Nitek MC71XSG-XX User manual

Model MC71XSG-XX
Gigabit 1000Base FIBER MEDIA CONVERTER
Installation and
Operation Manual
Introduction
TheMC71XSG‐XXauto‐negotiatingfastEthernetmediaconvertersetisdesignedtotranslates1000Base‐TXcopperand
1000Base‐FXfastEthernetfibercabling.ThemediaconverterenablesyoutoextendthedistanceofyourGigabitEthernetnetwork
upto40km(XXinthepartnumberwillindicatemaxdistance).
TheConvertersareequippedwith[1]duplexSCfiberconnectortotransmitdataBi‐directionallyoverasinglefiberopticcable.
SixLEDindicatorsarebuiltinforeasymonitoringandsystemdiagnosticsforpower,fiberandUTP,linkandactivity.
MC71XSG‐XXFiberMediaConverterInstallationDrawing
InstallingtheMC71XST‐XXFiberMediaConverters
Refertotheabovediagramwheninstalling.Usebestindustrypracticesandfollowalllocalbuildingcodes.
1)Connectanetworkpatchcablefromthenetworkequipment’sEthernetstothereceiver.
2)ConnectaSingleModefibercablebetweenthetransmitterandthereceiverusingSCfiberconnectors.
3)Connectanetworkpatchcablefromthetransmitter’sEthernetjacktotheremoteIPdevice(IPcamerainthisexample).
4)Connectthesuppliedpowertransformerstothetransmitterandreceiver.

