Next STANTON 859337 User manual

Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: [phone]
ASSEMBLY INSTRUCTIONS.
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• Carefully check that you have all parts before beginning assembly.
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
859337 STANTON LEANING SHELF
859337 STANTON LEANING SHELF859337 STANTON LEANING SHELF
859337 STANTON LEANING SHELF
• Wall fixings are not included.
• We recommend that the packaging is used to protect the surfaces during assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• Carefully check that you have all parts before beginning assembly.
CARE INSTRUCTIONS
PRODUCT INFORMATION
• We recommend the use of the wall attachment bracket/strap provided for safety reasons.
• Made in China.
• A minimum of two persons is required to assemble this product.
• Made from hollow board,particle board & MDF with a wood effect finish.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Do not put hot dishes directly on the surfaces of the item.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching
or damage.
• Do not use furniture polish.
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• Please do not apply adhesive substrates for example , sticky tape to the product.
Page 1 of 5

FITTINGS
PARTS
DX14BX3AX34 EX20 FX10 GX1 HX2 IX2
8*30mm 5g 15*12.5mm 7.5*24.5mm 4*45mm 4*16mm
1.5*13*40*40mm
CX14
6*80mm D=4mm
1. Insert 14 x cambolts (D) into panels 1, 2 & 5 and
tighten with a screwdriver.
2. Attach 2 x brackets (H) to panel 10 with 2 x screws
(I).
STEP ONE
5
2
1
Page 2 of 5

1. Glue and insert 10 x wooden dowels (A) into
panels 6, 7, 8, 9 & 10.
2. Attach panels 6, 7, 8, 9 & 10 to panels 1 & 4.
3. Insert 5 x camlocks (C) into panels 6, 7, 8, 9 & 10
and tighten with a screwdriver.
Ensuring the arrow indicator is pointing toward the
panel edge before tightening with a screwdriver.
1. Glue and insert 10 x wooden dowels (A) into
panels 6, 7, 8, 9 & 10.
2. Attach panels 2 & 3 to panels 6, 7, 8, 9 & 10.
3. Insert 5 x camlocks (C) into panels 6, 7, 8, 9 & 10
and tighten with a screwdriver.
Ensuring the arrow indicator is pointing toward the
panel edge before tightening with a screwdriver.
STEP TWO
STEP THREE
4
B
A
C
1. Attach panels 3 & 4 to panels 6, 7, 8, 9 & 10 with 10
x screws (F) and tighten by an Allen key (G).
STEP FOUR
A
C
4
3
F
G
Page 3 of 5

1. Glue and insert 6 x wooden dowels (A) into panels
6.
2. Attach panels 11 (x2) & 12 (x2) to panel 6 with 10 x
screws (E) and tighten with a screwdriver.
Please ensure slope side of panels 12 (x2) face to
panels 1 & 2.
1. Carefully lift the unit upright. The unit should be
lifted by two people.
2. Glue and insert 4 x wooden dowels (A) into panel 5.
3. Attach panel 5 to panels 1, 2, 3 & 4.
4. Insert 4 x camlocks (C) into panels 1, 2, 3 & 4 and
tighten with a screwdriver.
Ensuring the arrow indicator is pointing toward the
STEP FIVE
STEP SIX
4
A
C
B
A
E
slope side
straight side
Ensuring the arrow indicator is pointing toward the
panel edge before tightening with a screwdriver.
1. Glue and insert 4 x wooden dowels (A) into panel 5.
2. Attach panels 11(x2) & 13(x2) to panel 5 with 10 x
screws (E) and tighten with a screwdriver.
Please ensure slope side of panels 13(x2) face to
panels 1 & 2.
STEP SEVEN
1
3
2
5
11
13
5
1
2
Page 4 of 5

1. Move the unit into desired position.
2. Secure the 2 × "H" metal brackets to the wall with
an appropriate screw and wall plug for your wall type
(not provided).
Warning:
please note this item need to be fixed on
the wall to prevent falling forward when
product is in use.
Warning:
Always ensure intended wall area to be
drilled is free from hidden electrical
wires,water and gas pipes.
NB:Wall fixings are not included-Please
source suitable fixing for your wall type. If in
doubt please consult a qualified trades
person.
STEP EIGHT
10
Next Retail Ltd, Desford Road, Leicester, LE19 4AT
Page 5 of 5
