Nilfisk-Advance Liberty SC50 User manual

WARNING:
The operation of this machine is strictly reserved to trained and qualified operators.
Model No:
56104500 (X20D), 56104501 (X20R)
Nilfisk Liberty SC50
Instructions for use Instructions for Use
Original Instructions
Instrucciones de uso
Mode d’ emploi
12/2017 revised 9/2018 REV B
Form no. 56091197
A-English
B-Español
C-Français

A - 2 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
INTRODUCTION
This manual will help you get the most from your Nilfisk Scrubber. Read it thoroughly before operating the machine.
Note: Bold numbers in parentheses indicate an item illustrated on pages A-8 – A-12.
This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops, offices and rental businesses. The
Nilfisk Liberty SC50 is a battery powered floor cleaning machine.
WARNING:
The operation of this machine is strictly reserved to trained and qualified operators.
TABLE OF CONTENTS
Introduction................................................................................. 2
Parts and Service...................................................................... 3
Modifications ............................................................................. 3
Name Plate................................................................................ 3
Uncrate the Machine ................................................................. 3
Transporting the Machine.......................................................... 3
Cautions and Warnings.............................................................. 4
Know Your Machine.................................................................... 8
Control Panel........................................................................... 10
Information Menu Display........................................................ 13
Autonomous Menu (Informational Messages)......................... 17
Autonomous Menu (Actions/Commands)................................ 18
Understanding Autonomy ........................................................ 19
Remote.................................................................................... 20
Prepare the Machine for Use................................................... 21
Batteries .................................................................................. 21
Install the Batteries.................................................................. 21
Location Tag............................................................................ 22
Home Position ......................................................................... 23
Magnetic Smartkey™ .............................................................. 24
Install the Brush (Disc System) ............................................... 25
Install the Pad (REV System).................................................. 26
Install the Squeegee................................................................ 27
Clean Sensor Lenses.............................................................. 28
Fill the Solution Tank ............................................................... 29
Solution Tank Indicator ............................................................ 29
Detergent System Preparation (Ecoflex)................................. 29
Detergent System Use (Ecoflex)............................................. 30
Operating the Machine............................................................. 32
Starting the Machine ............................................................... 32
Stopping the Machine.............................................................. 33
Training the Machine for Autonomous Mode........................... 34
Playback of Recorded Plan, Autonomous Mode..................... 37
Operating the Machine Manual Mode ..................................... 40
LED Status Bar Operation....................................................... 42
Speaker Operation .................................................................. 42
After Use ................................................................................. 43
Maintenance.............................................................................. 43
Maintenance Schedule............................................................ 43
Lubricating the Machine .......................................................... 44
Electromagnetic Brake ............................................................ 44
Charging GEL/AGM (VRLA) Batteries .................................... 45
Squeegee Maintenance .......................................................... 47
Squeegee Adjustment ............................................................. 47
Remote Battery Replacement ................................................. 48
Troubleshooting ....................................................................... 49
General Machine Troubleshooting .......................................... 49
Autonomous Mode Troubleshooting........................................ 50
Remote Troubleshooting ......................................................... 50
Fault Code Display.................................................................. 51
Fault Code History................................................................... 56
Specifications ........................................................................... 57
Accessories / Options.............................................................. 57
Material Composition and Recyclability................................... 57
Solution Flow Rates ................................................................ 57
Technical Specifications .......................................................... 58

12/2017 A - 356091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
PARTS AND SERVICE
Repairs, when required, should be performed by Nilfisk, Inc., who employs factory trained service personnel, and maintains an inventory of Nilfisk
original replacement parts and accessories.
Call NILFISK, INC. for repair parts or service. Please specify the Model and Serial Number when discussing your machine.
MODIFICATIONS
Modifications and additions to the cleaning machine which affect capacity and safe operation shall not be performed by the customer or user
without prior written approval from Nilfisk, Inc. Unapproved modifications will void the machine warranty and make the customer liable for any
resulting accidents.
NAME PLATE
The Model Number and Serial Number of your machine are shown on the Nameplate, located on the inside of the battery compartment.
Date of Manufacture “Date Code” is marked on the nameplate. Date Code: A17, means January 2017.
This information is needed when ordering repair parts for the machine. Use the space below to note the Model Number and Serial Number of your
machine for future reference.
MODEL NO. ___________________________________________________________
SERIAL NO. ___________________________________________________________
UNCRATE THE MACHINE
When the machine is delivered, carefully inspect the shipping packaging and the machine for damage. If damage is evident, save the shipping
carton (if applicable) so that it can be inspected. Contact the Nilfisk Customer Service Department immediately to file a freight damage claim.
Refer to the unpacking instruction sheet included with the machine to remove the machine from the pallet.
TRANSPORTING THE MACHINE
CAUTION!
Before transporting the machine on an open truck or trailer, make sure that . . .
• All tanks are empty.
•Recovery tank cover is latched securely.
• The machine is tied down securely - see Tie Down Locations (6) in Know Your Machine. Only use locations designated as “Tie Down
Locations” to secure the machine during transport. Using any other location of the machine to tie down the machine may cause damage or
injury.
•The machine’s electromagnetic brake is engaged (not manually overridden), see Electromagnetic Brake section if necessary.
This product contains the chemical DOTE (2-ethyihexyl 10-ethyl-4,4-dioctyl-7-oxo-8-oxa-3,5-dithia-4-stannatetradecanoate; CAS
number: 15571-58-1) which is listed on the candidate list of the EU REACH Regulation (1907/2006/EC).

A - 4 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
CAUTIONS AND WARNINGS
SYMBOLS
Nilfisk uses the symbols below to signal potentially dangerous conditions. Always read this information carefully and take
the necessary steps to protect personnel and property.
DANGER!
Is used to warn of immediate hazards that will cause severe personal injury or death.
WARNING!
Is used to call attention to a situation that could cause severe personal injury.
CAUTION!
Is used to call attention to a situation that could cause minor personal injury or damage to the machine or other property.
Read all instructions before using.
GENERAL SAFETY INSTRUCTIONS
Specific Cautions and Warnings are included to warn you of potential danger of machine damage or bodily harm.
This machine is for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than
normal residential housekeeping purposes.
WARNING!
•This machine shall be used only by properly trained and authorized persons.
•The operation of this machine is strictly reserved to trained and qualified operators.
•This machine is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge.
•While on ramps or inclines, avoid sudden stops. Avoid abrupt sharp turns. Use low speed down ramps.
•Observe the Gross Vehicle Weight, GVW, of the machine when loading, driving, lifting or supporting the machine.
•Keep sparks, flame and smoking materials away from batteries. Explosive gases are vented during normal operation.
•Charging the batteries produces highly explosive hydrogen gas. Charge batteries only in well-ventilated areas, away
from open flame. Do not smoke while charging the batteries.
•Remove all jewelry when working near electrical components.
•Turn the machine power OFF and disconnect the batteries before servicing electrical components.
•Never work under a machine without safety blocks or stands to support the machine.
•Do not dispense flammable cleaning agents, operate the machine on or near these agents, or operate in areas where
flammable liquids exist.
•Do not clean this machine with a pressure washer.
•Only use the brushes or pad driver provided with the appliance or those specified in the instruction manual. The use
of other brushes may impair safety.
•Do not look at the laser beams used by the machine. Permanent eye damage could result. Lasers are eye-safe if
viewed briefly, such as to determine that they are functioning. Do not look directly into lasers or stare at them without
wearing protective laser safety glasses.
•Safety Lasers work to detect the presence of individuals in the area of an operating machine. Safety Lasers function
only in the Autonomous Operating Mode.

12/2017 A - 556091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
CAUTIONS AND WARNINGS - CONTINUED
CAUTION!
•This machine is not approved for use on public paths or roads.
•This machine is not suitable for picking up hazardous dust.
•Do not use scarifier discs and grinding stones. Use only pads or brushes intended for floor cleaning. Nilfisk will not
be held responsible for any damage to floor surfaces caused by using the wrong or improper pads or brushes.
•When operating this machine, ensure that third parties, particularly children, are not endangered.
•Before performing any service function, carefully read all instructions pertaining to that service task.
•After use do not leave the machine unattended where it can be accessed by others without first powering the machine
off at the power switch.
•Power the machine OFF at the power switch and remove the magnetic SmartKey, before changing the brushes, and
before opening any access panels.
•Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.
•Use caution when moving this machine in below freezing temperature conditions. Any water in the solution, recovery
or detergent tanks or in the hose lines could freeze, causing damage to valves, pumps and fittings. Flush with low-
temperature windshield washer fluid.
•The batteries must be removed from the machine before the machine is scrapped. The disposal of the batteries
should be safely done in accordance with your local environmental regulations.
•Do not use on surfaces having a gradient exceeding that marked on the machine.
•All doors and covers are to be positioned as indicated in the instruction manual before using the machine.
• This machine should only be used and stored indoors.
•The machine’s magnetic SmartKey has a built-in magnet. Do not place objects having magnetic bands (such as
credit cards, electronic keys, phone cards) near the key. The built-in magnet can damage or erase the data stored on
the magnetic bands.
•Only use locations designated as “Tie Down Locations” to secure the machine during transport. Using any other
location of the machine to tie down the machine may cause damage or injury.

A - 6 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
CAUTIONS AND WARNINGS - CONTINUED
CAUTION!
• Do not operate the machine in an environment exceeding 104°F (40°C).
• Do not operate the machine without the Bumper (18) in place.
• Avoid driving the machine onto stairways or escalators, into open elevator shafts, or into any area where there is a
significant drop in elevation. Serious machine damage may result if it falls down stairs, escalators, or open shafts.
The machine cannot climb stairs. Machine is designed for use only on flat surfaces (less than 2 degree incline). Place
safety cone in front of escalators to prevent machine entry.
• While driving the machine manually, to develop navigational maps as part of training the autonomous function, it is
the Operator’s responsibility to avoid contact with obstacles. The machine will not avoid them in the manual operating
mode. There are no autonomous safety functions operating in the manual mode.
CAUTIONS FOR 2-D MAPPING LASER (14)
CLASS 1 LASER PRODUCT
The 2-D Laser Scanner corresponds to laser class 1 (eye-safe).
The laser beam is not visible to the human eye.
CAUTION!
• The use of controls, or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
• Do not open the housing (opening the housing will not switch off the laser).
• Pay attention to the laser safety regulations as per IEC 60825-1 (latest version).

12/2017 A - 756091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
CAUTIONS AND WARNINGS - CONTINUED
CAUTION!
CAUTIONS FOR 2-D SAFETY LASER (17)
Read the following guidelines for correct use of the 2-D Safety Laser (17) hence referred to as the UAM. Proper handling
and usage will ensure the UAM to operate accordingly.
GENERAL PRECAUTIONS
• UAM is designed to protect human begins or systems by monitoring the hazardous area. It is not designed for the
protection from high speed objects or the electromagnetic radiation.
• Perform pre operation tests in order to verify the performance of UAM.
• Do not modify or disassemble UAM. Such modifications will affect the detection capability leading to injuries or death.
• Do not modify or disassemble UAM to maintain its housing rating. Such modifications will void the warranty.
• The person in charge should be qualified to operate UAM. The person must be trained, on safety requirements with
necessary cautions for handling the device.
• The person in charge should train the user with correct installation, operation, inspection and maintenance
procedures.
• The person in charge is responsible to ensure the proper working environment for UAM.
• The person in charge is responsible for the compliance with the local safety requirements, standards, rules and
regulations, laws of respective nations, states or districts when UAM is used in a safety related system.
• UAM has been manufactured and shipped under the strict quality control. If you find any defect in the product contact
the nearest distributor or sales representative.
• Hokuyo cannot be held responsible for the damages or failure due to misuse of the product.
• User should prepare test pieces for detection capability verification. The test piece should emulate the smallest object
that is intended to be detected during the operation.
• Maximum level of homogeneous pollution for UAM to operate normally is under 30%. UAM will report error if the
pollution exceeds the stated limit. Always keep the optical window in clean condition to avoid the error.
• Before resetting the interlock of UAM, user must ensure the surrounding is safe especially the protected area.
• Apply sufficient measures to ensure safety of the protected area when decommissioning UAM. Protective materials
such as guards or light curtain should be used to prevent the passage to the hazardous area.
• UAM including its accessories are subject to change without prior notice for the improvement.
• UAM should be disposed as industrial waste or in accordance with the local disposal directives.
SAVE THESE INSTRUCTIONS

A - 8 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
KNOW YOUR MACHINE
As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item
shown on these pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in the
text. NOTE: Refer to the service manual for detailed explanations of each item illustrated on the next 4 pages.
1 Control Panel
2 Steering Wheel
3 Detergent Cartridge
4 LED Status Bar
5 Solution Tank
6 Tie Down Locations (3)
7 Drive Wheel
8 Solution Drain Valve
9 Scrub Deck
1
2
3
4
5
6
7
9
10
11
6
12
8
17
14
13
16
16
15
17
18
10 Squeegee Roller
11 Squeegee Assembly
12 Squeegee Cover Knobs (4)
13 Antenna
14 2-D Mapping Laser
15 3-D Camera Lenses
16 Drop-Off Safety Laser (4)
17 2-D Safety Laser (2)
18 Bumper (NOT a lifting or tie down point)

12/2017 A - 956091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
KNOW YOUR MACHINE
20 Control Panel Housing / Recovery Tank Cover
21 Recovery Tank Full Float
22 Recovery Tank
23 Debris Catch Tray
24 Go Pedal
25 Operator Presence Pedal
26 Platform
27 Recovery Tank Lift Handles (2)
28 Vacuum Motor Fan Inlet Screen
29 Rear Wheel (2)
30 Rear Squeegee Blade Removal Latch
31 Battery Charger
32 Solution Solenoid Valve
33 Solution Filter
34 Solution Shutoff Valve
35 Solution Pump
36 Latch
37 Recovery Tank Drain Hose
38 Solution Tank Level Sight Tube
39 Prop Rod
40 On-Board Charger Power Cord
41 Solution Tank Fill Port
42 Fuse Holder Boot (Main Fuse 100 Amp)
43 Machine Battery Connector
44 Location Tag
20
21
22
23
24
25
26
29
30 31
32
33
34
36
38
39
35
41
37
40
28
27
43
42
44

A - 10 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
CONTROL PANEL
A SmartKey™ Reader
B Power Switch
C Horn Switch
D Emergency Stop
E Control Circuit Breaker (5 Amp)
F Circuit Breaker (K1) (5 Amp)
G Steering Motor Circuit Breaker (15 Amp)
H Manual Operation Indicator
J Solution Flow Adjustment Switch
K Detergent Switch
L Vacuum Switch
M One-Touch™Scrub ON/OFF Switch
N Extra Pressure Switch
O Burst of Power Switch
P Speed Adjustment Knob
Q Forward Drive Switch
R Reverse Drive Switch
S Autonomous Mode / Autonomous Menu Switch
T Stop Switch
U Record Switch
V Play/Pause Switch
W CopyCat™/Fill-In Switch
X Display (see Control Panel-Continued)
Y Information Switch & Navigation Switches
Z Magnetic SmartKey™
-Blue = User
-Yellow = Supervisor
AA Remote
AB Remote Status Request Button
Remote Status Indicators
AC1 - Red LED = Machine Alarm State
AC2 - Green LED = Machine Functioning Normally
AD Remote Pause Button
CB2
5A
CB3
15A
CB1
5A K1
E
K
H
M
A
D
S T U V W
R
X
Q
P
J
G
L
Y
F
B
C
O
N
AD
AB
AC2
Z
AA
AC1

12/2017 A - 1156091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
CONTROL PANEL - CONTINUED
X1 Hour Meter (Drive Hours) [see page 13]
X2 Active Fault Codes [see page 48]
X3 Battery Charge Indicator [see page 43]
X3a = Battery Charge Full
X3b = Battery Charge Low
X4 Vacuum Indicator
X5 Vacuum Indicator Bar Graph
FIRST = Quiet Mode
SECOND = Regular Mode
NONE = Off
X6 Detergent Indicator
X7 Detergent Ratio/Percentage Indicator
X8 Detergent Indicator Bar Graph
FIRST = Detergent Low Mode
SECOND = Detergent High Mode
NONE = Off
X9 Solution Flow Indicator
X10 Solution Flow Rate Bar Graph
FIRST = Low
SECOND = Medium
THIRD = High
NONE = Off
X11 Scrub Pressure Indicator
X12 Scrub Brush Pressure Bar Graph
FIRST = Regular
SECOND = Heavy
NONE = Off
X13 Battery Low Voltage Indicator
X14 Critical Fault Indicator
X15 Fault Code (Critical)
X44 Date Display (Year/Month/Day)
X45 Time Display (Local)
X46 Time Display (Coordinated Universal Time)
X1
X2
X5
X4
X8X7
X6
X10
X12
X11
X9
X15
X14
X3
X3a
X3b
X13
X44
X45
X46

A - 12 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
CONTROL PANEL - CONTINUED
X16 Recovery Tank Full Indicator
X17 Purge Indicator
X18 Emergency Stop Activated Indicator
X19 No Key Indicator
X20 Key Read Error Indicator [see Troubleshooting]
X21 Restricted User Key Indicator [see Troubleshooting]
X22 Burst of Power Indicator
X23 Solution Tank Empty Indicator
X24 Impact Lockout Indicator
X25 Autonomous Indicator
X26 Countdown Timer
X27 Go To Home Position Indicator
X28 Advancing Lines (machine in Training or Playback)
X29 Playback Available Indicator
X30 Spinning Arrows / Computer Processing
X31 No Home Position Set Indicator
X32 Machine On A Plan Indicator
X33 Resume Plan Available Indicator
X38 Remove Key Indicator
X39 Save Plan Indicator
X40 Delete Plan Indicator
X26
X22
X19
X20
X21
X23
X17 X18
X16
X24
X25
X27 X28 X29
X30 X31 X32 X33
X38
X39
X40

12/2017 A - 1356091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
INFORMATION MENU DISPLAY
Menu Display
Pressing the Information Switch (Y) will bring up the menu
shown below which allows the operator to change machine
settings and gather machine information. Use the four
Navigation Arrows (Y1) (up, down, left & right) to move through
the menu and the information switch to exit the menu.
Menu visible with either blue (User) or yellow (Supervisor) SmartKey.
Menu Level Notes
12
Hours Displays various system hours
On Time Displays Power ON hours
Drive Time Displays drive (non-neutral) hours
Scrub Time Displays scrub/brush ON hours
CopyCat Teach Displays hours spent training CopyCat plans
Fill-In Teach Displays hours spent training Fill-In plans
CopyCat Replay Displays hours spent playing back CopyCat plans
Fill-In Replay Displays hours spent playing back Fill-In plans
Recovery Time Displays recovery/vacuum ON hours
Faults**
Active Faults Displays list of active faults w/ timestamp and description
Fault History Displays list of fault history w/ timestamp and description
Clear Autonomy History*** Clear autonomy fault history list
**See Fault Code Display
***Supervisor and Technician Only
Menu visible only with yellow (Supervisor) SmartKey.
Menu Level Notes
12 3
Keys
Read Key
Read the key serial number, family and type for key inserted into holder
- if user key, allows supervisor to add to key list
- if key is of appropriate type, allows supervisor and technician to program a
supervisor key
Key List Display the current approved user key list
supervisor can also remove selected key from list
Add Key
Clear Key List
Options Supervisor selectable options
Language
English*
Italiano
Deutsch
Portuguese
Français
Español
Menu display language
Scrub Startup
Light
Heavy
Last Used*
Scrub level at start
Scrub Max Light
Heavy* Maximum scrub level allowed
*Default setting
Y
Menu
Hours
Faults
Keys
Options
iExit Select Y1
Y1

A - 14 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
INFORMATION MENU DISPLAY – CONTINUED
Menu visible only with yellow (Supervisor) SmartKey.
Menu Level Notes
12 3
Options Supervisor selectable options
Solution SmartFlow* (proportional to speed)
Fixed Adjust solution flow to speed, or fixed flow
Solution In Rev No*
Yes Leave solution on in reverse?
Warning Beep
Backup Beep*
Beep On
Beep Off
Beep when backing up, beep always on when
moving, beep off
Autonomy Beep
Beep Off*
Beep Low
Beep Medium
Beep High
Beep when scrubbing autonomously – off, low,
medium, high volume
Other Sounds
Normal
Quiet
Off
Volume of sounds (apart from horn, starting
autonomy beep, and backup beep)
Manual Light
On to Scan*
Always On
Always Off
“On to Scan” means the LED strip will be white
with blue corners when the camera is attempting
to read a Location Tag or a QR Code.
Obstacle Color Red
Orange
Color of “Obstacle” chasing lights displayed on
LED status bar when an obstacle is encountered
Detergent Low
(300,256,200,150,128,100,64,50,32,26):1
– ratio cannot be > Detergent High
(0.3, 0.4, 0.5, 0.7, 0.8, 1.0, 1.5, 2.0, 3.0, 3.8)%
– percentage cannot be > Detergent High
Set detergent ratio for detergent low level
Detergent High
(300,256,200,150,128,100,64,50,32,26):1
– ratio cannot be < Detergent Low
(0.3, 0.4, 0.5, 0.7, 0.8, 1.0, 1.5, 2.0, 3.0, 3.8)%
– percentage cannot be < Detergent Low
Set detergent ratio for detergent high level
Detergent shown as xxx:1
x.x% Ratio or percentage
Neutral Delay (s)
min = 0.5*
max = 5.0
step = 0.5
Time to keep brushes on when in neutral
(seconds)
Vac Off Delay (s)
min = 15*
max = 25
step = 1
Time to keep vacuum on after turning off scrub
system (seconds)
Vac Startup
Full
Quiet
Last Used*
Vacuum level at start
Burst Of Power (s)
min = 60*
max = 300
step = 60
Burst-of-power (BOP) time span (seconds)
Fwd Speed Max (%)
min = 50%
max = 100%*
step = 10
Maximum forward speed as percentage of
maximum available speed in manual mode
Inactivity Time (min)
min = 5
max = 60
step = 5
default = 15
Inactivity time before putting machine in sleep
mode (minutes)
*Default setting

12/2017 A - 1556091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
INFORMATION MENU DISPLAY – CONTINUED
Menu visible only with yellow (Supervisor) SmartKey.
Menu Level Notes
12 3
Options Supervisor selectable options
User
Replay Only*
Replay/Train
Replay/Train/Delete
User key plan permissions -- only replay; replay and train; replay, train,
and delete plans
No Add/Delete Tags*
Add Tags
Add/Delete Tags
User key location tag permissions -- no permissions, can add tags, can
add and delete tags
Delete ALL PLANS? Yes/No Deletes all plans
Delete ALL TAGS? Yes/No Delete all tags (and plans)
Ignore water meter? Yes/No
Ignore water meter and do constant flow with no feedback loop. Allows
operator to keep cleaning in autonomous or manual mode with a broken
flow meter.
OvrCurProt. Enabled? Yes/No Over Current Protection can be disabled for using the machine on certain
rubber flooring where current draw is higher than expected
Impact Action Log Only*
Log & Lock
Impact detection status
Log Only – Impact is recorded
Log & Lock – Impact is recorded and User is locked out of scrub functions
(Display shows (X24)) until machine is reset with a Supervisor key.
Impact Level High*
Low
Impact detection sensitivity level. If nuisance tripping occurs (i.e. driving
over a floor transition), adjust setting to low.
Impact Log User ID? Yes/No Whether to record the User ID in the impact log
Date/Time/Timezone Set the date, time and timezone
Timezone Choose timezone that matches machine’s location
Hour Set current time, hours in 24-hour format
Minute Set current time minutes
Second Set current time seconds
Year Set current year
Month Set current month
Day Set current day
*Default setting

A - 16 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
INFORMATION MENU DISPLAY – CONTINUED
Menu visible with either blue (User) or yellow (Supervisor) SmartKey.
Menu Level Notes
12
System
A1 Firmware Rev Display current firmware revision
A8 Charger F/W Display current charger firmware revision
A1 Serial Number Display PCB serial number from factory
A5 Compute Display current autonomy Compute box firmware
A5 Platform Display current autonomy Platform box firmware
A5 Safety Display current autonomy Safety box firmware
E5 Camera Display current Camera firmware
2D Map Laser Display current Mapping Laser firmware
Impact Log** Display list of impact events with max value, timestamp and user id (only if enabled)
- single item view will show max values for each axis (x,y,z)
CRL Wireless Update** Go to menu for wireless update of autonomy firmware
Network Status Is network up, or down (down includes an error number)
IP Address IP Address of machine, shown as 123.456.789.666
QR String QR string scanned in from “Scan QR Code” menu command
Autonomy
Create Location Tag*** Creates the first locatoin tag
Scan new locatoin tag*** Adds a new location tag
Delete current tag #NNN*** Deletes the current tag NNN (deletes all plans)
Delete next seen tag*** Deletes the next tag scanned
Delete this plan*** Deletes the plan the machine is currently on
Change Location Tag Forget the current tag and scan for a known tag
**Only visible with yellow (Supervisor) SmartKey.
***Only visible to blue User key if permission is granted by Supervisor.

12/2017 A - 1756091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
AUTONOMOUS MENU (INFORMATIONAL MESSAGES)
Pressing the Autonomous Mode / Autonomous Menu Switch (S) will bring up a menu of information and/
or actions the operator can take at that particular point in time (menu will vary depending upon what the
machine is currently doing, where it’s located and what is allowed). Use the four Navigation Arrows (Y1)
(up, down, left & right) to move through the menu and the information switch to exit the menu. The table
below shows informational messages, the table on the next page shows actions that can be taken directly
from the menu.
S
Machine State Appears on Display Autonomous Menu
During startup (X25) &
(X26)
Autonomy is booting up …[countdown timer]
Manual mode available
After startup, autonomy
has failed to boot up.
Active Fault
Code
Autonomy Unavailable
Autonomy not responding
Manual mode only
While operator is training
a CopyCat plan
(X25) &
(X28)
Training a copycat
Press nor to end
Press yy to pause
While operator is training
a Fill-In plan
(X25) &
(X28)
Training a fill-in
Press nor to end
Press yy to pause
While machine is playing
back a CopyCat plan
(X25) &
(X28)
Playing back a copycat
Press nto stop
Press yy to pause
While machine is playing
back a Fill-In plan
(X25) &
(X28)
Playing back a fill-in
Press nto stop
Press yy to pause
After training a new plan,
machine needs time to
compile/save the plan
(X25) &
(X30)
Autonomy compiling a plan
If you move the machine, it
will become lost and need
to see a tag when done
At the start of a plan (X29) At start: yy to replay
Within the resume area of
a paused plan (X33) Continue: yy to resume
Not on a trained plan Manual Mode Display No plan: make new plan
At the start of a plan but
unable to play the plan (X13)
LOW BATTERY
No Autonomy functions

A - 18 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
AUTONOMOUS MENU (ACTIONS/COMMANDS)
Pressing the Autonomous Mode / Autonomous Menu Switch (S) will bring up a menu of information and/
or actions the operator can take at that particular point in time (menu will vary depending upon what the
machine is currently doing, where it’s located and what is allowed). Use the four Navigation Arrows (Y1)
(up, down, left & right) to move through the menu and the information switch to exit the menu. The table
below shows actions that can be taken directly from the menu, the table on the previous page shows
S
informational messages.
Machine State Appears on Display Autonomous Menu
No home tag set (X31)
Need to set home tag!
Create home tag
Back Select Tag:0 . . *
Machine is disoriented (X27)
Lost, show me a tag! .
Set new home tag
Delete next seen tag
Back Select Tag:0 . . *
On a trained plan (X25) &
(X32)
On plan: make new plan
Delete this plan
Back Select
Not on a trained plan Manual Mode Display
No plan: make new plan
Set new home tag
Delete current tag #4**
Delete next seen tag
Become lost
Back Select Tag:4**
*Tag: 0 . . moving “0” indicates that machine is actively scanning for a location tag.
**Tag: “x” where “x” is the location tag ID number.

12/2017 A - 1956091197 - Nilfisk Liberty SC50
ENGLISH - AINSTRUCTIONS FOR USE
9/2018
UNDERSTANDING AUTONOMY
The Nilfisk Liberty SC50 can function autonomously meaning that it functions (operates) on its own, without operator involvement. The machine
can be trained to clean an area independently and actively maneuver around certain obstacles.
Components that make up the Autonomy system, and their basic function, include the following (shown in Figure 1-1):
• 3-D Camera (45) - provides a three-dimensional image of the area in front of the machine.
• 2-D Mapping Laser (14) - provides detection of obstacles in front of and to the left of the machine.
• Drop-off Safety Lasers (16) - detect drop-offs, or major changes in floor elevation.
• 2-D Safety Lasers (17), located at front corners of machine – aides in collision prevention and presence detection in the area of an
operating machine.
• Remote (AA). This allows the exchange of status information between the operator and the machine.
• Autonomy Box (46). This is the primary computer for safety during operation.*
• Computer software Interface, (not shown). Defines how the autonomous control system interfaces with machine control software and
control system.
FIGURE 1-1
16
17
14
46
17
45
AA
*NOTE
This equipment is approved for this application by the Federal Communications Commission (FCC). FCC ID: 2AMDR00068. This equipment has
been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
pro-vide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
*NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and
can radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.

A - 20 Nilfisk Liberty SC50 - 56091197 12/2017
INSTRUCTIONS FOR USEA - ENGLISH 9/2018
REMOTE
The battery-powered Remote (AA) (shown in Figure 1-2) is a hand-held device that provides two-way communication when the machine is
operating autonomously. Normally it is used when the machine is operating some distance from the operator, and they cannot see or hear it.
NOTE
Remote is approved for this application by the Federal Communications Commission (FCC). FCC ID: 2AMDR00069. This device complies with
part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications to this device, not expressly approved by the party responsible for compliance, could void the user’s authority to operate
the equipment.
AD
AB
AC2AC1
AA
Start-up Check
1. Remote will flash both LEDs (AC1 & AC2) and beep, when the machine is powered
ON to indicate machine and remote are properly paired together.
While the machine is operating in autonomous mode there are three interactions the
operator can have with the machine through the remote.
1- The remote can communicate to the operator by sending alerts using the LEDs
and audible beeps
2- User can request machine status information.
3- User can use the remote to pause the playback of a plan while operating
autonomously.
Remote Status Guide
Button Pressed Response Seen Machine Mode
N/A
Flashes red (left LED) (AC1)
Beeps
Unexpected exit out of autonomy
Flashes red & green (left & right LED) (AC1 &
AC2)
)
Beeps
Plan playback is complete
(AB)
Green flash when pressed (AC2) Remote is transmitting
Machine is off or out of range if no response is seen within 5
seconds of press
Solid green, 5 seconds after pressed (AC2) Signal received, in Autonomous
Solid red, 5 seconds after pressed (AC1) Signal received, in Manual
(AD)
Machine stops Machine has been paused in autonomous mode
- Machine playback cannot be restarted via the remote. Return
to the machine with SmartKey to restart.
Beeping stops Machine was in alarm mode, alarms have now been turned
off
- Return to the machine with SmartKey and clear the error.
FIGURE 1-2
