China forNext Retail Ltd.
6x65mm 2
15 x 12mm 4
3
1
2
90
12
34
All manuals and user guides at all-guides.com

7
540040
LOUISWIDECHEST
540040-2019-V1.
Assembly instructions
Produced in China forNext Retail Ltd.
TURN THE CAM IN A CLOCKWISE DIRECTION
PUSH THE TWO PANELSTOGETHER ALLOWING THE
DOWELTO ALIGN WITH THE HOLE
DON'TSTOP UNTILTHE 2O'CLOCK LOCK
TURNTHE CAMIN ACLOCKWISEDIRECTION UNTILTHE
ARROW POINTS IN THEPOSITIONSSHOWN INTHE
DIAGRAMS BELOW
START CORRECT
LOCK
3
4
All manuals and user guides at all-guides.com

7
8
540040
LOUISWIDECHEST
540040-2019-V1.
4
Assembly instructions
Produced in China forNext Retail Ltd.
5
8x35mm 4
N/A 2
5
All manuals and user guides at all-guides.com

9
540040
LOUISWIDECHEST
540040-2019-V1.
6
Assembly instructions
Produced in China forNext Retail Ltd.
7
8
6
All manuals and user guides at all-guides.com

10
540040
LOUISWIDECHEST
540040-2019-V1.
8
9
Assembly instructions
Produced in China forNext Retail Ltd.
9
9
All manuals and user guides at all-guides.com

10
11
540040
LOUISWIDECHEST
540040-2019-V1.
Assembly instructions
Produced in China forNext Retail Ltd.
11
11
Finishedside
10
10
10
10
All manuals and user guides at all-guides.com

12
540040
LOUISWIDECHEST
540040-2019-V1.
12
Assembly instructions
Produced in China forNext Retail Ltd.
13
12
13
14
Finished side
15
All manuals and user guides at all-guides.com

14
13
540040
LOUISWIDECHEST
540040-2019-V1.
15
Assembly instructions
Produced in China forNext Retail Ltd.
17
18
19
20
16
Wide
Narrow
Narrow
Wide
All manuals and user guides at all-guides.com

14
16
540040
LOUISWIDECHEST
540040-2019-V1.
Assembly instructions
Produced in China forNext Retail Ltd.
17
15
Finished side
22
21
Wide Narrow
Wide
Narrow
All manuals and user guides at all-guides.com

18
15
540040
LOUISWIDECHEST
540040-2019-V1.
Produced in China forNext Retail Ltd.
Assembly instructions
N/A 24
21
21 22
22
All manuals and user guides at all-guides.com

19
16
540040
LOUISWIDECHEST
540040-2019-V1.
Produced in China forNext Retail Ltd.
Assembly instructions
All manuals and user guides at all-guides.com

20
17
540040
LOUISWIDECHEST
540040-2019-V1.
Assembly instructions
Produced in China forNext Retail Ltd.
WHENLOOSENINGTHE CAM
TURN THE CAMINA COUNTERCLOCKWISE DIRECTION
UNTILTHE ARROWPOINTSINTHE POSITIONSHOWN
INTHEDIAGRAMSBELOW
TURN UNLOCKED
MAXIMUM
LOCK TO UNLOCK
TOP
WALL
STRAP
SCREW
WASHER
12
All manuals and user guides at all-guides.com

540040
540040-2019-V1.
540040
LOUISWIDECHEST
540040-2019-V1.
H85x W120xD39cm
Produced in China forNext Retail Ltd.
Actualproductsize
285mm
525mm
525mm
147mm
285mm
All manuals and user guides at all-guides.com

540040
LOUISWIDECHEST
540040-2019-V1.
