Nikon Lite Touch Zoom 100ED User manual

E
F
G
S
Instruction Manual (Pages 2-49)
Manuel d’ulilisation (Pages 50-97)
Bedienungsanleitung (Seiten 98-145)
Manual de instrucciones (Páginas 146-193)

2Getting Started
Thank you for purchasing the Nikon Lite Touch Zoom 100ED / Lite
Touch Zoom 100ED QD camera.
Be sure to read this manual thoroughly before use, and keep it
handy until you feel confident using the camera.
Some of the illustrations show the model with the date function.
Your Nikon camera features:
•Compact, light-weight construction with built-in 2.6X zoom lens
from 38 to 100 mm focal length range. ( p. 21)
•ANikon ED (Extra-low Dispersion) lens with low chromatic
aberration (popularly used as lenses for Nikon single-lens reflex
cameras), as well as two high-contrast, high-resolution
aspherical lenses.
• Automatic backlight compensation to automatically fire the
flash when the subject is backlit. ( p. 32)
•Aviewfinder eyepiece that will not easily become fogged up
even if you breathe on it. ( p. 17)
Symbols used in this manual
:Indicates items to be checked, such as requirements and
restrictions.
:Indicates notes and cautions you are requested to follow.
:Indicates supplementary descriptions.
: Indicates pages for reference.

Getting Started 3
E
Accessories
(The following item is supplied with this camera.)
Optional accessories
•Camera case CS-L23
(Remote control unit can be stored in the pocket inside.)
• Remote control unit ML-L1 ( p. 39)
•Remote control unit case CML-L1
Attaching the strap
Strap
Put your head
through this
loop.
Attach the strap as shown
in the illustration.
Adjust the length using the
lug on the strap.

4Getting Started
Table of Contents
To take a picture right away ___________________________ 6
Camera parts _____________________________________ 8-10
Body _________________________________________ 8-9
LCD panel _____________________________________ 10
Indications in the viewfinder __________________________ 11
1Preparations
Installing a battery __________________________________ 12
Turning the camera on _______________________________ 13
Checking the battery power ___________________________ 13
Loading the film ___________________________________ 14
2Basic Operations
Imprinting the date/time on pictures
(Lite Touch Zoom 100ED QD only) __________________ 16
Adjusting diopter ___________________________________ 17
Holding the camera properly __________________________ 18
Operating the Shutter Release button ___________________ 19
Selecting Regular or Panorama mode
(Lite Touch Zoom 100ED QD only) __________________ 20
Zooming _________________________________________ 21
Shooting _________________________________________ 22
Rewinding the film _________________________________ 24
Removing the film __________________________________ 25

Getting Started 5
E
3Advanced Operations
When the main subject is not in the center of the picture ____ 26
Difficult-to-focus subjects ____________________________ 28
Close-up photography _______________________________ 29
Flash photography __________________________________ 30
To automatically fire the flash ______________________ 32
To cancel flash operation __________________________ 33
To fire the flash intentionally _______________________ 34
To photograph a person in a night view _______________ 35
To reduce the "Red-eye" effect ______________________ 36
Using the self-timer _________________________________ 38
Using the remote control (optional) ____________________ 39
Shooting a distant view or landscape through a window _____ 40
4Additional Information
Correcting the date and time
(Lite Touch Zoom 100ED QD only) __________________ 41
Troubleshooting ____________________________________ 42
Camera care tips ___________________________________ 44
Specifications _____________________________________ 46
For safe handling of the camera _______________________ 48

6Getting Started
To take a picture right away
Quick operation guide
If you wish to use this camera immediately, proceed as follows:
For details see the pages indicated for reference.
1.
Insert a battery. ( p. 12)
2.
Turn the camera on. (p. 13)
3.
Load film. ( pp. 14, 15)
4.
Select Regular or Panorama mode (Lite Touch
Zoom 100ED QD only). (p. 20)

Getting Started 7
E
5.
Press the Zoom button and compose your
picture. (p. 21)
6.
Lightly press the Shutter Release button.
(p. 19)
7.
Check the green LED, then shoot.
(p. 23)
When the end of the film roll is reached,
The film is automatically rewound. ( p. 24)
Remove the film. (p. 25)
Take some trial shots
Before taking important pictures, it is strongly recommended to
take a few trial shots first to familiarize yourself with the camera
and all of its features.
Nikon cannot be held responsible for malfunctions caused by
using the Lite Touch Zoom 100ED / Lite Touch Zoom 100ED QD in
ways not specified in this manual.

8Getting Started
Camera parts (Body)
Auto Exposure
metering window
Lens
Flash ( pp. 30, 31)
Autofocus window
Viewfinder window
Remote-control reception sensor
(p. 39)
Slide cover (power switch)
(p. 13)
AF assist illuminator/Red-eye
Reduction lamp ( pp. 36, 37)/
Self-Timer lamp ( p. 38)
LCD panel ( p. 10)
Strap slot ( p. 3)
Shutter Release button
(p. 19)
*Lite Touch Zoom 100ED QD only
ADJ. button*
(p. 41)
button
Flash mode ( pp. 30-35)
Infinity Focus mode ( p. 40)
(Mid-roll Rewind) button
(p. 24)
MODE/SEL button*
Date/time select
mode ( p. 16)
Date/time setting
mode ( p. 41)
button
Red-eye Reduction ( pp. 36, 37)
Self-Timer ( p. 38)
Remote Control ( p. 39)

Getting Started 9
E
Green LED
(pp. 11, 23)
Orange LED
(pp. 11, 31)
Viewfinder eyepiece
(p. 11)
Panorama switch*( p. 20)
Zoom buttons ( p. 21)
Diopter
adjustment dial
(p. 17)
Camera back lock release lever
(p. 14)
Battery chamber lid
(p. 12)
Tripod socket
(pp. 33, 35, 38, 39)
Film cartridge confirmation
window

10 Getting Started
Low battery power
indicator ( p. 13)
Date/time indicator
(pp. 16, 41)
Red-eye Reduction indicator
(pp. 36, 37)
<Lite Touch Zoom 100ED QD>
Flash Mode indicator
(pp. 30-35) Frame counter ( p. 15)
Self-Timer indicator ( p. 38)
Remote Control indicator ( p. 39)
Red-eye Reduction indicator
(pp. 36, 37)
Infinity Focus Mode indicator ( p. 40)
Low battery power indicator ( p. 13)
Flash Mode indicator ( pp. 30-35) Frame counter ( p. 15)
The illustrations are fully labeled for your reference.
Self-Timer indicator ( p. 38)
Remote Control indicator ( p. 39)
Infinity Focus Mode indicator
(p. 40)
Date recording indicator ( p. 16)
Camera parts (continued)
LCD panel
<Lite Touch Zoom 100ED>

Getting Started 11
E
Indications in the viewfinder
1Parallax compensation marks (p. 29)
For close-up shooting at a distance less than 1 m.
2Autofocus frame marks (p. 22)
Center the main subject to be in focus within this frame.
3Orange LED (p. 31)
Slowly blinks while the flash is being charged, and lights up
when the flash is ready to fire.
If you press down on the popped-up flash unit, the LED blinks
rapidly as a warning.
4Green LED (p. 23)
Lights when focus is achieved. It blinks if correct focus cannot
be achieved.
In close-up photography, the LED slowly blinks as a warning if
the subject is closer than approx. 0.75 m in 38mm wide-angle
shooting, or approx. 0.8 m in 100mm telephoto shooting.
Panorama viewfinder
(Lite Touch Zoom
100ED QD only)
1
2
2
3
4
3
4

12 Preparations
Installing a battery
Battery type
Use one CR123A or DL123A 3V lithium battery in this camera.
1.
Open the battery chamber lid.
While releasing the lock as indicated by the arrow in the illustration
above, open the battery chamber lid.
2.
Install a new battery.
Observe the correct polarities and insert the battery in the direction
shown in the illustration above.
3.
Close the battery chamber lid.
Firmly press the battery chamber lid until it clicks shut.
The built-in clock is reset when the battery is removed. Remember to
set the time and date. ( p. 41)

13
Preparations
E
Turning the camera on
Open the slide cover.
Once you open the cover in the direction of the arrow, the camera is
turned on, the built-in flash pops up, and the lens extends out to the
wide-angle position.
Slide the cover until it clicks.
When closing the cover, first slide it slightly in to start lens retraction.
When the lens is completely retracted, slowly close the cover.
Checking the battery power
Check the Low Battery Power indicator ( ) on
the LCD panel.
Lite Touch Zoom 100ED Lite Touch Zoom 100ED QD
If “ ” is not indicated, battery power is sufficient.
If “ ” is blinking, or all the indicators on the LCD panel do not
appear, the battery is exhausted. Replace it with a new one.
Always check the battery condition before shooting.
It is recommended to carry spare batteries with you. The batteries may
be difficult to obtain in some areas.

14 Preparations
Use 35-mm DX-coded film with this camera.
For DX-coded film, film speed is automatically set.
Film speeds valid for automatic setting are ISO50, 100, 200, 400, 800,
1600, and 3200.
With a non-DX-coded film, the film speed is automatically set to
ISO100.
When loading/unloading film, be sure not to open the camera back
cover into direct sunlight.
Film recommended
It is recommended to use ISO400 film, which provides good results in
flash photography, and reasonable protection against camera shake.
1.
Open the camera back.
Slide the camera back lock release lever (1), and open the camera
back (2).
2.
Insert a film cartridge.
Loading the film
Tips on 35-mm DX-coded film
DX code
Film cartridge
DX mark
Number of frames
Film speed

15
Preparations
E
3.
Pull the film leader out to the red index mark.
Hold the film cartridge and ensure film is properly positioned with no
slack.
4.
Close the camera back, and check that the film
has been correctly loaded.
Lite Touch Zoom 100ED Lite Touch Zoom 100ED QD
Once the camera back is closed, the film automatically advances to the
first frame. Until film loading is complete, “ ” blinks on the LCD
panel.
When the film has been properly set, “ ” is displayed on the LCD panel.
If the letter “ ” blinks on the LCD panel, film is not properly installed.
Open the camera back again and reload film.

16 Basic Operations
Imprinting the date/time on pictures
(Lite Touch Zoom 100ED QD only)
Select the date/time indicator by pressing the
MODE/SEL button.
The year is indicated by the lower two digits, and the time is in the
24-hour cycle. The example in the illustration shows Aug. 1, 2000.
The letter “M” appears to label the month indication, but it is not
imprinted on pictures.
Each time you press the MODE/SEL button, the indicator changes in the
order shown below:
If “ ” is displayed on the LCD panel, the date/time of the shot will be
imprinted on the picture.
Set to “ ” (No printing) if you prefer the date/time not to be
imprinted.
Imprint position of date/time
The imprint positions on film are shown in the illustration.
The imprinted date/time may be difficult to recognize if the imprint
position or the subject is:
• White or bright.
• Orange or yellow.
Imprint position in Panorama
shooting
Imprint position in Regular
shooting
No printing Day/Hour/Minute
Year/Month/Day Month/Day/Year Day/Month/Year

17
Basic Operations
E
Adjusting diopter
Turn the diopter adjustment dial.
If the image in the viewfinder is unclear, turn and adjust the diopter
adjustment lever.
Caution:
As you look into the viewfinder and operate the diopter adjustment
dial, make sure not to injure your eye with your finger or fingernail
during adjustment.
About the AntifogViewfinder
The viewfinder of this camera employs an eyepiece with a special
surface coating which reduces fogging on the eyepiece when you
breathe on it or by vapor from perspiration.
If the antifog viewfinder eyepiece is smeared, gently wipe it with a dry,
soft cloth (e.g. a lens cloth). Avoid wiping with force; otherwise, the
eyepiece may be damaged.

18 Basic Operations
Holding the camera properly
Hold the camera firmly.
<When holding the camera horizontally>
Prop your elbows against your body and hold the camera with both
hands.
<When holding the camera vertically>
When holding the camera vertically, make sure that the flash is on top as
shown.
Do not block the lens, autofocus window, or flash with your fingers or
hair, or the strap.
Be careful not to press down on the flash unit when it is in the popped
up position.

19
Basic Operations
E
Operating the Shutter Release button
1.
Lightly press the button and confirm the green
LED lights up.
When you press the button lightly, the focus and exposure are achieved,
and the green LED lights up.
The focus is locked (Focus lock p. 26) while the Shutter Release
button is depressed lightly.
2.
Fully depress the Shutter Release button to
take the picture.
The flash automatically fires when there is not enough light or the
subject is backlit.
Pressing the Shutter Release button abruptly in one stroke may result in
camera shake. Be sure to slowly press the Shutter Release button.

20 Basic Operations
Selecting Regular or Panorama mode
(Lite Touch Zoom 100ED QD only)
What’s Panorama mode?
In panorama mode, a portion of the top and bottom part of the frame is
cut exposing an area of approx. 13 ×36 mm and is usually printed in
approx. 89 ×254 mm size.
Select Regular or Panorama mode.
Regular mode Panorama mode
The date/time can also be printed in Panorama mode. ( p. 16)
When compared with regular-format pictures, extra time and cost may be
required for developing/printing panorama pictures.
Caution:
To prevent possible injury to your eye, hold the camera away from
your face when you operate the Panorama switch.
Set the Panorama switch
to the right position.
Set the Panorama switch
to the left position.
Regular mode Panorama mode
