nifty Mk 3 Seies Assembly instructions

[email protected]
.com
Heightrider
Operating & Safety Instructions
MODEL HR15N (SP45N) &
HR17N (SP50N)
Mk 3 SERIES
Manufactured by:
Niftylift Limited
Chalkdell Drive
Shenley Wood
Milton Keynes
MK5 6GF
England
www.niftylift.com
e-mail: [e-mail]
Tel: [phone]
Fax: [phone]
M50461/03

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
1
Table of Contents
1Introduction and General Information 2
1.1 FOREWORD..................................................................................................... 2
1.2 SCOPE............................................................................................................. 3
1.3 INTRODUCING THE HEIGHT RIDER SELF-PROPELLED (SP) SERIES ................. 3
1.4 GENERAL SPECIFICATION................................................................................ 4
1.5 IDENTIFICATION (UK PLATE)............................................................................ 5
1.6 EC DECLARATION OF CONFORMITY (Typical) .................................................. 7
2Safety 8
2.1 MANDATORY PRECAUTIONS ........................................................................... 8
2.2 ENVIRONMENTAL LIMITATIONS..................................................................... 11
2.3 NOISE AND VIBRATION.................................................................................. 12
2.4 TEST REPORT ............................................................................................... 12
3Preparation and Inspection 13
3.1 UNPACKING................................................................................................... 13
3.2 PREPARATION FOR USE................................................................................ 13
3.3 PRE-OPERATIONAL SAFETY CHECK SCHEDULES.......................................... 14
3.4 PLACARD, DECALS & INSTALLATION (UK SPEC) .......................................... 17
3.5 TORQUE REQUIREMENTS.............................................................................. 19
4Operation 20
4.1 CONTROL CIRCUIT COMPONENTS ................................................................ 20
4.2 GROUND CONTROL OPERATION.................................................................... 23
4.3 PLATFORM CONTROL OPERATION ................................................................ 25
4.4 DRIVING CONTROLS...................................................................................... 31
4.5 CAGE WEIGH SYSTEM................................................................................... 32
4.6 BATTERIES AND CHARGING .......................................................................... 33
4.7 TRANSPORTING, TOWING, CRANEAGE, STORAGE AND SETTING TO WORK.. 36
5Emergency Controls 39
5.1 GENERAL ...................................................................................................... 39
5.2 IN THE EVENT OF AN INCAPACITATED OPERATOR ........................................ 39
5.3 IN THE EVENT OF MACHINE FAILURE ............................................................ 39
5.4 INCIDENT NOTIFICATION................................................................................ 39
6Responsibilities 40
6.1 CHANGES IN OWNERSHIP ............................................................................. 40
6.2 MANUAL OF RESPONSIBILITIES (USA only)................................................... 40
6.3 INSPECTION/SERVICE/PRE-HIRE CHECK LIST ............................................... 41
Appendix A 43

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
2
1Introduction and General Information
1.1 FOREWORD
The purpose of these manuals is to provide the customer with appropriate safety operating and
maintenance instructions essential for proper machine operation.
All information in these manuals should be READ and fully UNDERSTOOD before any attempt is made
to operate the machine. THESE MANUALS ARE VERY IMPORTANT TOOLS - Keep them with the
machine at all times.
The manufacturer has no direct control over machine application and use, therefore
conformance with good safety practices is the responsibility of the user and his operating
personnel.
All information in these manuals is based on the use of the machine under proper operating
conditions. Alteration and/or modification of the machine are strictly forbidden.
One of the most important facts to remember is that any equipment is only as safe as those
who operate it.
DANGER, WARNING, CAUTION, IMPORTANT, INSTRUCTIONS, AND NOTICE
Any place these topics may appear, either in this manual or on the machine, they are defined as
follows:
DANGER: If not correctly followed there is a high probability of serious injury or death to personnel.
WARNING OR CAUTION:If not correctly followed there is some possibility of serious injury or death to
personnel.
THE 'SAFETY ALERT' SYMBOL IS USED TO CALL ATTENTION TO POTENTIAL
HAZARDS THAT MAY LEAD TO SERIOUS INJURY OR DEATH, IF IGNORED.
IMPORTANT AND INSTRUCTIONS: Denotes procedures essential to safe operation and prevention of
damage to or destruction of the machine.
NOTICE: Indicates general safety rules and/or procedures relating to the machine.
It is the owner's/user's responsibility to know and comply with all applicable rules,
regulations, laws, codes, and any other requirements applicable to the safe use of this
equipment.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
3
1.2 SCOPE
These operating instructions contain all the necessary information required to allow the safe operation
of any Niftylift Height Rider 15N or 17N (SP45N or SP50N in the USA), powered by DC electric (E).
For further technical information, circuit diagrams and specific instructions for all maintenance which
may need to be carried out by specialist trained personnel, see the associated Workshop and Parts
manual for your model of Niftylift Height Rider.
1.3 INTRODUCING THE HEIGHT RIDER SELF-PROPELLED (SP) SERIES
Please note at the time of going to press all information, illustrations, details and descriptions contained
herein are valid. Niftylift reserves the right to change, modify or improve its products without any
obligations to install them on previously manufactured machines.
If, after reading this manual you require further information, please do not hesitate to contact us.
Niftylift Ltd, Fingle Drive, Stonebridge, Milton Keynes MK13 0ER, Great Britain
Tel: [phone] Fax: [phone]
Niftylift Inc, 1525 S.Buncombe Road, Greer, SC 29651 USA
Tel: [phone] Fax: [phone]
Nifty Pty Ltd, 11 Kennington Drive, Tomago, NSW 2322, Australia
Tel: [phone] Fax: [phone]
Driven from the platform, the Niftylift Height Rider 15N or 17N (SP45N or SP50N) is an extremely
versatile articulated boom platform of unique and simple design. The HR15N can place two men and
their tools at a height of 15.5m (50ft 10in) or an outreach of 9.7m (32ft).
The booms are mounted via a 360° powered swing mechanism onto a compact narrow base with a
tight turning circle that ensures excellent manoeuvrability and maximum efficiency.
Automatic braking and audible alarms activated by a tilt sensor help to prevent the operator from
working on unsafe terrain whilst elevated.
A digital control system gives smooth, reliable movement of the platform and maximum reliability in the
harshest environments.
This Operating Manual is applicable to the following machines;
Model
Power Source
HR15 Narrow 2x4
Electric
HR17 Narrow 2x4
Electric

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
4
1.4 GENERAL SPECIFICATION
FEATURE
HR15N
HR17N
MAXIMUM HEIGHT - WORKING
15.50m
50ft 10in
17.0m
56ft 0in
MAXIMUM HEIGHT - PLATFORM
13.50m
44ft 3in
15.0m
49ft 6in
MAXIMUM OUTREACH
9.7m
32ft
MAXIMUM HEIGHT –STOWED
2.00m
6ft 7in
MAXIMUM WIDTH
1.50m
4ft 11in
MAXIMUM LENGTH –STOWED
4.93m
16ft 2in
PLATFORM CAPACITY
225kg (500lbs)
WHEELBASE
1.80m
5ft 11in
TURNING RADIUS
3.5 m
11ft 6in
TURRET ROTATION
3550
TURRET TAIL SWING
0.01m
0ft 1in
TRAVEL SPEED
0-2.2 mph
0-3.5 kph
PLATFORM SIZE
1.50m x 0.85m
4ft 11in x 2ft 9in
BOOMS CONTROLS
Proportional electric
DRIVE CONTROLS
Proportional electric
HYDRAULIC PRESSURE
207bar (Booms) 280bar (Drive)
TYRES
Solid
GRADE-ABILITY
25%
MINIMUM VEHICLE WEIGHT
7250kg
15980lbs
7400kg
16300lbs
MAXIMUM GROUND PRESSURE
0.129 kn/cm2
26900 lbs/ft2
0.132 kn/cm2
27600 lbs/ft2
POWER SOURCE
E (DC Electric) –8 x 6v 350 AH batteries

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
5
1.5 IDENTIFICATION (UK PLATE)
This manufacturer’s plate is attached to the chassis on each machine at the time of
manufacture on every Niftylift. Please ensure all sections have been stamped and are legible.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
6
1.5a IDENTIFICATION (USA PLATE)
This manufacturer’s plate is attached to the chassis on each machine at the time of
manufacture on every Niftylift. Please ensure all sections have been stamped and are legible.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
7
1.6 EC DECLARATION OF CONFORMITY (Typical)

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
8
2Safety
2.1 MANDATORY PRECAUTIONS
When operating your Niftylift, your safety is of utmost concern. In order to fully appreciate all aspects
of the machine’s operation it should be ensured that each operator has READ and fully UNDERSTOOD
the relevant manual covering machine use, maintenance, and servicing. If any doubts exist concerning
any point covered in your manual, contact your local dealer or Niftylift Ltd.
Before using any Niftylift, thoroughly inspect the machine for damage or deformation to any major
components. Likewise, check the control systems for hydraulic leaks, damaged hoses, cable faults, or
loose covers to electrical components. At no time should damaged or faulty equipment be used -
Correct all defects before putting the platform to work. If in doubt, contact your local dealer or Niftylift
Ltd. (details on page 3).
THE MANUFACTURER HAS NO DIRECT CONTROL OVER THE MACHINE
APPLICATION AND USE. THEREFORE CONFORMATION WITH GOOD SAFETY
PRACTICES IS THE RESPONSIBILITY OF THE USER AND THEIR OPERATING
PERSONNEL. FAILURE TO UNDERSTAND AND FOLLOW ALL SAFETY RULES
COULD RESULT IN SERIOUS INJURY OR DEATH.
2.1.1 Only trained persons will be permitted to operate the Niftylift.
2.1.2 Always operate the Niftylift in full accordance with the manufacturer’s Operating & Safety Instructions
for that model.
2.1.3 Before use each day and at the beginning of each shift the Niftylift shall be given a visual inspection
and functional test including, but not limited to, operating and emergency controls, safety devices,
personal protective clothing, including fall protection, air, hydraulic and fuel system leaks, cables and
wiring harness, loose or missing parts, tyres and wheels, placards, warnings, control markings and
Operating and Safety Manuals, guards and guard rail systems, and all other items specified by the
manufacturer.
2.1.4 Any problems or malfunctions that affect operational safety must be repaired prior to use of the
platform, with specific regard to any safety components (refer to the Parts Manual for part numbers
and details). If in doubt, contact Niftylift Ltd. (details on page 3). Ensure wheels are chocked before
carrying out any maintenance that involves gearbox disengagement as described in
Section 4.7.2
2.1.5 Always ensure that all warning labels, instructions, placards, control markings, and Safety Manuals are
intact and clearly legible. If replacements are required contact your local dealer or Niftylift Ltd. Always
observe and obey safety and operating instructions on such labels.
2.1.6 Do not alter, modify, or disable in any way the controls, safety devices, interlocks, or any other part of
the Niftylift.
2.1.7 Before the Niftylift is used and during use the user shall check the area in which it is to be used for
possible hazards such as, but not limited to, uneven ground, drop-offs, holes, bumps, obstructions,
debris, floor and overhead obstructions, high voltage conductors, wind and weather, unauthorised
persons, and any other possibly hazardous conditions.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
9
2.1.8 This Niftylift contains several hazardous substances such as, but not limited to, battery acid and
hydraulic fluid.
2.1.9 Covers and canopies should remain closed when the Niftylift is in operation. Only trained personnel
should carry out maintenance on the Niftylift, ensuring at all times they protect themselves from
electrical, heat, and mechanical hazards.
2.1.10 Never exceed the maximum platform capacity, as indicated on the decals and machine serial plate.
2.1.11 Only operate the Niftylift on a firm, level surface.
2.1.12 Never position any part of the Niftylift inside the Minimum approach distances (MAD) to above-
ground electrical conductors as listed in the table below. (Reference ISO 18893:2014).
Voltage range (kV)
MAD (m)
<0.7
1
≥0.7 to 7
1.2
>7 to 50
3
>50 to 220
4
>220 to 500
5
>500 to 750
10
>750 to 1000
13
>1000 to 1250
16
THIS MACHINE IS NOT INSULATED.
If in doubt, contact the local appropriate governing authority.
2.1.13 On entering the platform ensure that the drop down entry bar is closed afterwards.
2.1.14 Use of an approved safety belt and lanyard, hard hat, and appropriate safety clothing is mandatory.
Fasten harness to designated harness securing points within the platform and do not remove until
leaving the platform whilst in the stowed position.
2.1.15 Always remain standing within the platform. Do not sit, stand, or climb on the guard
rail, mid rail, boom linkage, or any other object to attempt to increase your height or
reach. KEEP YOUR FEET ON THE PLATFORM FLOOR. The use of planks, ladders,
or any other devices on the Niftylift for achieving additional height or reach shall be
prohibited.
2.1.16 Do not use the platform levelling system to artificially increase the outreach of the platform.
2.1.17 Do not use the platform to lift overhanging or bulky items that may exceed the maximum capacity or
objects that may increase the wind loading on the platform e.g. notice boards etc.
2.1.18 The Niftylift shall not be operated from a position on trucks, trailers, railway cars, floating vessels,
scaffolds, or similar equipment unless the application is approved in writing by Niftylift Ltd. in Great
Britain.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
10
2.1.19 Always check that the area below and around the platform is clear of personnel and obstructions
before lowering or slewing. Care should be taken when slewing out into areas where there may be
passing traffic. Use barriers to control traffic flow or prevent access to the machine.
2.1.20 Stunt driving and horseplay on or around the Niftylift shall not be permitted.
2.1.21 Where other moving equipment or vehicles are present, special precautions shall be taken to comply
with local ordinances or safety standards established for the work place. Warnings such as but not
limited to flags, roped-off areas, flashing lights, and barricades shall be used.
2.1.22 Before and during driving while the platform is elevated, the operator shall maintain a clear view of the
path of travel and maintain a safe distance from obstacles, debris, drop-offs, holes, depressions,
ramps, and other hazards to ensure safe elevated travel. Maintain a safe distance from overhead
obstacles.
2.1.23 Under all travel conditions the operator shall limit travel speed according to conditions of ground
surface, congestion, visibility, slope, location of personnel, and other factors causing hazards of
collision or injury to personnel.
2.1.24 The Niftylift shall not be driven on grades, side slopes, or ramps exceeding those for which it is rated
by the manufacturer.
2.1.25 It shall be the responsibility of the user to determine the hazard classification of any particular
atmosphere or location. Aerial platforms operated in hazardous locations shall be approved and
suitable for the duty (see ANSI/NFPA 505 where applicable).
2.1.26 The operator shall immediately report to his supervisor any potentially hazardous location(s)
(environment) which become evident during operation.
2.1.27 If an operator encounters any suspected malfunction of the Niftylift or any hazard or potentially unsafe
condition relating to capacity, intended use, or safe operation,theyshall cease operation of the Niftylift
and request further information as to safe operation from his management, or owner, dealer or
manufacturer before further operation of the Niftylift.
2.1.28 The operator shall report to his superior immediately any problems or malfunctions that become
evident during operation of the Niftylift. Any problems or malfunctions that affect the safety of
operation shall be repaired prior to continued use.
2.1.29 The boom and platform of the Niftylift shall not be used to jack the wheels off the ground.
2.1.30 The Niftylift shall not be used as a crane.
2.1.31 The Niftylift shall not be positioned against another object to steady the platform.
2.1.32 Care should be taken to prevent rope, electric cords, or hoses from becoming entangled in the aerial
platform.
2.1.33 Batteries shall be recharged in a well-ventilated area free of flame, sparks, or other sources of ignition
that may cause explosion. Highly explosive hydrogen gas is produced during the charging process.
2.1.34 When checking electrolyte levels, great care should be taken to protect eyes, skin, and clothing. Battery
acid is highly corrosive and the use of protective glasses and clothing is recommended.
2.1.35 If the platform or elevating assembly becomes caught, snagged, or otherwise prevented from normal
motion by an adjacent structure or other obstacle such that control reversal does not free the platform,
all personnel shall be removed from the platform safely before attempts are made to free the platform
using ground controls.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
11
2.1.36 When the machine is not in use, always stow the booms correctly. NEVER LEAVE
THE KEYS IN THE MACHINE if it is to be left for any period of time. Use wheel
chocks if leaving on an incline.
2.1.37 The engine must be shut down while fuel tanks are being filled. Fuelling must be done in a well-
ventilated area free of flame, sparks, or any other sources of ignition that may cause fire or explosion.
PETROL (GASOLINE), LIQUID PROPANE, AND DIESEL FUELS ARE FLAMMABLE.
2.1.38 NEVER START THE NIFTYLIFT IF YOU SMELL PETROL (GASOLINE), LIQUID
PROPANE, OR DIESEL FUEL. THESE FUELS ARE HIGHLY FLAMMABLE
2.1.39 The operator shall implement means provided to protect against use by unauthorised persons.
2.1.40 Never remove anything from the Niftylift that may affect the stability of the machine such as, but not
limited to, batteries, covers, engines, tyres, or ballast.
2.2 ENVIRONMENTAL LIMITATIONS
Unless specifically configured otherwise, the machine will have a short operational time in extreme
temperatures such as in freezers or cold storage, due to reduced battery performance. For electrical
cables and components, the temperature must be within the range -5°C to 60°C.
The recommended operational range for these machines is - 5°C to +40°C. Please contact
Niftylift Ltd. for special considerations if the machine is required to operate outside these
temperatures.
Extended operation in dusty environments is not recommended and frequent cleaning will be
necessary. All dust, dirt, salt encrustation, and excess oil and grease should be removed. Deposits of
paint or bitumen, particularly on legends or labels should be removed.
All standard Niftylift machines are rated for a wind speed of 12.5 m/s, which equates to 45kph / 28mph
or force 6 on the Beaufort scale. No attempt should be made to operate a Niftylift in wind strengths
above this limit and if the operator has any doubts over the wind speed they should cease operation
immediately until it can be established that the wind speed has fallen to a safe level.
DO NOT USE THE NIFTYLIFT IN ELECTRICAL STORMS

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
12
2.3 NOISE AND VIBRATION
The airborne noise emission on the Height Rider range of machines does not exceed 79dB(A),
measured at a perpendicular distance of 4m, under equivalent continuous A-weighted sound pressure
test conditions. This was based on a diesel powered machine working on high throttle and under load.
All other models will exhibit significantly lower emissions than this figure, dependant on power option.
In normal operation the vibration level to which the operator is subjected will not exceed a weighted
root mean square acceleration value of 2.5 m/s².
2.4 TEST REPORT
All Niftylift machine models are subjected to a comprehensive ‘type test’ which duplicates all
combinations of safe working load (SWL), overload, windage, inertia, and pull force to assess the
various safe stability criteria. Self-propelled machines are also subjected to kerb and braking tests at
the SWL to satisfy additional ‘worst case’ stability requirements.
Each individual machine is then subjected to static overload tests on flat level ground with 150% of the
SWL, exceeding the requirements of EN280 for power operated MEWPs. Self-propelled machines are
also tested at the maximum working angle plus 0.5° with a test load of 125% of the SWL. Finally, on all
machines, a functional test is performed with 110% of SWL.
All safety devices are checked for correct operation, operating speeds are checked against benchmark
figures, and the dynamic functions are checked to ensure that all acceleration and deceleration forces
are within acceptable limits. All noted defects are rectified and recorded before the machine is
permitted to enter into service.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
13
3Preparation and Inspection
3.1 UNPACKING
Since the manufacturer has no direct control over the shipping or carriage of any Niftylift, it is the
responsibility of the dealer and/or owner and/or lessee to ensure that the Niftylift has not been
damaged in transit and that a Pre-operational Report has been carried out by a qualified engineer
before it is put into service.
1) Remove all ropes, straps, and/or chains used to secure the aerial platform during transit.
2) Ensure any ramp, loading dock, or forklift used is capable of supporting or lifting the Niftylift.
3) If the Niftylift is to be driven off transport, please ensure that the operator has read and fully
understood this entire manual. Refer to the appropriate section for precise operating instructions.
***Carry out the Pre-operational Report before placing machine in service (Section 6.3).
3.2 PREPARATION FOR USE
Whilst every effort has been made at the Niftylift factory to ensure your machine arrives in a safe and
operable condition, it is necessary to carry out a systematic inspection prior to putting the Niftylift into
service.
THIS IS NOT A REQUEST IT IS MANDATORY
To assist the user in this task you will find enclosed a Pre-operational Report, which must be filled out
upon delivery/receipt of the machine.
Before the user carries out the Pre-operational Report they must have read and fully understood all the
contents of the Operating, Safety and Maintenance Manual.
WARNING - DO NOT OPERATE A POTENTIALLY DEFECTIVE OR
MALFUNCTIONING MACHINE. CORRECT AND REPAIR ANY DEFECTS BEFORE
OPERATING YOUR NIFTYLIFT.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
14
3.3 PRE-OPERATIONAL SAFETY CHECK SCHEDULES
Before use each day and at the beginning of each shift the aerial platform shall be given a visual
inspection and functional test including, but not limited to, the following: It is recommended that these
be performed at regular intervals as indicated on each checklist.
3.3.1 DAILY SAFETY CHECKS
1) Check that all labels (decals) are in place and legible.
2) Visually inspect the machine for damaged or loose components.
3) Check that batteries are charged (Refer to Section 4.6 for further information).
4) Check the fuel level (if applicable).
5) Check that canopies/covers and guards are in place and secure.
6) Check that the boom rest switch is operable (if applicable).
7) Check that control levers are secure and operate freely.
8) Check that operating buttons and emergency stop buttons function correctly.
9) Check the operation of the manual hand pump.
10) Visually inspect all hydraulic hoses and fittings for damage or leaks.
11) Check that the platform pivot pins and their tag bolts are secure.
12) Check that the tilt alarm is functioning correctly (On a slope of 3.00or more the alarm should
sound and drive should be disabled).
13) Check the operation of SiOPS (Refer to Section 4.3.5).
14) Check the operation of the cage weigh system (If fitted).
3.3.2 WEEKLY SAFETY CHECKS
1) Inspect tyres and wheels for damage and wear.
2) Check that the joystick manipulators are secure.
3) Check battery fluid levels and specific gravity (after charging) and general condition.
4) Check hydraulic oil level, ISO Grade 22 (Europe), Grade 32 (Rest of World).
5) Inspect hose track for damage or missing parts.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
15
3.3.3 MONTHLY SAFETY CHECKS
1) Check the engine oil level (if applicable).
2) Check rear wheel nuts are secured (torque 166ft lbs / 225Nm).
3) Check front wheel nuts are secured (torque 110ft lbs / 150Nm).
4) Check that the slew worm is secured and correctly in mesh. Clean and re-grease.
5) Check the track rod linkage.
6) Check telescopic boom wear pads and nylon studs (if applicable).
7) Every Six months perform a thorough examination in accordance with the ‘Lifting Operation
and Lifting Equipment Regulations’ (LOLER) 1998, Regulation (9)(3)(a).
3.3.4 ANNUAL SAFETY CHECKS
1) Check that all pivot pins and their tag bolts are secure.
2) Inspect for any cracks or badly rusted areas on booms and chassis.
3) Change the hydraulic oil filters.
4) Check the bushes in the front wheel hubs for wear.
5) Check that slew ring bolts are secure (torque 205ft lbs. 279Nm).
Toughcage
Niftylift toughcage is fully UV stabilised for outdoor use in the most demanding climates. However, the
user and machine owner should consider the following;
Discolouration of the material may occur; this is a natural aging process which does not
significantly alter the material properties.
Degredation to the floor may occur as a consequence of product use and effect of UV exposure.
The toughcage’s multi-layer construction means degradation of the top surface may occur over
time without compromising the structural strength of the internal and base layers.
The rate at which the toughcage floor ages is dependant upon the machines application and its
country of use (Typical levels of UV exposure). Refer to table below for aging rate applicable to your
specific area.
UK, NETHERLANDS, GERMANY, POLAND, SCANDINAVIA, CANADA, RUSSIA
14 years
FRANCE, ITALY, USA (NORTH EAST STATES)
11 years
SPAIN, GREECE, TURKEY, CHINA, USA (MID WEST STATES), AUSTRALIA (TASMANIA)
9.5 years
MALAYSIA, INDONESIA
8 years

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
16
USA (SOUTH STATES), SOUTH AMERICA, AUSTRALIA (VICTORIA, NEW SOUTH WALES)
7.5 years
USA (WEST STATES), SOUTH AFRICA, INDIA, PAKISTAN, IRAN, AUSTRALIA (WESTERN,
SOUTH, QUEENSLAND)
7 years
NORTH AFRICA, SAUDI, DUBAI, AUSTRALIA (NORTHERN TERRITORY)
6 years
Note: The date of manufacture of the toughcage floor is located on its underside.
Niftylift recommends that the user and machine owner regularly inspect the toughcage floor for
damage. If any significant damage is found then the floor must be replaced. For further guidance
please contact Niftylift Limited.

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
17
3.4 PLACARD, DECALS & INSTALLATION (UK SPEC)
ITEM
DESCRIPTION
NUMBER
QTY
1
Serial Plate
P15383
1
2
Point Load, HR15N - 44kN
HR17N - 46.5kN
P27316
P27317
4
4
3
Travel Direction
P27047
1
4
Travel Direction (Large)
P27048
1
5
No Step
P14785
2
6
Battery Isolator
P18600
1
7
Logo 'HR15N'
'HR17N'
P26431
P26433
2
2
8
General Crush Hazard
P14782
4
9
Gearbox Disengage
P18811
2
10
Base Levers
P25066
1
11
Emergency Controls
P21700
1
12
IPAF ‘Are You Trained?’
P22055
2
13
Read Manual
P14892
2
14
If E-Stop Disabled
P14864
2
15
Manual Descent
P23035
1
16
Level Sensor testing
P23801
1
17
Emergency Controls Location
P22877
1
18
Base Control Box
P26612
1
19
Tie Down Points
P14958
2
20
Raise flyboom
P19442
1
21
General Warning
P24900
1
22
“Niftylift.com”
P14389
1
23
Safe Working Load (SWL)
P17328
1
24
Footswitch Disabled
P14884
1
25
Harness Point
P14883
2
26
Cage Gate Warning
P18335
1
27
Clunk Click
P19961
2
28
Do Not Place Objects On Controls
P21511
1
29
‘Fitted with SiOPS’
P22820
1
31
Cage Controls
P27368
1
34
Cage Tie-Down Warning
P21404
2
35
Hydraulic Oil
Low Temperature Bio Oil
P14415
P23622
1
1
36
Daily Safety Checks
P14908
1
37
Hazard Tape
N/A
N/A
38
Battery Drain
P19850
1
39
Warning - Tank Pressure
P16365
1
40
Charger Point - 230V
P26863
1

Height Rider/SP Series
Operating & Safety Instructions
English/USA –05/15
Original instructions
18
41
Charger Point - 110V
P26424
1
42
Power to Cage - 110V
P26426
2
43
Power to Cage - 230V
P26862
2
44
Rotary machinery
P15010
2
45
Auxiliary Descent
P25067
1
