nifty 140 Series Quick guide
.com
140/TM40
Operating and Safety Instructions
MODEL 140 (TM40) SERIES
Manufactured by:
Niftylift Limited
Fingle Drive
Stonebridge
Milton Keynes
MK13 0ER
England
www.niftylift.com
e-mail: info@niftylift.com
Tel: +44 (0)1908 223456
Fax: +44 (0)1908 312733
M50131/04
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 1
Table of Contents
1INTRODUCTION AND GENERAL INFORMATION PAGE
1.1 Foreword 2
1.2 Scope 3
1.3 Introducing the 140 Trailer Mount (TM) Series 3
1.4 General Specification 4
1.5 Identification 5-6
2 SAFETY
2.1 Mandatory Precautions 7-10
2.2 Environmental Limitations 10
2.3 Noise & Vibration 10
3 PREPARATION AND INSPECTION
3.1 Unpacking 11
3.2 Preparation for Use 11
3.3 Pre-Operational Safety Check Schedules 12-13
3.4 Placards, Decals and Installation 14-18
3.5Torque Requirements
19
4 OPERATION
4.1 Control Circuit Components 20
4.2 Setting Up Procedures 21
4.3 Ground Control Operation 22-23
4.4 Platform Control Operation 24-25
4.5 Cage Weigh System 26-28
4.6 Batteries and Charging 30-31
4.7 Transporting, Towing, Craneage, Storage and Setting to Work 32-35
4.8 Traction Drive 36-37
5 EMERGENCY CONTROLS
5.1 General 38
5.2 Emergency Procedures - Incapacitated Operator 38
5.3 Emergency Procedures - Machine Failure 38
5.4 Incident Notification 38
6 RESPONSIBILITIES
6.1 Changes in Ownership 38
6.2 Manual of Responsibilities (USA only) 38
6.3 Inspection/ Service Check List 39-40
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
2
1 Introduction and General Information
1.1 FOREWORD
The purpose of these manuals is to provide the customer with appropriate safety operating and
maintenance instructions essential for proper machine operation.
All information in these manuals should be READ and fully UNDERSTOOD before any attempt is made
to operate the machine. THESE MANUALS ARE VERY IMPORTANT TOOLS - Keep them with the
machine at all times.
The manufacturer has no direct control over machine application and use, therefore
conformance with good safety practices is the responsibility of the user and his operating
personnel.
All information in these manuals is based on the use of the machine under proper operating
conditions. Alteration and/or modification of the machine are strictly forbidden.
One of the most important facts to remember is that any equipment is only as safe as those
who operate it.
DANGER, WARNING, CAUTION, IMPORTANT, INSTRUCTIONS AND NOTICE
Any place these topics may appear, either in this manual or on the machine, they are defined as
follows:
DANGER: If not correctly followed there is a high probability of serious injury or death to personnel.
WARNING OR CAUTION:If not correctly followed there is some possibility of serious injury or death to
personnel.
THE 'SAFETY ALERT' SYMBOL IS USED TO CALL ATTENTION TO POTENTIAL
HAZARDS THAT MAY LEAD TO SERIOUS INJURY OR DEATH, IF IGNORED.
IMPORTANT AND INSTRUCTIONS: Denotes procedures essential to safe operation and prevention of
damage to or destruction of the machine.
NOTICE: Indicates general safety rules and/or procedures relating to the machine.
It is the owner's/user's responsibility to know and comply with all applicable rules,
regulations, laws, codes and any other requirements applicable to the safe use of this
equipment.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 3
1.2 SCOPE
These operating instructions contain all the necessary information required to allow the safe operation
of any Niftylift 140 (TM40), powered by electric (DC), diesel (D), petrol (gasoline) engine, or a
combination of these.
For further technical information, circuit diagrams and specific instructions for all maintenance which
may need to be carried out by specialist trained personnel, see the associated Workshop and Parts
manual for your model of Niftylift 140 (TM40).
1.3 INTRODUCING THE 140 TRAILER MOUNT (TM) SERIES
Please note at the time of going to press all information, illustrations, details and descriptions contained
herein are valid. Niftylift reserves the right to change, modify or improve its products without any
obligations to install them on previously manufactured machines.
If you require further information after reading this manual, please do not hesitate to contact us.
Niftylift Ltd, Fingle Drive, Stonebridge, Milton Keynes MK13 0ER, Great Britain
Tel: +44 (0) 1908 223456 Fax: +44 (0) 1908 312733
Niftylift Inc, 32 Concourse Way, Greer, SC 29651 USA
Tel: +01 864 968 8881 Fax: +01 864 968 8836
Nifty Pty Ltd, 11 Kennington Drive, Tomago, NSW 2322, Australia
Tel: +61 (0) 2 4964 9765 Fax: +61 (0) 2 4964 9714
The Niftylift 140 trailer mount is an extremely versatile articulated boom platform of unique and simple
design. It is capable of placing two men and their tools up to a height of 14.3m (46ft 8ins) or an
outreach of 6.3m (20ft 8in).
The booms are mounted via a 360opowered swing mechanism on to a compact base balanced on a
single axle. The fully articulating booms give an outstanding working envelope. The large pneumatic
wheels and minimal weight make the unit light and simple to manoeuvre.
A simple, all-hydraulic proportional control system gives smooth, reliable movement of the platform
and maximum reliability in the harshest environments.
The hydraulic outriggers make setting up both swift and simple and a unique pressure sensitive
microswitch system fitted to each outrigger prevents operation of the machine until all outriggers have
been correctly deployed. This is coupled with a loud audible alarm warning of a possibly hazardous
situation.
Models include the following:
E: - DC ELECTRIC DE: - DIESEL & BATTERY
AC: - AC ELECTRIC PE: - PETROL & BATTERY
D: - DIESEL LPG: - PETROL & LPG (PROPANE)
P: - PETROL T: - PETROL, PROPANE & BATTERY
A: - AIR
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
4
1.4 GENERAL SPECIFICATION
FEATURE N140H (TM40)
MAXIMUM HEIGHT - WORKING 14.3m
46ft 8ins
MAXIMUM HEIGHT - PLATFORM 12.3m
40ft 4ins
MAXIMUM HEIGHT - STOWED 1.98m
6ft 6in
MAXIMUM OUTREACH 6.3m
20ft 8in
MAXIMUM WIDTH - TOWING 1.6m
5ft 3in
JACK SPREAD 3.20m
10ft 6in
MAXIMUM LENGTH - STOWED 6.75m
22ft 2in
MAXIMUM CAPACITY
225kg
500lb
TURRET ROTATION 360º
TURRET TAILSWING Zero
MAXIMUM TRAVEL SPEED 45 mph
72 kph
PLATFORM SIZE - LENGTH X WIDTH 0.7m x 1.5m
28in x 55in
CONTROLS Full proportional hydraulic
HYDRAULIC PRESSURE 200bar
2900 PSI
TYRES 175 R14C 8PR
4.5 bar(65 psi)
GROUND CLEARANCE 25cm
10in
GROSS VEHICLE WEIGHT (MAXIMUM) 1500kg
3300lb
MAXIMUM GROUND PRESSURE 0.034kn/cm2
7084lb/ft2
POWER SOURCE E (Electric) models - 4 x 6v 250 AH batteries
P (G) (Petrol/Gasoline) models - Honda GX200 Engine
D (Diesel) models - Yanmar L40 or Kubota OC60 engine
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 5
1.5 IDENTIFICATION
!"#$%& %'()*'%(+,&%(+-)#
)
.
/0/
123 4533
3 .3 63 45
/ 1 33 45
/ ./333
/ 1 .333 #78
1 0333 !5
/ 2/0 ./33 9$:
/ 3333
3 .333
0 00 3 /
2 00 33 /
.
This manufacturer’s plate is attached to Boom 1 on each machine at the time of
manufacture on every Niftylift 140H (TM40). Please ensure all sections have been
stamped and are legible.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
6
1.5a IDENTIFICATION (USA PLATE)
! "
#$%&'( ')*+,)'*-.('*-/+%
0 1 2 32 10 $
434
323 5 55
2 00555
10555
!4 043 2455 2
!4 5555
5 2555
3 33 5 4
0 33 55 4
2"
This manufacturer’s plate is attached to Boom 1 on each machine at the time of
manufacture on every Niftylift. Please ensure all sections have been stamped and are
legible.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 7
2 Safety
2.1 MANDATORY PRECAUTIONS
When operating your Niftylift, your safety is of utmost concern. In order to fully appreciate all aspects
of the machines operation it should be ensured that each operator has READ and fully UNDERSTOOD
the relevant manual covering machine use, maintenance and servicing. If any doubts exist concerning
any points covered in your manual, contact your local dealer or Niftylift Ltd.
Before using any Niftylift, thoroughly inspect the machine for damage or deformation to all major
components. Likewise, check the control systems for hydraulic leaks, damaged hoses, cable faults or
loose covers to electrical components. At no time should damaged or faulty equipment be used -
Correct all defects before putting the platform to work. If in doubt, contact your local dealer or Niftylift
Ltd (see front cover for address).
THE MANUFACTURER HAS NO DIRECT CONTROL OVER THE MACHINE
APPLICATION AND USE. THEREFORE CONFORMATION WITH GOOD SAFETY
PRACTICES IS THE RESPONSIBILITY OF THE USER AND HIS OPERATING
PERSONNEL. FAILURE TO UNDERSTAND AND FOLLOW ALL SAFETY RULES
COULD RESULT IN SERIOUS INJURY OR DEATH.
2.1.1 Only trained persons will be permitted to operate the Niftylift.
2.1.2 Always operate the Niftylift in full accordance with the manufacturers Operating & Safety Instructions
for that model.
2.1.3 Before use each day and at the beginning of each shift the Niftylift shall be given a visual inspection
and functional test including, but not limited to, operating and emergency controls, safety devices,
personal protective clothing, including fall protection, air, hydraulic and fuel system leaks, cables and
wiring harness, loose or missing parts, tyres and wheels, placards, warnings, control markings and
Operating and Safety Manuals, guards and guard rail systems and all other items specified by the
manufacturer.
2.1.4 Any problems or malfunctions that affect the safety of operations shall be repaired prior to the use of
the Niftylift.
2.1.5 Always ensure that all warning labels, instructions, placards, control markings and Safety Manuals are
intact and clearly legible. If replacements are required contact your local dealer or Niftylift. Always
observe and obey safety and operating instructions on such labels.
2.1.6 Do not alter, modify or disable in any way the controls, safety devices, interlocks or any other part of
the machine.
2.1.7 Before the Niftylift is used and during use the user shall check the area in which it is to be used for
possible hazards such as, but not limited to, uneven ground drop-offs, holes, bumps, obstructions,
debris, floor and overhead obstructions, high voltage conductors, wind and weather, unauthorised
persons and any other possibly hazardous conditions.
2.1.8 Never exceed the maximum platform capacity, as indicated on the decals and machine serial plate.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
8
2.1.9 Never position any part of the Niftylift within 4.0m, (12ft) of any electrical power line, conductor or
similar not exceeding 66kV. (Minimum span 125m) Other distances for increased voltages and
different spans are given in NZECP 34:1993.
THIS MACHINE IS NOT INSULATED.
If in doubt, contact the appropriate authorities.
2.1.10 On entering the platform ensure that the drop down entry bar is closed afterwards.
2.1.11 Use of an approved safety belt and lanyard, hardhat and appropriate safety clothing is mandatory.
Fasten harness to designated harness securing points within the platform and do not remove until
leaving the platform whilst in the stowed position.
2.1.12 Always remain standing within the platform. Do not attempt to increase your
height or reach by standing and/or climbing on the platform guardrails or any
other object. KEEP YOUR FEET ON THE PLATFORM FLOOR. Do not sit, stand
or climb on the guardrail, mid rail or boom linkage. Use of planks, ladders or
any other devices on the Niftylift for achieving additional height or reach shall
be prohibited.
2.1.13 Do not use the platform levelling system to artificially increase the outreach of the platform. Never use
boards or ladders in the platform to achieve the same result.
2.1.14 Do not use the platform to lift overhanging or bulky items that may exceed the maximum capacity or
carry objects that may increase the wind loading on the platform. (E.g. Notice boards etc.)
2.1.15 The Niftylift shall not be operated from a position on trucks, trailers, railway cars, floating vessels,
scaffolds or similar equipment unless Niftylift Ltd in Great Britain approves the application in writing.
2.1.16 Always check below and around the platform before lowering or slewing to ensure that the area is clear
of personnel and obstructions. Care should be taken when slewing out into areas where there may be
passing traffic. Use barriers to control traffic flow or prevent access to the machine.
2.1.17 Stunt driving and horseplay, on or around the Niftylift, shall not be permitted.
2.1.18 When other moving equipment and vehicles are present, special precautions shall be taken to comply
with local ordinances or safety standards established for the work place. Warnings such as, but not
limited to, flags, roped off areas, flashing lights and barricades shall be used.
2.1.19 It shall be the responsibility of the user to determine the hazard classification of any particular
atmosphere or location. Aerial platforms operated in hazardous locations shall be approved and of the
type required. (For the USA refer to ANSI/NFPA 505-1987.)
2.1.20 The operator shall immediately report to his supervisor any potentially hazardous location(s)
(environment) which become evident during operation.
2.1.21 If an operator encounters any suspected malfunction of the Niftylift or any hazard or potentially unsafe
condition relating to capacity, intended use or safe operation he shall cease operation of the Niftylift
and request further information as to safe operation from his management, or owner, dealer or
manufacturer before further operation of the Niftylift.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 9
2.1.22 The operator shall immediately report to his superior any problems or malfunctions of the Niftylift,
which becomes evident during operation. Any problems or malfunctions that affect the safety of
operation shall be repaired prior to continued use.
2.1.23 The boom and platform of the Niftylift shall not be used to jack the wheels off the ground.
2.1.24 The Niftylift shall not be used as a crane.
2.1.25 The Niftylift shall not be positioned against another object to steady the platform.
2.1.26 Care should be taken to prevent rope, electric cords and hoses from becoming entangled in the aerial
platform.
2.1.27 Batteries shall be recharged in a well-ventilated area free of flame, sparks or other hazards that may
cause explosion. Highly explosive hydrogen gas is produced during the charging process.
2.1.28 When checking electrolyte levels great care should be taken to protect eyes, skin and clothing. Battery
acid is highly corrosive and protective glasses and clothing is recommended.
When the machine is not in use always stow the booms correctly. NEVER LEAVE
THE KEYS IN THE MACHINE,if it is to be left for any period of time. Use wheel
chocks if leaving on an incline.
2.1.29 If the platform or elevating assembly becomes caught, snagged or otherwise prevented from normal
motion by adjacent structure or other obstacles, such that control reversal does not free the platform,
all personnel shall be removed from the platform safely before attempts are made to free the platform
using ground controls.
2.1.30 The engine must be shut down while fuel tanks are being filled. Fuelling must be done in a well-
ventilated area free of flame, sparks or any other hazard that may cause fire or explosion. PETROL
(GASOLINE), LIQUID PROPANE AND DIESEL FUELS ARE FLAMMABLE.
NEVER START THE NIFTYLIFT IF YOU SMELL PETROL (GASOLINE), LIQUID
PROPANE OR DIESEL FUEL. THESE FUELS ARE HIGHLY FLAMMABLE
2.1.31 The operator shall implement means provided to protect against use by unauthorised persons.
2.1.32 Never remove anything that may affect the stability of the machine such as, but not limited to, batteries,
covers, engines, tyres or ballast.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
10
2.2 ENVIRONMENTAL LIMITATIONS
All Niftylift Trailer Mounts are limited to operation as previously described and any slopes must be
adjusted by use of the outriggers and jacks. Unless specifically configured otherwise, the machine will
have short time rating for operation in extreme temperatures, i.e. reduced battery cycle times for low
temperatures such as freezers, food storage etc. and cooling limitations for high temperatures as oil
temperature must remain between -23° and 93° Celsius.
Extended operation in dusty environments is not recommended and frequent cleaning will be
necessary. All dust, dirt, salt encrustation, excess oil or grease should be removed. Deposits of paint or
bitumen, particularly on legends or labels should also be removed.
All standard Niftylift machines are rated for a wind speed of 12.5 m/s, which equates to 45kph / 28mph
or force 6 on the Beaufort scale. No attempt should be made to operate a Niftylift in wind strengths
above this limit and if the operator has any doubts over the wind speed he / she should cease operation
immediately until it can be established that the wind speed has fallen to a safe level.
DO NOT USE THE NIFTYLIFT IN ELECTRICAL STORMS
2.3 NOISE AND VIBRATION
The airborne noise emission on the 140 range of machines does not exceed 73dB(A), measured at a
perpendicular distance of 4m, under equivalent continuous A-weighted sound pressure test conditions.
This was based on a Diesel powered machine, working under load. All other models will exhibit
significantly lower emissions than this figure, dependant on power option.
In normal operation the Vibration level to which the operator is subjected will not exceed a weighted
root mean square acceleration value of 2.5 m/s2.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 11
3 Preparation and Inspection
3.1 UNPACKING
Since the manufacturer has no direct control over the shipping or carriage of any Niftylift it is the
responsibility of the dealer and/or owner and/or hirer to ensure the Niftylift has not been damaged in
transit and a Pre-operational Report has been carried out by a qualified engineer before the aerial
platform is put into service.
A) Remove all ropes, straps and or chains used to secure the aerial platform during transit.
B) Ensure any ramp, loading dock or forklift used is capable of supporting or lifting the aerial
platform.
***Carry out the Pre-operational Report before placing machine in service.
3.2 PREPARATION FOR USE
Whilst every effort has been made at the Niftylift factory to ensure your machine arrives in a safe and
operable condition it is necessary to carry out a systematic inspection prior to putting the aerial
platform into service.
THIS IS NOT A REQUEST IT IS MANDATORY
To assist the user in this task you will find enclosed an Inspection Check List (see section 6.3), which
must be filled out upon delivery/receipt of the machine.
Before the user carries out the Inspection Check List he must have read and fully understood all the
contents of the Operating, Safety and Maintenance Manual.
WARNING - DO NOT OPERATE A POTENTIALLY DEFECTIVE OR
MALFUNCTIONING MACHINE. CORRECT AND REPAIR ANY DEFECTS
BEFORE OPERATING YOUR NIFTYLIFT.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
12
3.3 PRE-OPERATIONAL SAFETY CHECK SCHEDULES
Before use at the beginning of the work shift, the aerial platform shall be given a visual inspection and
functional tests including, but not limited to the following. It is recommended that these be performed
at regular intervals as indicated on each checklist.
3.3.1 DAILY SAFETY CHECKS
1) Check that all labels (decals) are in place and legible.
2) Visually inspect the machine for damaged or loose components.
3) Check that batteries are charged (i.e. Charger has a solid green light and a pulsing red light).
4) Check the fuel level (if applicable).
5) Check that canopies/covers and guards are in place and secure.
6) Check that the boom rest switch is operable (if applicable).
7) Check that control levers are secure and operate freely.
8) Check that operating buttons and emergency stop buttons function properly.
9) Check the operation of the emergency hand pump.
10) Visually inspect all hydraulic hoses and fittings for damage or leaks.
11) Check operation of the stabiliser alarm.
12) Check that outrigger footpads are secure.
13) Check that the platform pivot pins and their tag bolts are secure.
14) Check security and operation of the boom clamp.
15) Check the operation of the cage weigh system (If fitted). See section 4.5.3 for testing and
verification procedure.
3.3.2 WEEKLY SAFETY CHECKS
1) Inspect tyres and wheels for damage and wear.
2) Check tyres for correct pressure. 65psi (4.5 bar)
3) Check mudguards for security and damage.
4) Check battery fluid levels and specific gravity (after charging) and general condition.
5) Check hydraulic oil level,ISO Grade 22(Europe), Grade 32 (Rest of World).
6) Inspect the engine air filter and clean or replace if necessary.
7) Check that the tow hitch ball lock, breakaway cable/chain and jockey wheel are secure.
8) Check operation and security of stabiliser micro switches in conjunction with the alarm system.
9) Inspect hose track for damage or missing parts.
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 13
3.3.3 MONTHLY SAFETY CHECKS
1) Check the engine oil level (if applicable).
2) Check the wheel nuts (torque 80ft lbs / 110Nm).
3) Check outriggers for condition, security and operation.
4) Check that the slew worm is secure and correctly in mesh. Clean and re-grease.
5) Inspect brakes for operation and wear.
6) Grease the knuckle and centre post.
7) Inspect the engine fuel tank for damage or leaks.
8) Grease the tow hitch assembly.
9) Lightly oil the jack pad ball joints and outrigger housings.
10) Every three months check and verify the calibration of the cage weigh system. See section
4.5.4 for the calibration procedure.
11) Every Six months perform a thorough examination in accordance with the ‘Lifting Operation
and Lifting Equipment Regulations’ (LOLER) 1998, Regulation (9)(3)(a).
3.3.4 ANNUAL SAFETY CHECKS
1) Check that all pivot pins and their tag bolts are secure.
2) Inspect for any cracks or badly rusted areas on booms and chassis.
3) Change the hydraulic oil and the oil filters.
4) Inspect the suspension on each axle unit.
5) Check that slew ringbolts are secure (torque 155ft lbs. 210Nm).
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
14
3.4 PLACARD, DECALS & INSTALLATION (UK SPEC)
ITEM DESCRIPTION NUMBER QTY
1 Daily Safety Checks P14908 1
2 Tilt alarm P18842 2
3 General Crush P14782 8
4 Cage Step P13812 1
5 Lighting Board P14022 1
6 Coupling instructions P14896 1
7 Harness Point P14883 2
8 Component Stability… P19708 1
9 Tyre Pressure 65 psi P14876 2
10 No Step P14785 8
11 Emergency Hand Pump P19090 1
12 Cage Gate Warning P18335 1
13 General Warning P20330 2
14 Head Protection P14921 1
15 Serial Plate P15383 1
17 SWL 225kg P17328 1
18 Nifty 140 Grey P14599 2
19 Niftylift.com P14390 1
20 Push and Release P19092 1
21 General Notice P18863 1
22 Point Load P14963 4
23 Outriggers - Hydraulic P14841 4
24 Outrigger Controls P14922 1
25 Hydraulic Controls – 4 lever P13299 2
26 Base Control Cage weigh
Non cage weigh
P17219
P15881
1
1
27 Warning Stripes A/R
28 Battery Isolator P18600 1
29 Hydraulic oil ISO32 P17226 1
30 Battery Charger P14904 1
31 Cage Control (E/AC) Cage weigh
Non cage weigh
P17158
P17930
1
1
33 Petrol OFF P19055 1
34 Diesel ONLY P14414 1
35 Cage Control (D/DE) Cage weigh
Non cage weigh
P17159
P17684
1
1
36 Operating Instructions P14892 1
38 Overload Warning P18848 2
39 Traction Drive - Engage P18890 1
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 15
ITEM DESCRIPTION NUMBER QTY
40 Hand Crush P14782 2
41 Noise Warning 85dB P17124 1
42 Noise Warning 73dB P17123 1
44 E-Stop, Do not disable P14864 2
45 Cage Rotate P15634 1
46 Traction Drive – Release P18975 1
47 Blank Axle Plate P16190 1
48 Cage Control (P/PE) Cage weigh
Non cage weigh
P17796
P16369
1
1
49 Tow hitch (Australia/NZ) P17970 1
50 Traction Drive – On slope P18976 1
51 Charger socket (E/PE/DE) P19699 1
52 Inlet socket 110v
220v
P17719
P17720
1
1
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
16
27
13
14
5
19
3
33
27
18
6
43 23 10
30
10 23 22
3
44 11 10 18
3
2
24 23 26 25 15 28 13 10 23
17
77
31
35 25 2
36
41
40
40
45
38
42
44 38
46
839
34
48
50
49
3
10
9
9
12
21
20
2x4 POSNS
47
1
UNDER
COVER
51 52
OPTIONS
29
OPTIONS
UNDER COVER
ON TANK
4 POSNS
4 POSNS
4 POSNS
VIEW ON INSIDE
FACE OF CAGE
140 Series
*
*PLACED ON HYDRAULIC OIL
TANK NEAR FILLER CAP
D80528/18
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04 17
3.4a PLACARD, DECALS & INSTALLATION (USA SPEC)
ITEM DESCRIPTION NUMBER QTY
1 Cage gate warning P18335 1
2 Tilt alarm P18842 2
3 General Crush P14782 8
4 Cage Step P13812 1
6 Coupling instructions P14896 1
7 Harness Point P14883 2
8 Component Stability P19708 1
9 Tyre Pressure 65 psi P14876 2
10 No Step P14785 10
11 Emergency Hand Pump P19090 1
13 General Warning P20330 2
14 Head Protection P14921 1
15 Serial Plate P15383 1
17 SWL 500lbs P17328 1
18 Nifty TM40 Grey P14613 2
19 Niftylift.com P14390 1
22 Point Load P14963 4
23 Outriggers - Hydraulic P14841 4
24 Outrigger Controls P14922 1
25 Hydraulic Controls – 4 lever P13299 2
26 Base control P15881 1
27 Warning Stripes A/R
28 Battery Isolator P18600 1
30 Battery Charger P14904 4
31 Cage Control P15925 1
33 Petrol OFF P19055 1
34 Diesel ONLY P14414 1
35 Cage Control P16369 1
36 General Notice P18863 1
37 Daily Check List P14908 1
39 Operating Instructions P14892 1
40 Rotating Machinery P15010 2
42 E-Stop, Do not disable P14864 2
45 Emissions P15334 1
46 Noise Warning 73dB P17123 1
47 Noise Warning 85dB P17124 1
48 Traction Drive – On slope P18976 1
49 Traction Drive – Release P18975 1
50 Traction Drive – Engage P18890 1
TM Series
Operating & Safety Instructions
English/USA – 10/06
Issue 04
18
51 Hand Crush P14782 2
52 Footswitch P14884 1
27
13
14
19
3
33
34
27
18
3
6
4
38
22 10 910 46 22
3
811 10 18
3
2
22
24
23
26 25 1528
37
940 22
17
77
31
35 25 2
23 51
36
42 3
13
42
39
10
10
45
23
30
47
40
51
52
50 48 49
1
33
10
10 23
10
3
TM40 Series
D80582/3
VIEW ON INSIDE
FACE OF CAGE
4 POSNS
UNDER
COVER
OPTIONS
COVER
UNDER
UNDER COVER
ON TANK
OPTIONS
OPTION
This manual suits for next models
4
Table of contents
Other nifty Boom Lift manuals
nifty
nifty SD64 Series User manual
nifty
nifty TM34T Series Quick guide
nifty
nifty Heightrider HYBRID Series Assembly instructions
nifty
nifty Heightrider SP HYBRID Series Assembly instructions
nifty
nifty TrackDrive TD120T Series Assembly instructions
nifty
nifty Niftylift Heightrider HR15N Series Assembly instructions
nifty
nifty 170SD series Assembly instructions
nifty
nifty Heightrider HR17N Assembly instructions
nifty
nifty Mk 3 Seies Assembly instructions
nifty
nifty SP45 Assembly instructions
