Ninja BL770 30 User manual

Mega Kitchen System®
®BL770 series
OWNER’S GUIDE
www.ninjakitchen.com
1 877 646-5288

11-877-646-5288
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING ELECTRICAL APPLIANCES,
BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED, INCLUDING THE
FOLLOWING:
READ ALL INSTRUCTIONS BEFORE
USING YOUR NINJA®MEGA KITCHEN
SYSTEM®.
POLARIZED PLUG
WARNING: To reduce the risk of
electric shock, this appliance has a polarized
plug (one blade is wider than the other). This
plug will fit into a polarized outlet only one
way. If the plug does not fit fully into the
outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the
proper outlet. DO NOT modify the plug in
any way.
WARNING: Extension cords are
not recommended for use with this product.
WARNING: TO REDUCE THE RISK OF
FIRE, ELECTRIC SHOCK OR INJURY:
1 CAUTION: Blade assemblies are
sharp and removable, handle with care.
When handling the blade assemblies,
always hold by the shaft.
2CAUTION: DO NOT BLEND HOT FOODS
OR HOT LIQUIDS.
3CAUTION: We do not recommend
grinding in any of our Nutri Ninja®Cups.
4 To protect against electrical shock, do not
submerge the appliance or allow the power
cord to come into contact with water or
any other liquid.
5 DO NOT allow young children to operate the
appliance or use as a toy. Close supervision
is necessary when any appliance is used by
or near children.
6 Never leave an appliance unattended when
inuse.
7 Appliance accessories are not intended to
be used in the microwave as it may result in
damage to the accessories.
8 Turn the appliance Off and remove the power
cord from the electrical outlet when not in
use, before assembling or disassembling
parts and before cleaning. To unplug, grasp
the plug and pull from the electrical outlet.
Never pull from the power cord.
9 DO NOT abuse the power cord. Never carry
the appliance by the power cord or yank it
to disconnect from electrical outlet; instead
grasp the plug and pull to disconnect.
THIS BOOK COVERS MODEL NUMBERS:
BL770 30
BL770A 30
BL770W 30
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz.
Power: 1500 Watts
Pitcher Capacity: 72 ounces (9 cups, 2.1 L)
MAX Liquid Capacity: 64 ounces (8 cups, 1.9 L)
Bowl Capacity: 64 ounces (8 cups, 1.8 L)
Nutri Ninja®Cup Capacity: 16 ounces (2 cups, 470ml)

2
www.ninjakitchen.com
21 To reduce the risk of injury, NEVER operate
the appliance without the lid in place; DO
NOT try to defeat the interlock mechanism;
make sure that the attachment is properly
installed before operating the appliance.
22 DO NOT expose containers to extreme
temperaturechanges.
23 DO NOT overfill.
24 DO NOT operate the appliance empty.
25 To reduce the risk of burns, always allow
the appliance to cool before taking off parts
and before cleaning.
26 In the event that the unit overloads, the unit
will shut down. Unplug the appliance and let
it cool down for approximately 15 minutes
before using again.
27 THIS PRODUCT IS INTENDED FOR
HOUSEHOLD USE ONLY. Do not use
this appliance for anything other than its
intended use. Do not use outdoors.
28 The maximum rating is based on the
6-Blade Assembly (pitcher) that drives the
greatest power and other recommended
attachments may draw significantly less
power or current.
SAVE THESE
INSTRUCTIONS
10 DO NOT operate any appliance with
a damaged cord or plug, or after the
appliance malfunctions, has been dropped
or damaged in any manner. This appliance
has no serviceable parts. Return the
appliance to EURO-PRO Operating LLC for
examination, repair or adjustment.
11 DO NOT let the power cord hang over
the edge of table or counter or touch hot
surfaces such as the stove.
12 Always use appliance on a dry, level surface.
13 Keep hands, hair, clothing, as well as utensils
out of container while processing to reduce the
risk of severe injury to persons or damage to
the appliance. A scraper may be used but only
when the appliance is not running.
14 Avoid contact with moving parts.
15 DO NOT attempt to sharpen blades.
16 DO NOT use the appliance if blade
assembly is bent or damaged.
17 To reduce risk of injury, never place the
blade assembly on base without pitcher or
bowl properly attached.
18 DO NOT operate this appliance on or near
any hot surfaces (such as gas or electric
burner or in a heated oven).
19 The use of attachments or accessories
including canning jars, not recommended by
the manufacturer may result in fire, electric
shock or personal injury.
20 DO NOT remove the container from the
motor base while the appliance is in
operation.

31-877-646-5288
Contents
Thank you for
purchasing
the Ninja®
Mega Kitchen
System®.
Getting to Know Your Ninja®Mega Kitchen System®....................................................4
Using the Ninja®Mega Kitchen System®...................................................................5
Assembly and Use for the Blender Pitcher ..................................................................6
Assembly and Use for the Nutri Ninja®Cup.................................................................8
Assembly and Use for the Food Processor Bowl ..........................................................9
Speed Setting & Uses..............................................................................................11
Care & Maintenance ...............................................................................................12
Troubleshooting Guide.............................................................................................13
Replacement Parts..................................................................................................13
Warranty & Registration...........................................................................................14
FEATURES:
• PatentedNinja®Technology
• ExtraLarge,72oz.BlenderPitcher(MAXLiquidCapacity:64oz.)-BPAFree
• 64oz.FoodProcessorBowlwithDrizzleHoleLid-BPAFree
• NutriNinja®Cups - BPA Free
• Lock–InLid,FeaturingPourSpout
• EasytoCleanElectronicControlPanel
• Sturdy,Non-SlipBase

4
www.ninjakitchen.com
d64 oz. Food Processor Bowl
eBowl Lid with Locking Handle
fDough Blade (bowl)
g4-Blade Assembly (bowl)
a16 oz. Nutri Ninja®Cup (x2)
bTo-Go Lid (x2)
cSingle Serve Blade
NOTE: Blades are not interchangeable.
Getting To Know Your Ninja®Mega Kitchen System®
a
d
e
bc
fg
h
i
k
j
h72 oz. Blender Pitcher
iPitcher Lid with Locking Handle
j6-Blade Assembly (pitcher)
kMotor Base
lPower Cord (not shown)

51-877-646-5288
Using the Ninja®Mega Kitchen System®
CAUTION: Blade assemblies are sharp, not locked in
place and removable, handle with care. When handling
the blade assemblies, always hold them by the shaft.
BEFORE FIRST USE
1Remove all packaging material and labels from the
appliance.
2Wash the lids, pitcher, bowl, Nutri Ninja®cups and
attachments in warm, soapy water with a soft cloth.
CAUTION: Handle the blade assemblies with care
when washing, as the blades are very sharp.
3Rinse and dry thoroughly.
4 The pitcher, bowl, Nutri Ninja®cups, lids and
attachments, are all dishwasher safe. It is recommended
that the lids and attachments be placed on the top rack.
Ensure that the attachments are removed from the
containers before placing in the dishwasher.
5Wipe the motor base clean with a damp cloth.
PLEASE KEEP THESE IMPORTANT
SAFEGUARDS IN MIND WHEN USING THE
APPLIANCE:
WARNING: Never leave the appliance
unattended while in use.
WARNING: Secure the appliance while in use
by pressing down on the lid with one hand.
CAUTION: Blades are sharp! Use extreme
caution when handling the blade
assemblies. Always hold them by the shaft
of the blade assembly.
CAUTION: DO NOT BLEND HOT FOODS OR HOT
LIQUIDS.
CAUTION: Never remove the container while
the appliance is still running.
CAUTION: We do not recommend grinding in
any of our Nutri Ninja®Cups.
IMPORTANT: Never add ingredients into the
container before placing the attachment in
first.
IMPORTANT: Attachments are not
interchangeable.
IMPORTANT: DO NOT attempt to operate the
appliance without the lid on.
IMPORTANT: Never run the appliance empty
IMPORTANT: Appliance accessories are not
intended to be used in the microwave as it
may result in damage to the accessories.
.
CAUTION: Blades
are not locked in
place. If using the
pour spout, ensure
the lid is fully
locked onto the
blender pitcher.
CAUTION: Blades
are not locked in
place. If pouring
with the lid
removed, ALWAYS
remove the blade
assembly first.

6
www.ninjakitchen.com
Fig. 3b
Fig. 1
Assembly and Use for the Blender Pitcher
1Place the motor base on a clean, dry, level surface
such as a counter or table top.
2Align and lower the Pitcher onto the motor base.
(Fig. 1) Handle should be aligned slightly to the right of
the “LOCK” symbol on the motor base.
3Rotate the pitcher clockwise until it locks in place. You
will hear a click when the lock is engaged. (Fig. 2)
4The pitcher can be placed on the motor base two ways;
the handle can be on the front right corner or the front
left corner. (Fig. 3a, Fig. 3b)
5Holding the 6-Blade Assembly by the top of the shaft,
place it onto the drive gear inside the pitcher. Ensure
that the attachment is seated properly and is standing
upright. (Fig. 4)
NOTE: The blade will fit loosely on the drive gear.
6Add the ingredients to the pitcher, making sure that
they do not exceed the highest measured marking line
on the side of the pitcher.
NOTE: If you need to add additional ingredients while
the appliance is processing, open the pour spout cap
and pour the ingredients in through the opening.
NOTE: When blending any kind of liquids, such as
mixtures of any drinks or smoothies, do not exceed the
“Max liquid” mark (64 ounces) on the pitcher.
7Plug the power cord into the electrical outlet and press
the power button ( ).
IMPORTANT: As a safety feature, the power
button ( ) will flash and the motor will not work
if the pitcher and lid are not installed correctly.
When the pitcher and lid are installed properly,
the power button ( ) will be solid, indicating that
the appliance is ready for use.
8Holding the lid by the handle in the upright position,
place it on top of the pitcher aligning the arrow ( )
located on the lid with the arrow ( ) located on the
pitcher’s handle. (Fig. 5) Press the handle down until
you hear a click.
Fig. 4 Fig. 5
ASSEMBLY
Fig. 3a
WARNING: Never leave the appliance unattended while in use.
CAUTION: Handle the blade assemblies with care, as the blades are very sharp.
IMPORTANT: Make sure that the motor base is plugged in for use.
Fig. 2

71-877-646-5288
WARNING: Never leave the appliance unattended
while in use.
9Select the speed that best suits your needs. (Fig. 6)
NOTE: Pulse ingredients for even chopping by pressing
down in short intervals.
10 When you have reached your desired consistency, stop
the appliance by pressing the power button ( ) and
wait for the attachment to stop turning. (Fig. 7)
11 To remove the lid, press the release button on the lid,
pull the lid handle up to a 90° angle and lift the lid off.
Turn the pitcher counter clockwise and then lift off the
base. (Fig. 7, Fig. 8)
CAUTION: Never insert your hands in the pitcher
as the blades are sharp. Always use a spatula to
dislodge food that has stuck to the sides of the
pitcher.
Assembly and Use for the Blender Pitcher - cont.
Fig. 7
USE REMOVAL
Fig. 6 Fig. 8
12 Depending on the consistency of the contents in the
container, open the pour spout cap and use the spout
to empty liquid contents. For thicker consistencies,
remove the lid and attachment carefully (by its shaft),
then empty contents from the container.
CAUTION: Blades are not locked in place. If using
the pour spout, ensure the lid is fully locked onto
the blender pitcher.
13 For thicker consistencies, remove the lid and blade
attachment carefully (by its shaft), then empty contents
from the container. To remove the lid, press the release
button on the lid and pull the lid handle up to a 90°
angle and lift the lid off the blender pitcher.
CAUTION: Blades are not locked in place. If
pouring with the lid removed, ALWAYS remove the
blade assembly first.
14 Make sure that the unit is unplugged when not in use.
15 To release the motor base from the counter or table top,
place your hands underneath both sides of the motor base
and gently pull the unit up and towards you. (Fig. 9)
Fig. 9

8
www.ninjakitchen.com
1Place the motor base on a clean, dry, level surface such
as a counter or table top.
2Add ingredients to the Nutri Ninja®cup.
3Place the single serve blade onto the cup and screw it
tightly until you have a good seal. (Fig. 1)
4Turn the Nutri Ninja®cup upside down and place it
onto the motor base, aligning the tabs on the cup with
the motor base. Turn the Nutri Ninja®cup clockwise to
lock into place. You will hear a click when the lock is
engaged. (Fig. 2) Turn the power button on, the single
serve button will illuminate.
5Press down on the Single Serve button in short
intervals to activate. (Fig. 3)
6Once you have reached your desired consistency,
turn the power button off. Turn the Nutri Ninja®cup
counter clockwise and pull straight up to remove.
(Fig. 4, Fig. 5)
Fig. 2
Assembly and Use for the Nutri Ninja®Cup
Fig. 3 Fig. 4 Fig. 5
ASSEMBLY USE REMOVAL
NOTE: Do not overfill! To avoid spilling, do not add
ingredients past the “Max” fill line.
7Turn the cup upright and remove the single serve blade
by twisting the blade assembly counter clockwise.
8Place the To-Go drinking lid onto the Nutri Ninja®cup,
twist to seal and enjoy!
9Make sure that the motor base is unplugged when not
in use.
10 To release the motor base from
the counter or table top, place your
hands underneath both sides of the
motor base and gently pull the unit
up and towards you. (Fig. 6)
NOTE: To order additional Nutri
Ninja®Cups, please visit our website:
www.ninjakitchen.com or feel free to contact
customer service: 1-877-646-5288.
Fig. 1
For best results, use short “PULSES”... Practice makes perfect!!
Fig. 6
WARNING: Never leave the appliance unattended while in use.
CAUTION: Handle the blade assemblies with care, as the blades are very sharp.
CAUTION: DO NOT BLEND HOT FOODS OR HOT LIQUIDS.
IMPORTANT: Make sure that the motor base is plugged in for use

91-877-646-5288
Assembly and Use for the Food Processor Bowl
ASSEMBLY
1Place the motor base on a clean, dry, level surface such
as a counter or table top.
2Align and lower the Bowl onto the motor base. (Fig. 1)
Handle should be aligned slightly to the right of the
“LOCK” symbol on the motor base.
3 Rotate the bowl clockwise to lock into place. You will
hear a click when the lock is engaged. (Fig. 2)
4The bowl can be placed on the motor base two ways;
the handle can be on the front right corner or the front
left corner. (Fig. 3a, Fig. 3b)
5Holding the desired blade by the top of the shaft, place
it onto the drive gear inside the bowl. Ensure that the
attachment is seated properly and is standing upright.
(Fig. 4)
NOTE: The blade will fit loosely on the drive gear.
6 Add the ingredients to the bowl, making sure that they
do not exceed the highest measured marking line on
the side of the bowl.
7Holding the lid by the handle in the upright position,
place it on top of the bowl aligning the arrow ( )
located on the lid with the arrow ( ) located on the
bowl’s handle. (Fig. 5) Press the handle down until you
hear a click.
NOTE: The 64 oz. bowl is not intended for
blending drinks. Do not overfill.
NOTE: To add liquids during processing,
open the drizzle hole on the top of the
lid and pour the liquid slowly into the
mixture.
8Plug the power cord into the electrical outlet and press
the power button ( ).
IMPORTANT: As a safety feature, the power
button ( ) will flash and the motor will not work
if the bowl and lid are not installed correctly.
When the bowl and lid are installed properly, the
power button ( ) will be solid, indicating that the
appliance is ready for use.
Fig. 4 Fig. 5
Fig. 1 Fig. 3a
Fig. 3b
WARNING: Never leave the appliance unattended while in use.
CAUTION: Handle the blade assemblies with care, as the blades are very sharp.
IMPORTANT: Make sure that the motor base is plugged in for use.
Fig. 2
