Ningbo RM-9600 User manual

AUTO REFRACTOMETER
RM/KR-9600
OPERATOR’S MANUAL
0120

BEFORE USE, READ THIS MANUAL.
This instrument is manufactured according to the general requirements of GB9706.1 medical
electrical equipment safety. The instrument must be grounded reliably. Please pay attention to the
warning labels on the product and the instructions and review the random files to prevent damage
to the operator and other persons, or to other facilities.
ISO 9001/13485Authentication—Product design and development, production and service of
Ningbo Ming Sing Optical R & D Co., Ltd. through ISO 9001/13485 certification.The IEC
standard is applicable to this manual. Refractive power showed a reference wavelength of D =
587.56 NM. The material with patients contacting have been evaluated by ISO10993. There is no
risk of unacceptable.
Safety precautions and procedures must be thoroughly understood before using the
equipment and keep this manual. The device complies with ISO 10342 (ophthalmic instruments,
eye refractometer) ISO 10343 (ophthalmic instruments, Keratometer). In addition to the
replacement of the printed paper, the instrument does not require the user to repair parts. If you
have any questions about the equipment, please contact the local dealer that Ningbo Ming Sing
Optical R & D Co., Ltd. authorized or direct contact with the customer service department of our
company
This manual is also used as a training reference manual.In order to ensure the best
performance of the new machine, it is recommended that you carefully read and follow the steps
in this guide.Please keep this manual as a reference for future communication with other users. If
you need additional copies or any questions about the device, please contact our company or
authorized dealer.
The information contained in this manual has been confirmed before publication.If change
the product model without notice.Ningbo Ming Sing Optical R & D Co., Ltd. reserves the right to
change the product contained in this manual without notice. The sold products do not involve such
changes.
Without written permission of Ningbo Ming Sing Optical R & D Co., Ltd. isn’t available in
electronic, mechanical, or any other means reproduction, retrieval and reprint any chapter in this
book.
Manufacturer: Ningbo Ming Sing Optical R & D Co., Ltd.
Address：No. 702, Tiantong Road，Yinzhou District，Ningbo, Zhejiang
Zip Code：315192
Telephone：[phone]
Facsimile：0574-87296439，0574-87296162
Document NO.：Q/MS-J510D.12-2018
Version NO.：A/1Date：March. 1st, 2018

1. Introduction..................................................................................................................................... 1
1.1 Product Features and Use Scope...........................................................................................1
1.2 Classification.........................................................................................................................1
1.3 Main performance index....................................................................................................... 2
2. Safety precautions........................................................................................................................... 4
2.1 Safety identification.............................................................................................................. 4
2.2 Safety precautions before use............................................................................................... 4
2.3 Safety precautions during use............................................................................................... 5
2.4 Safety precautions after use.................................................................................................. 6
2.5 Maintenance and check.........................................................................................................6
2.6 Disposal.................................................................................................................................7
3. Configuration and Functions...........................................................................................................8
3.1 Device configuration.............................................................................................................8
3.2 Accessories............................................................................................................................9
3.3 Symbols...............................................................................................................................10
3.4 Operation flow.................................................................................................................... 11
3.5 Set screen description......................................................................................................... 14
4. Installation and measurement preparation.................................................................................... 19
5. Measurement................................................................................................................................. 20
5.1 Model eye measurement..................................................................................................... 20
5.2 Patient measurement........................................................................................................... 21
6. Self-diagnosis and maintenance....................................................................................................22
6.1 Troubleshooting.................................................................................................................. 22
6.2 Printer Paper Replacement..................................................................................................22
6.3 Cleaning and disinfection................................................................................................... 22
6.4 Replace fuse........................................................................................................................ 23
6.5 Instrument site change........................................................................................................ 23
6.6 Preventive inspection and maintenance..............................................................................23
6.7 Scrap....................................................................................................................................24
7. Outline dimension and other instructions..................................................................................... 25

7.1 Outline specification, Contraindication..............................................................................25
7.2 Service life.......................................................................................................................... 25
7.3 Disclaimer........................................................................................................................... 25
8. After-sale service...........................................................................................................................26
9. Main specifications....................................................................................................................... 27
10. EMC(Electromagnetic Compatibility）.....................................................................................28

1
1.Introduction
The Auto-Refractometer (RM-9600, RM-9800)/ Auto ref-keratometer(KR-9600, KR-9800) is
used to measure spherical, cylinder, axial, PD, corneal radius and corneal diopter (KR-9600,
KR-9800)of the patient’s eye.
1.1Product Features and Use Scope
a) The classification of equipment according to the type of shock proof: class I,external
power supply equipment.
b) The classification of equipment according to the degree of shock proof: B type.
c) The classification of equipment according to the ability to prevent liquid
entry:ordinary equipment.
d) Application part of the equipment: chinrest, forehead rest.
e) The type of device power: single phase, network power supply: 100-240V ~ 50/60Hz
50VA.
f) Equipment belongs to non AP or APG type.
g) The operation mode: continuous operation.
h) Equipment belongs toimpermanent installation equipment.
1.2 Classification
The model number is RM-9600/ KR-9600/ RM-9800/KR-9800.
The Auto Ref/keratometer is composed of the host, the base and the bracket (according to the
appearance). The bracket material is ABS.
The Auto Ref/keratometer is composed of optical system, electronic system and software,
mechanical system, shells(according to the functional system).
The main difference between the main models KR-9000 is the difference in shape. The principle
and intended uses are the same.
The classification of appearance according to design serial number: KR/RM-9600 is same.
KR/RM-9800 is same.
The classification of functional according to model number: KR-9600/9800 is
same.RM--9600/9800 is same. (The Auto Ref/keratometerKR-9600 and KR-9800can measure
corneal curvature)
Transport and transport conditions:
Temperature:-40℃- +55℃
Humidity:≤80%
Atmospheric pressure: 700hPa - 1060hPa(transport), 500hPa - 1060hPa(transport)
Working environment condition:
Temperature:10℃- 40℃
Humidity:≤80%

2
Atmospheric pressure: 760hPa - 1060hPa
Power requirements:
Voltage: 100-240V～、50/60Hz
Input power: 50VA
1.3 Main performance index
1 Measurable range
Spherical power: -25.00 m -1 - +22.00 m -1。
Cylindrical power:-10.00 m -1 - +10.00 m -1。
Cylindrical axis:0º - 180º
PD measurement: 10mm - 85mm
Corneal radius:5mm - 10mm (KRseries)
Corneal diopter:67.50 m -1 - 33.75 m -1 (KRseries)
2Measurement increments（step）
Spherical power (step):0.12 m -1/0.25 m -1
Cylindrical power (step): 0.12 m -1/0.25 m -1
Cylindrical axis (step): 1º
PD measurement (step): 1mm
Corneal radius (step): 0.01mm(KR series)
Corneal diopter (step): 0.12 m -1/0.25 m -1(KR series)
3Tolerance
The tolerance of the Auto refractometer/ Auto ref-keratometer should meet the requirements of
Table 1
Table 1 Tolerance
Measurable range
Tolerance
Spherical power
-10 - +10 m -1
±0.25 m -1
＜-10or＞+10 m -1
±0.50 m -1
Cylindrical power
-10 - +10 m -1
±0.25 m -1
Corneal refractiveradius
≤8.0mm
±0.02mm
＞8.0mm
±0.03mm
Corneal refractivepower
≤43 m -1
±0.13 m -1
＞43 m -1
±0.25 m -1
The tolerance ofcylindrical axis: ≤±5º
The tolerance of PD: ≤±1mm
4 General technical requirements
a)The installation of the whole equipment should be firm and isn’t obvious loosening.
Chinrest should be able to smooth lifting. The rated load of chinrest is 2.5Kg.Shaking the joystick,
the device should be flexible to move all around.
b) The surfaces of all optical components shall be clean, free of damage, and no other defects
that affect light transmission or imaging.
c) Display screen should be able to clear imaging.
d)Digital display complete, stable, no flicker and print legible. Measurement results should

3
include left and right eye identification, spherical power and cylindrical power,+/-, axis and
degree,etc.
e)Auto ref/keratometer has the function of printing test results.
f) Optical radiation shall comply with the applicable requirements of ISO15004-2.
5Under the working conditions, the noise should not be greater than 55dB (A).
6 The surface temperature of the device is not more than 15℃.
7 Safety requirements shall comply with the requirements of GB9706.1.
8The test environment shall be consistent with the requirements of the mechanical test
environment II group in GB/T14710-1993.
9 The Device for external connection with Auto ref/keratometer shall comply with the
requirements of GB9706.1.

4
2.Safety precautions
2.1 Safety identification
In this manual, signal words are used to designate the degree or level of safety alerting.
The definitions are as follows.
CAUTION
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or property damage
accident.
Even situations indicated by CAUTION may result in serious injury under certain conditions.
Safety precautions must be strictly followed at all times.
2.2 Safety precautions before use
CAUTION
The safety precautions and operating procedures must be thoroughly understood prior to
operation of the device.Use of the device outside the scope of this manual may cause adverse
events.
Do not open shell and do not touch the interior of the device. This may cause electric shock
or instrument failure.
Install and use the device in an environment that meets the following conditions.
Temperature：10℃- 40℃
Humidity：≤80%
Atmospheric pressure：760hPa - 1060hPa
A room with low dust and little light
A location free from vibration and shock
--- If the device is not installed and used under the above conditions, the reliability of
measured results is impaired, and malfunction may result. In addition, there is a
possibility of injury if the device receives shock and falls down.
Avoid storage the device near water, poisonous gas or liquid. The device may be corrosion or
failure.
Avoid installing the device where it is exposed to direct air-conditioning flow.Changes in
temperature may result in condensation inside the device or adversely affect measurements.
Be sure to use a power outlet which meets the power specification requirements. If the
voltage is too high or too low, the device will not perform properly, and fire may occur.
To avoid the risk of electric shock, the equipment must be connected with the power supply
in the case of the protection of grounding equipment. Electric shock or fire may occur if the
device malfunction or electric leakage.
Do not use socket overload. This May cause fire.
Insert the power plug into the socket. Improper connections may cause a fire.

5
Never use a power strip or extension cable to supply the device with power. This may cause
failures and fire.
Do not place heavy objects on the power cord. A damaged power cord may cause fire or
electric shock.
Switch off the power switch and disconnect the power cord from the power outlet before
connecting the cable. Otherwise it may result in device failure
When moving the instrument, be sure to turn off the power switch, unplug the power cord
and the power cable, lock the head (with a lock sign),to avoid equipment falling that may
cause injury or equipment damage.
Special packing materials are used to protect the equipment during transportation. Excessive
vibration or shock can cause malfunction.
When installing and operating equipment, observe the following EMC instructions (EMC):
1. The device can’t be used in conjunction with other electronic devices to avoid
electromagnetic interference with other electronic devices.
2. The equipment can’t be used in the same room with other devices, including life support
devices, other devices that have a significant impact on the lives of patients and the results
of treatment and the measurement or treatment devices of small current.
3.The equipment can’t be used in conjunction with portable and mobile radio frequency
communication devices because of their electromagnetic interference may adversely affect
the operation of the device.
4. Don’t use cables and accessories other than those specified by the company. These may
increase the electromagnetic wave emitted by the equipment or system and reduce the
electromagnetic interference resistance of the device.
If there is a potential electromagnetic interference between the equipment and other
equipments, shielding measures should be taken or the location of the device to be changed
to reduce the possible interference.
2.3 Safety precautions during use
CAUTION
When the equipment is disuse, please turn off the power and cover the dust cover. If the
equipment is exposed for a long time, it may have dust, which will affect the accuracy.
Please check the equipment before the operation. If there is any abnormal, do not use the
equipment. The equipment used to abnormal conditions that may affect the accuracy of the
data, the unexpected failures or diagnosis errors may cause harm.
Before measuring each patient, clean the chinrest and forehead rest with clean gauze or
absorbent cotton. If necessary, dampen a cloth with rubbing alcohol and gently wipe them
off. If you use a Chinrest paper, a replacement for each patient.
Keep the measuring window free of fingerprints and dust. Also confirm that it is not dirty
before use, or else measurement accuracy may decrease substantially.
In the event of smoke or strange odors, immediately turn off the device and disconnect the
power plug from the power outlet. After it is certain that the smoke has stopped, contact

6
MSOC or your authorized distributor.
The continued use of the equipment under unusual circumstances may cause a fire or electric
shock. In case of fire, use a dry powder (ABC) fire extinguisher.
Never press on the LCD with a hard object such as a ball-point pen. Keep magnetic objects
away from the LCD. Malfunction of the device may result.
Do not operate the LCD screen with wet hands. Water infiltration devices may cause
malfunction of the equipment
There may be a few dead or constantly-lit pixels on the LCD. This does not represent failure
of the LCD.It is due to the structure of the LCD.
Only after training qualified personnel can operate the instrument, or operate under its
guidance.
2.4 Safety precautions after use
CAUTION
If the device is a long period of disuse, disconnect the power supply. Dust may collect
moisture that may cause short circuit or fire.
Occasionally use a dry cloth to clean the tip of the power supply plug. If the dust falls on the
tip, water may be collected, resulting in a short circuit or fire.
Don't jerk when pulling out power line. This will destroy the metal line and may cause
electric shock, short circuit or fire.
Maintain the following environmental conditions during transport and storage of the device.
Temperature：-40℃- +55℃
Humidity：≤80%
Atmospheric pressure：700hPa - 1060hPa(transport)、500hPa - 1060hPa(storage)
A location with low dust
A location not exposed to direct sunlight
Special packing materials are used to protect the equipment during transportation. Excessive
vibration or shock can cause malfunction.
2.5 Maintenance and check
CAUTION
Do not wipe any part of the instrument with a solvent or a strong cleaning solution.Otherwise
the instrument may be damaged.
Do not use organic solvents such as paint thinner to clean the outside of the
device.Otherwisethe surface of the equipmentmay be damaged.
Avoid touching the optical components of the instrument to prevent performance degradation
caused by fingerprints or grease stains on the lens set.
Any repairs and services to this instrument must be carried out by personnel or dealers
trained by MSOC.
Adjustments must be made by the technical service personnel of MSOC or other authorized

7
personnel.
The battery of the instrument must be replaced by thetechnical service personnel of MSOC or
other authorized personnel.
When the equipment is returned to the company for repair or maintenance, use a clean cloth
dipped in the alcohol disinfection device (especially the area of patient contact).
When there is a big difference between the results of the Auto ref/keratometer measurements
and the subjective measurements, please contact MSOC or the dealer to determine whether
the current equipment requires calibration of the measurement accuracy.
2.6 Disposal
CAUTION
Follow local governing ordinances and recycling plans regarding disposal or recycling of
devicecomponents.
It is recommended to deal with industrial waste by the designated contractor.
Deal with packaging material in accordance with local laws and regulations.

8
3.Configuration and Functions
3.1 Device configuration
Figure 1 instrument view
1．7 inch resistive screen: Display measurement results. The screen can adjust angle.
2．Power pilot lamp: When the instrument is working, the indicator light is bright.
3．Printer: print measurement results.
4．Measurement button: When the measurement button is pressed, measurement starts.
5．Joystick: Adjust the measuring window position forward and backward/ Left and right / up and
down.
6．Chinrest up/down button（/）:Realize the function of lifting the chinrest.

9
7．Reset print key（/）: Reset print function.
8．Measuring unit: It is functional unit.
9．Locking lever: Fixation the main body to the base.
10．Power switch: Turn on or off the instrument power switch.
11．Forehead rest: Here on the forehead.
12．Measuring window: Measurement of retinal imaging
13．Chinrest: Fixed chin.
14 ．Eye level marker:The height of the chinrest should be adjusted so that the patient’s eye
roughly aligns with this line.
15．Adjust the foundation: Support the instrument to adjust the level of equipment.
16．Fixing pins: Fix the model eye and chinrest paper.
17．Fuse holder: 2 fuses installed inside.
18．Power inlet: Connect ~220V, 50Hz AC.
19．The cover of measuring window
3.2Accessories
1．Socket head wrench: Unlock plug screw.
2．Model eye: Use to proofreading accuracy.
3．Fuse wire: To prevent short circuit.
4．Printing paper: Measurement of retinal imaging.
5．Operator’s manual: Instructions for use of this device.
6．Dust cover: When not using the instrument, dustproof.
7．Chinrest paper：Customer put on the chinrest.
8．Horizontal bubble: Display instrument level.

10
WARNING
The instrument accessoriesare provided by MSOC, and the accessories of other
manufacturers need to be verified and confirmed before use.
3.3 Symbols
The following symbolsare applied to the device.
0120
Equipment is to meet the basic requirements of the EU
MDD 93/42/EEC.
Indicates that this equipment is to prevent moisture.
Reading operator’s manual.
Indicates that the degree of protection against electric
shock is of a Type B Applied Part.
Indicates therequirements for disposal of electronic and
electrical equipment.
Indicates the equipment manufacturers.
EU authorized representative.
Indicates the year of manufacture.
Warning, please read the operator’s manual before
using.
Indicates the device serial number.
“丨”and“O” respectively represent the power switch
on and off.
Alternating current.
Fuse indication.
3V CR1220 button battery.
Push down to lock the mobile body .Push up to unlock
the mobile body.
Joystick:For the front and back / left and right / upper
and lower to adjust the measurement window position.
The window rises when the joystick is turned

11
clockwise. The window drops when the joystick is
turned counterclockwise.Press the button when the
focus is completed.
Button for chinrest up.
Button for chinrest down.
Button for reset.
Button for print.
3.4Operation flow
The design block diagram of the software and user interface is shown below. Through the
operating interface,the user can achieve the measurement,data display, image analysis,the
parameters and functions of the modification.
Parameter setting Screen
Start
Data display screen
Start screen
Measurement
screen
Image analysis screen
RMParameter
KRParameter
Function setting
Information setting
Time setting
Operation screen flow chart

12
The following introduceseveral main screens in detail:
1. Start screen
Center shows the company LOGO,instrument type, company name and other information.
2. Measurement screen
As shown in the figure：
The function buttons on the screen and the display of each region are as follows:
Set button ：Press this button to enter the parameter settings interface, specific in the

13
chapter.
Clear button：Press this button to clear the test record in memory.
Display history data button:Press this button to display the measured historical data.
Display the symbol of the cylinder: touch this button can be cycle
switch.
PDMeasurement button: Touch this button to enter the PDMeasurementscreen.
Measurement mode switch: Touch this key tocircularlyswitch measurement mode.
The show step of the Sphere and cylinder: Touch the key to circularlyswitch the
step.
VD display: Touch this key tocircularlyswitch VD value.
Count the times of left and right measurement: "L" means "left".The
second letter R represents the measurement of REF.The third is the times of measurement.The
fourth letter K represents the measurement of KER. The last is the times of measurement.
Count the times of left and right measurement:The first letter K
represents the measurement of KER.The second is the times of measurement.The third letter R
represents the measurement of REF.The fourth is the times of measurement.The last"R" means
"right".
The value of PD display:When left and right eye measurements are completed and PD
switchturn "ON",the PD value will be displayed. Otherwise displayed “- -”.
For REF data display Three forms of corneal curvature data
display
Serial number of patients
/ Manual / automatic mode:Touch this button to switch measurement mode
between manual and automatic.
/ Manual / auto alignment method: Touch this key to switch up and down
alignment between manual alignment and automatic alignment.

14
/ IOL switch button:Touch this key to switch IOL mode.
3.5Set screen description
Touching the setting button in the measurement interface, you can enter the parameter settings
screen.
The buttons on the left side of the screen are all kinds of function parameters:
Touch this button to display the REF function parameters.
Touch this button to display the KER function parameters.
Touch this button to display the function setting parameters.
Touch this button to display the information setting parameters.
Touch this button to display the time setting parameters.
Touch this button to return to the measurement screen.
The Description of functional parameters is as follows:
1. REF functional parameter:

15
RM step:0.12D / 0.25D
VERTEX DIST:0 / 12 / 13.5 / 15
CYL SIGN: -/ + /MIX
AR CONTINUE:1/3/5
FOGGING: one time/always
2. KER functional parameter:
KM unit: MM / D / AVG
KM Display: 0.12D / 0.25D
REF INDEX: 1.332 / 1.336 / 1.3375
KM CONTINUE 1/3/5
3.Function setting:

16
Language: English / Chinese
PD display: OFF / ON
Screen Sleep: OFF / 5MIN / 15MIN
Beep job: OFF / ON
Auto print: OFF / ON
RM print: OFF / AVG / STD
KR print: OFF / AVG / STD
EyePrint: OFF / ON
RS232C output: OLD / NEW
baud rate: 115200 / 9600 / 4800 / 2400
4. Information setting
