Niveo NGSME24G4S User manual

Version 2.0
Niveo NGSME24G4S
24-Port 10/100/1000Base-T + 4-Port 10G SFP+
Full Management Stackable High Power PoE Switch
User Manual

FCC/CE Mark Warning
NGSME24G4S User Manual | 2
FCC Warning
This Equipment has been tested and found to comply with the limits for a Class-A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy. It may cause harmful interference to radio
communications if the equipment is not installed and used in accordance with the instructions.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-Aproduct. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

Table of Contents
NGSME24G4S User Manual | 3
Table of Contents
Before Starting...........................................................................................................................10
Intended Readers...................................................................................................................11
Icons for Note, Caution, and Warning ..................................................................................11
Product Package Contents....................................................................................................12
Chapter 1: Product Overview.................................................................................................13
1.1. Product Brief Description...............................................................................................14
1.2. Product Specification .....................................................................................................15
1.3. Hardware Description.....................................................................................................18
1.4. Hardware Installation......................................................................................................19
Chapter 2: Preparing for Management ..................................................................................20
2.1. Preparation for Serial Console.......................................................................................21
2.2. Preparation for Web Interface ........................................................................................23
2.3. Preparation for Telnet/SSH Interface .............................................................................25
Chapter 3: Web Management.................................................................................................27
3.1. Web Management - Configure........................................................................................28
3.1.1. Configuration - System ............................................................................................30
3.1.1.1. System - Information .........................................................................................30
3.1.1.2. System - IP .........................................................................................................31
3.1.1.3. System - IPv6......................................................................................................32
3.1.1.4. System - NTP......................................................................................................33
3.1.1.5. System - Time.....................................................................................................34
3.1.1.6. System - Log ......................................................................................................36
3.1.2. Configuration - Power Reduction............................................................................37
3.1.2.1. Power Reduction - EEE......................................................................................37
3.1.3. Configuration - Ports................................................................................................38
3.1.4. Configuration - Security...........................................................................................40
3.1.4.1. Security - Switch - Users...................................................................................40
3.1.4.2. Security - Switch - Privilege Level ....................................................................42
3.1.4.3. Security - Switch - Authentication Method.......................................................44
3.1.4.4. Security - Switch - SSH......................................................................................45
3.1.4.5. Security - Switch - HTTPS .................................................................................46
3.1.4.6. Security - Switch - Access Management ..........................................................47
3.1.4.7. Security - Switch - SNMP...................................................................................48
3.1.4.7.1. Security - Switch - SNMP - System.............................................................48
3.1.4.7.2. Security - Switch - SNMP - Community......................................................52

Table of Contents
NGSME24G4S User Manual | 4
3.1.4.7.3. Security - Switch - SNMP - User .................................................................53
3.1.4.7.4. Security - Switch - SNMP - Groups.............................................................55
3.1.4.7.5. Security - Switch - SNMP - Views ...............................................................56
3.1.4.7.6. Security - Switch - SNMP - Access.............................................................57
3.1.4.8. Security - Switch - RMON..................................................................................58
3.1.4.8.1. Security - Switch - RMON - Statistics.........................................................58
3.1.4.8.2. Security - Switch - RMON - History ............................................................59
3.1.4.8.3. Security - Switch - RMON - Alarm...............................................................60
3.1.4.8.4. Security - Switch - RMON - Event...............................................................62
3.1.4.9. Security - Network - Limit Control ....................................................................63
3.1.4.10. Security - Network - NAS (Network Access Server).......................................66
3.1.4.11. Security - Network - ACL..................................................................................77
3.1.4.11.1. Security - Network - ACL - Ports...............................................................77
3.1.4.11.2. Security - Network - ACL - Rate Limiter....................................................79
3.1.4.11.3. Security - Network - ACL - Access Control List.......................................80
3.1.4.12. Security - Network - DHCP ..............................................................................96
3.1.4.12.1. Security - Network - DHCP - Snooping.....................................................96
3.1.4.12.2. Security - Network - DHCP - Relay............................................................97
3.1.4.13. Security - Network - IP Source Guard.............................................................99
3.1.4.13.1. Security - Network - IP Source Guard - Configuration............................99
3.1.4.13.2. Security - Network - IP Source Guard - Static Table..............................100
3.1.4.14. Security - Network - ARP Inspection.............................................................101
3.1.4.14.1. Security - Network - ARP Inspection - Configuration............................101
3.1.4.14.2. Security - Network - ARP Inspection - Static Table................................102
3.1.4.15. Security - AAA................................................................................................103
3.1.5. Configuration - Aggregation..................................................................................107
3.1.5.1. Aggregation - Static .........................................................................................107
3.1.5.2. Aggregation - LACP.........................................................................................109
3.1.6. Configuration - Loop Protection............................................................................111
3.1.7. Configuration - Spanning Tree...............................................................................113
3.1.7.1. Spanning Tree - Bridge Settings.....................................................................113
3.1.7.2. Spanning Tree - MSTI Mapping .......................................................................115
3.1.7.3. Spanning Tree - MSTI Priorities.......................................................................117
3.1.7.4. Spanning Tree - CIST Ports .............................................................................118
3.1.7.5. Spanning Tree - MSTI Ports.............................................................................121
3.1.8. Configuration - MVR...............................................................................................123
3.1.9. Configuration - IPMC..............................................................................................127

Table of Contents
NGSME24G4S User Manual | 5
3.1.9.1. IPMC - IGMP Snooping ....................................................................................127
3.1.9.1.1. IPMC - IGMP Snooping - Basic Configuration .........................................127
3.1.9.1.2. IPMC - IGMP Snooping - VLAN Configuration.........................................129
3.1.9.1.3. IPMC - IGMP Snooping - Port Group Filtering .........................................131
3.1.9.2. IPMC - MLD Snooping......................................................................................132
3.1.9.2.1. IPMC - MLD Snooping - Basic Configuration...........................................132
3.1.9.2.2. IPMC - MLD Snooping - VLAN Configuration ..........................................134
3.1.9.2.3. IPMC - MLD Snooping - Port Group Filtering...........................................136
3.1.10. Configuration - LLDP............................................................................................137
3.1.10.1. LLDP - LLDP...................................................................................................137
3.1.10.2. LLDP - LLDP-MED..........................................................................................140
3.1.11. Configuration - PoE..............................................................................................147
3.1.12. Configuration - MAC Table...................................................................................150
3.1.13. Configuration - VLANs .........................................................................................152
3.1.13.1. VLANs - VLAN Membership...........................................................................152
3.1.13.2. VLANs - Ports.................................................................................................154
3.1.14. Configuration - Private VLAN ..............................................................................156
3.1.14.1. Private VLAN - Port Isolation.....................................................................156
3.1.15. Configuration - VCL..............................................................................................157
3.1.15.1. VCL - MAC-based VLAN ................................................................................157
3.1.15.2. VCL - Port-based VLAN .................................................................................159
3.1.15.2.1. VCL - Port-based VLAN - Protocol to Group..........................................159
3.1.15.2.2. VCL - Port-based VLAN - Group to VLAN ..............................................161
3.1.15.3. VCL - IP Subnet-based VLAN ........................................................................162
3.1.16. Configuration - Voice VLAN.................................................................................164
3.1.16.1. Voice VLAN - Configuration...........................................................................164
3.1.16.2. Voice VLAN - OUI ...........................................................................................166
3.1.17. Configuration - QoS..............................................................................................167
3.1.17.1. QoS - Port Classification...............................................................................167
3.1.17.2. QoS - Port Policing ........................................................................................169
3.1.17.3. QoS - Port Scheduler.....................................................................................170
3.1.17.4. QoS - Port Shaping........................................................................................175
3.1.17.5. QoS - Port Tag Remarking.............................................................................180
3.1.17.6. QoS - Port DSCP ............................................................................................183
3.1.17.7. QoS - DSCP-Based QoS ................................................................................185
3.1.17.8. QoS - DSCP Translation.................................................................................186
3.1.17.9. QoS - DSCP Classification.............................................................................187

Table of Contents
NGSME24G4S User Manual | 6
3.1.17.10. QoS - Storm Control.....................................................................................188
3.1.17.11. QoS - WRED..................................................................................................189
3.1.18. Configuration - Mirroring .....................................................................................191
3.1.19. Configuration - UPnP ...........................................................................................193
3.1.20. Configuration - Stack............................................................................................194
3.1.21. Configuration - sFlow...........................................................................................197
3.2. Web Management - Monitor .........................................................................................200
3.2.1. Monitor - System ....................................................................................................200
3.2.1.1. System - Information .......................................................................................200
3.2.1.2. System - CPU Load..........................................................................................202
3.2.1.3. System - Log ....................................................................................................203
3.2.1.4. System - Detailed Log......................................................................................204
3.2.2. Monitor - Ports........................................................................................................205
3.2.2.1. Ports - State......................................................................................................205
3.2.2.2. Ports - Traffic Overview ...................................................................................206
3.2.2.3. Ports - QoS Statistics.......................................................................................207
3.2.2.4. Ports - Detailed Statistics ................................................................................208
3.2.3. Monitor - Security...................................................................................................211
3.2.3.1. Security - Access Management Statistics ......................................................211
3.2.3.2. Security - Network............................................................................................212
3.2.3.2.1. Security - Network - Port Security - Switch..............................................212
3.2.3.2.2. Security - Network - Port Security - Port..................................................215
3.2.3.2.3. Security - Network - NAS - Switch............................................................216
3.2.3.2.4. Security - Network - NAS - Port ................................................................218
3.2.3.2.5. Security - Network - ACL Status ...............................................................223
3.2.3.2.6. Security - Network - DHCP - Snooping Statistics....................................225
3.2.3.2.7. Security - Network - DHCP - Relay Statistics...........................................227
3.2.3.2.8. Security - Network - ARP Inspection........................................................229
3.2.3.3. Security - Network............................................................................................233
3.2.3.3.1. Security - AAA - RADIUS Overview ..........................................................233
3.2.3.3.2. Security - AAA - RADIUS Details...............................................................235
3.2.3.4. Security - Switch - RMON................................................................................239
3.2.3.4.1. Security - Switch - RMON - Statistics.......................................................239
3.2.3.4.2. Security - Switch - RMON - History ..........................................................242
3.2.3.4.3. Security - Switch - RMON - Alarm.............................................................244
3.2.3.4.4. Security - Switch - RMON - Events...........................................................246
3.2.4. Monitor - LACP .......................................................................................................247

Table of Contents
NGSME24G4S User Manual | 7
3.2.4.1. LACP - System Status......................................................................................247
3.2.4.2. LACP - Port Status ...........................................................................................248
3.2.4.3. LACP - Port Statistics ......................................................................................249
3.2.5. Monitor - Loop Protection......................................................................................250
3.2.6. Monitor - Spanning Tree.........................................................................................251
3.2.6.1. Spanning Tree - Bridge Status ........................................................................251
3.2.6.2. Spanning Tree - Port Status.............................................................................252
3.2.6.3. Spanning Tree - Port Statistics........................................................................253
3.2.7. Monitor - MVR.........................................................................................................254
3.2.7.1. MVR - Statistics................................................................................................254
3.2.7.2. MVR - MVR Channel Groups ...........................................................................255
3.2.7.3. MVR - MVR SFM Information...........................................................................256
3.2.8. Monitor - IPMC........................................................................................................258
3.2.8.1. IPMC - IGMP Snooping ....................................................................................258
3.2.8.1.1. IPMC - IGMP Snooping - Status ................................................................258
3.2.8.1.2. IPMC - IGMP Snooping - Groups Information..........................................260
3.2.8.1.3. IPMC - IGMP Snooping - IPv4 SFM Information.......................................261
3.2.8.2. IPMC - MLD Snooping......................................................................................263
3.2.8.2.1. IPMC - MLD Snooping - Status .................................................................263
3.2.8.2.2. IPMC - MLD Snooping - Groups Information ...........................................265
3.2.8.2.3. IPMC - MLD Snooping - IPv6 Group Information.....................................266
3.2.9. Monitor - LLDP........................................................................................................268
3.2.9.1. LLDP - Neighbours...........................................................................................268
3.2.9.2. LLDP - LLDP-MED Neighbours .......................................................................270
3.2.9.3. LLDP - PoE .......................................................................................................274
3.2.9.4. LLDP - EEE .......................................................................................................276
3.2.9.5. LLDP - Port Statistics.......................................................................................278
3.2.10. Monitor - PoE........................................................................................................280
3.2.11. Monitor - MAC Table.............................................................................................282
3.2.12. Monitor - VLANs ...................................................................................................284
3.2.12.1. VLANs - VLAN Membership...........................................................................284
3.2.12.2. VLANs - VLAN Ports ......................................................................................286
3.2.13. Monitor - Stack......................................................................................................288
3.2.14. Monitor - VCL........................................................................................................290
3.2.14.1. VCL - MAC-based VLAN ................................................................................290
3.2.15. Monitor - sFlow.....................................................................................................291
3.3. Web Management - Diagnostics ..................................................................................293

Table of Contents
NGSME24G4S User Manual | 8
3.3.1. Diagnostics - Ping ..................................................................................................293
3.3.2. Diagnostics - Ping6 ................................................................................................295
3.3.3. Diagnostics - VeriPHY............................................................................................296
3.4. Web Management - Maintenance.................................................................................298
3.4.1. Maintenance - Restart Device................................................................................298
3.4.2. Maintenance - Factory Defaults.............................................................................299
3.4.3. Maintenance - Software Upload.............................................................................300
3.4.3. Maintenance - Configuration .................................................................................301
3.4.3.1. Configuration - Save........................................................................................301
3.4.3.2. Configuration - Load........................................................................................302
Chapter 4: CLI Management.................................................................................................303
4.1. CLI Management - Overview ........................................................................................304
4.2. CLI Management - System............................................................................................305
4.3. CLI Management - Stack...............................................................................................310
4.4. CLI Management - Port.................................................................................................311
4.5. CLI Management - MAC................................................................................................314
4.6. CLI Management - VLAN...............................................................................................315
4.7. CLI Management - PVLAN (Private VLAN)...................................................................316
4.8. CLI Management - Security..........................................................................................317
4.9. CLI Management - STP .................................................................................................334
4.10. CLI Management - Aggr..............................................................................................337
4.11. CLI Management - LACP.............................................................................................339
4.12. CLI Management - LLDP.............................................................................................342
4.13. CLI Management - LLDPMED.....................................................................................343
4.14. CLI Management - EEE...............................................................................................347
4.15. CLI Management - POE...............................................................................................348
4.16. CLI Management - QoS...............................................................................................350
4.17. CLI Management - Mirror............................................................................................353
4.18. CLI Management - Config...........................................................................................354
4.19. CLI Management - Firmware ......................................................................................355
4.20. CLI Management - UPnP.............................................................................................356
4.21. CLI Management - MVR ..............................................................................................357
4.22. CLI Management - Voice VLAN ..................................................................................359
4.23. CLI Management - Loop Protect ................................................................................361
4.24. CLI Management - IPMC .............................................................................................362
4.25. CLI Management - sFlow............................................................................................364
4.26. CLI Management - VCL...............................................................................................366

Table of Contents
NGSME24G4S User Manual | 9
Appendix A: Product Safety ...................................................................................................368
Appendix B: IP Configuration for Your PC ............................................................................369
Appendix C: Glossary.............................................................................................................372

NGSME24G4S User Manual | 10
Before Starting
In Before Starting:
This section contains introductory information, which includes:
Intended Readers
Icons for Note, Caution, and Warning
Product Package Contents

Before Starting
NGSME24G4S User Manual | 11
Intended Readers
This manual provides information regarding to all the aspects and functions needed to install,
configure, use, and maintain the product you’ve purchased.
This manual is intended for technicians who are familiar with in-depth concepts of networking
management and terminologies.
Icons for Note, Caution, and Warning
To install, configure, use, and maintain this product properly, please pay attention when you
see these icons in this manual:
A Note icon indicates important information which will guide you to use this
product properly.
A Caution icon indicates either a potential for hardware damage or data
loss, including information that will guide you to avoid these situations.
A Warning icon indicates potentials for property damage and personal
injury.

Before Starting
NGSME24G4S User Manual | 12
Product Package Contents
Before starting install this product, please check and verify the contents of the product
package, which should include the following items:
One Network Switch
One Power Cord
One User Manual CD
One pair Rack-mount kit + 8 Screws
Note: If any item listed in this table above is missing or damaged, please contact your
distributor or retailer as soon as possible.

NGSME24G4S User Manual | 13
Chapter 1:
Product Overview
In Product Overview:
This section will give you an overview of this product, including its feature
functions and hardware/software specifications.
Product Brief Description
Product Specification
Hardware Description
Hardware Installation

Chapter 1: Product Overview
Product Brief Description
NGSME24G4S User Manual | 14
1.1. Product Brief Description
Introduction
This NGSME24G4S switch is 24-port 10/100/1000Base-T and two 10G SFP+for Stacking
and two 10G SFP+ Open Slot Rack-mount L2+Full Management Network Switch that is
designed for medium or large network environment to strengthen its network connection. This
NGSME24G4S switch supports 128Gbps non-blocking switch fabric, its 24 gigabit ports and 2
10G uplink ports can transmit and receive data traffic without any lost. The EEE feature
reduces the power consumption when there is no traffic forwarding even port is still
connected. The 10G uplink port design is available and important for high bandwidth uplink
request when cascaded with other switch. This NGSME24G4Sswitch also supports Layer 2+
full management software features. These features are powerful to provide network control,
management, monitor and security feature requests. Including rack-mount brackets, the 19"
size fits into your rack environment. It is a superb choice to boost your network with better
performance and efficiency.
Two 10 Gigabit SFP+ Open Slots
This NGSME24G4S switch equips with two 10G SFP+open slots as the uplink ports, the 10G
uplink design provides an excellent solution for expanding your network from 1G to 10G. By
10G speed, this product provides high flexibility and high bandwidth connectivity to another
10G switch or the Servers, Workstations and other attached devices which support 10G
interface. The user can also aggregate the 10G ports as Trunk group to enlarge the
bandwidth.
Stacking Features
The NGSME24G4S switch include a stacking feature by using 2 SFP+ports that allows
multiple switches to operate as a single unit.A single switch in the stack can manages all the
units in the stack and uses a single IP address which allows the user to manage every port in
the stack from this one address. These stacks can include up to 16 switches, or total 384
gigabit ports plus 32 10G ports in total.
Full Layer 2 Management Features
The NGSME24G4S switch includes full Layer 2+Management features. The software set
includes up to 4K 802.1Q VLAN and advanced Protocol VLAN, Private VLAN,
MVR…features. There are 8 physical queriers Quality of Service, IPv4/v6 Multicast filtering,
Rapid Spanning Tree protocol to avoid network loop, Multiple Spanning Tree Protocol to
integrate VLAN and Spanning Tree, LACP, LLDP; sFlow, port mirroring, cable diagnostic and
advanced Network Security features. It also provides Console CLI for out of band
management and SNMP, Web GUI for in band Management.

Chapter 1: Product Overview
Product Specification
NGSME24G4S User Manual | 15
1.2. Product Specification
Interface
10/100/1000 Base RJ45 Ports
24
10G Uplink SFP+Slot
2
10G Stacking SFP+Slot
2
Console Port for CLI Management
1
System Performance
Packet Buffer
32Mb
MAC Address Table Size
32K
Switching Capacity
128Gbps
Forwarding Rate
95.2Mpps
PoE Features
IEEE 802.3 af/at
IEEE 802.3 af/at
Number of PSE Ports
24
Max. Power Consumption
500W
External/Internal Power
Internal Power
Power Feeding Detecting Capability on PD

PD Alive Check

PD Classification

Power Management
(per-port)
Enable/Disable PoE Per Port

Priority Setting Per Port

Power Level Setting Per Port

Overloading Protection

L2 Features
Auto-negotiation

Auto MDI/MDIX

Flow Control (duplex)
802.3x (Full)

Back-Pressure (Half)

Spanning Tree
IEEE 802.1D (STP)

IEEE 802.1w (RSTP)

IEEE 802.1s (MSTP)

VLAN
VLAN Group
4K
Tagged Based

Port-based

Link Aggregation
IEEE 802.3ad with LACP

Static Trunk

Max. LACP Link Aggregation Group
12
IGMP Snooping
IGMP Snooping v1/v2/v3

IPv6 MLD Snooping

Querier, Immediate Leave

Storm Control (Broadcast/Multi-cast/Un-known Unicast)

Jumbo Frame Support
10K

Chapter 1: Product Overview
Product Specification
NGSME24G4S User Manual | 16
QoS Features
Number of priority queue
8 queues/port
Rate Limiting
Ingress
Yes, 1KBps/1pps
Egress
Yes, 1KBps/1pps
DiffServ (RFC2474 Remarking)

Scheduling (WRR, Strict, Hybrid)

CoS
IEEE 802.1p

IP ToS precedence, IP DSCP

Security
Management System User Name/Password Protection

User Privilege
Set user privilege up to 15 Level
Port Security (MAC-based)

IEEE 802.1x Port-based Access Control

ACL (L2/L3/L4)

IP Source Guard

RADIUS (Authentication, Authorization, Accounting)

TACACS+

HTTP & SSL (Secure Web)

SSH v2.0 (Secured Telnet Session)

MAC/IP Filter

Management
Command Line Interface (CLI)

Web Based Management

Telnet

Access Management Filtering
SNMP/WEB/SSH/TELNET
Firmware Upgrade via HTTP

Dual Firmware Images

Configuration Download/Upload

SNMP (v1/v2c/v3)

RMON (1,2,3,&9 groups)

DHCP (Client/Relay/Option82/Snooping)

System Event/Error Log

NTP/LLDP

Cable Diagnostics

IPv6 Configuration

Port Mirroring
One to One or Many to One
Mechanical
Power Input
100~240VAC
Dimension (H*W*D)
44*440*331 mm
LED
Power, 10/100/1000M, PoE, SFP
LCD
LCD for Displaying Stacking ID
Operating Temperature
0~45°C
Operating Humidity
5~90% (non-condensing)
Weight
4.3KG
Certification
CE, FCC Class A

Chapter 1: Product Overview
Product Specification
NGSME24G4S User Manual | 17
Standard
IEEE 802.3 –10BaseT

IEEE 802.3u - 100BaseTX

IEEE 802.3ab - 1000BaseT

IEEE 802.3z 1000BaseSX/LX

IEEE 802.3af Power over Ethernet (PoE)

IEEE 802.3at Power over Ethernet (PoE+)

IEEE 802.3az - Energy Efficient Ethernet (EEE)

IEEE 802.3x - Flow Control

IEEE 802.1Q - VLAN

IEEE802.1v - Protocol VLAN

IEEE 802.1p - Class of Service

IEEE 802.1D - Spanning Tree

IEEE 802.1w - Rapid Spanning Tree

IEEE 802.1s - Multiple Spanning Tree

IEEE 802.3ad - Link Aggregation Control Protocol (LACP)

IEEE 802.1AB - LLDP (Link Layer Discovery Protocol)

IEEE 802.1X - Access Control


Chapter 1: Product Overview
Hardware Description
NGSME24G4S User Manual | 18
1.3. Hardware Description
This section mainly describes the hardware of NGSME24G4S switch and gives a physical
and functional overview on the certain switch.
Front Panel
The front panel of the NGSME24G4S switch consists of 24 10/100/1000 Base-TX RJ-45 ports,
2 10G uplink SFP ports, and 2 10G SFP+ stacking ports. The LED Indicators are also located
on the front panel.
LED Indicators
The LED Indicators present real-time information of systematic operation status. The
following table provides description of LED status and their meaning.
LED
Color / Status
Description
No. of LEDs
Power
Amber On
Power on
Power
10/100/1000M
Green On
Link Up
24(1~24)
Green Blinking
Data Activating
SFP
Green On
linked to Power Device
25~26
Green Blinking
Data Activating
25~26
Rear Panel
The rear panel of the NGSME24G4S switch contains 2 ventilation fans, a power switch, and
an IEC 60320 plug for power supply.

Chapter 1: Product Overview
Hardware Installation
NGSME24G4S User Manual | 19
1.4. Hardware Installation
To install the NGSME24G4 Sswitch, please place it on a large flat surface with a power
socket close by. This surface should be clean, smooth, and level. Also, please make sure that
there is enough space around the NGSME24G4S switch for RJ45 cable, power cord and
ventilation.
If you’re installing this NGSME24G4S switch on a 19-inch rack, please make sure to use the
rack-mount kit (L brackets) and screws come with the product package. All screws must be
fastened so the rack-mount kit and your product are tightly conjoined before installing it on
your 19-inch rack.
Ethernet cable Request
The wiring cable types are as below:
10 Base-T: 2-pair UTP/STP CAT. 3, 4, 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
100 Base-TX: 2-pair UTP/STP CAT. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
1000 Base-T: 4-pair UTP/STP CAT. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
PoE: To delivery power properly, it is recommended to use CAT 5e and CAT 6 cable.
Ethernet cables of higher qualities can reduce the power lost during transmission.
SFP Installation
While install the SFP transceiver, make sure the SFP type of the 2 ends is the same and the
transmission distance, wavelength, fiber cable can meet your request. It is suggested to
purchase the SFP transceiver with the switch provider to avoid any incompatible issue.
The way to connect the SFP transceiver is to Plug in SFP fiber transceiver fist. The SFP
transceiver has 2 plug for fiber cable, one is TX (transmit), the other is RX (receive).
Cross-connect the transmit channel at each end to the receive channel at the opposite end.
For more information regarding to the product safety and maintenance guide, please refer to
Appendix A: Product Safety.

NGSME24G4S User Manual | 20
Chapter 2:
Preparing for Management
In Preparing for Management:
This section will guide your how to manage this product via serial console,
management web page, and Telnet/SSH interface.
The switch provides both out-of-band and in-band managements.
Out-of-band Management: You can configure the switch via RS232 console
cable without having the switch or your PC connecting to a network. Out-of-band
management provides a dedicated and secure way for switch management.
In-Band Management: In-band management allows you to manage your switch
with a web browser (such as Microsoft IE, Mozilla Firefox, or Google Chrome) as
long as your PC and the switch are connected to the same network.
Preparation for Serial Console
Preparation for Web Interface
Preparation for Telnet/SSH Interface
