Nintendo Mv1-7.1 User manual

Mv1-7.1 installation manual

Installation guide
Required Items:
Recommended Tools:
1. MicroSD card containing atmospheric integration
package and genuine SanDisk card are recommended.
2. Mv1-7.1 cracking chipset
3. Nintendo switch V1 (Erista) / V2 (Mariko)
4. Tip soldering iron (340c) / solder
5. Y00 human screwdriver and #00 Philips cross
screwdriver
6. CPU heat dissipation paste
1. Liquid flux
2. Electronic magnifying glass or head mounted
magnifying glass
3. Alcohol (more than 91%)
4. Cotton swab / scissors
5. Kapton heat resistant tape / electrical tape
1

2

3

4

5

6

7

8
GENTLY BEND BACK THE CABLE
AND IT TO THE CHIP,CONNECT
THEN LAY IT FLAT AGAIN
IT SHOULD LINE UP
WITH THE PLUP.NAND
PRESS DOWN TO SECURE
THE CONNECTION

9
Assemble all removed parts again,
replace the cleaned heat dissipation
paste, and cut a little antimagnetic
wave so that the cable can pass through.
Cut off part of the metal
back plate, and use
heat-resistant adhesive
tape for insulation
protection. Finally,
the shell will not be tilted
after installation.
Install the NAND module
and fix it with adhesive tape.

10
Crack Description:
1. Please do not insert the microSD card when starting up for the first time
2. After the first boot, you need to wait a few minutes to boot successfully,
and the screen displays "NO SD"
3. LED display status during the first boot process:
yellow light flashes - > pink light flashes - > green light is always on for about 3 seconds
4. After the first startup, the factory setting can be restored by short circuiting
the two round holes on Mv1-7.1

11
Restore factory settings and firmware upgrade methods:
1. Restore the factory setting method: use tweezers to short circuit the two round holes in
the figure, turn on the machine, turn the white light into blue light, and restore the
factory setting.
2. Firmware upgrade method: insert and connect Uv1-7 (USB adapter board) to PC according
to the direction in the figure to upgrade.
Short circuiting these two round
holes can restore the factory
settings
Firmware upgrade interface
Restore factory settings
and
firmware upgrade methods
