SP64
Operating & Safety Instructions
MODEL SP64 SERIES
(4x4)
M50408/02
Niftylift Limited
1525 S.Buncombe Road
Greer
SC 29651
USA
www.niftylift.com
e-mail: [e-mail]
Tel: [phone]
Fax: [phone]
SP64

SP Series
Operating & Safety Instructions
USA – 12/12
1
Table of Contents
1INTRODUCTION AND GENERAL INFORMATION PAGE
1.1 Foreword 2
1.2 Severity of Hazards 2
1.3 Scope 3
1.4 Introducing the Self Propelled (SP) Series 3
1.5 General Specification 4
1.6 Identification 5
1.7 EC Declaration of Conformity (Typical) 6
2 SAFETY
2.1 Mandatory Precautions 7-9
2.2 Environmental Limitations 10
2.3 Noise & Vibration 10
2.4 Test Report 11
3 PREPARATION AND INSPECTION
3.1 Unpacking 12
3.2 Preparation for Use 12
3.3 Pre-Operational Safety Check Schedules 13-15
3.4 Placard, Decals and Installation 16-17
3.5 Torque Requirements 18
4 OPERATION
4.1 Control Circuit Components 19-20
4.2 Ground Control Operation 21-22
4.3 Basket Control Operation 23-25
4.4 Driving Controls 26
4.5 Basket Weigh System (If Fitted) 27
4.6 Transporting, Craneage, Storage and Setting to Work 28-30
5 EMERGENCY CONTROLS
5.1 General 31
5.2 Emergency Procedures - Incapacitated Operator 31
5.3 Emergency Procedures - Niftylift Failure 31
5.4 Boom Controls 32
5.5 Towing 33-34
5.6 Incident Notification 34
6 RESPONSIBILITIES
6.1 Changes in Ownership 34
6.2 Manual of Responsibilities (USA only) 34
6.3 Inspection/ Service Check List 35-36

SP Series
Operating & Safety Instructions
USA – 12/12
2
1 Introduction and General Information
1.1 FOREWORD
The purpose of this manual is to provide the customer with safety, operating and maintenance
instructions essential for proper Niftylift operation.
This manual should be READ and fully UNDERSTOOD before any attempt is made to operate
the Niftylift!
Niftylift has no direct control over the Niftylift’s application and use, therefore conformance with good
safety practices is the responsibility of the user and his operating personnel.
These manuals are very important tools - Keep them with the Niftylift at all times.
All information in these manuals is based on the use of the Niftylift under proper operating conditions.
Alteration and/or modification of the Niftylift are STRICTLY FORBIDDEN.
Remember: Any equipment is only as safe as those who operate it!
1.2 SEVERITY OF HAZARDS
The use of this type of equipment presents certain dangers to the operator which are clearly identified
both in this manual and on the Niftylift. The varying levels of risk are defined as follows:
DANGER
If not correctly followed there is a high probability of serious injury or death to personnel.
WARNING or CAUTION
If not correctly followed there is some possibility of serious injury or death to personnel.
The 'Safety Alert Symbol' is used to call attention to potential hazards
which may lead to serious injury or death, if ignored.
IMPORTANT and INSTRUCTIONS
This denotes procedures essential to safe operation and prevention of damage to, or destruction of the
Niftylift.
NOTICE
This indicates general safety rules and/or procedures relating to the Niftylift.
It is the owner’s/user’s responsibility to know and comply with all applicable rules,
regulations, laws, codes and any other requirements applicable to the safe use of this
equipment.

SP Series
Operating & Safety Instructions
USA – 12/12
3
1.3 SCOPE
These operating instructions contain all the necessary information required to allow the safe operation
of any Niftylift SP64, with a diesel (D) engine.
For further technical information, circuit diagrams and specific instructions for all maintenance which
may need to be carried out by specialist trained personnel, see the associated Workshop and Parts
manual for your model of Niftylift Height Rider.
1.4 INTRODUCING THE SP SELF-PROPELLED SERIES
Please note at the time of going to press all information, illustrations, details and descriptions contained
herein are valid. Niftylift reserves the right to change, modify or improve its products without any
obligations to install them on previously manufactured Niftylifts.
If, after reading this manual you require further information, please do not hesitate to contact us.
Niftylift Inc, 1525 S. Buncombe Road, Greer, SC 29651 USA
Tel: [phone] Fax: [phone] Email: [e-mail]
Driven from the basket, the Niftylift SP64 is an extremely versatile articulated boom platform of unique
and simple design. It is capable of placing two men and their tools up to a height of 67ft 9in or an
outreach of 41ft 4in.
The compact narrow base and tight turning circle, combined with powered boom rotation, up and over
capability, good outreach, combined with sensitive controls, ensure excellent manoeuvrability and
maximum efficiency.
High traction tires and powerful hydraulic wheel motors give unsurpassed performance with the option
of fast drive speed when the booms are in the stowed position. Automatic braking and audible alarms
activated by a five-degree tilt sensor help to prevent the operator from working on unsafe terrain whilst
elevated.
The Niftylift SP64 provides a fast, safe, cost effective method of access, both inside and out, for a
multitude of applications where overhead working is required.
Models include the following:
D: - DIESEL

SP Series
Operating & Safety Instructions
USA – 12/12
4
1.5 GENERAL SPECIFICATION
FEATURE SP64
MAXIMUM HEIGHT - WORKING 67ft 9in
MAXIMUM HEIGHT - PLATFORM 61ft 4in
MAXIMUM OUTREACH 41ft 4in
MAXIMUM HEIGHT – STOWED 7ft
MAXIMUM WIDTH 7ft 5in
MAXIMUM LENGTH – STOWED 16ft 5in
PLATFORM CAPACITY - Europe 500lbs
WHEELBASE 7ft 6in
TURNING RADIUS – OUTSIDE 13ft
TURRET ROTATION 3550
TURRET TAIL SWING 1ft 7in
TRAVEL SPEED 0-4.1mph
PLATFORM SIZE 5ft 11in x 2ft 2in
CONTROLS Proportional electric over hydraulic
HYDRAULIC PRESSURE 2900psi
TIRES Solid
GRADE-ABILITY 45%
MINIMUM VEHICLE WEIGHT 13,700lb
MAXIMUM GROUND PRESSURE 21,951lb/ft2
POWER SOURCE D (Diesel) models - Kubota 1505 (4x4)

SP Series
Operating & Safety Instructions
USA – 12/12
5
1.6 IDENTIFICATION (USA PLATE)
This manufacturer’s plate is attached to Boom 1 on each Niftylift at the time of
manufacture on every Niftylift. Please ensure all sections have been stamped and are
legible.

SP Series
Operating & Safety Instructions
USA – 12/12
6
1.7 EC DECLARATION OF CONFORMITY (Typical)

SP Series
Operating & Safety Instructions
USA – 12/12
7
2 Safety
2.1 MANDATORY PRECAUTIONS
When operating your Niftylift, your safety is of utmost concern. In order to fully appreciate all aspects
of the Niftylifts operation it should be ensured that each operator has READ and fully UNDERSTOOD
the relevant manual covering Niftylift use, maintenance and servicing. If any doubts exist concerning
any points covered in your manual, contact your local dealer or Niftylift Ltd.
Before using any Niftylift, thoroughly inspect the Niftylift for damage or deformation to all major
components. Likewise, check the control systems for hydraulic leaks, damaged hoses, cable faults or
loose covers to electrical components. At no time should damaged or faulty equipment be used -
Correct all defects before putting the platform to work. If in doubt, contact your local dealer or Niftylift
Ltd (see front cover for address).
THE MANUFACTURER HAS NO DIRECT CONTROL OVER THE NIFTYLIFT
APPLICATION AND USE. THEREFORE CONFORMATION WITH GOOD SAFETY
PRACTICES IS THE RESPONSIBILITY OF THE USER AND HIS OPERATING
PERSONNEL. FAILURE TO UNDERSTAND AND FOLLOW ALL SAFETY RULES
COULD RESULT IN SERIOUS INJURY OR DEATH.
2.1.1 Only trained persons will be permitted to operate the Niftylift.
2.1.2 Always operate the Niftylift in full accordance with the manufacturers Operating & Safety Instructions
for that model.
2.1.3 Before use each day and at the beginning of each shift the Niftylift shall be given a visual inspection
and functional test including, but not limited to, operating and emergency controls, safety devices,
personal protective clothing, including fall protection, air, hydraulic and fuel system leaks, cables and
wiring harness, loose or missing parts, tires and wheels, placards, warnings, control markings and
Operating and Safety Manuals, guards and guard rail systems and all other items specified by the
manufacturer.
2.1.4 Any problems or malfunctions that affect operational safety must be repaired prior to use of the
platform, with specific regard to any safety components refer to the Parts Manual for part numbers and
details. If in doubt, contact Niftylift Ltd (Details on page 3). Ensure wheels are chocked before
carrying out any maintenance that involves a bypass of parking brakes as described in
Section 5.6.
2.1.5 Always ensure that all warning labels, instructions, placards, control markings and Safety Manuals are
intact and clearly legible. If replacements are required contact your local dealer or Niftylift. Always
observe and obey safety and operating instructions on such labels.
2.1.6 Do not alter, modify or disable in any way the controls, safety devices, interlocks or any other part of
the Niftylift.
2.1.7 Before the Niftylift is used and during use the user shall check the area in which it is to be used for
possible hazards such as, but not limited to, uneven ground drop-offs, holes, bumps, obstructions,
debris, floor and overhead obstructions, high voltage conductors, wind and weather, unauthorised
persons and any other possibly hazardous conditions.
2.1.8 Never exceed the maximum basket capacity, as indicated on the decals and Niftylift serial plate.
2.1.9 Only operate the Niftylift on a firm, level surface.

SP Series
Operating & Safety Instructions
USA – 12/12
8
2.1.10 Never position any part of the Niftylift within 12ft of any electrical power line, conductor or similar not
exceeding 66kV. (Minimum span 125m) Other distances for increased voltages and different spans
are given in NZECP 34:1993.
THIS NIFTYLIFT IS NOT INSULATED.
If in doubt, contact the appropriate authorities
2.1.11 On entering the basket ensure that the drop down entry bar is closed afterwards.
2.1.12 Use of an approved safety belt and lanyard, hard hat and appropriate safety clothing is mandatory.
Fasten harness to designated harness securing points within the platform and do not remove until
leaving the platform whilst in the stowed position.
2.1.13 Always remain standing within the basket. Do not attempt to increase your height
or reach by standing and/or climbing on the basket guard rails or any other object.
KEEP YOUR FEET ON THE BASKET FLOOR. Do not sit, stand or climb on the
guard rail, mid rail or boom linkage. Use of planks, ladders or any other devices
on the Niftylift for achieving additional height or reach shall be prohibited.
2.1.14 Do not use the basket levelling system to artificially increase the outreach of the Niftylift. Never use
boards or ladders in the basket to achieve the same result.
2.1.15 Do not use the basket to lift overhanging or bulky items that may exceed the maximum capacity or
carry objects that may increase the wind loading on the basket. (e.g. Notice boards etc.)
2.1.16 The Niftylift shall not be operated from a position on trucks, trailers, railway cars, floating vessels,
scaffolds or similar equipment unless the application is approved in writing by Niftylift Ltd in Great
Britain.
2.1.17 Always check that the area below and around the platform is clear of personnel and obstructions
before lowering or rotating the booms. Care should be taken when rotating the booms out into areas
where there may be passing traffic. Use barriers to control traffic flow or prevent access to the Niftylift.
2.1.18 Stunt driving and horseplay, on or around the Niftylift, shall not be permitted.
2.1.19 When other moving equipment and vehicles are present, special precautions shall be taken to comply
with local ordinances or safety standards established for the work place. Warnings such as, but not
limited to, flags, roped off areas, flashing lights and barricades shall be used.
2.1.20 Before and during driving while the basket is elevated the operator shall maintain a clear view of the
path of travel, maintain a safe distance from obstacles, debris, drop offs, holes, depressions, ramps
and other hazards to ensure safe elevated travel. Maintain a safe distance from overhead obstacles.
2.1.21 Under all travel conditions the operator shall limit travel speed according to conditions of ground
surface, congestion, visibility, slope, location of personnel and other factors causing hazards of
collision or injury to personnel.
2.1.22 The Niftylift shall not be driven on grades, side slopes or ramps exceeding those for which the aerial
platform is rated by the manufacturer.

SP Series
Operating & Safety Instructions
USA – 12/12
9
2.1.23 It shall be the responsibility of the user to determine the hazard classification of any particular
atmosphere or location. Aerial platforms operated in hazardous locations shall be approved and
suitable for the duty. (See ANSI/NFPA 505-1987 where applicable).
2.1.24 The operator shall immediately report to his supervisor any potentially hazardous location(s)
(environment) which become evident during operation.
2.1.25 If an operator encounters any suspected malfunction of the Niftylift or any hazard or potentially unsafe
condition relating to capacity, intended use or safe operation, he shall cease operation of the Niftylift
and request further information as to safe operation from his management, or owner, dealer or
manufacturer before further operation of the Niftylift.
2.1.26 The operator shall immediately report to his superior any problems or malfunctions of the Niftylift,
which becomes evident during operation. Any problems or malfunctions that affect the safety of
operation shall be repaired prior to continued use.
2.1.27 The boom and basket of the Niftylift shall not be used to jack the wheels off the ground.
2.1.28 The Niftylift shall not be used as a crane.
2.1.29 The Niftylift shall not be positioned against another object to steady the platform.
2.1.30 Care should be taken to prevent rope, electric cords and hoses from becoming entangled in the aerial
platform.
2.1.31 Batteries shall be recharged in a well-ventilated area free of flame, sparks or other hazards, which may
cause explosion. Highly explosive hydrogen gas is produced during the charging process.
2.1.32 When checking electrolyte levels great care should be taken to protect eyes, skin and clothing. Battery
acid is highly corrosive and protective glasses and clothing is recommended.
2.1.33 If the basket or elevating assembly becomes caught, snagged or otherwise prevented from normal
motion by adjacent structure or other obstacles, such that control reversal does not free the Niftylift, all
personnel shall be removed from the basket safely before attempts are made to free the Niftylift using
ground controls.
2.1.34
When the Niftylift is not in use always stow the booms correctly. NEVER
LEAVE THE KEYS IN THE NIFTYLIFT,if it is to be left for any period of
time. Use wheel chocks if leaving on an incline.
2.1.35 The engine must be shut down while fuel tanks are being filled. Fuelling must be done in a well-
ventilated area free of flame, sparks or any other hazard that may cause fire or explosion. GASOLINE,
LIQUID PROPANE AND DIESEL FUELS ARE FLAMMABLE.
2.1.36
NEVER START THE NIFTYLIFT IF YOU SMELL GASOLINE, LIQUID PROPANE
OR DIESEL FUEL. THESE FUELS ARE HIGHLY FLAMMABLE
2.1.37 The operator shall implement means provided to protect against use by unauthorised persons.
2.1.38 Never remove anything that may affect the stability of the Niftylift such as, but not limited to,
batteries, covers, engines, tires or ballast.

SP Series
Operating & Safety Instructions
USA – 12/12
10
2.2 ENVIRONMENTAL LIMITATIONS
Unless specifically configured otherwise, the Niftylift will have a short operational time in extreme
temperatures such as freezers and cold storage, due to reduced battery performance. For electrical
cables and components, the temperature must be within the range -5°C to 60°C.
The Niftylift is limited in high temperatures because of the cooling requirement for engines and
hydraulic oil. Coolant temperatures must be within the range -37°C to 110°C (at 50% mixture of water
to anti-freeze). Oil temperature not to exceed –23°C to 93°C.
The recommended operational range for these Niftylifts is - 5°C to +40°C. Please contact
Niftylift Ltd for special considerations if the Niftylift is required to operate outside these
temperatures.
Extended operation in dusty environments is not recommended, frequent cleaning will be necessary. All
dust, dirt, salt encrustation, excess oil or grease should be removed. Deposits of paint or bitumen,
particularly on legends or labels should be removed.
All standard Niftylifts are rated for a wind speed of 28mph or force 6 on the Beaufort scale. No attempt
should be made to operate a Niftylift in wind strengths above this limit and if the operator has any
doubts over the wind speed he / she should cease operation immediately until it can be established that
the wind speed has fallen to a safe level.
DO NOT USE THE NIFTYLIFT IN ELECTRICAL STORMS
2.3 NOISE AND VIBRATION
The airborne noise emission on the Height Rider range of Niftylift’s does not exceed 79dB(A),
measured at a perpendicular distance of 13ft, under equivalent continuous A-weighted sound pressure
test conditions. This was based on a Diesel powered Niftylift, working on high throttle, and under load.
All other models will exhibit significantly lower emissions than this figure, dependant on power option.
In normal operation the Vibration level to which the operator is subjected will not exceed a weighted
root mean square acceleration value of 2.5 m/s2.

SP Series
Operating & Safety Instructions
USA – 12/12
11
2.4 TEST REPORT
All Niftylift models are subjected to a comprehensive ‘type test’ which duplicates all combinations of
safe working load (SWL), overload, windage, inertia and pull force to assess the various safe stability
criteria. Self propelled Niftylifts are also subjected to kerb and braking tests at the SWL to satisfy
additional ‘worse case’ stability requirements.
Each individual Niftylift is then subjected to static overload tests on flat level ground with 150% of the
SWL, exceeding the requirements of EN280 for power operated MEWPs. Self propelled Niftylifts are
also tested at the maximum working angle plus 0.5º with a test load of 125% of the SWL. Finally, on all
Niftylifts, a functional test is performed with 110% of SWL.
All safety devices are checked for correct operation, operating speeds are checked against benchmark
figures and the dynamic functions ensure that all acceleration and deceleration forces are within
acceptable limits. All noted defects are rectified and recorded before the Niftylift is permitted to enter
into service.

SP Series
Operating & Safety Instructions
USA – 12/12
12
3 Preparation and Inspection
3.1 UNPACKING
Since the manufacturer has no direct control over the shipping or carriage of any Niftylift it is the
responsibility of the dealer and/or owner and/or lessee to ensure the Niftylift has not been damaged in
transit and a Pre-operational Report has been carried out by a qualified engineer before the aerial
platform is put into service.
A) Remove all ropes, straps and or chains used to secure the aerial platform during transit.
B) Ensure any ramp, loading dock or forklift used is capable of supporting or lifting the Niftylift.
C) If the Niftylift is to be driven off, please ensure that the operator has read and fully understood
this entire manual. Refer to the appropriate section for precise operating instructions.
***Carry out the Pre-operational Report before placing Niftylift in service.
3.2 PREPARATION FOR USE
Whilst every effort has been made at the Niftylift factory to ensure your Niftylift arrives in a safe and
operable condition it is necessary to carry out a systematic inspection prior to putting the aerial
platform into service.
THIS IS NOT A REQUEST IT IS MANDATORY
To assist the user in this task you will find enclosed a Pre-operational Report, which must be filled out
upon delivery/receipt of the Niftylift.
Before the user carries out the Pre-operational Report he must have read and fully understood all the
contents of the Operating, Safety and Maintenance Manual.
WARNING - DO NOT OPERATE A POTENTIALLY DEFECTIVE OR
MALFUNCTIONING NIFTYLIFT. CORRECT AND REPAIR ANY DEFECTS
BEFORE OPERATING YOUR NIFTYLIFT.

SP Series
Operating & Safety Instructions
USA – 12/12
13
3.3 PRE-OPERATIONAL SAFETY CHECK SCHEDULES
Before use each day and at the beginning of each shift the aerial platform shall be given a visual
inspection and functional test including, but not limited to, the following:
3.3.1 DAILY SAFETY CHECKS
1) Check that all labels (decals) are in place and legible.
2) Visually inspect the Niftylift for damaged or loose components.
3) Check the fuel level (if applicable).
4) Check that canopies/covers and guards are in place and secure.
5) Check that the boom rest switch is operable (if applicable).
6) Check that control levers are secure and operate freely.
7) Check that operating buttons and emergency stop buttons function properly.
8) Check the operation of the manual hand pump.
9) Visually inspect all hydraulic hoses and fittings for damage or leaks.
10) Check that the basket pivot pins and their tag bolts are secure.
11) Check that the tilt alarm is functioning properly (On a slope of 50or more the alarm should
sound and drive should be disabled).
12) Check the operation of the basket weigh system (If fitted). See section 4.5.3 for testing and
verification procedure.
3.3.2 WEEKLY SAFETY CHECKS
1) Inspect tires and wheels for damage and wear.
2) Check that the joystick is secure.
3) Check battery fluid levels and specific gravity (after charging) and general condition.
4) Check hydraulic oil level, Grade 32.
5) Inspect the engine air filter and clean or replace if necessary.
6) Inspect hose track for damage or missing parts.

SP Series
Operating & Safety Instructions
USA – 12/12
14
3.3.3 MONTHLY SAFETY CHECKS
1) Check the engine oil level (if applicable).
2) Check the wheel nuts (torque 110ft lbs / 150Nm).
3) Check that the bolts holding the wheel motors to the chassis are secure.
4) Check that the boom rotation gear worm is secured and correctly in mesh. Clean and re-grease.
6) Inspect the engine fuel tank for damage or leaks.
7) Check telescopic boom wear pads and nylon studs (if applicable).
8) Check and adjust if necessary the Nylatron studs around the telescope boom.
9) If fitted, every three months check and verify the calibration of the basket weigh system. See
section 4.5.4 for the calibration procedure.
10) Every Six months perform a thorough examination in accordance with the ‘Lifting Operation
and Lifting Equipment Regulations’ (LOLER) 1998, Regulation (9)(3)(a).
3.3.4 ANNUAL SAFETY CHECKS
1) Check that all pivot pins and their tag bolts are secure.
2) Inspect for any cracks or badly rusted areas on booms and chassis.
3) Change the hydraulic oil filters.
4) Check the bushes in the front wheel hubs for wear.
5) Check that boom rotation gear ring bolts are secure (torque 220ft lbs. 300Nm).
Toughcage
Niftylift toughcage is fully UV stabilised for outdoor use in the most demanding climates. However, the
user and Niftylift owner should consider the following;
•Discolouration of the material may occur; this is a natural aging process which does not
significantly alter the material properties.
•Degredation to the floor may occur as a consequence of product use and effect of UV exposure.
The toughcage multi-layer construction means degradation of the top surface may occur over time
without compromising the structural strength of the internal and base layers.
•The rate at which the toughcage floor ages is dependent upon the Niftylifts application and its
country of use (Typical levels of UV exposure). Refer to table below for aging rate applicable to your
specific area.
UK, NETHERLANDS, GERMANY, POLAND, SCANDINAVIA, CANADA, RUSSIA 14 years
FRANCE, ITALY, USA (NORTH EAST STATES) 11 years

SP Series
Operating & Safety Instructions
USA – 12/12
15
SPAIN, GREECE, TURKEY, CHINA, USA (MID WEST STATES), AUSTRALIA (TASMANIA) 9.5 years
MALAYSIA, INDONESIA 8 years
USA (SOUTH STATES), SOUTH AMERICA, AUSTRALIA (VICTORIA, NEW SOUTH WALES) 7.5 years
USA (WEST STATES), SOUTH AFRICA, INDIA, PAKISTAN, IRAN, AUSTRALIA (WESTERN,
SOUTH, QUEENSLAND)
7 years
NORTH AFRICA, SAUDI, DUBIA, AUSTRALIA (NORTHERN TERRITORY) 6 years
Note: The date of manufacture of the toughcage floor is located on its underside.
Niftylift recommends that the user and Niftylift owner regularly inspect the tough basket floor for
damage. If any significant damage is found then the floor must be replaced. For further guidance please
contact Niftylift Limited.

SP Series
Operating & Safety Instructions
USA – 12/12
16
3.4 PLACARD, DECALS & INSTALLATION (USA)
ITEM DESCRIPTION NUMBER QTY
1 “Niftylift.com” P14390 1
2 Harness Point P14883 2
3 Head Protection P14921 1
4 Danger HR & TM’s P18672 2
5 “If E-Stop Disabled P21970 2
6 Hydraulic Oil P14415 1
7 SWL 500 lbs P17328 1
8 Manual Hand Pump P19605 1
9 Daily Safety Check List P14908 1
10 “If Tilt Alarm Sounds” P14868 2
11 Basket Gate Warning P18335 1
12 Hand Crush P14782 5
13 Travel Direction P14784 1
15 Gearbox Disengage P18811 4
16 Oil level indicator P14676 1
17 Tie down point P14958 4
18 Hydraulic Levers -Basket P14020 1
19 Hydraulic Levers – Base P14018 2
20 “4 x 4” P14697 2
21 “SP64” Logo P19070 2
22 Battery drain P19850 1
23 Footswitch P14884 1
24 No Step P14785 2
25 General Notice HR’s P18870 1
26 Basket Button Box P20237 1
28 Diesel P14414 1
30 Operating Instructions P14892 1
31 Noise Warning P17124 1
32 Base Button Box P16752 1
33 Overload Warning P18848 2
34 Component Stability P19708 1
35 Trip – Push to Reset P19056 1
36 Point Loading P15215 4
37 “Raise Flyboom” P19442 1
39 110v Power Inlet P17719 1
40 Chain Inspection P16535 1
41 SP64 Boom Rotation Pin P18587 2
44 Battery Isolator P18600 1

SP Series
Operating & Safety Instructions
USA – 12/12
17

SP Series
Operating & Safety Instructions
USA – 12/12
18
3.5 TORQUE REQUIREMENTS
SCREW QUALITY/SIZE Tightening torque in ft lbs (Nm)
Grade 8.8 10.9
M 6 7.0 (10) 10 (14)
M 8 19 (25) 26 (35)
M 10 36 (49) 51 (69)
M 12 63 (86) 89 (120)
M 14 99 (135) 140 (190)
M 16 155 (210) 218 (295)
M 18 214 (290) 300 (405)
WHEEL NUTS 110ft lbs 150Nm
WHEEL MOTOR NUTS 99ft lbs 135Nm
BOOM ROTATION GEAR RING BOLTS 220ft lbs 300Nm
